Futurecom VR Operating instructions

Futurecom Systems Group, ULC
VR Programming Guide
Document: 8G093X01
Revision: R5
Date: August 2022

8G093X01 R5
VR Programming Guide
August 2022 Page 2 of 144
NOTES

8G093X01 R5
VR Programming Guide
August 2022 Page 3 of 144
Contents
Contents........................................................................................................................3
Manual Revisions..........................................................................................................7
Foreword .......................................................................................................................8
Computer Software Copyrights ...................................................................................9
Publicly Available Software List.................................................................................10
Publicly Available Software –Common Licenses......................................................11
CodeGuru License....................................................................................................14
Document Copyrights................................................................................................14
Disclaimer.................................................................................................................14
Trademarks...............................................................................................................14
Commercial Warranty................................................................................................14
Declaration of Conformity ......................................................................................15
Important Safety Information .................................................................................15
Notice to Users (FCC/ISED)....................................................................................15
Déclaration de Conformité......................................................................................16
Informations de Sécurité Importantes...................................................................16
Avis Aux Utilisateurs (FCC / ISED).........................................................................16
VR Programming Basics ............................................................................................17
Key Terminology.......................................................................................................17
Installing Futurecom Repeater Configurator (FRC) ...................................................17
Previous Installation ..............................................................................................................17
New Installation.....................................................................................................................17
Menu Bar ..................................................................................................................18
Compatibility Charts ..............................................................................................................19
Setting Up Communications with the VR...................................................................20
Reading from the VR (Uploading Data).....................................................................20
Writing to the VR (Downloading Data).......................................................................20
Understanding FRC Programming Files....................................................................20
Codeplug Applications...........................................................................................................21
Data Categories.....................................................................................................................21
Codeplug Content..................................................................................................................21
Codeplug Encryption.............................................................................................................21
Codeplug Summary...............................................................................................................22

8G093X01 R5
VR Programming Guide
August 2022 Page 4 of 144
FRC Icons.................................................................................................................22
How To Create an EPR File......................................................................................23
How To Create a DPD File........................................................................................24
Creation of New File..............................................................................................................24
Modify an Existing File ..........................................................................................................24
How To Create a DCD File........................................................................................27
Creation of New File..............................................................................................................27
Modify an Existing File ..........................................................................................................27
Feature Licenses.......................................................................................................30
Introduction............................................................................................................................30
License Delivery....................................................................................................................30
Applying License to Repeater via FRC .................................................................................30
Bundling a License File with a DCD File...............................................................................33
Applying License to Template Files.......................................................................................34
How To Clone a VR ..................................................................................................35
Steps for Cloning...................................................................................................................35
Using FRC Off-Line...................................................................................................37
Viewing Codeplugs Off-Line..................................................................................................37
Modifying Codeplugs Off-Line...............................................................................................37
Saving Codeplugs Off-Line ...................................................................................................37
Applying Firmware to VR...........................................................................................38
Upgrading Firmware..................................................................................................41
Downgrading Firmware.............................................................................................42
VR Programming Guidelines......................................................................................44
Programming Steps Overview...................................................................................44
The DVRS operation depends on the following: ...................................................................44
Additional CPS Programming for VR.........................................................................45
VR BASIC PROGRAMMING.....................................................................................45
VR FEATURE PROGRAMMING...............................................................................46
VR FINE TUNING.....................................................................................................48
P25 Trunking OTAR via VR ......................................................................................48
MSU Scan Programming Requirements....................................................................48
MSU Group Services Programming Requirements ..............................................................48
Exporting MSU data (.xml file)...............................................................................................49
Programming the PSUs for DVRS Operation............................................................50
Programming the P25 ‘DVRS Enabled’ PSU.............................................................50
XTS Series ‘DVRS Enabled’ PSUs ...........................................................................50
APX Series ‘DVRS Enabled’ PSUs ...........................................................................51
Programming of Generic P25 PSU for Digital VR Mode............................................51
Programming of the P25 PSU (Generic P25 or ‘DVRS Enabled’) for operation on
Conventional P25 MSU System................................................................................51

8G093X01 R5
VR Programming Guide
August 2022 Page 5 of 144
Programming of the P25 XTS PSU (Generic P25 or ‘DVRS Enabled’) for Inbound Digital
Takeover...................................................................................................................52
Programming of Analog Conventional PSU for Analog VR Mode..............................52
Feature Programming ...............................................................................................53
How to Program GPS Driven Deactivation Feature..............................................................53
How to Program NAC Linking Feature..................................................................................55
How to Program TPS Signaling.............................................................................................56
How to Program Talkgroup Matching....................................................................................57
How to Program Talkgroup Proxying ....................................................................................58
How to Program Talkgroup Translation.................................................................................59
How to Program Unit ID Translation......................................................................................62
FRC Window and Field Definitions............................................................................63
Documentation Conventions .....................................................................................63
Options .....................................................................................................................65
Ports ......................................................................................................................................65
Repeater Setup.........................................................................................................66
RF / Analog Setup.................................................................................................................66
Frequency Band Setup..........................................................................................................66
User Info................................................................................................................................66
Hardware / Software Info.......................................................................................................69
Update Info............................................................................................................................69
Personality Data........................................................................................................71
Repeater Channel Setup Window.........................................................................................71
Mode Change........................................................................................................................77
Mode Change of VR by Local PSU ......................................................................................77
Remote Mode change of VR by Dispatcher / System PSU ..................................................78
Mobile Radio Channel Setup.................................................................................................79
Hardware Setup Window...........................................................................................87
MSU Data..............................................................................................................................92
PSU IDs Allowed...................................................................................................................93
VR Remote Activation IDs.....................................................................................................93
PSU NAC Table.....................................................................................................................93
Analog Setup ............................................................................................................94
VR Common Setup...................................................................................................98
MSU Interface Setup...............................................................................................104
Emergency Setup....................................................................................................105
Tone Setup..........................................................................................................................109
Station ID Setup ..................................................................................................................109
Digital Setup............................................................................................................109
Primary / Secondary Setup .....................................................................................115
VRS-EP Options..................................................................................................................116
VRS-EP Tables ...................................................................................................................120
Maintenance Screens ...............................................................................................121
Using the Monitoring Screen...................................................................................121
BER Test Setup...................................................................................................................123

8G093X01 R5
VR Programming Guide
August 2022 Page 6 of 144
RSSI Setup.............................................................................................................124
Setting up the RSSI ON range ............................................................................................128
Setting up the Voting Parameters (Primary / Secondary Range) ......................................129
Troubleshooting........................................................................................................130
Software / Programming Related Problems.............................................................130
Multiple issues when using DVRS with TDMA* .......................................................133
Appendix 1 –VR Status Display ..............................................................................134
Appendix 2 –Grant Timeout Timer..........................................................................135
Appendix 3 –Icon Legend........................................................................................136
Appendix 4 –CPS VR Related Programming..........................................................137
Glossary ....................................................................................................................140
Reference ..................................................................................................................143
Contact Information.......................................................................................................i

8G093X01 R5
VR Programming Guide
August 2022 Page 7 of 144
Manual Revisions
Rev #
Date
Notes & References
0
October 2020
Original Release
1
February 2021
Update for SR2021.1
2
July 2021
Update for SR2021.2
3
August 2021
Update for SR2021.3
4
November 2021
Update for SR2021.4
5
August 2022
Update for SR2022.2

8G093X01 R5
VR Programming Guide
August 2022 Page 8 of 144
Foreword
Futurecom Vehicular Repeater (VR) is designed to be seamlessly interfaced to:
Remote Mount APX Series Mobile Subscriber Unit (MSU) with or without control head
When the VR is interfaced to a Remote Mount Motorola APX Mobile Radio, the complete
equipment package is referred to as Digital Vehicular Repeater System (DVRS).
For compatibility requirements for Mobile and Portable radios refer to Futurecom website →
Support → Documentation and Software → DVR-LX/DVR/VRX1000 → Compatibility Charts
For details on the APX series Mobile or Portable Radios operation, please refer to the applicable
Manuals available from Motorola.
For details on how to operate a VR, please refer to the Vehicular Repeater (VR) User’s Guide
Template available on Futurecom website → Support → Documentation and Software → DVR-
LX/DVR/VRX1000
Futurecom Repeater Configurator (FRC) contains three main components to service all
hardware programming needs
1. Configurator for APX Repeaters (VRX1000, DVR and DVR-LX®)
2. Configurator for PDR8000®
3. Flash Downloader Utility
This is used to update the firmware of the repeater. In the past the user had to download
it separately from the Futurecom website, integrating into FRC makes it more of an all-
in-one utility and adds a layer of convenience
FRC is backwards compatible with all VR firmware versions. It supports reading all previously
configured devices. It is continually updated with business rules to ensure integrity of VR
configuration.

8G093X01 R5
VR Programming Guide
August 2022 Page 9 of 144
Computer Software Copyrights
The products described in this manual include copyrighted Futurecom computer programs
stored in semiconductor memories or other media. Laws in the United States, Canada and other
countries preserve for Futurecom certain exclusive rights for copyrighted computer programs,
including but not limited to, the exclusive right to copy or reproduce in any form the copyrighted
computer programs. Any copyrighted computer program contained in the Futurecom products
described in this manual may not be copied, reproduced, modified, reverse-engineered, or
distributed in any manner without the express written permission of Futurecom. The purchase of
Futurecom products shall not be deemed to grant either directly or by implication, estoppels, or
otherwise, any license under the copyrights, patents, or patent applications of Futurecom,
except for the normal non-exclusive license to use that arises by operation of law in the sale of a
product.

8G093X01 R5
VR Programming Guide
August 2022 Page 10 of 144
The Futurecom Repeater Configurator provided by Futurecom Systems Group ULC includes the
following Publicly Available Software.
Publicly Available Software List
Name: MFC Grid Control
Version: 2.24
Modified: Yes
Software Site: http://www.codeproject.com/KB/miscctrl/gridctrl.aspx
Source Code: No Source Code Distribution Obligations. The Source Code may be obtained from the original Software
Site.
License: The Article associated with the Source Code is licensed under the Code Project Open License (CPOL),
version 1.02. Reference the Common Licenses Section for the terms of the CPOL. The Source Code licensed is under
Custom Freeware / Open Source Software License, see below:
Written by Chris Maunder <[email protected]>
Copyright (c) 1998-2002. All Rights Reserved.
This code may be used in compiled form in any way you desire. This file may be redistributed unmodified by any means
PROVIDING it is not sold for profit without the authors written consent, and providing that this notice and the authors
name and all copyright notices remains intact.
An email letting me know how you are using it would be nice as well.
This file is provided "as is" with no expressed or implied warranty.
The author accepts no liability for any damage / loss of business that this product may cause.
Additional Notices:
CInPlaceEdit, http://www.codeguru.com/listview/edit_subitems.shtml, licensed under the CodeGuru License.
Refer to the Common Licenses Section for the terms of the CodeGuru License.
Credits:
Zafir Anjum
Eric Woodruff
Ken Bertelson
Joe Willcoxson

8G093X01 R5
VR Programming Guide
August 2022 Page 11 of 144
Publicly Available Software –Common Licenses
The Code Project Open License (CPOL) 1.02
Preamble
This License governs Your use of the Work. This License is intended to allow developers to use the Source Code and
Executable Files provided as part of the Work in any application in any form.
The main points subject to the terms of the License are:
•Source Code and Executable Files can be used in commercial applications.
•Source Code and Executable Files can be redistributed; and
•Source Code can be modified to create derivative works.
•No claim of suitability, guarantee, or any warranty whatsoever is provided. The software is provided "as-is".
•The Article accompanying the Work may not be distributed or republished without the Author's consent
This License is entered between You, the individual or other entity reading or otherwise making use of the Worklicensed
pursuant to this License and the individual or other entity which offers the Work under the terms of this License
("Author").
License
THE WORK (AS DEFINED BELOW) IS PROVIDED UNDER THE TERMS OF THIS CODEPROJECT OPEN LICENSE
("LICENSE"). THE WORK IS PROTECTED BY COPYRIGHT AND/OR OTHER APPLICABLE LAW. ANY USE OF THE
WORK OTHER THAN AS AUTHORIZED UNDER THIS LICENSE OR COPYRIGHT LAW IS PROHIBITED.
BY EXERCISING ANY RIGHTS TO THE WORK PROVIDED HEREIN, YOU ACCEPT AND AGREE TO BE BOUND
BY THE TERMS OF THIS LICENSE. THE AUTHOR GRANTS YOU THE RIGHTS CONTAINED HEREIN IN
CONSIDERATION OF YOUR ACCEPTANCE OF SUCH TERMS AND CONDITIONS. IF YOU DO NOT AGREE TO
ACCEPT AND BE BOUND BY THE TERMS OF THIS LICENSE, YOU CANNOT MAKE ANY USE OF THE WORK.
1. Definitions.
a. "Articles" means, collectively, all articles written by Author which describes how the Source Code and
Executable Files for the Work may be used by a user.
b. "Author" means the individual or entity that offers the Work under the terms of this License.
c. "Derivative Work" means a work based upon the Work or upon the Work and other pre-existing
works.
d. "Executable Files" refer to the executable files, binary files, configuration, and any required data files
included in the Work.
e. "Publisher" means the provider of the website, magazine, CD-ROM, DVD or other medium from or
by which the Work is obtained by You.
f. "Source Code" refers to the collection of source code and configuration files used to create the
Executable Files.
g. "Standard Version" refers to such a Work if it has not been modified or has been modified in
accordance with the consent of the Author, such consent being in the full discretion of the Author.
h. "Work" refers to the collection of files distributed by the Publisher, including the Source Code,
Executable Files, binaries, data files, documentation, whitepapers and the Articles.
i. "You" is you, an individual or entity wishing to use the Work and exercise your rights under this
License.
2. Fair Use / Fair Use Rights. Nothing in this License is intended to reduce, limit, or restrict any rights arising
from fair use, fair dealing, first sale or other limitations on the exclusive rights of the copyright owner under
copyright law or other applicable laws.
3. License Grant. Subject to the terms and conditions of this License, the Author hereby grants You a worldwide,
royalty-free, non-exclusive, perpetual (for the duration of the applicable copyright) license toexercise the rights
in the Work as stated below:
a. You may use the standard version of the Source Code or Executable Files in Your own applications.

8G093X01 R5
VR Programming Guide
August 2022 Page 12 of 144
b. You may apply bug fixes, portability fixes and other modifications obtained from the Public Domain
or from the Author. A Work modified in such a way shall still be considered the standard version and
will be subject to this License.
c. You may otherwise modify Your copy of this Work (excluding the Articles) in any way to create a
Derivative Work, provided that You insert a prominent notice in each changed file stating how, when
and where You changed that file.
d. You may distribute the standard version of the Executable Files and Source Code or Derivative Work
in aggregate with other (possibly commercial) programs as part of a larger (possibly commercial)
software distribution.
e. The Articles discussing the Work published in any form by the author may not be distributed or
republished without the Author's consent. The author retains copyright to any such Articles. You may
use the Executable Files and Source Code pursuant to this License, but you may not repost or
republish or otherwise distribute or make available the Articles, without the prior written consent of
the Author.
Any subroutines or modules supplied by You and linked into the Source Code or Executable Files of this Work
shall not be considered part of this Work and will not be subject to the terms of this License.
4. Patent License. Subject to the terms and conditions of this License, each Author hereby grants to You a
perpetual, worldwide, non-exclusive, no-charge, royalty-free, irrevocable (except as stated in this section)
patent license to make, have made, use, import, and otherwise transfer the Work.
5. Restrictions. The license granted in Section 3 above is expressly made subject to and limited by the following
restrictions:
a. You agree not to remove any of the original copyright, patent, trademark, and attribution notices and
associated disclaimers that may appear in the Source Code or Executable Files.
b. You agree not to advertise or in any way imply that this Work is a product of Your own.
c. The name of the Author may not be used to endorse or promote products derived from the Work
without the prior written consent of the Author.
d. You agree not to sell, lease, or rent any part of the Work. This does not restrict you from including
the Work or any part of the Work inside a larger software distribution that itself is being sold. The
Work by itself, though, cannot be sold, leased or rented.
e. You may distribute the Executable Files and Source Code only under the terms of this License, and
You must include a copy of, or the Uniform Resource Identifier for, this License with every copy of
the Executable Files or Source Code You distribute and ensure that anyone receiving such
Executable Files and Source Code agrees that the terms of this License apply to such Executable
Files and/or Source Code. You may not offer or impose any terms on the Work that alter or restrict
the terms of this License or the recipients' exercise of the rights granted hereunder. You may not
sublicense the Work. You must keep intact all notices that refer to this License and to the disclaimer
of warranties. You may not distribute the Executable Files or Source Code with any technological
measures that control access or use of the Work in a manner inconsistent with the terms of this
License.
f. You agree not to use the Work for illegal, immoral or improper purposes, or on pages containing
illegal, immoral or improper material. The Work is subject to applicable export laws. You agree to
comply with all such laws and regulations that may apply to the Work after Your receipt of the Work.
6. Representations, Warranties and Disclaimer. THIS WORK IS PROVIDED "AS IS", "WHERE IS" AND "AS
AVAILABLE", WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS OR
GUARANTEES. YOU, THE USER, ASSUME ALL RISK IN ITS USE, INCLUDING COPYRIGHT
INFRINGEMENT, PATENT INFRINGEMENT, SUITABILITY, ETC. AUTHOR EXPRESSLY DISCLAIMS ALL
EXPRESS, IMPLIED OR STATUTORY WARRANTIES OR CONDITIONS, INCLUDING WITHOUT
LIMITATION, WARRANTIES OR CONDITIONS OF MERCHANTABILITY, MERCHANTABLE QUALITY OR
FITNESS FOR A PARTICULAR PURPOSE, OR ANY WARRANTY OF TITLE OR NON-INFRINGEMENT,
OR THAT THE WORK (OR ANY PORTION THEREOF) IS CORRECT, USEFUL, BUG-FREE OR FREE OF
VIRUSES. YOU MUST PASS THIS DISCLAIMER ON WHENEVER YOU DISTRIBUTE THE WORK OR
DERIVATIVE WORKS.
7. Indemnity. You agree to defend, indemnify and hold harmless the Author and the Publisher from and against
any claims, suits, losses, damages, liabilities, costs, and expenses (including reasonable legal or attorneys’
fees) resulting from or relating to any use of the Work by You.
8. Limitation on Liability. EXCEPT TO THE EXTENT REQUIRED BY APPLICABLELAW, IN NO EVENT WILL
THE AUTHOR OR THE PUBLISHER BE LIABLE TO YOU ON ANY LEGAL THEORY FOR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR EXEMPLARY DAMAGES ARISING OUT OF THIS

8G093X01 R5
VR Programming Guide
August 2022 Page 13 of 144
LICENSE OR THE USE OF THE WORK OR OTHERWISE, EVEN IF THE AUTHOR OR THE PUBLISHER
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
9. Termination.
a. This License and the rights granted hereunder will terminate automatically upon any breach by You
of any term of this License. Individuals or entities who have received Derivative Works from You
under this License, however, will not have their licenses terminated provided such individuals or
entities remain in full compliance with those licenses. Sections 1, 2, 6, 7, 8, 9, 10 and 11 will survive
any termination of this License.
b. If You bring a copyright, trademark, patent or any other infringement claim against any contributor
over infringements You claim are made by the Work, your License from such contributor to the Work
ends automatically.
c. Subject to the above terms and conditions, this License is perpetual (for the duration of the applicable
copyright in the Work). Notwithstanding the above, the Author reserves the right to release the Work
under different license terms or to stop distributing the Work at any time; provided, however that any
such election will not serve to withdraw this License (or any other license that has been, or is required
to be, granted under the terms of this License), and this License will continue in full force and effect
unless terminated as stated above.
10. Publisher. The parties hereby confirm that the Publisher shall not, under any circumstances, be responsible
for and shall not have any liability in respect of the subject matter of this License. The Publisher makes no
warranty whatsoever in connection with the Work and shall not be liable to You or any party on any legal
theory for any damages whatsoever, including without limitation any general, special, incidental or
consequential damages arising in connection to this license. The Publisher reserves the right to cease making
the Work available to You at any time without notice
11. Miscellaneous
a. This License shall be governed by the laws of the location of the head office of the Author or if the
Author is an individual, the laws of location of the principal place of residence of the Author.
b. If any provision of this License is invalid or unenforceable under applicable law, it shall not affect the
validity or enforceability of the remainder of the terms of this License, and without further action by
the parties to this License, such provision shall be reformed to the minimum extent necessary to
make such provision valid and enforceable.
c. No term or provision of this License shall be deemed waived and no breach consented to unless
such waiver or consent shall be in writing and signed by the party to be charged with such waiver or
consent.
d. This License constitutes the entire agreement between the parties with respect to the Work licensed
herein. There are no understandings, agreements or representations with respect to the Work not
specified herein. The Author shall not be bound by any additional provisions that may appear in any
communication from You. This License may not be modified without the mutual written agreement of
the Author and You.

8G093X01 R5
VR Programming Guide
August 2022 Page 14 of 144
CodeGuru License
http://www.codeguru.com/submission-guidelines.php#permission
As you know, this site is a valuable resource for the developer community. Please note, however, that to
avoid legal complications, we need to obtain your permission to use any computer code and any related
materials ("resources") that you are providing to us. Accordingly, by submitting any such resource to
CodeGuru, you grant to QuinStreet a nonexclusive, worldwide, perpetual license to reproduce, distribute,
adapt, perform, display, and sublicense the submitted resource (in both object and source code formats,
as well as on and off the Web), and you acknowledge that you have the authority to grant such rights to
QuinStreet.
By submitting the resource, you also grant your article's readers the permission to use any source code in
the resource for commercial or noncommercial software. PLEASE NOTE THAT YOU RETAIN
OWNERSHIP OF ANY COPYRIGHTS IN ANY RESOURCES SUBMITTED!
ALSO, IN MAKING THE RESOURCE AVAILABLE TO OTHER SITE VISITORS FOR DOWNLOADING,
QUINSTREET WILL INFORM SUCH OTHER VISITORS THAT, ALTHOUGH THEY MAY DOWNLOAD
ANY RESOURCES FOR COMMERCIAL OR NONCOMMERCIAL USES, THEY MAY NOT REPUBLISH
THE SOURCE CODE SO THAT IT IS ACCESSIBLE TO THE PUBLIC WITHOUT FIRST OBTAINING THE
COPYRIGHT OWNER'S PERMISSION.
Document Copyrights
No part of this manualmay be reproduced,distributed or transmitted in any form or by any means,
for any purpose without written permission of Futurecom.
Disclaimer
The information in this document is carefully examined and is believed to be entirely reliable.
However, no responsibility is assumed for inaccuracies. Futurecom Systems Group, ULC.
reserves the right to make changes to any products herein to improve reliability, function or
design. Futurecom does not assume any liability arising out of the application or use of any
product or circuit described herein.
Trademarks
Futurecom, DVR-LX®, PDR8000®, the Futurecom Logo and the Stylized FC logo are registered
trademarks of Futurecom Systems Group, ULC. All other trademarks are the property of their
respective owner. © 2022 Futurecom Systems Group, ULC. All rights reserved.
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or
registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other
trademarks are the property of their respective owners.
Commercial Warranty
Please reference Futurecom’s Terms and Conditions of Sale, Section 7 regarding standard
warranty. (Futurecom Website →Terms and Conditions)

8G093X01 R5
VR Programming Guide
August 2022 Page 15 of 144
Declaration of Conformity
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation.
Changes or modifications not expressly approved by Futurecom Systems Group, ULC. could void
the User’s authority to operate the equipment.
Important Safety Information
The DVRS Repeater is intended for use in occupational / controlled conditions, where users have
full knowledge of the operator exposure and can exercise control over the operator exposure to
meet FCC/ISED limits. This radio is NOT authorized for general population, consumer, or any
other use.
Notice to Users (FCC/ISED)
To satisfy FCC/ISED RF exposure requirements for mobile transmitting devices, refer to the RF
Safety Booklet[1] for TX –RX duty cycle and a separation distance between the antenna of this
device and persons during operation. To ensure compliance, operations at closer than this
distance is not allowed.
Futurecom requires the P25 DVRS operator to ensure FCC/ISED Requirements for Radio
Frequency Exposure are met. The minimum distance between all possible personnel and the
body of the DVRS equipped vehicle is specified in the RF Safety Booklet[2]. Failure to observe the
Maximum Permissible Exposure (MPE) distance exclusion area around the antenna may expose
persons within this area to RF energy above the FCC exposure limit for bystanders (general
population).
It is the responsibility of the repeater operator to ensure that MPR limits are observed at all times
during repeater transmissions. The repeater operator must ensure at all times that no person
comes within MPE distance from the antenna.
[1] Refer to RF Safety Booklet available on the Futurecom website.
[2] Refer to RF Safety Booklet available on the Futurecom website.

8G093X01 R5
VR Programming Guide
August 2022 Page 16 of 144
Déclaration de Conformité
Cet équipement a été testé et déclaré conforme aux limites pour appareils numériques de classe A, selon
la partie 15 des règlements de la FCC. Ces limites sont destinées à assurer une protection raisonnable
contre les interférences nuisibles dans une installation commerciale. L’équipement génère, utilise et peut
émettre de l’énergie de fréquence radio et peut causer des interférences nuisibles aux communications
radio s’il n’est pas installé ou utilisé conformément au mode d’emploi. Toutefois, rien ne garantit
l’absence d’interférences dans une installation particulière.
Les changements et les modifications qui n’ont pas été approuvés expressément par Futurecom Systems
Group ULC pourraient faire perdre à l’utilisateur son droit à utiliser cet équipement.
Informations de Sécurité Importantes
Le répéteur DVRS est conçu pour être utilisé dans des conditions professionnelles / contrôlées, dans
lesquelles les utilisateurs connaissent à fond leur exposition et peuvent exercer le contrôle nécessaire sur
celle-ci pour se conformer aux limites de la FCC / ISED. Cette radio N’EST PAS autorisée pour être utilisée
par le grand public, les consommateurs ou autres.
Avis Aux Utilisateurs (FCC / ISED)
Pour satisfaire les exigences de la FCC / ISED en matière d’exposition à l’énergie RF pour les
transmetteurs mobiles, prière de consulter la Brochure Sécurité RF
1
pour obtenir le facteur d’utilisation
transmission / réception et la distance de séparation entre l’antenne de cet appareil et les personnes
pendant l’utilisation. Pour assurer la conformité, le fonctionnement à une distance moins élevée n’est pas
autorisé.
Futurecom demande à l’opérateur du répéteur P25 DVRS de satisfaire aux exigences de la FCC / ISED
en matière d’exposition à l’énergie RF. La distance minimale entre toutes les personnes possibles et une
antenne omnidirectionnelle doit respecter les indications de la Brochure Sécurité RF. Tout manquement à
respecter la zone d’exclusion autour de l’antenne définie par la distance correspondant à la limite
d’exposition maximale peut exposer les personnes qui se trouvent dans ce rayon à une énergie RF
supérieure à la limite d’exposition de la FCC pour les spectateurs (population générale).
C’est à l’opérateur du répéteur qu’il incombe de s’assurer que les limites d’exposition maximales sont
respectées en tout temps pendant les transmissions du répéteur. L’opérateur du répéteur doit s’assurer en
tout temps que personne ne s’approche de l’antenne à une distance inférieure à celle correspondant à la
limite d’exposition minimale.
1
Prière de consulter la Brochure Sécurité RF (Canada) ou la brochure Sécurité RF (États-Unis) pour les
distances de séparation

8G093X01 R5
VR Programming Guide
August 2022 Page 17 of 144
VR Programming Basics
Key Terminology
A few frequently used terms throughout this programming guide.
VR
Futurecom line of Vehicular Repeaters.
It applies to the following products: VRX1000, DVR and DVR-LX®.
DVRS
When a Vehicular Repeater (VR) is interfaced with an MSU, the
complete equipment package is referred to as a Digital Vehicular
Repeater System (DVRS).
FRC
Futurecom Repeater Configurator (FRC)
Configurator application for servicing the hardware programming
needs on all supported VR.
It is continually updated with business rules to ensure data integrity
on our VR configuration.
Installing Futurecom Repeater Configurator (FRC)
SYSTEM REQUIREMENTS
Operating Systems
Windows 10 or Windows 11
Processor
400 MHz or higher Pentium grade processor
Peripherals
USB Port
Previous Installation
Remove any previous installations of older Tweaker / FRC versions: go to Windows Start →
Settings →Apps, find the DVRS Tweaker / FRC and select the Uninstall option.
New Installation
The latest version of FRC is available on the Futurecom website:
Home →Support →Documentation and Software →DVR-LX/DVR/VRX1000 →FRC
Programming Software for DVR-LX/DVR/VRX1000
Step 1: Download and save the Futurecom Repeater Configurator (FRC) installer.
Step 2: Unzip the file (if needed).
Step 3: Double click on the APX Setup application located inside the FRC folder.
Step 4: Follow the Setup Wizard instructions to complete the installation.

8G093X01 R5
VR Programming Guide
August 2022 Page 18 of 144
Menu Bar
The top Menu Bar is a strip of menu items that, when clicked, display a dropdown menu of other
options and commands.
Field
Description
Dropdown Menus
(Keyboard Shortcuts in parentheses)
File
Commands for file
operations, including
applying, loading, saving
DPD Files (Templates)
Apply DPD to Repeater, Save DPD File, Load DPD
File (Ctrl+F6)
DCD Files (Templates)
Apply DCD to Repeater, Save DCD File, Load
DCD File
EPR Files (Futurecom Support)
Save EPR File, Load EPR File (F6)
Import
Motorola File
Apply Rescue File to Repeater
Apply License File
Preferences
Exit
Repeater
Commands for Repeater,
including load, save, reset
Load Data from Repeater (F2)
Save Changes to Repeater (F4)
Reset Repeater (F3)
EEprom Maintenance (Ctrl+E)
Info
Application
Log information for
Futurecom support
purposes.
Log Windows
RS232 Log
Save, Clear
Application Log
Show, Save, Clear
Clear All Data
User
For Futurecom support
purposes.
Change User
Options
COM Ports (opens Ports window)
Help
Links to support
documentation and
compatibility charts,
provides search
functionality.
Help
About
Find (Ctrl+F) (see below)
Compatibility Charts (see below)

8G093X01 R5
VR Programming Guide
August 2022 Page 19 of 144
Find functionality provides a quick way to search through FRC for a particular field. Enter a few
letters of a field name, click FIND and results will show all fields matching the string. Click on
desired result and click GO to open that screen.
Figure 1: Help Menu - 'Find' Feature
Compatibility Charts can be accessedthrough the Help drop downmenu. This is a static version
from the Futurecom website corresponding to the specific FRC release.
To use FRC on-line, the following is required:
1. FRC installed on the PC.
2. Powered up DVRS.
3. Programming cable (USB cable connected to VR).
Figure 2: Help Menu - Compatibility Charts

8G093X01 R5
VR Programming Guide
August 2022 Page 20 of 144
Setting Up Communications with the VR
Ensure USB cable is plugged into PC and connected to the USB port on the VR.
Ensure VR is powered up. Note: VR may be connected to DC power but will power up only when
the MSU interfaced to it is also powered up.
Reading from the VR (Uploading Data)
To read a VR unit:
1. Establish communication with the VR.
2. Select Repeater →Load Data from APX Repeater OR Press F2.
3. Data of the currently connected VR unit will be loaded into FRC for reviewing and/or editing.
Writing to the VR (Downloading Data)
Valid Changes: If any of the parameters within FRC are modified from its original value,
the modified fields are shaded in green.In addition, the EEprom maintenance icon flashes yellow,
and when hovering over it, a message indicates EEprom Changed.
Invalid Changes: If any invalid changes are made, the modified fields are shaded in red. In
addition, the EEprom maintenance icon flashes red and the configuration window(s)
containing conflicting data is marked with a red exclamation mark on the FRC navigation tree.
The changes cannot be written to the VR until the errors are eliminated.
After making the necessary changes to correct any programming errors, the data changes can
be saved to the VR by executing any of the following:
Repeater →Save Changes to APX Repeater (F4)
OR
Repeater →EEprom Maintenance (Ctrl+E) →Changes →Repeater
OR
Click on the EEPROM Maintenance Icon →Changes →Repeater
Reset the repeater (after the changes are saved) to ensure the changes take effect. Resetting of
the VR can be done by executing any of the following methods:
Repeater →Reset APX Repeater (F3)
OR
Repeater →EEprom Maintenance (Ctrl+E) →Reset Repeater
OR
Power OFF and ON the MSU
Understanding FRC Programming Files
There are three different types of files that can be used to program a VR: an EEPROM Data file
(EPR), a Device Programming Data file (DPD), or a Device Configuration Data file (DCD). These
files are referred to as codeplugs and each is used for a different purpose. There are also different
categories of data and not all are included in each codeplug type.
