Futech MULTIPOWER 4.6 User manual

USER
MANUAL
400.46 MULTIPOWER 4.6
EN ENGLISH
Manual
in your language?
Check the back cover

2
1
2
3
4
5
6
7 8
9
10
11
12
13
14
OVERVIEW
FRONT
01 Display
02 Relative button
03 RANGE button
04 MODE button
05 Rotary function switch
06 10A input jack
07 µA, mA input jack
08 COM input jack
09 V/Ω/ / /CAP/Hz%/°C/°F input jack
10 Backlight/HOLD button
11 PEAK/Flashlight button
12 MAX/MIN/AVG button
13 Auto backlight sensor
14 Flashlight

3
A
Q
R
S
T
U
V
W
H
G
F
E
D
C
B
I
X
P
Z
Y
J
K
L
M
N
O
DISPLAY
A Auto power off
B milli (10-3)
C Volt (tension)
D micro (10-6)
E Ampere (current)
F nano (10-9)
G Farad (capacitance)
H mega (106)
I kilo (103)
J Ohm (resistance)
K Hertz (frequency)
L Diode test
M Continuity
N Percent (duty ratio)
O Degrees Fahrenheit
P Degrees Celcius
Q Direct current
R Minus sign
S Alternating current
T Low battery
U Autoranging
V Display hold
W Relative
X Peak hold
Y Maximum/Minimum/Average
Z Overload (replaces main visual)

4
SAFETY
Please read the safety instructions provided in
the separate booklet provided with the device.
Risk of electrocution. High voltage circuits, both
AC and DC, are very dangerous and should be
measured with great care.
Turn function switch OFF when meter is not in
use. “OL“ appears when a measurement exceeds
the selected range.
BATTERY
To avoid electric shock, remove test leads from
the meter before removing battery/fuse cover.
This appliance should only be used with the
supplied 4x AAA alkaline batteries or similar AAA
batteries.
FIRST TIME USAGE
Remove all protection foils.
Open the battery compartment and insert the
4x AAA alkaline batteries. Please take care to
respect indicated polarities.
USE
RANGE-BUTTON
The autorange mode automatically selects the
proper range for the measurement being made
and is generally best for most applications.
For measurement situatons requiring that a range
be manually selected, perform the following:
· Press the RANGE-button [03]. The “AUTO”
indicator [U] will no longer be shown on the
display.
· Press the RANGE-button [03] to step through
the available ranges until the desired range is
selected.
· To exit the Manual Ranging mode, press and
hold the RANGE-button [03] until the “AUTO”
indicator [U] reappears.
NOTE
The RANGE-button [03] does not work on
Frequency Duty Cycle, Capacitance or Temper-
ature.

5
MODE-BUTTON
Press the MODE-Button [04] to select AC or DC,
Frequency or Duty Cycle, Resistance, Continuity
or Diode test and °C or °F.
REL-BUTTON
The RELATIVE function zeros out the reading on
the display and stores it as a reference.
Subsequent readings will be displayed as the
relative difference between the actual
measurement and the stored reference value.
· To activate, press the REL-button [02]. The “REL”
indicator [W] will appear on the display along
with the relative reading.
· Press the REL button [02] again to return to
normal operation.
NOTE
The meter does not AUTO-range when the
relative mode is active. The display will show
“OL”(Overload) [Z]ifthedifrenceexceedsthe
range. REL does not work on frequency, Duty
Cycle, Temperature or Low Z.
MAX/MIN/AVG-BUTTON
Press the MAX/MIN/AVG-button [12] to activate
the MAX/MIN mode. The “MAX” [Y] indicator will
appear on the LCD display. The meter will display
and hold the maximum reading and will update
when a higher “MAX” occurs.
· Press the MAX/MIN/AVG-button [12] again to
view the lowest reading. The “MIN” [Y] will ap-
pear on the LCD display. The meter will display
and hold the minimum reading and will update
when a lower “MIN” occurs.
· Press the MAX/MIN/AVG-button [12] again to
view the average reading. The “AVG“ [Y] symbol
will appear on the LCD display. The meter will
display the running average and will update

6
when the average value changes.
· Press and hold the MAX/MIN/AVG-button [12]
to end MAX/MIN/AVG and return to normal
operations.
NOTE
MAX/MIN does not work on Frequency, Duty
Cycle, Capacitance or Temperature.
BACKLIGHT/HOLD-BUTTON
To freeze the reading on the LCD display, press
the HOLD-button [10]. The “HOLD” indicator [V]
will be displayed while the reading is being held.
Press the HOLD-button [10] again to exit HOLD
and return to normal operation.
· To turn the backlight in the display on, press
and hold the HOLD button until the backlight
turns on. To turn the backlight off, press and
hold the HOLD buttton until the backlight turns
off.
AUTO BACKLIGHT
When the meter is in the darkness, the backlight
can be automatically opened, not controlled by
the button.
FLASHLIGHT/PEAK-BUTTON
Press the PEAK-button [11]toturntheashlight
on or off. The PEAK function is accessible when
measuring AC voltage or Current. It captures and
displays the highest positive peak and the high-
est negative peak of the AC waveform.
· Press and hold the PEAK-button [11] untill “Peak
MAX” [X] appears on the display. The meter
will display the highest reading and will update
the reading when a higher positive peak occurs.
· To view highest negative peak, press and hold
the PEAK-button [11] until “Peak MIN” [X]
apears on the display. The meter will display
and hold the largest negative reading. The
meter will update the reading when a larger
negative peak occurs.
· Press the PEAK-button [11] for approximately
one second to switch between Peak MAX and
Peak MIN readings.

7
· Press and hold the PEAK-button [11] to exit
PEAK and return to normal operation.
NOTE
The meter does not Autorange when the Peak
mode is active. The display will read “OL” (over-
load) [Z] if the range is exceeded. When this
occurs, exit Peak and use the RANGE-button [3]
to select a higher range. Peak does not work on
DCV, DCA, Frequency, Duty Cycle, Capacitan-
ceor Low Z.
AC/DV VOLTAGE MEASUREMENT
—
V
+
Hz
%
NOTE
Observe all safety precautions when working
on live voltages!
· Set the rotary function switch [05] to the V
~Hz% position.
· Press the MODE-button [04] to select AC or DC
voltage. The AC “~” [S] or DC “ ” [Q] symbol
will appear on the display.
· Insert the black test lead into the COM input
jack [08] and the red test lead into the V input
jack [09].
· Touch the test lead probes to the circuit under
test. If measuring DC voltage, touch the red
test lead to the positive side of the circuit and
the black test lead to the negative side of the
circuit.
· Read the voltage on the display.

8
FREQUENCY AND % DUTY CYCLE
MEASUREMENTS
—
V
+
Hz
%
NOTE
Observe all safety precautions when working
on live voltages!
· Set the rotary function switch [05] to the V
~Hz% position.
· To select Frequency, press and hold the
MODE-button [04] until the “Hz” symbol [K]
appears on the display. To select % Duty Cycle,
press and hold the MODE-button [04] again
until the “%” [N] appears on the display.
· Insert the black test lead into the COM input
jack [08] and the red test lead into the V input
jack [09].
· Touch the test lead probes to the circuit under
test.
· Read the frequency or % duty cycle on the
display.
· To return to AC voltage, press and hold the
MODE-button [04] again until the “~” symbol
[S] appears on the display.
NOTE
The Frequency function can only be accessed
when the meter is set to AC voltage.
LOW Z VOLTAGE
— +

9
NOTE
Observe all safety precautions when working
on live voltages!
Do not connect to circuits that exceed 600V
AC/DC when the meter is set to Low Z!
Low Z is used when there is a suspicion of a
“ghost” voltage. Ghost voltages are present when
non-powered wires are in close proximity to wires
powered by AC voltages. Capacitive coupling
between wires make it appear that non-powered
wires are connected to a real source of voltage.
The low Z setting places a load on the circuit,
which dissipates and greatly reduces ghost
voltage.
· Set the rotary function switch [05] to the Low Z
position.
· Press the MODE-button [04] to select AC or DC
voltage. The AC “~” [S] or DC “ ” [Q] symbol
will appear on the display.
· Insert the black test lead into the COM input
jack [08] and the red test lead into the V input
jack [09]. If measuring DC voltage, touch the
red test lead to the positive side of the circuit
and the black test lead to the negative side of
the circuit.
· Read the voltage on the display.
AC/DC CURRENT MEASUREMENTS
—
A
+
—
A
+
MAX. 600mA
MAX. 10A

10
NOTE
Observe all safety precautions when working
on live circuits.
Do not measure current on circuits that exceed
1000V. Measurements in the 10A range should
be limited to 30 seconds maximum every 15
minutes.
· Insert the black test lead into the negative COM
input jack [08]
· For current measurements up to 600mA, set the
rotary function switch [05] to the mA position
and insert the red test lead into the µA/mA
input jack [07].
· For current measurements up to 6000µA, set
the rotary function switch [05] to the µA posi-
tion and insert the red test lead into the µA/mA
input jack [07].
· For current measurements up to 10A, set the
rotary fucntion switch [05] to the 10A position
and insert the red test lead into the 10A input
jack [06].
· Press the MODE-button [04] to select AC or DC
current. The AC “~” [S] or DC “ ” [Q] symbol will
appear on the display.
· Remove power from the circuit under test, then
open up the circuit at the point where you wish
to measure current.
· Touch the test lead probes in series with the
circuit being measured. For DC current, touch
the red probe to the positive side of the circuit
and touch the black probe to the negative side
of the circuit.
· Apply power to the circuit.
· Read the current on the display.
RESISTANCE MEASUREMENT
— +
NOTE
Never test resistance on a live circuit.

11
· Set the rotary function switch [05]totheΩ/
position.
· Press the MODE-button [04]untilthe“Ω”sym-
bol [J] appears on the display.
· Insert the black test lead into the COM input
jack [08]andtheredtestleadintotheΩinput
jack [09].
· Touch the test lead probes to the component
under test. If the component is installed in a
circuit, it is best to disconnect one side before
testing to eliminatie interferences with other
devices.
· Read the resistance on the display.
CONTINUITY TEST
— +
NOTE
Never test continuity on a live circuit.
· Set the rotary function switch [05]totheΩ/
position.
· Press the MODE-button [04 ]until the “ ” symbol
[M] appears on the display.
· Insert the black test lead into the COM input
jack [08]andtheredtestleadintotheΩinput
jack [09].
· Touch the test lead probes to the component
under test
· A beeper will sound if the resistance is approxi-
mately50Ωorlessandtheresistancevaluewill
be shown on the display.

12
DIODE TEST
— +
NOTE
Never test diodes on a live circuit.
· Set the rotary function switch [05] to the
position.
· Press the MODE-button [04 ]until the “ ” symbol
[M] appears on the display.
· Insert the black test lead into the COM input
jack [08] and the red test lead into the input
jack [09].
· Touch the test lead probes to the diodes under
test
· Forward voltage will indicate 0.4 to 0.7 on
the display. Reverse voltage will indicate “OL”
(overload) [Z]. Shorted devices will indicate
near 0 and an open device will indicate “OL” in
both polarities.
CAPACITANCE MEASUREMENTS
—
F
+
—+
NOTE
Safely discharge capacitors before taking
capacitance measurements.
· Set the rotary function switch [05] to the CAP
position.
· Insert the black test lead into the COM input
jack [08] and the red test lead into

13
the CAP input jack [09].
· Touch the test lead probes to the capacitor
under test
· Read the capacitance value on the display. It
may take up to a minute to get a stable reading
on large capacitors.
TEMPERATURE MEASUREMENTS
°C
°F
NOTE
Never touch the temperature probe to a live
circuit.
· Set the rotary function switch [05] to the °F/°C
position.
· Press the MODE-button [04] to select readings
in °C or °F
· Connect the Temperature Probe to the banana
Plug adapter. Note the - and + markings on
the adapter. Connect the adapter to the meter,
making sure the - side goes into the COM input
jack [08] and the + side goes into the °C °F
input jack [09].
· Touch the tip of the Temperature probe to the
object being measured. Hold the probe touch-
ing the object until the reading stabilizes (about
30 seconds).
· Read the temperature on the display.
BATTERY REPLACEMENT

14
NOTE
To avoid electric shock, remove the test leads
from the meter before removing the battery/
fuse cover.
· Lift up the stand on the back of the device.
· Loosen the screws on the battery/fuse cover.
· Remove battery/fuse cover
· Replace the batteries with four AAA batteries.
· Observe polarity as shown inside battery com-
partment
· Reinstall the battery/fuse cover and tighten the
screws.
NOTE
To avoid electric shock, do not operate the
meter untill the battery/fuse cover is securely
fastened to the meter.
FUSE REPLACEMENT
NOTE
To avoid electric shock, remove the test leads
from the meter before removing the battery/
fuse cover.
· Loosen the screws on the batter/fuse cover.
· Remove the battery/fuse cover
· Gently remove fuse and install new fuse into the
holder.
· Always use a UL recognized fuse of the proper
size and value: 800mA/1000V (6.3 x 32mm)
fast blow for the µA/mA ranges and 10A/1000V
(10x38mm) fast blow for the 10A range.
· Reinstall the back cover and tighten the screws.
NOTE
To avoid electric shock, do not operate the
meter untill the battery/fuse cover is securely
fastened to the meter.
SAFETY CATEGORY RATINGS
Per iec1010 overvoltage installation category
Overvoltage category I
Equipment of overvoltage category I is equipment for connection
to circuits in which measures are taken to limit the transient over-
voltages to an appropriate low level.
Note: Examples include protected electronic circuits.
Overvoltage category II
Equipment of overvoltage category II is energy-consuming equip-
menttobesuppliedfromthexesinstallation.
Note:Examplesincludehousehold,ofce,andlaboratory
appliances.

15
Overvoltage category III
EquipmentofOvervoltagecategoryIIIisequipmentinxed
installations.
Note:Examplesincludeswitchesinthexedinstallationand
some equipment for industrial use with permanent connection to
thexedinstallation.
Overvoltage category IV
Equipment of overvoltage category IV is for use at the origin of
the installation.
Note: Examples include electricity meters and primary over-cur-
rent protection equipment.
INPUT LIMITATIONS
Voltage AC or DC 1000V AC RMS/1000V DC
Low Z 600V AC RMS/600V DC
µA, mA current
or AC/DC
800mA 1000V fast acting fuse
10A Current AC or DC
10A 1000V fast acting fuse
(10A for 30 seconds max. every 15
minutes)
Resistance,
Continuity,
Diode Test,
Capacitance,
Frequency,
Duty Cycle
600V AC RMS/600V DC
Temperature 600V AC RMS/600V DC
DECLARATION OF CONFORMITY
Futech (Belgium) declares under its own responsibility that
this device:
- 400.46 Multipower 4.6
is in conformity with the standards
EN 61326-1:2013
EN 61326-2-2:2013
following the provisions of Directive(s)
Electromagnetic Compatibility Directive 2014/30/EU
Lier, Belgium,
March 30, 2023
Patrick Waûters
Potential misprints are reserved. Images used are not strict. All features,
functionalityandotherproductspecicationsaresubjecttochangewithout
notice or obligation.

@futechtools
Facebook
@futechtools
futechtools
LinkedIn
YouTube
futech-tools.com
World Wide Web
230420132604
DA DANSK
DE DEUTSCH
ES ESPAÑOL
ET EESTI KEEL
FI SUOMEN KIELI
FR FRANÇAIS
IS ÍSLENSKA
IT ITALIANO
NL NEDERLANDS
NO NORSK
PT PORTUGUÊS
SL SLOVENŠČINA
SV SVENSKA
USER MANUAL
other languages:
