SYSTEM CONFIGURATION
Environmental Category
Antenna unit
Communication unit,
ISDN handset, etc.
To be installed in an exposed area
To be installed in a protected area
Antenna Unit
SF-130 standard supply optional supply
Communication Unit
SF-230
shipyard supply
N Type
N Type
Antenna cable
103154 25m 5.3
φ
RF
ISDN Handset
SF-870
ISDN
(RJ-45)
ISDN
(RJ-45)
ISDN
(4 wire)
RS-232C
RS-232C
USB
DC IN
(11-32 V)
2 pin
10 m
12-24 VDC
RJ-45
RJ-45
USB (B)
Dsub9
Dsub9
RJ-45
ISDN cable
QRPM911-3000
(3 m)
Terminal
Adapter
QDGY 911912
RJ-11 RJ-11
G3 FAX
FAX-8070P
ISDN bus:max 100 m
103776 Dsub25
9-pin to 25 pin printer cable
RS-232C cable
R906686
(3 m)
USB cable
100001(3 m)
Printer
PC
Dsub9
RS-232C
USB (A)
ISDN
Wall Socket
102176
RJ-45 RJ-45
RJ-45
ISDN Handset
SF-870
RJ-11 RJ-11
RJ-45
ISDN
Wall Socket
102176
ISDN
Wall Socket
102176
Terminal
Adapter
QDGY 911912
RJ-45
G3 FAX
FAX-8070P
Telephone
DBAR104001/888
Telephone
FC755D1
(Japanese)
DC OUT
AC-DC Power Supply
PR-240
DC IN AC IN
12-24 VDC 100/110/200/220 VAC
DPYC-1.5
DPYC-2.5
www.reelschematic.com
www.reelschematic.com

iv
EQUIPMENT LISTS
Standard Supply
Name Type Code No. Qty Remarks
Antenna Unit SF-130 — 1 w/cable 103154 (25 m)
Communication
Unit
SF-230 — 1
ISDN Handset SF-870 — 1
Terminal Adapter QDGY911912 000-147-698 1
CP16-03200 000-150-697 1Installation
Materials* CP16-03210 000-043-445 1
Accessories FP16-03000 000-043-466 1 CD-ROM for communication unit
*: See lists at the back of this manual.
Optional Supply
Name Type Code No. Qty Remarks
FAX-8070P 000-043-443 For CE type, w/CP16-02601
FAX-2850 000-043-438 w/CP16-02601
Facsimile
MFC-4800J 000-043-439
1 set
Japanese version
Drum Unit DR-10J 000-146-598 1 For above facsimile
Toner Cartridge TN-10J 000-146-599 1 For above facsimile
Telephone FC755D1 000-433-690 1 set w/CP16-00511, 00512
Antenna Cover QB05-1801 100-079-480 1
OP16-10 000-043-278 1 Box typeModular Jack Box
OP16-11 000-043-279 1 Flush mount type
Modular Jack Set OP16-13 000-043-228 1
000-120-792 For ISDN connection, 10 m
000-120-794 For ISDN connection, 20 m
000-120-214 For ISDN connection, 30 m
000-132-827 For ISDN connection, 40 m
2-pair cable CO-SPEVV-SB-C
0.2x2P
000-132-826
1
For ISDN connection, 50 m
000-110-681 For analog telephone, 10 m
000-138-789 For analog telephone, 20 m
000-138-790 For analog telephone, 30 m
000-138-791 For analog telephone, 40 m
1-pair cable CO-SPEVV-SB-C
0.2x1P
000-138-792
1
For analog telephone, 50 m
Serial Printer ML280S 000-150-443 1
www.reelschematic.com
www.reelschematic.com

v
Optional supply (con’t)
Name Type Code No. Qty Remarks
Transformer 0P16-25 004-446-850 1
Transformer E-300+cable
100VAC→220VAC (300VA)
For FAX-2850 or FAX-8070P
Analog Telephone DBR104001/888 000-147-693 1
Terminal Adapter QDGY911912 000-147-698 1
ISDN Wall Socket 102176 000-147-699 1
ISDN Handset SF-870 000-043-252 1
Incoming Indicator KK-893-3977 000-148-478 1 For analog telephone line
Transformer SD-221 000-139-903 1 For Facsimile MFC-4800J
Signal Cable S16-4-15 004-446-970 1 Cable 103776
Antenna Cable 105052 000-150-706 1 50 m
Antenna Cable QTZC502012 000-150-708 1 140 m
AC/DC Power PR-240-CE 000-053-373 1
Cable (LAN) FR-FTPC-CY *10m* 000-147-472 1 10 m
Cable (LAN) FR-FTPC-CY *20m* 000-147-473 1 20 m
Cable (LAN) FR-FTPC-CY *30m* 000-147-474 1 30 m
ISDN Cable (3m) QRRM911111-3000 000-150-709 1
ISDN Cable (10m) QRRM911111-10000 000-015-711 1
www.reelschematic.com
www.reelschematic.com

1
1. PLANNING
1.1 Placing the Antenna Unit
General
Interfering objects (especially metallic objects such as masts) near the antenna can, in the
worst case, prevent reception or transmission. Further, RF radiation from the antenna will
affect the human body. Keep these and the following guidelines in mind when selecting a
mounting location for the antenna unit.
Secure unobstructed path in all directions
The ideal mounting location secures an unobstructed path between the antenna unit and
the satellites, from horizontal to zenith. In order words, whatever the direction the antenna
unit is pointing there are no interfering objects within the main beam (16°). While this might
be feasible on some vessels, on others it is impossible due to space considerations. The
antenna unit should be located at least 3 meters away from masts having a diameter less
than 15 centimeters.
Select a location low in vibration
The maximum permissible vibration amplitude in three axis direction should be as shown in
the table below. Consult with the shipyard to determine the mounting location which meets
the requirements shown in the table.
Freq. Range Max. Amplitude
4 to 10 Hz
10 to 15 Hz
15 to 25 Hz
25 to 33 Hz
2.54 mm (max. 9.8 m/s²)
0.76 mm (max. 6.86 m/s²)
0.40 mm (max. 9.8 m/s²)
0.23 mm (max. 9.8 m/s²)
Half Vibration
Maximum amplitudes
www.reelschematic.com
www.reelschematic.com

2
Locate away from passengers and crew
Radio waves can be harmful to the human body. Since safe distances vary by country and
ship construction there is no uniform formula for calculating safe distance. However, below
are general guidelines.
• Personnel should not approach an area in which the radiation level is higher than 10
W/m2, i.e., within 1.00 m from the radome surface.
Do not approatch within 1.00 m of the
antenna radome when it is transmiting.
Microwave radiation can be harmful to
the human body, particularly the eyes.
WARNING
• Construct a protection fence around the antenna unit so that personnel can not approach
the antenna unit within 1.00 m. Also, to alert personnel not to approach the antenna unit,
attach the caution labels (supplied as installation materials) to any bulkhead which is at
the position of 1.00 m from the antenna unit.
1.00 m 1.00 m
MICROWAVE RADIATION !
NO ADMITTANCE WITHIN 1.00 m
www.reelschematic.com
www.reelschematic.com

3
Minimum distance from other antennas
HF antennas, communication/navigation antennas:
The antenna should be at least 5 meters from a HF antenna. VHF, satellite navigation
antenna and other communication antennas should be at least 4 meters away.
Radar:
The antenna should be at least 5 meters away to protect the low noise amplifier in the radar
antenna. However, if this distance cannot be secured be sure the antenna is not within the
radar beam.
More than 5 m
If installed within 5 m of
radar antenna, the antenna
unit must not be within the
radar beam.
20
30
Distance from radar antenna
Compass safe distance
Locating the antenna unit too close to a compass can affect compass performance. The
compass safe distance is 0.75 meters, steering compass, 0.45 meters, standard compass.
Other mounting guidelines
Other important mounting guidelines are
• Locate the antenna unit away from exhaust stacks (foreign material on the radome can
interfere with reception and transmission).
• Keep the unit away from heat sources.
• Locate the unit away from places where fuels and chemical solvents are stored.
• Keep in mind the length of the cable from the communication unit is maximum 100
meters.
www.reelschematic.com
www.reelschematic.com

4
1.2 Designing the Antenna Mast
General
To facilitate servicing, construct a mast of 1500 mm in height and 60 mm in diameter. (See
page 5.) The paragraphs which follow provide guidelines for selection and construction of
the mast. Refer to the drawing at back of this manual.
Guardrail, platform
Fit the mast with a guardrail and platform (or steps), for serviceman’s safety. (In most
installations the serviceman stands on the platform while checking the radome. Thus this
distance should be secured for ease of servicing.) The guardrail should be as high as
possible for sufficient safety.
Mast strength
The mast material must be sufficiently strong to meet the
demands of the marine environment. It should satisfy the
following requirements.
• It must be able to support radome mass plus at least
2.5 cm of ice and snow. Special consideration should
be given if the unit is operated in areas of heavy snow
or freezing temperature.
• Mast bending moment must be able to withstand
expected maximum pitching, rolling and wind pressure.
• To prevent resonance at low frequencies (about 5 Hz),
four stays can be fixed between the mast and the
mounting base.
Item Mass
Antenna unit mass 8 kg ±10%
Platform, guardrail mass
Expected ice and snow
Maximum wind pressure (at wind speed 75 m/s) 1654.9 N
Mast
Mass Bending
Moment
Wind
Pressure
www.reelschematic.com
www.reelschematic.com

5
Mounting pole and mounting base
In order to ensure long life for the antenna electronics and mechanics, the antenna must be
installed properly on a specially designed pole with suitable flange and rubber gasket.
Below are guidelines for installation of the mounting pole and mounting base.
• The pole serves the purpose of protecting the coax cable and its N-type male connector
where it joins the N-type female connector at the bottom of the dome. Further, it is a very
important part of the ventilation system of the dome; the hole in the pipe allows trapped
moisture to escape from the dome.
• The face of the mounting base should be flat as possible (tolerance: within 2 millimeters
of the horizontal plane).
• The mounting base should be parallel with ship’s horizontal plane (tolerance: ±1°).
• The fixing bolts of the mounting base should be parallel with the ship’s keel line
(tolerance: ±2°).
• Weld a ground bolt (stainless steel, M10x40, local supply) to the mast within 50 cm of a
fixing bolt on the antenna unit. The length of the ground wire (local supply) is 50 cm.
100 mm
140 mm
100 mm 140 mm
HOLE
DIA 9 mm
Mounting pole and mounting base
www.reelschematic.com
www.reelschematic.com

6
1.3 Mounting Dimensions of Units
100 mm 100 mm
COAXIAL
CONNECTOR
and ventilation hole SEEN FROM BELOW
400 mm
400 mm
M4x24
SOCKET HEAD
UNBRAKO
SCREWS
(RADOME TOP
FASTENERS)
Mass: 8 kg
* The hole encircling the coaxial connector functions as a
ventilation hole, allowing trapped moisture to escape the dome.
For that reason, ensure the hole is not blocked.
Bolt length to be
entered inside the
radome*:
- max 20 mm
- min 13 mm
Max torque 20Nm
M8 SOCKETS (4)
www.reelschematic.com
www.reelschematic.com

7
ISDN Handset Handset holder/cradle
22.5
40
37.5
15 1530
60mm
22 mm
100mm
FUNC
ALPHA
ENTER
SHIFT
MORE/
HELP
LES
PTT
ESC
7
STU
DATA
ØÁ.
4
JKL
1
ABC
LIST
LIST
3
GHI
6
PQR
9
LIGHT
YZ
Æ
SPC
ON/OFF
DEL
2
DEF
PLAY
5
MNO
8
VWX
TAX
0
ÄÖÜ
ON
SHIFTBAT
ALPHA
DIAL 00+INTL
TEL NO+
54mm
2000mm
198mm
RJ45
34mm
Mass: 0.3 kg Mass: 0.06kg
Communication unit
6.5mm
7 7
9.25
145.5
145.5
9.25
166
ON
DCOUT
SYNC
ALARM
RS-232ARS-232B
USB
ISDN
ISDN
5 4 32 1
9 8 76
5 4 321
987
6
1 8
8 1
81mm
180
mm
Mass: 3kg
309.5 mm
Notice:
Secure free space of at
least 15 cm around the
CU for adequate cooling,
and to allow removal
of unit for service.
70mm
82mm
30mm
ISDN wall socket
(option)
Terminal Adapter
144
mm
140
mm
44
mm
www.reelschematic.com
www.reelschematic.com

8
1.4 Communication Unit Connectors
Rear connector panel
ON/OFF
NOT IN USE RFSIM CARD 11-32 VDC / 110W
(50 TERM)
SIM CARD INSIDE
WHEN CHANGING MODEM UNIT
REMOVE COVER
AND TAKE OUT SIM CARD
SIM Card
Do not remove
50 ohm termination
Antenna
Connector
ON/OFF Switch
Battery
Terminals
11-32 VDC/110 W
Front connector panel
RS-422
TX- TX+ RX- RX+
ON
48V DC
SYNC
ALARM
RS-232 A RS-232 B
USB
ISDN
ISDN
ISDN
TX+ TX- RX+ RX-
NMEA- NMEA+
5 4 3 2 1
9 8 7 6
5 4 3 2 1
9 8 7 6
1 8
8 1
RS-232 :
9-pin serial dat a port s for:
• operation and
configuration from PC.
• sof tware download
(RS-232A)
• 9.6 kbp s dat a service
• MPDS
USB :
serial dat a port for:
• operation and
configuration from PC.
• 9.6 kbp s dat a service
• MPDS
ISDN :
Connectors/RJ45
Services:
• 4.8 kbp s speech
• 9.6 kbp
via Terminal
NMEA :
Connection of
NMEA-0183
for external
GPS input
(not required)
RS-422 :
serial port for connection
of dat a equipment with
up to 100 metres cables:
• operation and
• 9.6 kbp s dat a service
• MPDS
INDICATORS:
- Power input ON (green)
- Antenna power (green)
- Satellite signal sync (green)
- Alarm (red)
RS-232C:
9-pin serial data port for:
- Operation and
configuration from PC
- Software download
(RS232A)
- 9.6 kbps data service
- MPDS
- Serial printer
(traffic logging)
USB:
Serial data port for:
- Operation and
configuration from PC
- 9.6 kbps data service
- MPDS
NMEA:
Connection of
NMEA-0183
for external
GPS input
(not required)
RS-422:
Serial data port for
connection of data equip-
ment with up to 100
meter cables:
- Operation and
configuration from PC
- 9.6 kbps data service
- MPDS
ISDN:
Connectors/RJ45
Services:
- 4.8 kbps speech
- 9.6 kbps kbps fax service
via terminal adapter
Hole for
ground
wire
www.reelschematic.com
www.reelschematic.com

9
1.5 Examples of Installation
Fax
PC
Analog Telephone
Remote installations
Antenna Cable
Communication
Unit
ISDN
Handset
7
4
1
3
6
9
DEL
2
5
8
0
DIAL00+INTL
TEL.NO.+
ONSHIFT
Ground
Terminal
Adapter
Terminal
Adapter
www.reelschematic.com
www.reelschematic.com

10
Connection examples
PC PC
RS-422
TX- TX+ RX- RX+
ON
48V DC
SYNC
ALARM
RS-232 A RS-232 B
USB
ISDN
ISDN
ISDN
TX+ TX- RX+ RX-
NMEA- NMEA+
5 4 3 2 1
9 8 7 6
5 4 3 2 1
9 8 7 6
1 8
8 1
ISDN
Handset
s
ISDN
Handset ISDN phone
7
pqrs
4
ghi
1
3
def
6
mno
9
wyz
DEL
2
abc
5
jkl
8
tuv
0
OK
TelenorIOR
Readyforcall
ISDN
7
pqrs
4
ghi
1
3
def
6
mno
9
wyz
DEL
2
abc
5
jkl
8
tuv
0
OK
TelenorIOR
Readyforcall
ISDN
Analog
telephone Analog
telefax (G3)
Serial printer
ISDN
wall
socket Terminal
adapter
www.reelschematic.com
www.reelschematic.com

11
1.6 Placing Units
Placing the communication unit
The communication unit should be placed in a ventilated area. To ensure adequate cooling
for the unit, a 10 cm unobstructed space must be maintained above and below the unit.
A space of 10 cm above the unit is also required to allow removal of units.
Locating the communication unit too close to a compass can affect compass performance.
The compass safe distance is 0.30 meters for both steering and standard compasses.
For grounding, see pages 13 and 18.
Six holes through the unit’s mounting plate allow the unit to be fixed to a bulkhead or a
desktop.
Dia 6.5 mm
77
9.25
145.5
145.5
9.25
166
Placing the ISDN handset
The ISDN handset functions as a display and
communication unit for alert transmission. It may also be
used for normal voice communication. Up to two (2) ISDN
handsets may be connected in series. The units may be
installed anywhere onboard the vessel.
Four separate ISDN ports are available on the
communication unit as RJ45 jacks or screw terminal blocks.
Max cable length: 100 m, 4x0.22 mm2.
FUNC
ALPHA
ENTER
SHIFT
MORE/
HELP
LES
PTT
ESC
7
STU
DATA
ØÁ.
4
JKL
1
ABC
LIST
LIST
3
GHI
6
PQR
9
LIGHT
YZÆ
SPC
ON/OFF
DEL
2
DEF
PLAY
5
MNO
8
VWX
TAX
0
ÄÖÜ
DIAL 00+INTL
TEL.NO.+
ON
SHIFTBAT
ALPHA
www.reelschematic.com
www.reelschematic.com

12
Placing the terminal adapter
The terminal adapter may be installed almost anywhere. However, install it where vibration
is minimal and locate it away from heat sources.
Placing the ISDN handset as a standard telephone
The ISDN handsets may be installed as standard telephones. The units may be installed
anywhere onboard the vessel.
Four separate ISDN ports are available on the communication unit as RJ45 jacks or screw
terminal blocks.
Placing the telefax (option)
A digital telefax (Group 4) can be connected to one of the ISDN outlets, or to an ISDN bus
for transfer at 64 kbps rate.
An analog telefax (Group 3) should be connected to the Terminal Adapter
Placing the PC (user supply)
A PC w/ISDN card can be connected to one of the ISDN outlets, or to an ISDN bus for 64
kbps rate data communication for installation up to 100 m away from the communication
unit.
With the PC connected to the USB/RS-232/RS-422 port it can also be used for control and
configuration of the Communication Unit.
This requires that the vtLite Marine program accessible on the FELCOM CD is installed.
Connection to the USB/RS-232/RS-422 port also allows 64 kbps data transmission. See the
PC’s user’s manual.
Cable lengths:
• ISDN port: See “ISDN telephones/equipment” on page 27.
• USB port: 3 m
• RS-232 ports: 3 m
• RS-422 port: 100 m
www.reelschematic.com
www.reelschematic.com

13
Placing analog telephones (option)
Analog 2-wire telephones can be installed anywhere onboard the
vessel.
The analog telephone DBAR104001/888 (option) should be installed
on a bulkhead.
1.7 Grounding Considerations
A successful installation of a maritime satellite terminal must take into account the noisy
environment in which the equipment shall operate.
Electrical noise
The electrical environment on board a ship is usually quite noisy. Powerful electrical
installations cause voltage variations and transients, as well as low and high frequency
noise. Radio and radar equipment radiate radio frequency signals which frequently
impregnate cables on board with unwanted interference.
Ground plane
Most ships have a steel hull. One should think that the steel construction of the ship would
constitute a good ground plane. This is often not quite true. Rust, other forms of corrosion,
paint and grease, often prevent a good ground connection. A consequence of this is that
high energy power distribution on board a ship can cause significant ground potential
differences.
Antenna unit
Adequate grounding of the antenna unit depends on the fastening bolts making good
contact with the top flange of the mast. This is obtained by removing paint and using
supplied washers and nuts and running a ground wire (local supply) between an antenna
fixing stud on the antenna unit and a ground stud (local supply) bolted to the mast. Coat the
antenna fixing stud and ground stud with silicon sealant. For details, see page 17.
Antenna cable
The antenna coaxial cable normally has a solid or meshed metal screen which must be
terminated to ground both at the antenna pedestal and at the communication unit. The
supplied cable is 25 meters; lengths of 50 m and 140 m are optionally available. If the
ground potential level at the two points differ, the communication unit passing through the
screen of the coaxial cable can be quite strong. The antenna cable screen constitutes a
heavy gauge wire, which is capable of conducting large amounts of current.
Below deck equipment
The communication unit must be provided with a good electrical connection to the ship's
hull for grounding. This is obtained with the supplied ground wire. “Location and grounding
of units” on page 18.
UP
www.reelschematic.com
www.reelschematic.com
