LAUNCH TECH X-431 PRO5 User manual

Version: V1.00.000
Revised date: 07-30-2021

LAUNCH X-431 PRO5 User Manual
i
Copyright Information
Copyright © 2021 by LAUNCH TECH CO., LTD (also called LAUNCH for short).
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written
permission of LAUNCH.
Statement: Launch owns the complete intellectual property rights for the
software used by this product. For any reverse engineering or cracking actions
against the software, Launch will block the use of this product and reserve the
right to pursue their legal liabilities.
Disclaimer of Warranties and Limitation of Liabilities
All information, illustrations, and specifications in this manual are based on the
latest information available at the time of publication.
The right is reserved to make changes at any time without notice. We shall not
be liable for any direct, special, incidental, indirect damages or any economic
consequential damages (including the loss of profits) due to the use of the
document.

LAUNCH X-431 PRO5 User Manual
ii
Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional
equipment that are not included in your system.
The following conventions are used.
Bold Text
Bold text is used to highlight selectable items such as buttons and menu options.
Example:
Tap OK.
Notes and Important Messages
Notes
A NOTE provides helpful information such as additional explanations, tips, and
comments.
Example:
Note: Remember to remove the VCI connector from the vehicle’s DLC after use.
Warning
Warning indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury to the operator or to bystanders.
Example:
Warning: Retrieving and using DTCs for troubleshooting vehicle operation is only
one part of an overall diagnostic strategy. Never replace a part based only on the DTC
definition. Each DTC has a set of testing procedures, instructions and flow charts that
must be followed to confirm the location of the problem. This information can be found
in the vehicle’s service manual.
Danger
Danger indicates an imminently or potentially hazardous situation which, if not
avoided, could result in death or serious injury to the operator or to bystanders.
Example:
Danger: If you must drive the vehicle in order to perform a troubleshooting
procedure, always have a second person help you. Trying to drive and operate the
diagnostic tool at the same time is dangerous, and could cause a serious traffic accident.

LAUNCH X-431 PRO5 User Manual
iii
Illustrations
Illustrations used in this manual are samples, the actual testing screen may vary
for each vehicle being tested. Observe the menu titles and on-screen
instructions to make correct option selection.
Important Safety Precautions
To avoid personal injury, property damage, or accidental damage to the product,
read all of the information in this section before using the tool.
DANGER
• When an engine is operating, keep the service area well-ventilated or attach
a building exhaust removal system to the engine exhaust system. Engines
produce various poisonous compounds (hydrocarbon, carbon monoxide,
nitrogen oxides, etc.) that cause slower reaction time and result in death or
serious personal injury.
• Please use the included battery and power adaptor. Risk of explosion if the
battery is replaced with an incorrect type.
• DO NOT attempt to operate the tool while driving the vehicle. Have second
personal operate the tool. Any distraction may cause an accident.
WARNING
 Always perform automotive testing in a safe environment.
 Do not connect or disconnect any test equipment while the ignition is on or
the engine is running.
 Before starting the engine, put the gear lever in the Neutral position (for
manual transmission) or in the Park (for automatic transmission) position to
avoid injury.
 NEVER smoke or allow a spark or flame in vicinity of battery or engine. Do
not operate the tool in explosive atmospheres, such as in the presence of
flammable liquids, gases, or heavy dust.
 Keep a fire extinguisher suitable for gasoline/chemical/electrical fires nearby.
 Wear an ANSI-approved eye shield when testing or repairing vehicles.
 Put blocks in front of the drive wheels and never leave the vehicle unattended
while testing.
 Use extreme caution when working around the ignition coil, distributor cap,

LAUNCH X-431 PRO5 User Manual
iv
ignition wires and spark plugs. These components create hazardous voltage
when the engine is running.
 To avoid damaging the tool or generating false data, please make sure the
vehicle battery is fully charged and the connection to the vehicle DLC (Data
Link Connector) is clear and secure.
 Automotive batteries contain sulfuric acid that is harmful to skin. In operation,
direct contact with the automotive batteries should be avoided. Keep the
ignition sources away from the battery at all times.
 Keep the tool dry, clean, free from oil, water or grease. Use a mild detergent
on a clean cloth to clear the outside of the equipment when necessary.
 Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or
hot engine parts.
 Store the tool and accessories in a locked area out of the reach of children.
 Do not use the tool while standing in water.
 Do not expose the tool or power adapter to rain or wet conditions. Water
entering the tool or power adaptor increases the risk of electric shock.
 This tool is a sealed unit. There are no end-user serviceable parts inside. All
internal repairs must be done by an authorized repair facility or qualified
technician. If there is any inquiry, please contact the dealer.
 Keep the tool far away from magnetic devices because its radiations can
damage the screen and erase the data stored on the tool.
 Do not attempt to replace the internal rechargeable lithium battery. Contact
the dealer for factory replacement.
 Do not disconnect battery or any wiring cables in the vehicle when the ignition
switch is on, as this could avoid damage to the sensors or the ECU.
 Do not place any magnetic objects near the ECU. Disconnect the power
supply to the ECU before performing any welding operations on the vehicle.
 Use extreme caution when performing any operations near the ECU or
sensors. Ground yourself when you disassemble PROM, otherwise ECU and
sensors can be damaged by static electricity.
 When reconnecting the ECU harness connector, be sure it is attached firmly,
otherwise electronic elements, such as ICs inside the ECU, can be damaged.

LAUNCH X-431 PRO5 User Manual
v
FCC Statement
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy, and if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

LAUNCH X-431 PRO5 User Manual
vi
TABLE OF CONTENTS
1 Introduction ................................................................................................. 1
1.1 Product Profile ........................................................................................ 1
1.2 Components & Controls ......................................................................... 3
1.2.1 Display Tablet .................................................................................. 3
1.2.2 VCI Device ...................................................................................... 4
1.3 Technical Parameters ............................................................................. 7
1.4 Package List ........................................................................................... 8
2 Initial Use ....................................................................................................10
2.1 Charging & Turning On ......................................................................... 10
2.2 Screen Layout ...................................................................................... 10
2.3 Basic Gestures ..................................................................................... 10
2.4 Change System Language ................................................................... 11
2.5 Adjust Brightness ................................................................................. 11
2.6 Set Standby Time ................................................................................. 11
2.7 Network Setup ...................................................................................... 12
3 Getting Started ...........................................................................................13
3.1 Register & Update ................................................................................ 13
3.2 Job Menu ............................................................................................. 15
3.3 Diagnostics Toolbar .............................................................................. 17
4 Connections ...............................................................................................18
4.1 Preparation ........................................................................................... 18
4.2 Vehicle Connection (Only for Passenger Vehicle Configuration) .......... 19
4.2.1 OBD II vehicle Connection ............................................................ 19
4.2.2 Non-OBD II vehicle Connection .................................................... 19
4.2 Vehicle Connection (Only for Commercial Vehicle Configuration) ........ 20
4.2.1 OBD II vehicle Connection ............................................................ 20
4.2.2 Non-OBD II vehicle Connection .................................................... 21
5 Diagnosis ....................................................................................................22

LAUNCH X-431 PRO5 User Manual
vii
5.1 Intelligent Diagnose .............................................................................. 22
5.2 Local Diagnose ..................................................................................... 25
5.2.1 Health Report (Quick Test) ............................................................ 30
5.2.2 System Scan ................................................................................. 34
5.2.3 System Selection .......................................................................... 34
5.3 Remote Diagnose ................................................................................. 45
5.3.1 Add Friends ................................................................................... 46
5.3.2 Start Instant Messaging ................................................................. 47
5.3.3 Launch Remote Diagnosis (Device-To-Device) ............................. 48
5.3.4 Launch Remote Diagnosis (Device-To-PC) ................................... 51
5.4 Feedback ............................................................................................. 53
5.5 Diagnostic History................................................................................. 54
6 Service (Reset) Function ...........................................................................55
6.1 Oil Reset Service .................................................................................. 55
6.2 Electronic Parking Brake Reset ............................................................ 56
6.3 Steering Angle Calibration .................................................................... 56
6.4 ABS Bleeding ....................................................................................... 56
6.5 Tire Pressure Monitor System Reset .................................................... 56
6.6 Gear Learning ...................................................................................... 56
6.7 IMMO Service ....................................................................................... 57
6.8 Injector Coding ..................................................................................... 57
6.9 Battery Maintenance System Reset...................................................... 57
6.10 Diesel Particulate Filter (DPF) Regeneration ...................................... 57
6.11 Electronic Throttle Position Reset ....................................................... 58
6.12 Gearbox Matching .............................................................................. 58
6.13 AFS (Adaptive Front-lighting System) Reset ...................................... 58
6.14 Sunroof Initialization ........................................................................... 58
6.15 Suspension Calibration ....................................................................... 58
6.16 IMMO Programming ........................................................................... 59
7 Software Update .........................................................................................60

LAUNCH X-431 PRO5 User Manual
viii
7.1 Update Diagnostic Software & APP ...................................................... 60
7.2 Update Frequently Used software ........................................................ 61
7.3 Renew Subscription.............................................................................. 61
8 Add-on Modules .........................................................................................64
8.1 ADAS (Calibration) ............................................................................... 64
8.2 TPMS ................................................................................................... 64
8.3 BST360 (Battery Tester) ....................................................................... 64
8.4 Videoscope........................................................................................... 64
8.5 PROG3 (Immobilizer Programmer)....................................................... 64
9 User Info......................................................................................................66
9.1 My Report ............................................................................................. 66
9.2 VCI ....................................................................................................... 66
9.3 VCI Management ................................................................................. 66
9.4 Activate VCI.......................................................................................... 66
9.5 Firmware Fix......................................................................................... 67
9.6 Data Stream Sample ............................................................................ 67
9.7 My Order .............................................................................................. 67
9.8 Subscription Renewal Card .................................................................. 67
9.9 Profile ................................................................................................... 67
9.10 Change password............................................................................... 68
9.11 Settings .............................................................................................. 68
9.11.1 Units ............................................................................................ 68
9.11.2 Shop Information ......................................................................... 68
9.11.3 Printer Set ................................................................................... 69
9.11.4 Orientation ................................................................................... 72
9.11.5 Clear Cache ................................................................................ 72
9.11.6 About ........................................................................................... 72
9.11.7 Diagnostic Software Auto Update ................................................ 72
9.11.8 Device Account Management ...................................................... 72
9.11.9 Login/Logout................................................................................ 74

LAUNCH X-431 PRO5 User Manual
ix
9.12 Diagnostic Software Clear .................................................................. 74
10 J2534 Programming .................................................................................75
10.1 Working principle ................................................................................ 75
10.2 Connection ......................................................................................... 75
10.3 Install the software & driver ................................................................ 77
11 FAQ ............................................................................................................78

LAUNCH X-431 PRO5 User Manual
1
1 Introduction
1.1 Product Profile
This Android OS-based, tablet-style diagnostic tool incorporates the best
possible coverage of OE-level diagnostics with multitasking capable software.
Using the powerful 8-core 1.8GHz processor and a 10.1 inch IPS capacitive
touch screen with a resolution of 1920 x 1200 pixels, it delivers quick and
complete diagnostic functionalities which technicians need to diagnose,
research and repair vehicles in one solution.
Through the simple Bluetooth communication between VCI (Vehicle
Communication Interface) device and the display tablet, it achieves full car
model and full system vehicle trouble diagnosis, which include Reading DTCs,
Clearing DTCs, Reading Data Stream, Actuation Test and Special Functions.
It has the following features:
 Intelligent Diagnose: This module allows you to use the VIN information of the
currently identified vehicle to access its data (including vehicle information,
historical diagnostic records) from the cloud server to perform quick test,
eliminating guesswork and step-by-step manual menu selection.
 Local Diagnose: Follow the on-screen prompts to start diagnostic session
step by step.
 Remote Diagnose: This option aims to help repair shops or technicians
launch instant messaging and remote diagnosis, making the repair job getting
fixed faster.
 Service Function: All kinds of common maintenance and reset items including
Oil Reset Service, Electronic Parking Brake Reset, Steering Angle Calibration,
ABS Bleeding, TPMS (Tire Pressure Monitor System) Reset, Gear Learning,
IMMO Service, Injector Coding, Battery Maintenance System, Diesel
Particulate Filter (DPF) Regeneration, Electronic Throttle Position Reset,
Gearbox Matching, AFS (Adaptive Front-lighting System) Reset, Sunroof
Initialization, Suspension Calibration etc.
 One-click Update: Lets you update your diagnostic software online.
 ADAS calibration: Allows you to perform Advanced Driver Assistance System
(ADAS) calibration operations. This function needs to be activated before

LAUNCH X-431 PRO5 User Manual
2
normal use and only works with the specific ADAS calibration tool.
 TPMS: Configures the tool as a professional Tire Pressure Monitoring
System (TPMS) service tool. It needs to work with the TSGUN device (sold
separately) to perform all kinds of various TPMS functions.
 Mall: Enables you to subscribe some extra software or service functions that
are not integrated in the tool online.
 Diagnostic History: This function provides a quick access to the tested
vehicles and users can choose to view the test report or resume from the last
operation, without the necessity of starting from scratch.
 Feedback: Enables you to submit the vehicle issue to us for analysis and
troubleshooting.
 Vehicle Coverage: Quick dial to view the vehicle models that the tool covers.
 Add-on modules: Optional. BST 360 Battery Tester, Videoscope and
Immobilizer Programmer are available as add-on modules, extending the
functions of the tool.

LAUNCH X-431 PRO5 User Manual
3
1.2 Components & Controls
There are two main components to the diagnostic system:
 Display Tablet – the central processor and monitor for the system (See
Chapter “1.2.1”).
 VCI Device – the device for accessing vehicle data (See Chapter “1.2.2”).
1.2.1 Display Tablet
The tablet acts as the central processing system, which is used to receive and
analyze the live vehicle data from the VCI device and then output the test result.
1
Volume +/
-
Adjusts the system volume.
2 POWER Key In Off mode, press it for 3 seconds to turn

LAUNCH X-431 PRO5 User Manual
4
the tablet on.
In On mode:
• Press it once to activate the LCD if the
LCD is off. Press it once to turn off the
LCD if the LCD lights up.
• Press and hold it for 3 seconds to turn it
off. Press and hold it for 8 seconds to
perform forced shutdown.
3
LCD Screen
Indicates the test results.
4 Speakers
5 Front Camera
6 Charging / Data I/O
Port
• Connects to AC outlet for charging.
• Connects to PC for data exchange.
7 Microphone
8 Rear Camera
9 Adjustable stand Flip it out to any angle and work comfortable
at your desk, or hang it on steering wheel.
1.2.2 VCI Device
Compatible with commercial & passenger vehicles, the VCI can work as a
vehicle communication interface device or a J2534 pass-thru device.
• When working with the diagnostic tablet, it acts as a vehicle communication
interface device. It is used to read the vehicle data and then send it to the
tablet via Bluetooth.

LAUNCH X-431 PRO5 User Manual
5
• When working with a PC, it acts as a J2534 Pass-thru device to perform the
J2534 programming. For more details, refer to Chapter 10.
The LEDs enable you to easily identify the working status of the module.

LAUNCH X-431 PRO5 User Manual
6
1
Diagnostic socket
Connect the diagnostic cable.
2 LEDs
Identify the working status of the VCI. It is
defined as follows:
 Power: It illuminates solid red when the
VCI is powered on.
 Vehicle: While communicating with the
vehicle, it lights up and flashes. Otherwise,
it will not illuminate.
 BT: Blue indicates the VCI is working in
Bluetooth mode.
 I/O: It lights up when the VCI is connected

LAUNCH X-431 PRO5 User Manual
7
to the PC via data cable.
 Wireless: It lights up when the VCI is
working in wireless communication mode.
3 Data I/O port Connect to the VCI device to perform J2534
programming operations.
4
Reset hole
Reset the VCI.
5
DC
-
IN power j
ack
Connect the power adaptor.
1.3 Technical Parameters
Display Tablet
Operating system: Android
Memory: 3GB
Storage: 32GB
Screen: 10.1 inch FHD IPS capacitive touch screen with a resolution of 1920 x
1200 pixels
Camera: Front-facing 5.0MP + Rear-facing 8.0MP camera
Connectivity:
• Wi-Fi (802.11a/b/g/n/ac)
• Bluetooth
Working temperature: 0℃ ~ 50℃
Storage temperature: -20 ~ ℃70℃
VCI Connector
Working Voltage: DC 9V ~ 36V
RAM: 256MB
ROM: 8GB
USB: Type B x 1
Wi-Fi: Dual Band 2.4G/5GHz
Power consumption: ≤6.6W
Working Temperature: 0℃ ~ 50℃

LAUNCH X-431 PRO5 User Manual
8
Dimension: 200mm x 75mm x 40mm
1.4 Package List
The following packing list is for reference purpose only. For different destinations,
the accessories may vary. For details, please consult from the local dealer or
check the packing list supplied with this tool together.
No.
Item
Descriptions
Qt.
1 Display tablet Indicates the test result. 1
2 VCI connector A device for accessing vehicle live
data. 1
3 OBD II extension
cable
Connects the VCI connector to
vehicle’s OBD II diagnostic socket. 1
4 Password envelope
A piece of paper bearing the product
Serial Number and Activation Code for
product registration.
1
5 Power adaptor Charges the tablet via AC outlet. 2
6
Charging (Type A
to Micro) cable Charges the tablet. 1
7 Type A to Type B
USB cable
Connects the VCI device to the PC to
reflash the ECU 1
8 OBD I adaptor box
Connects the diagnostic cable and
non-16pin adaptor cable. (Optional)
9 Battery clamps
cable
Supplies power to the non-16pin
connector from the vehicle’s battery. (Optional)
10
Cigarette lighter
cable
Supplies power to the non-16pin
connector from the cigarette lighter (Optional)

LAUNCH X-431 PRO5 User Manual
9
receptacle.
11
Non-16pin adaptor
cable kit
For different vehicle diagnostic socket,
it may be necessary to use one of the
non-16pin connectors included within
the kit.
For detailed non-16pin connectors,
please check the package box.
(Optional)

LAUNCH X-431 PRO5 User Manual
10
2 Initial Use
2.1 Charging & Turning On
1. Use the included power adaptor to charge the tablet.
2. After charging is complete, press the POWER button to turn the tablet on.
The system starts initializing and then enters the home screen.
Note: If the battery remains unused for a long period of time or the battery is
completely discharged, it is normal that the tool will not power on while being charged.
Please charge it for a period of 5 minutes and then turn it on.
Warning: Please use the included power adaptor to charge your tool. No
responsibility can be assumed for any damage or loss caused as a result of using power
adaptors other than the one supplied.
Press [POWER] for 3 seconds, an option menu will pop up on the screen. Tap
Power off to turn the tool off.
2.2 Screen Layout
The following on-screen buttons are available on the bottom of the screen.
BACK: Tap it to return to the previous screen.
HOME: Tap it to navigate to the Android’s home screen.
Recent Apps: Tap it to view the recently opened applications.
Screenshot: Tap it to capture the current screen.
2.3 Basic Gestures
Single-tap: To select an item or launch a program.
Double-tap: To zoom in so that the text on a webpage appears in a
column that fits your device’s screen.
Long press: Tap and hold on the current interface or area until a
contextual menu pops up on the screen, and then release it.
