SAFETY AND
INSTALLATION
MANUAL
Photovoltaic Modules:
FU XXX M / MV / P / PV
FU XXX M / MV NEXT
FU XXX M / MV NEXT PRO

2
FuturaSun srl – The specifications in this manual are subject to revisions without further notice
This document applies to modules FU XXX M / MV / P / PV / M / MV NEXT / M / MV NEXT PRO
Contents
1. General Information 3
2. Disclaimer of Liability 4
3. IEC 61215 & 61730 certifications 4
4. Limited Warranty 4
5. Module Specification 4
6. Safety Precautions 4
7. Installation 5
8. Use and Maintenance 12
9. Packaging, Handling and Storage of Modules 14

3
FuturaSun srl – The specifications in this manual are subject to revisions without further notice
This document applies to modules FU XXX M / MV / P / PV / M / MV NEXT / M / MV NEXT PRO
1. General Information
The photovoltaic (PV) modules FU XXX M /
MV / P / PV / NEXT / NEXT PRO, (hereafter
“FU XXX” or “FU”) are devices that produce
electrical energy by converting the sunlight’s
radiation reaching their surface, when
appropriately exposed, into continuous/direct
current (DC).
The FU modules are intended to be used in
photovoltaic module systems connected to the
electrical grid. It is also possible to use them in
battery powered photovoltaic module systems
(stand alone).
The rated currents at Standard Test
Conditions (STC) of the FU modules are
variable depending on the model and the
relative power rating, as indicated in the
respective technical data sheets. Most of the
electrical parameters of the modules, specified
in the datasheets, are determinable only by
using special instrumentation in the laboratory;
therefore, only some of them are measurable
outside of a lab, using common
instrumentation (voltmeter, AM meter,
solarimeter/pyranometer).
It is possible, following very precise
procedures, to carry out electrical
measurements of voltage and current as
snapshots, which enable you to monitor the
operation of the modules and determine
possible, although rare, anomalies.
The electrical output parameters for FU
modules, of technical importance during the
operation, installation and maintenance, are
the following:
• Voltage at open circuit (Voc) with
tolerance of ± 4%
• Current at short circuit (Isc) with
tolerance of ± 5%
• Voltage at point of maximum power
(Vmpp)
• Current at point of maximum power
(Impp)
• Power (Pmax) with tolerance of ± 3%
• Solar radiation in W/m2 at the time
• Temperature of the modules
The general performance of the modules is
heavily dependent on the intensity of the
incident solar radiation, as illustrated in Fig.1.
Acheiving maximum performance requires
proper installation, with the modules oriented
towards the South in Northern hemisphere
and their surface exposed as perpendicularly
possible to the incident rays of the sun;
furthermore, avoiding any shading caused by
obstacles in and around the area of
installation.
Fig. 1: IV curve at different irradiance
A high ambient temperature and therefore, an
increased operational temperature of the
modules, also contribute to a proportional
reduction in electrical performance. Please
see fig. 2
Fig. 2: IV curve at different temperatures
In order to optimize the production of electrical
energy of the modules, and therefore of the

4
FuturaSun srl – The specifications in this manual are subject to revisions without further notice
This document applies to modules FU XXX M / MV / P / PV / M / MV NEXT / M / MV NEXT PRO
system connected to an electrical grid, it is the
responsibility of the installer to make sure the
modules are positioned as much as possible
facing south in northern hemisphere, with the
tilt angle (β) (inclination of the surface of the
modules in respect to the ground, as shown in
Fig.3) optimal for the type of desired
application.
The tilt angle of ideal average throughout Italy
is β = 30°; however, even the inclination typical
the roof of a dwelling (β = 15-20°), being
already an inclined plane, could make the
angle acceptable, if not ideal, for the
installation of coplanar modules on it (using a
special standard structure for support).
Depending on the variation of the tilt angle of
the modules with respect to the ground, or of
their orientation in relation to facing south
(Azimuth), there will be changes in the annual
average amount of energy produced by the
modules themselves, and therefore, of the
plant connected to the network to which they
are linked.
Fig. 3: Orientation Vs. Azimuth
