Fuller Brush FB-HM User manual

Owner’s Manual
For Fuller Brush
Canister Vacuums
Models
FB-HM
FB-HMP
Thank you for purchasing this
Fuller Brush Canister Vacuum.
To ensure the best results, please read this
manual rst and keep it for future reference.

1
Important Safety Instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �2
Two-Wire Polarized Cord � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �3
State of California Proposition 65 Warnings � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �3
Parts Identification and Replacement Bags, Belts, Filters (Model FB-HMP) � � � � � � � � � � � � � � � � � � � � � � � �4
Parts Identification and Replacement Bags, Filters (Model FB-HM) � � � � � � � � � � � � � � � � � � � � � � � � � � � � �5
How to Assemble and Operate the Vacuum � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �6
How to Replace the Bag � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �7
How to Replace the Filters � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �7
Tools Cleaning � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �8
Wand Storage � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �9
How to Operate the Power Nozzle� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �10
How to Replace the Power Nozzle Belt � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �11
Troubleshooting Guide � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �12
For Best Performance � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �12
The model and serial number of this product may be found on the back of the unit� Register your Fuller Brush
vacuum online at www�FullerBrushVacuums�com as soon as possible for your protection� Also, note the model
and serial numbers of your unit in the spaces provided below, and retain this book as a permanent record of
your purchase�
Model Number ____________________________________________________________________________
Serial Number _____________________________________________________________________________
Date Purchased ____________________________________________________________________________
Your Fuller Brush vacuum cleaner is a product of high-quality materials and superior workmanship� We urge
you to read these operating instructions carefully before you use this vacuum cleaner in order to obtain the full
performance and satisfaction it can offer you�
Before you plug in your Fuller Brush vacuum cleaner, make sure the voltage indicated on the rating plate
located on the back of the vacuum cleaner is the same as your local supply�
Index
Customer’s Record
Save These Instructions

2
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
When using an electrical appliance, basic precautions should always be followed, including the following:
SAVE THESE INSTRUCTIONS.
WARNING: To reduce the risk of fire, electric shock or injury:
1� Do not leave appliance unattended when plugged in� Unplug from outlet when not in use and before servicing�
2� WARNING: ELECTRIC SHOCK COULD OCCUR IF USED OUTDOORS OR ON WET SURFACES�
3� Do not allow to be used as a toy� Close attention is necessary when used by or near children�
4� Use only as described in this manual� Use only manufacturer’s recommended attachments�
5� Do not use with damaged cord or plug� If appliance is not working as it should, has been dropped,
damaged, left outdoors or dropped into water, return it to a service center�
6� Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges
or corners� Do not run appliance over cord� Keep cord away from heated surfaces�
7� Do not unplug by pulling on cord� To unplug, grasp the plug, not the cord�
8� Do not handle plug or appliance with wet hands�
9� Turn off all controls before unplugging�
10� Do not put any object into openings� Do not use with any opening blocked; keep free of dust, lint, hair and
anything that may reduce air flow�
11� Keep hair, loose clothing, fingers and all parts of the body away from openings and moving parts�
12� Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes�
13� Do not use without vacuum filters in place�
14� Use extra care when cleaning on stairs�
15� Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may be
present�
16� Do not attempt to service the unit while appliance is plugged in�

3
This product is equipped with a polarized alternating current line plug (a plug having one blade wider than the
other)� This plug fits into the power outlet only one way� This is a safety feature� If you are unable to insert the
plug fully into the outlet, try reversing the plug� If the plug should still fail to fit, contact an electrician to replace
the obsolete outlet� Do not defeat the safety purpose of the polarized plug�
Two-Wire Polarized Cord
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer�
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects
or other reproductive harm�

4
Parts Identification
Replacement Bags, Belts and Filters
1� Hose
2� Carry Handle
3� Hose Electrical Cord
4� Bag Compartment Latch
5� Bag Compartment
6� Full Bag Indicator
7� Variable Speed Control
8� Power Cord Rewind Pedal
9� HEPA Media Filter
10� On/Off Pedal
11� Power Nozzle
12� Wand Release Button
13� Telescopic Wand
14� Cleaning Tools
15� Wand Extension Grip
16� Handle Release Button
17� Suction Control
18� On/Off Switch for Power Nozzle
19� Hose Handle
1
8
5
11
4
7
6
2
3
18
19
17
14
12
13
109
15
16
MODEL FB-HMP
• Genuine Fuller Brush Filter Set
Part # FBHM-HEPA
• Genuine Fuller Brush Vacuum Bags
Package of 6 Part # FHH-6
• Genuine Fuller Brush Power Nozzle Belt
Package of 2 Part # FBHMP-B2

5
Parts Identification
Replacement Bags and Filters
1� Hose
2� Carry Handle
3� Bag Compartment Latch
4� Bag Compartment
5� Full Bag Indicator
6� Variable Speed Control
7� Power Cord Rewind Pedal
8� HEPA Media Filter
9� On/Off Pedal
10� Rug/Floor Tool
11� Wand Extension Button
12� Upholstery Tool
13� Telescopic Wand
14� Cleaning Tools
15� Suction Control
16� Hose Handle
1
7
4
10
3
6
5
2
16
13
14
11
12
98
15
MODEL FB-HM
• Genuine Fuller Brush Filter Set
Part # FBHM-HEPA
• Genuine Fuller Brush Vacuum Bags.
Package of 6� Part # FHH-6

6
How to Assemble and Operate the Vacuum
Fig. 1
Fig. 2
How to Assemble and Operate the Vacuum
The vacuum, hose, wand and accessories are packed separately�
1� Push the hose cuff into the hose inlet on the top of the bag compartment
until it clicks into place (Fig� 1)�
2� Attach the electrical cord from the hose into the plug underneath the carry
handle (FB-HMP model only) (Fig� 2)�
How to Extend the Wand
Grasp the wand extension grip (FB-HMP model) or the wand extension
button (FB-HM model) and pull up on the hose handle to extend the wand to
the desired length�
On/Off Switch
1� To turn the vacuum on, push the power pedal on the top of the vacuum�
2� To turn the vacuum off, push the pedal again�
3� To turn the power nozzle on, turn the vacuum on first, then push the
On/Off switch on the hose handle to the “On” position
(FB-HMP model only)�
Full Bag Indicator
1� If the full bag indicator appears, change the vacuum bag�
2� If the full bag indicator appears, but the vacuum bag is not full, check the
hose for a clog�
NOTE: When cleaning with a tool (dusting brush, upholstery tool or crevice
tool), the full bag indicator may appear� In this case, continue
cleaning, as the indicator will likely go off once the tools are no
longer in use�
Variable Speed Control
To adjust the motor power, slide the variable speed control on the canister
body to the desired motor speed�
Suction Control
To adjust the suction level, slide the suction control switch on the handle to
reach the desired level of suction�

7
Fig. 1
How to Replace the Vacuum Bag
How to Replace the Vacuum Filters
Fig. 2
Fig. 1
Fig. 3
Fig. 2
Fig. 3
Always operate the vacuum cleaner with a bag installed properly� Change
the vacuum bag when the full bag indicator appears or when suction power
is weak� The bag compartment lid will not close without a bag in the holder
or if the bag is not properly installed�
1� Disconnect the hose from the canister by squeezing the two tabs on the
hose cuff and pulling it out of the inlet (Fig 1)�
2� Disconnect the electrical cord on the hose cuff from beneath the carrying
handle (FB-HMP model only)�
3� Open the bag compartment lid�
4� Remove the bag holder by pulling it up and out of the bag
compartment (Fig 2)�
5� Remove the bag by sliding the cardboard collar out of the bag
holder (Fig 3)�
6� Slide a new bag into the bag holder until it clicks into place�
7� Insert the bag holder back into the bag compartment�
8� Replace the hose� Reconnect the electrical cord (FB-HMP model only)�
When to Change the Filters
At a minimum, it’s recommended to replace the HEPA media and secondary
filters after using 12 vacuum bags� If someone in your household is sensitive
to airborne allergens, it is recommended to change the filters after every six
vacuum bags�
How to Replace the HEPA Media Filter
1� Lift up the two tabs of the filter cover to access the HEPA media filter (Fig 1)�
2� Remove the used filter and discard�
3� Insert a new filter and snap the filter cover back into place (Fig 2)�
NOTE: The HEPA media filter cannot be washed and reused�
How to Replace the Secondary Filter
1� Disconnect the hose from the canister by pushing in on the two tabs on the
hose cuff and pulling it out of the inlet�
2� Disconnect the electrical cord on the hose cuff from beneath the carrying
handle (FB-HMP model only)�
3� Open the bag compartment lid�
4� Remove the bag holder by pulling it up and out of the bag compartment�
5� Locate the filter behind the vacuum bag�
6� Pull the filter holder up and out of the bag compartment (Fig 3)�
7� Remove the used filter and discard�
8� Insert a new filter into the holder and slide the holder back into place�

8
Tools Cleaning
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5 Fig. 6
The Home Maid canister is equipped with a metal telescopic wand, hose,
crevice tool, dusting brush, upholstery tool and rug/floor tool�
All of these tools can be attached to the end of the wand or to the hose
handle for convenient cleaning�
Crevice Tool
The crevice tool is ideal for hard to reach places and along
baseboards (Fig� 1)�
Dusting Brush
The dusting brush is ideal for vacuuming delicate objects and
surfaces (Fig� 2)�
Upholstery Tool
The upholstery tool cleans pet hair quickly and easily from sofas
and chairs (Fig� 3)�
Rug/Floor Tool
This tool is great for cleaning area rugs with the brushes retracted and
glides along tile, hardwood and vinyl floors with the brushes exposed�
When attached to the wand, this tool conveniently stores on the back of
the vacuum (Fig� 4)�
Tools Storage
FB-HMP Model
The crevice tool, dusting brush and upholstery tool are conveniently stored
on the removable tool caddy attached to the wand (Fig� 5)�
FB-HM Model
The crevice tool and dusting brush are conveniently stored on the hose
handle for easy reach� The upholstery tool is stored on the tool caddy
attached to the wand (Fig� 6)�

9
Wand Storage
Fig. 2
Fig. 3
Fig. 1
How to Store the Wand
FB-HMP Model
1� The tab on the back of the wand conveniently stores onto the back of
the vacuum (Fig� 1)�
2� The tab on the back of the tool caddy conveniently stores on the bottom
of the vacuum (Fig� 3)�
FB-HM Model
1� The tab on the back of the rug/floor tool conveniently stores on the
back of the vacuum when it is attached to the end of the wand (Fig� 2)�
2� The tab on the back of the tool caddy conveniently stores on the bottom
of the vacuum (Fig� 3)�

10
FB-HMP Model
How to Turn On the Power Nozzle
1� The power nozzle can only be turned on if the
canister is also turned on� The canister On/Off
pedal is located on the main body�
2� The power nozzle On/Off switch is located on the
handle� Simply press the switch forward to engage
the power nozzle (Fig� 1)�
How to Use the Power Nozzle
1� Turn on the canister and lower the wand by
stepping on the top of the power nozzle and
pulling the wand toward you (Fig� 2)�
2� Turn on the power nozzle�
How to Remove and Insert the Wand
1� Removing the wand from the power nozzle allows
you to use cleaning tools for baseboard or ceiling
cleaning� Turn the power nozzle and canister off�
Then press the wand release button and pull the
wand out (Fig� 3)�
2� To reinsert the wand into the power nozzle, simply
press the wand back into the power nozzle� The
wand will then “click” into place�
How to Operate the Power Nozzle
Fig. 2
Fig. 3
Fig. 1

11
How to Replace the Power Nozzle Belt
FB-HMP Model
The brushroll may need to be removed at times, to
cut threads that have become tangled around it or to
replace the belt�
1� Turn the nozzle over and squeeze the tabs in the
middle toward each other� Then lift up on the tabs
on the outer edges� Lift off the baseplate (Fig� 1)�
2� Lift the non-belt end of the brushroll out of the
nozzle first� Remove the belt from the brushroll and
motor pulley (Fig� 2)�
3� To install a new belt, loop the belt around the
motor pulley and then around the brushroll (Fig� 3)�
4� Insert the belt end of the brushroll into the nozzle�
Then push the other end of the brushroll into the
nozzle� Turn the brushroll with your hand to ensure
it is installed correctly�
5� To replace the baseplate, insert the tabs on the
front of the baseplate into the grooves of the
nozzle� Push the baseplate onto the nozzle making
sure all four tabs lock into place�
Fig. 3
Fig. 2
Fig. 1

12
Please check each item below if you have trouble with your vacuum�
Unplug the vacuum from the power supply before servicing�
Problem Check Point Possible Solution
Suction power is weak. • Vacuum bag • If vacuum bag is full, replace it.
• Wand or hose • If clogged or blocked,
remove the object�
The vacuum does not work. • Is the hose adapter inserted • Insert hose until it snaps
into the suction opening of into place�
the vacuum completely?
• When the vacuum bag is full • Turn the vacuum off and
or any of the accessories are unplug the vacuum�
blocked, the over-heating Check the vacuum
protection for the motor bag and accessories
is activated� and remove any
blockages� The vacuum
can be turned on again after
approximately 20 minutes�
Power cord does not rewind. • Power cord • Pull the power cord out a
little and press the cord
rewind button again�
Power cord won’t pull out of • Power cord • Do not pull it out by force.
the vacuum� Rewind it a little by
pressing the cord rewind
button and try pulling it
out again�
Troubleshooting Guide
For Best Performance
• Keep machine and all accessories clean and in good operating condition.
• Replace filters after using 6 to 12 vacuum bags or more frequently if vacuuming fine powders such as flour
or dry wall dust�
• Always use genuine filters and parts, as use of other products may result in poor cleaning or filtration
performance� Fuller Brush filtration products are designed for maximum performance�
• Store machine carefully in a dry area.
• For optimum cleaning performance and safety, follow your owner’s manual.

Fuller Brush Vacuum Cleaners
PO Box 730
Fenton, MO 63026
www.FullerBrushVacuums.com
Item FBOM-HM©2013 Fuller Brush Vacuum Cleaners
