Furniture of America CM7152Q User manual

Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
1 / 8
2 - People
(Included)
Allen Wrench
Recommended
Phillips
Screwdriver
(Not Included)
(Included)
Wrench
MODEL #
CM7152Q/F
VERSION # 20-0 7-09

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ XXXXXXX8

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ XXXXXXX8

4/ XXXXXXX8

Ø1/4"
Flat Washer Ø5/16"
Allen Wrench M4
Lock Washer Ø5/16"
BED
#1 1pc #2 1pc #3 3pcs#4 2pcs
#5 3pcs #6 1pc #7 2pcs
Headboard
Footboard Slat Side Rail
#F 8pcs #G 8pcs
#A 10pcs #B 10pcs #C 10pcs #D 8pcs
Lock Washer Ø5/16"
Hex Nut Ø5/16" Flat Washer Ø5/16" Screw#8 x 25mm
#I 1pc #J 1pc
Wrench
Support Leg
Headboard
Down Rail Headboard Legs
5 / 8
170x30x30mm
CM7152Q/F
Bolt Ø5/16" x 1-3/4" Threaded Stud Ø5/16"x3"
#E 8pcs#H 6pcs

Carton Disignation Part Hardware
Headboard
Slat
Side Rail
#1
#2
Headboard Legs
#6
#7
Footboard
Headboard
Down Rail
#3
#4
#5
#2
#3
#4
#5
#6
#7
Support Leg
#1
6 / 8
#A 10pcs
#B 10pcs
#C 10pcs
#I 1pc
#D 8pcs
#E 8pcs
#F 8pcs
#G 8pcs
#H 6pcs
#J 1pc
CM7152Q/F is packed in 2 cases
CM7152Q/F-HB&FB
CM7152Q/F-R

1
2
ASSEMBLY INSTRUCTIONS
Part #1 x1pc
Part #6 x1pc
Part #7 x2pcs
Hardware #A x10pcs
Hardware #B x10pcs
X 3
Part #3 x3pcs
Part #5 x3pcs
7 / 8
#C
#A
Hardware #C x10pcs
#B
#I
#1
#7
#6
#7
#C
#A#B
#I
#3#5
Align HB legs (#7) to the headboard (#1),
then secure by using bolts (#A) with
washers (#B,C).
Align HB rail (#6) to the HB legs (#7),
then secure by using bolts (#A) with
washers (#B,C).
Align support legs (#5) to the slats
(#3), then adjust the leveler on the
bottom of the support legs (#5)
according to ground level.

3
4
Part #4 x2pcs
Part #2 x1pc
ASSEMBLY INSTRUCTIONS
Hardware #D x8pcs
Hardware #E x8pcs
Hardware #F x8pcs
Hardware #G x8pcs
Hardware #H x6pcs
8 / 8
#D
#G#F#E
#J
#4
#2
#H
Attach threaded studs (#D) to the
headboard and footboard (#2), then
align the side rails (#4) to the
threaded studs (#D). Secure by using
hex nuts (#E) with washers (#F,G).
Align slats to the side rails, then
secure by using screws (#H).
