Full Support Easiair 2020 User manual
THE RPE EXPERTS
CE Approved to BS EN 166:2001 S & EN 12941:1998+A1:2003+A2:2008
FSM69 Easiair®2020 Reusable Premium Full Soft Hood
For use with the Easiair®2020 Powered Air Purifying Respirator (PAPR)
Reusable Premium
Full Soft Hood
Instructions For Use
EASIAIR®20
20
THE RPE EXPERTS
2
EASIAIR®20
20
IMPORTANT
This Instructions For Use (IFU) manual must be read and fully understood before use,
in conjunction with the Easiair®2020 PAPR Kit IFU document.
Easiair®2020 Reusable Premium Full Soft Hoods may only be used in conjunction with
genuine Easiair®labelled products and offer no respiratory protection if used without a
fully assembled and operational Easiair®2020 PAPR.
This product is designed to protect your health and wellbeing. Failure to comply with
these user instructions may adversely affect your health/wellbeing leading to illness or
even death.
Do not use a faulty, torn or incomplete product. Unauthorised modication/maintenance/
repair work may adversely affect the protection level of the product and may adversely
affect your health/wellbeing leading to illness or even death.
If your product is faulty, please contact the manufacturer, using the details on the back of
this document.
Please retain this manual with the product for future reference.
ATTENTION!
If any of the conditions outlined in this IFU
document are not kept or followed,
your health may be at risk.
EASIAIR®20
20
THE RPE EXPERTS
3
CONTENTS
1. Components 4
2. Range of applications 4
3. Conditions of use 5
4. Approvals 5
5. Before use 5
6. Donning & Dofng 6
7. Cleaning & Maintenance 6
8. Storage 7
9. Technical Data 7
10. Materials 7
11. Warranty & Returns 7
12. Accessories 8
EASIAIR®20
20
THE RPE EXPERTS
4
Donning/Dofng Loop
Visor
Double-layer Cape
Air Intake Connection Hole
Hood Circumference Adjuster Hole
Loose-tting Neck Seal
The Easiair® 2020 Reusable Premium Full Soft Hood is a TH2, impact resistant, loose-tting hood top accessory for
the Easiair®2020 PAPR system and requires a fully assembled and working unit to function.
The Easiair® 2020 PAPR system circulates clean pressured air around a loose-tting hood. The belt-mounted
blower unit delivers air through a lter, via a hose, into the hooded headpiece. The constant supply of ltered air
creates positive pressure inside the headpiece, which prevents external contaminated air from entering the user’s
breathing zone.
A protective lm is applied to the visor during the manufacturing process to protect the visor from scratches.
Remove before use.
•For further information, please refer to the Easiair®2020 PAPR Kit IFU document.
ATTENTION!
If any components are cracked, torn or damaged, they should be replaced immediately.
Failure to do so may negatively affect the performance and protection of the respirator,
potentially resulting in user ill-health or even death.
2. RANGE OF APPLICATIONS
When used as part of a fully assembled and working Easiair®2020 PAPR, the Easiair®2020 Reusable Premium Full
Soft Hood offers TH2 P R SL protection with an Assigned Protection Factor (APF) of 20.
No recommendation is given by the manufacturer as to the suitability of this product for your specic needs.
Suitability of this product should be guided by organisation, local and national guidelines pertaining to Respiratory
Protective Equipment (RPE) and Powered Air Purifying Respirators (PAPRs).
1. COMPONENTS
EASIAIR®20
20
THE RPE EXPERTS
5
If you have any questions regarding the suitability of this product to your task, please contact an occupational
hygienist or call the manufacturer’s technical help line for further information. The relevant contact details can be
found on the back of this manual.
3. CONDITIONS OF USE
Easiair®2020 Reusable Premium Full Soft Hoods must be used in conjunction with a fully assembled and working
Easiair®2020 PAPR Kit. Without a fully operational PAPR system, the Easiair®2020 Reusable Premium Full Soft
Hood offers no respiratory protection to the wearer.
If your product is faulty, damaged or showing signs of excessive wear, please contact the manufacturer. The
protective effect of the headpiece may be impaired by:
- high wind velocities/crosswinds
- collars, earpieces or beards tucked under the neck cuff
•For a full list of conditions and limitations, please refer to section 4 of the Easiair®2020 PAPR Kit IFU document.
4. APPROVALS
The Easiair®2020 Reusable Premium Full Soft Hood has been designed and manufactured to comply with directive
89/686/EEC on personal protective equipment and has been certied according to BS EN 166:2001 S – denoting
impact resistant face and eye protection.
When used as part of a complete Easiair®2020 PAPR system, the Easiair®2020 Reusable Premium Full Soft Hood
complies with EN 12941:1998+A1:2003+A2:2008 as a TH2 P R SL respiratory protective device.
•For a full list of approvals, please refer to page 4 section 3 of the Easiair®2020 PAPR Kit IFU document.
5. BEFORE USE
Check the hood for any damage, wear or tears. If damaged, dispose and replace
before use.
Remove protective lm from the visor.
Attach the hood to the headgear using the following the process (also outlined in
section 7 of the Easiair®2020 PAPR Kit IFU):
5.1. Attach the head gear
- Locate the two holes at the back of the hood and slip the headgear’s air intake
through the larger hole at the top and the hood circumference adjuster through
the smaller hole at the bottom.
- Locate the clear plastic tabs inside the hood either side of the visor, and the
white plastic ‘arms’ either side of the headgear. Slide the clear plastic tab into
the grip of the white plastic arm.
- Attach disposable comfort bands (if used).
EASIAIR®20
20
THE RPE EXPERTS
6
6. DONNING & DOFFING
Ensure the Easiair®2020 PAPR device is assembled properly, switched on and
working before donning (see Easiair®2020 PAPR Kit IFU section 7 for further
instructions).
Do not turn off before dofng. Do not don/doff the Easiair®2020 Reusable
Premium Full Soft Hood in a hazardous area.
6.1. Donning
- Ensure that the blower unit is assembled, hose connected and the device is
switched on.
- Loosen the hood circumference adjuster clasp on the rear of the hood.
- Don the assembled headgear/hood and adjust the cape, unrolling the shroud
over any other PPE worn.
- Tighten the hood circumference adjuster clasp until comfortable and secure.
6.2. Dofng
- Loosen the hood circumference adjuster clasp on the rear of the hood.
- Pull over your head using the loop on top of the hood.
- Turn off the device.
7. CLEANING & MAINTENANCE
This guide should be used in conjunction with your organisation’s Health & Safety policy, and the Easiair®PAPR
Kit IFU document.
You should closely follow the processes outlined below. Using non-recommended cleaning products or methods
may cause damage or degradation of your product. Suitable PPE should be worn whilst disposing/cleaning/
decontaminating, depending on the potential hazards present on the product and your Health & Safety policies.
For further information please see section 8 of the Easiair®2020 PAPR Kit IFU.
7.1. Disposal
Used hoods may be contaminated and should be treated as potentially biological hazardous waste. When disposing,
please do so in accordance with your applicable waste disposal regulations.
7.2. Cleaning
Surface Dirt
- Using a soft cloth dampened with a neutral detergent solution wipe down the hood, working your way from
inside to out.
- Rinse off with clean water.
- Leave to air dry, away from direct sunlight.
EASIAIR®20
20
THE RPE EXPERTS
7
Deep Clean
- Using Chlorine wipes or a soft cloth dampened with a disinfectant solution (eg: a 0.5% chlorine solution or a
solution containing 5000 ppm available chlorine), wipe down the headpiece – working your way from inside to out.
- Allow the chlorine solution to sit for 1 minute and then rinse off with clean water.
- Leave to air dry, away from direct sunlight.
7.3. Maintenance
Do not attempt to modify or repair your Easiair®2020 Reusable Premium Full Soft Hood in any way, as this may
affect the protection level of your device. If worn or damaged, please dispose of immediately. If faulty, please
contact the manufacturer using the details provided on the back of this document.
•For further maintenance guidance, including a checklist for regular inspections, please see section 8 of the
Easiair®2020 PAPR Kit IFU document.
8. STORAGE
When not in use, Easiair®2020 Reusable Premium Full Soft Hoods should be stored in their original packaging,
out of direct sunlight, not in contact with solvents or liquids, and away from heavy items. Do not store outside the
temperature range of 0°C to 40°C or above humidity levels of 75%RH.
9. TECHNICAL DATA
Approvals EN 166:2001 S
Operating Temperature 0°C to 40°C
Operating Humidity <75% relative humidity
Hood Circumference 535mm-600mm
10. MATERIALS
Visor Impact Resistant Polycarbonate
Cape TPU Cloth
Protective Film PET
11. WARRANTY & RETURNS
For Easiair®2020 PAPR warranty information, please see the Easiair®PAPR Kit IFU. For health and safety reasons,
Easiair®2020 Reusable Premium Full Soft Hood may not be returned if opened, unless faulty.
This does not affect your statutory rights.
EASIAIR®20
20
8
Full Support Healthcare Ltd
Harrowden Court, 66-80 Huxley Close
Wellingborough, Northamptonshire NN8 6AB
United Kingdom
Telephone: +44 (0)1933 672180
www.fullsupportgroup.com
IM/2 072020
EU declaration of comformity present on the website: www.fullsupportgroup.com/DoC
THE RPE EXPERTS
12. ACCESSORIES
DESCRIPTION CODE
Easiair®2020 Powered Air Purifying Respirator Kit FSM39
Easiair®2020 Filter P R SL (P3) FSM40
Easiair® 2020 Standard Battery FSM42
Easiair® 2020 Battery Charger FSM44
Easiair®2020 Sweatband (x2) FSM45
Easiair® 2020 Breathing Hose FSM46
Easiair® 2020 PVC Decon Belt FSM47
Easiair® 2020 Blower Unit FSM48
Easiair®2020 Disposable Hose Cover (x50) FSM50
Easiair® 2020 Single Use Full Soft Hood (x10) FSM51
Easiair®2020 Headgear with Airduct FSM52
Easiair®2020 Reusable Premium Full Soft Hood FSM69
