Full Support Easiair 2020 User manual

THE RPE EXPERTS
CE Approved to BS EN 12941:1998+A1:2003+A2:2008
Respiratory Protective Device
Powered Air Kit, incorporating a soft hood
Class TH 3 P R SL
Powered Air Kit
Instructions For Use
EASIAIR®20
20

THE RPE EXPERTS
2
EASIAIR®20
20
IMPORTANT
This Instructions For Use (IFU) manual must be read and fully understood before using
the Easiair®2020 Powered Air Kit.
It is imperative that these user instructions are strictly followed when using/operating the
product(s) in question. Failure to follow these instructions may invalidate any warranty
protection that is offered or available to you in respect of the product(s). Please refer to
the terms of your purchase contract in respect of the product(s) for the specic details
of such warranty cover.
This product is designed to protect your health and wellbeing. Failure to comply with
these user instructions may adversely affect your health/wellbeing leading to illness
or even death.
No recommendation is given as regards to the suitability of this product for your needs.
If you have any questions regarding the suitability of this product to your task, please
contact an occupational hygienist or call the manufacturer’s technical help line for further
information. The relevant contact details can be found on the back of this manual.
Please retain this manual with the product for future reference.

EASIAIR®20
20
THE RPE EXPERTS
3
CONTENTS
1. Introduction 4
2. Range of applications 4
3. Approvals 4
4. Conditions of use 5
5. Unpacking 6
6. Before use 7
7. Assembly & Donning 8
8. Cleaning & Maintenance 11
9. Fault nding 13
10. Storage 14
11. Technical data 14
12. Warranty 15

EASIAIR®20
20
THE RPE EXPERTS
4
1. INTRODUCTION
The Easiair® 2020 Powered Air Kit circulates clean pressured air around a loose-tting hood. The belt-mounted
blower unit delivers air through a lter, via a hose, into the hooded headpiece. The constant supply of ltered air
creates positive pressure inside the headpiece, which prevents external contaminated air from entering the user’s
breathing zone.
This respirator must be used strictly in accordance with this user instruction manual and the instructions supplied
with the corresponding headpiece.
The user must read and understand this instruction manual to be able to use the respiratory protective system
correctly. Any questions should be directed to the manufacturer for further information. The relevant contact details
can be found on the back of this manual.
2. RANGE OF APPLICATIONS
The Easiair® 2020 Powered Air Kit is designed to allow safe breathing in an environment contaminated with airborne
pathogens and offers protection from general particulate hazards.
When assembled correctly, properly tted and equipped with the correct lter, this respiratory device will give a
high degree of protection against the inhalation of bacteria and virus particles. For complete protection, the Easiair®
2020 Powered Air Kit should be worn in conjunction with other personal protective equipment (PPE) appropriate for
the intended task and environment.
This device is not classied as “Breathing Apparatus” and cannot be used in oxygen depleted atmospheres, or
where toxic gases are present.
The Easiair® 2020 Powered Air Kit must not be used in the following conditions:
•Atmospheres that have an oxygen content of less than 19.5%.
•Areas subject to high winds.
•Conned spaces, or unventilated areas.
•Near open ames, sparks or areas with danger of explosion.
•Atmospheres containing unknown respiratory hazards or harmful gases.
3. APPROVALS
The Easiair® 2020 Powered Air Kit has been designed and manufactured to comply with EN 12941:1998+A1:2003
+A2:2008 as a TH 3 P R SL respiratory protective device.
BS4275 (Guide to implementing an effective respiratory protective device program), which the user is advised to
read, denes such a device as offering an Assigned Protection Factor (APF) of 40. The Easiair®2020 Powered Air
Kit can only provide this level of protection when used with genuine lters provided by the manufacturer marked
“Easiair®” and in conjunction with a compatible air hose and FSM41 impact resistant soft hood (EN 166:2001 S hood).
The Easiair® 2020 blower unit is manufactured under ISO 9001:2000 Quality System.
EU declaration of comformity present on the website: www.fullsupportgroup.com/DoC

EASIAIR®20
20
THE RPE EXPERTS
5
4. CONDITIONS OF USE
The Easiair® 2020 Powered Air Kit is for use by trained personnel only. Training should be provided by the
manufacturer, a qualied delegate, or a competent individual either in person or online.
Before assembling, visually inspect all components for damage or wear.
Ensure that all components are genuine and assembled according to this IFU manual.
Ensure that the hood and belt are tted appropriately to the user. The protective factor of the complete system is
reduced if the seal of the headpiece is not tted properly. Only if the headpiece is tted correctly is the device able
to operate effectively.
To avoid dislodging, the blower unit should be worn behind the wearer, in the small of their back.
The device is unlikely to cause allergic reactions to the wearer. However, in the unlikely event of a reaction, the
user should immediately leave the contaminated area, remove the unit and seek medical advice.
It is essential that you do not:
•Attempt to modify, alter or tamper with any of the components in any way.
•Touch any moving parts of the unit while in operation.
•Allow water or other liquid substances into the device.
ATTENTION!
If any of the conditions outlined in this IFU document are not kept or followed,
your health may be at risk and your warranty protection in respect of the
product(s) will be automatically invalidated.
The user is strongly advised to leave the contaminated area immediately if:
•The warning alarm sounds.
•Breathing becomes difcult.
•Dizziness or distress occurs.
•Any part of the system becomes damaged.
•Airow into the headpiece decreases or stops.
•Contaminant can be smelt or tasted inside the headpiece.

EASIAIR®20
20
THE RPE EXPERTS
6
5. UNPACKING
Check that the package is complete and that no part has been damaged due to transport or storage.
Easiair®2020 Powered Air Kit
Item No. Description Product Code
0 Easiair® 2020 Blower Unit FSM48
1 Easiair®2020 Full Soft Hood c/w Headgear FSM41
2 Easiair® 2020 Breathing Hose FSM46
3 Easiair® 2020 Filter P R SL (P3) FSM40
4 Easiair® 2020 Standard Battery FSM42
5 Easiair® 2020 Battery Charger FSM44
6 Easiair® 2020 PCV Decon Belt FSM47
0
0

EASIAIR®20
20
THE RPE EXPERTS
7
6. BEFORE USE
Every time before using the device, you should check that:
• All components are in good conition, with no visible damage (holes, scratches, tears, etc.). Any damaged or
worn parts should be replaced before assembling.
•The unit has been assembled correctly according to the following instructions (see 7).
•There is sufcient airow (see 6.1).
•The battery is charged (see 6.2/3).
•The alarm is working (see 6.4).
If any problems arise during the pre-use checks, please consult chapter 9 of this document.
6.1 Testing the airow
To ensure the Easiair® 2020 Powered Air Kit is working efciently,
an airow test should be taken.
•Disconnect the air hose from the blower unit.
•Attach the airow indicator to the blower unit air outlet.
•Switch on the device.
•Holding the unit at eye level in a vertical position, watch to
see if the ball reaches the minimum ow rate level.
6.2 Charging the battery
To ensure the Easiair® 2020 Powered Air Kit is working at maximum
capacity, it is recommended that a fully charged battery be
equipped at the start of a shift.
To charge the battery:
•Plug the supplied charger into a power supply of the correct
voltage.
•Plug the other end into the battery inlet located at the backside
of the battery. (The battery can be charged whether tted to
or disconnected from the blower unit)
•The charging state is indicated by an LED light located on the
plug. When red the battery is charging. When green the battery
is charged.
WARNING:
To prolong the life of the battery, it is advisable to
disconnect it from the power supply once fully charged.

EASIAIR®20
20
THE RPE EXPERTS
8
6.3 Testing the battery
To test the level of an equipped battery:
•Turn on the blower unit.
•The battery level will be displayed on the control
panel briey by ashing red LED lights:
- 1 LED = 25%
- 2 LED = 50%
- 3 LED = 75%
- 4 LED = 100%
6.4 Testing the alarm
If the Manufacturer’s Minimum Design Flow (MMDF) cannot be achieved, the battery is too low, or the lter needs
changing, an audible/visual alarm will be triggered. To ensure your Easiair® 2020 Powered Air Kit is working, the
alarm should be tested before every use.
•Turn on the device.
•Place the palm of your hand over the air outlet and hold.
•An audible/visual alarm should trigger.
•Turn off the device to reset.
7. ASSEMBLY & DONNING
The following instructions should be followed closely in order to maximise the efciency of your device. If your unit
is not assembled or tted correctly you may not be protected.
7.1 Battery
When supplied, your unit’s battery may hold a small charge. Before rst use, the battery should be run at and then
charged until fully charged. A fully charged battery should last up to 12 hours when in continuous use. From empty,
a battery should take 4-6 hours to charge.
Ensure the battery is fully charged before use, using the battery charger provided (see 6.2/3).
To remove the battery:
•Take the blower unit in both hands, with the rear
side facing you.
•Open the battery latch upwards with your thumb.
•Slide the battery forward to disconnect from the unit.
To attach the battery:
•Ensure the battery is the correct way around in
relation to the blower unit.
•Slide the battery along the guide rails.
•You should hear an audible ‘click’ as the battery locks
into place.

EASIAIR®20
20
THE RPE EXPERTS
9
7.2 Filters
The Easiair® 2020 Powered Air Kit is only compatible with
genuine TH3 PR SL lters and pre-lters supplied by Full
Support Healthcare Ltd. Using any other lters will invalidate
your warranty and could be a serious risk to your health.
Your respiratory device comes pre-tted with a genuine
Easiair® TH3 PR SL lter and pre-lter as standard.
Pre-lters are optional, disposable add-ons that can help
prolong the life of your lter in dirty environments. To attach,
simply sheathe around the lter body before inserting into
the blower unit.
Easiair® TH3 PR SL lters have a shelf-life of 5 years from
production. Once open, it is recommended that a lter be disposed of and changed every 6 months, or once soiled/
clogged – whichever comes sooner.
It is essential that the lter type used is suitable for the hazardous environment you will be working in. Please
consult with your Health & Safety Manager or an occupational hygienist if you are unsure.
If a lter is to be reused, store inside the unit to avoid dislodging contaminated matter.
Removing a soiled lter
•Twist the lter cover anti-clockwise approximately 25mm until it reaches its stopping point and lift off.
•Whilst wearing gloves, carefully remove the lter and pre-lter (if used) from the unit and dispose.
•Soiled lters should be disposed of according to your organisation’s policy for biological hazardous waste.
Fitting a new lter
•Sheath the lter with a pre-lter (if used).
•Align the lter with the aperture of the unit and push into
position.
•Slide a pre-lter around the outside of the lter if using.
•Place the blower unit casing ontop of the lter, aligning
the location slots with the indicator arrows.
•Push together and rotate clockwise until it ‘snaps’ into
place.
7.3 Belt
The Easiair® 2020 Powered Air Kit comes with a wipe-clean
PVC adjustable belt.
•Attach the blower unit onto the belt by passing the inner
belt strap through the loops at the back of the device.
•Put the belt around your waist with the blower unit to the
back and fasten the two belt ends together
•Tighten/loosen to t securely around your waste

EASIAIR®20
20
THE RPE EXPERTS
10
7.4 Hose
The Easiair® 2020 air hose can be used either way round to
avoid user error.
Disposable hose covers are available to speed up the
cleaning process.
•Sheathe the hose in an Easiair® hose cover (if using).
•Align the pins of the hose bayonet connector (on
either end) with the slots in the air outlet of the blower unit.
•Push together and twist in a clockwise direction until it
‘clicks into place.
•Repeat this process with the air inlet on the headpiece
to connect the hood.
•To remove, twist anti-clockwise and pull away from the
unit/hood.
•Dispose of the hose cover (if used).
7.5 Power
The Easiair® 2020 blower unit has an adjustable ow rate
of either 170 l/min or 215 l/min. The microprocessor inside
the unit will automatically regulate the motor speed to the
desired amount and compensate for any the state of the
battery and any lter clogging.
If the microprocessor cannot maintain the appropriate airow,
the unit will alarm. Please see section 6.4 for more information.
•Press the central power button on the control panel to turn ON/OFF the device.
•Adjust the airow rate to comfort by pressing the arrow buttons on the control panel.
7.6 Hood
The Easiair® 2020 Powered Air Kit comes with an an impact resistant hood (EN 166:2001 F hood & EN 166:2001
B visor).
The Easiair® 2020 hood is fully adjustable for head sizes between 535-600mm in circumference. Disposable comfort
bands are available to order, and should be tted to the internal suspension cradle before donning (if used).
You must ensure the device is switched on and working before attempting to don the hood.
•Attach disposable comfort bands (if used).
•Loosen the clasp on the rear of the hood.
•Don the hood and adjust the cape, unrolling the shroud over any other PPE worn.
•Tighten the rear clasp until comfortable and secure.

EASIAIR®20
20
THE RPE EXPERTS
11
8. CLEANING & MAINTENANCE
This guide should be used in conjunction with your organisation’s Health & Safety policy. Suitable PPE should be
worn during the decontamination procedure, depending on the substances used and your Health & Safety policies.
It is recommended that the blower unit, belt, lter housing, hose and headpiece be cleaned after each use to reduce
the risk of cross-contamination. Filters and pre-lters cannot be cleaned and should be disposed of in accordance
with your organisation’s policies, once soiled/clogged or after 6 months – whichever comes sooner (see 7.2).
Do not soak or submerge during cleaning.
Before cleaning:
•Doff the equipment.
•Ensure suitable PPE is equipped.
•Visually inspect all components for damage and fatigue.
WARNING:
If any components are cracked, torn or damaged, they should be replaced
immediately. Failure to do so may negatively affect the performance and protection
of the respirator, potentially resulting in user ill-health or even death.
Surface dirt – Neutral detergent
For surface dirt, the Easiair® 2020 Powered Air Kit can be wiped down with a soft cloth dampened with a neutral
detergent solution.
•Detach the belt and headpiece, and dispose of hose cover (if used) – leaving the hose still attached to the
blower unit.
•Wipe down the headpiece – working your way from inside to out.
•Wipe down the belt.
•Wipe down the blower unit with hose.
•Remove the battery and wipe down the battery and battery cavity.
•Rinse all components and leave to air dry before reassembling.
Deep clean – Clinell wipe/Chlorine solution
To decontaminate, the Easiair® 2020 Powered Air Kit can be wiped down with Clinell wipes or a soft cloth
dampened with a disinfectant solution (eg: a 0.1% chlorine solution or a solution containing 1000 ppm available
chlorine).
•Detach the belt and headpiece, and dispose of hose cover (if used) – leaving the hose still attached to the
blower unit.
•Wipe down the headpiece – working your way from inside to out.
•Wipe down the belt.
•Wipe down the blower unit with hose.
•Remove the battery and wipe down the battery and battery cavity.
•Rinse all components and leave to air dry before reassembling.

EASIAIR®20
20
THE RPE EXPERTS
12
Maintenance
You should inspect your equipment regularly and keep records, to ensure continued optimal use.
The following table can be used to track maintenance of your device.
Serial Number:
Date Commissioned:
Maintenance
required?
Date of
Action Fit for use? Name and Signature
Cleanliness Yes / No
Scratches Yes / No
Valve/Diaphragm Yes / No
Seal Yes / No
Filter check Yes / No
Visor/hood Yes / No
Straps Yes / No
Battery capacity Yes / No
Airow test Yes / No
Alarm test Yes / No

EASIAIR®20
20
THE RPE EXPERTS
13
9. FAULT FINDING
Please see section 6.1-6.4 for fault testing.
If a fault warning occurs whilst using your Easiair® 2020 Powered Air Kit, please consult the table below:
Fault Probable reason Recommendation
The blower unit
does not work
at all.
Entirely discharged battery
(verify if the blower unit works with
another charged battery).
Charge the battery
(if problem persists, check the battery).
Faulty motor, circuit board
or connector. Contact your supplier.
Low airow.
Blocked air hose or airduct. Check and remove blockage.
Leakage. Check all seals, connectors and the air hose. Make
sure that air cannot leak through holes or tears.
Battery is not charged enough. Charge the battery
(if problem persists, check the battery).
Blocked lter or pre-lter. Change the pre-lter. If the problem
persists change the main lter.
Short operating
time.
Clogged lter. Change the lters.
Battery is not charged properly. Charge the battery
(if problem persists, check the battery).
Battery cannot
be charged.
Battery contact is damaged. Check the battery contact.
Charger is faulty. Contact your supplier.
Battery cannot be
charged sufciently. Battery is worn out. Install a new battery.

EASIAIR®20
20
THE RPE EXPERTS
14
10. STORAGE
When not in use, all components should be stored in the container provided. Your Easiair®2020 Powered Air Kit
should be stored out of direct sunlight, not in contact with solvents or liquids, and away from heavy items. Do not
store outside the temperature range of +0°C to +40°C or above humidity levels of 75%RH.
11. TECHNICAL DATA
The Easiair® 2020 Powered Air Kit is a light-weight, easy to use powered air purifying respirator kit. It comes pre-tted
with a reusable TH3 PR SL particulate lter, affording reliable protection against viruses, particulates and aerosols.
Approvals EN 12941:1998 +A1:2003 +A2:2008
EN 166:2001 S Hood
Airow 170 l/min
215 l/min
Battery Rechargeable Li-ion 7.4V/5200mAh
Operating time 12 hours (at 170 l/min)
Charging time Approx. 4-6 hours
Weight 960g (blower unit with lter)
Alarm Optical alarm (ashing LED lights)
Acoustic alarm (>96 dBA)
Assigned Protection Factor 40 APF
Optimal operating temperature 0°C to +40°C
Belt length 125cm
Hood circumference 535mm - 600mm

EASIAIR®20
20
THE RPE EXPERTS
15
12. WARRANTY
Your Easiair® 2020 blower unit is guaranteed for a period of 12 months from the date of purchase, against
mechanical or electrical defects.
Your Easiair® 2020 battery is guaranteed for a period of on 12 months from the date of manufacture.
Full Support Healthcare Ltd undertake to exchange or repair, without charge, any part found to be defective
within this period.
This guarantee does not affect your legal rights, does not cover normal wear and tear, and is subject to the
device having:
•been used solely for its intended purpose by a trained individual, following the instructions as outlined in
this document.
•not been subject to misuse, modication, accident or repair.
For further information, please contact the manufacturer.

THE RPE EXPERTS
Full Support Healthcare Ltd
Harrowden Court, 66-80 Huxley Close
Wellingborough, Northamptonshire NN8 6AB
United Kingdom
Telephone: [phone]
www.fullsupportgroup.com
IM/1 042020
EU declaration of comformity present on the website: www.fullsupportgroup.com/DoC
