ORIGINAL USER MANUAL
Petrol leaf vacuum cleaner / blower
FUXTEC FX-LBS126P
Your new device has been developed and designed to meet FUXTEC's high standards, such as
easy operation and user safety. Properly treated, this device will serve you well for years to come.
WARNING: To reduce the risk of injury, the user must read and understand this manual
before operating the device.
FUXTEC GmbH
Kappstrasse 69, 71083 Herrenberg - Germany

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
3
Table of contents
1. Introduction...............................................................................................................................4
2. Scope of delivery......................................................................................................................4
3. Operating hours........................................................................................................................4
4. Safety symbols on the device and in the operating manual ....................................................5
5. Intended/non-intended use ......................................................................................................6
6. Residual risks and safe working ..............................................................................................7
7. fuel management....................................................................................................................10
8. Overview of the device...........................................................................................................11
9. Assembly as leaf blower ........................................................................................................12
10. Assembly as a leaf vacuum cleaner ................................ Fehler! Textmarke nicht definiert.
11. Commissioning - refuelling, 2-stroke engine oil .....................................................................14
12. Start/Stop the leaf blower.......................................................................................................16
13. Working notes ........................................................................................................................17
14. Maintenance and care............................................................................................................18
15. Technical data ........................................................................................................................21
16. Troubleshooting......................................................................................................................22
17. Customer Service...................................................................................................................23
18. Warranty .................................................................................................................................23
19. Disposal information...............................................................................................................23
20. EC Declaration of Conformity.................................................................................................24

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
4
1. Introduction
We would like to thank you for purchasing a leaf vacuum cleaner/blower from our company. This
user manual will explain how to use the vacuum in the best possible way. Before using it, please
read this manual carefully, operate the device correctly and work safely. Furthermore, it is possible
that not all details of your device comply with the operating manual due to further development of
the device. Therefore, we ask for your understanding.
2. Scope of delivery
•Petrol leaf blower/vacuum cleaner FX-LBS126P
•1x blowpipe middle piece
•1x blowpipe for paved ground straight version
•2-piece suction pipe
•Leaf trap bag and two-part bent connection pipe
•Tool bag
•Operating manual
After unpacking, check the contents of the carton for
•Completeness
•Possible transport damage
Please FUXTEX immediately of any complaints. Later complaints cannot be accepted.
3. Operating hours
According to the Device Noise Protection Ordinance of September 2002, leaf blowers may not be
used in pure, general and special residential areas, small housing estates, special areas used for
recreation, spa and clinic areas and areas for tourist accommodation, as well as on the premises
of hospitals and nursing homes on Sundays and public holidays and on working days from 8 p.m.
to 7 a.m. Please also observe the regional regulations on noise protection.

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
5
4. Safety symbols on the device and in the operating
manual
They provide important information about the product or manual for its use.
Before using the device, read the operating manual in detail and
become familiar with the device
Wear eye, mouth and hearing protection while using the device
Always wear safety gloves
Be careful when blowing against obstacles such as trees, as
objects can fly back
Ensure that there are no people around the working area of 15m.
Caution: Risk of injury!
Attention hot components. Caution danger of burns!
Do not reach into the chopper blade when the flap is open!
Caution: Risk of injury!
Do not suck up any pointed or metallic objects! Caution: Risk of
injury!
No open fire. Fire hazard!
The guaranteed noise level complies with the legal noise
guidelines

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
6
Dangerous situation or imminent danger. Failure to observe this manual may result in injury
or damage to property.
Important information on the correct handling of the device. Non-observance of these manual can
lead to malfunction of the device.
User manual. These hints will help you to make optimum use of all functions of the device.
Installation, operation and maintenance of the device. Here you will find detailed manual on
how to proceed
5. Intended/non-intended use
The petrol leaf blower is designed exclusively for blowing leaves. Proper use also includes reading
and adhering to the operating manual before each use. The device must be checked for
mechanical damage before and during use. If repairs are necessary, contact your specialist dealer.
Only spare parts approved by the manufacturer or original spare parts may be used. The device
may only be put into operation in open garden area.
If non-approved or non-original spare parts are used, the operator and not the manufacturer is
liable for any damage to property or persons.
Any use other than that mentioned above is an unintended use:
•Proper use also includes reading and adhering to the operating manual.
•If non-approved or non-original spare parts are used, the operator and not the manufacturer
is liable for any damage to property or persons.
•Any use other than that mentioned above is an unintended use.
•Intended use also includes compliance with the operating, maintenance and repair conditions
specified by the manufacturer and the safety manual contained in the manual.
•The applicable relevant accident prevention regulations as well as the other generally
accepted occupational health and safety rules must be observed.
•Any use beyond this is considered improper use. The manufacturer is not liable for damages
of any kind resulting from this: the risk is borne solely by the user.
•Own modifications to the device preclude any liability of the manufacturer for damages of any
kind resulting from such modifications.
•The device may only be set up, used and maintained by persons who are familiar with it and
have been informed about the dangers. Repair work may only be carried out by the
manufacturer or by service centres recommended by the manufacturer.
•The device must not be used in a potentially explosive environment or exposed to rain.

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
7
6. Residual risks and safe working
Even when used as intended, there may still be residual risks due to the design determined by the
intended use, despite compliance with all relevant safety regulations.
Residual risks can be minimized if the "Intended Use" and the "Safety Manual" as well as the
operating manual as a whole are observed.
•Consideration and caution reduce the risk of personal injury and damage.
•Injury due to disposal of parts.
•Risk of carbon monoxide poisoning when used in closed or poorly ventilated rooms.
•Danger of burns from hot components.
•Hearing is impaired if work is carried out over long periods without hearing protection.
Furthermore, despite all the information and precautions taken, there may be residual risks that
are not obvious.
Warning: The actual vibration emission value present during use of the device may differ from that
specified in the operating manual or by the manufacturer. This can be caused by the following
influencing factors, which should be observed before or during use:
•If the device is used correctly
•Is the device in good working order
•If the handles are fitted with optional vibration grips and are firmly attached to the
Device body
Read the following manual and the safety regulations applicable in your country before using this
product to protect yourself and others from possible injury.
Always keep these safety manual (operating manual) with the device. The device may only be
operated by persons with sufficient experience.
Repairs to the device must be carried out by the manufacturer or companies recommended
by him.
Getting started
•If you are working with the device for the first time, you must receive practical
instruction in the use of the device and personal protection device from an experienced
operator.
•Be alert. Work with common sense. If you are tired or under the influence of drugs,
alcohol or medication you must not use the device. Failure to use the device properly
may result in serious injury
•Familiarize yourself with the device before use. Inadequately informed operators can
endanger themselves or other persons through improper use.

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
8
•Make sure you are standing securely and keep your balance at all times. The use of e.g. A
ladder is not permitted.
•Do not use the device for purposes for which it is not intended (see "Intended use").
•Wear suitable work clothing:
•No jewellery or loose clothing, they could be caught in the device
•Gloves and non-slip footwear
•For long hair a hair net
•Wear protective clothing:
oHearing protection
oSafety goggles or face shield
oWork gloves
oSafety shoes
oTested helmet in situations where head injuries are to be expected.
•It is recommended to wear leg protection and a safety jacket.
•Keep your work area in order!
•Take environmental influences into account:
oDo not expose the device to rain.
oDo not use the device in a wet or humid environment.
oPostpone work in unfavourable weather conditions (rain, snow, ice, wind) due to increased
risk of accidents!
oEnsure good lighting.
oDo not use the device near flammable liquids or gases.
•You may not be able to hear danger because of the engine noise. Therefore, make yourself
familiar with your surroundings.
•Never leave the device unattended.
•During breaks in work, the device must be laid down in such a way that nobody is endangered.
Secure the device against unauthorized access.
•Persons under 18 years of age must not operate the device.
•Keep other people and children away.
•The operator is responsible for accidents or hazards that occur to other persons or their
property.
•Do not let other persons, especially children, touch the tool or the engine.
•Make sure that the device is not overloaded! You will work better and safer in the specified
power range.
•Only operate the device with complete and correctly fitted protective devices. Do not change
anything on the device that could impair safety.
•Switch off the device and pull the spark plug connector from the spark plug:
oIf the device touches soil, stones, nails or other foreign bodies check whether the device
is damaged.
oRepair work, as well as maintenance and cleaning work
oElimination of malfunctions (e.g. Clogging of the blow tube)

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
9
oTransport and storage
oLeaving the working area, even during short interruptions.
Maintain your leaf blower with care:
•Clean the device after each use
•Empty the tank after each use
•Keep handles dry and free from lubricants.
•Follow the maintenance manual.
Check the device for damage:
•Before further use of the device, safety devices must be carefully checked for their trouble-
free and proper function.
•Check that moving parts are working properly and are not jamming, or if parts are
damaged. All parts must be correctly mounted and meet all conditions to ensure proper
operation of the device.
•Damaged safety devices and parts must be properly repaired or replaced by us or a
recognised specialist workshop, unless otherwise stated in the manual for use.
•Damaged or illegible security stickers must be replaced.
•Never leave a tool key in place!
•Always check that keys and tools are removed before switching on.
•Store unused devices in a dry, locked place out of the reach of children.
•Do not repair the device yourself.
Do not carry out any repairs on the device other than those described in the chapter
"Maintenance", but contact the manufacturer or authorised customer service directly.
Repairs to other parts of the device must be carried out by the manufacturer or a specialist
workshop specified by him.
Only use original spare parts! The use of other spare parts or accessories may cause
danger to the user. The manufacturer is not liable for any damage resulting from this.

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
10
7. Fuel management
Fuels and fuel vapours are flammable and can cause serious damage if inhaled or on the
skin. Therefore, care must be taken when handling fuel and good ventilation must be
provided.
•Before refuelling, switch off the engine and let the device cool down.
•Avoid open flame when refuelling.
•Wear gloves when refuelling.
•Do not refuel in closed rooms (danger of explosion).
•Do not spill fuel or oil. Clean the device immediately if you have spilled fuel or oil. Change
your clothing if you have spilled fuel or oil on it.
•Do not let any fuel get into the ground.
•After refuelling, carefully close the fuel filler cap again and check that it does not become
loose during operation.
•Make sure that the fuel filler cap and fuel lines are tight. If leaks occur, the device must not be
put into operation.
•Transport and store fuels only in marked and approved containers.
•Do not transport or store fuel near flammable or highly inflammable materials or sparks or
open fire. Keep children away from fuel.
•To start the device, move away sufficiently from the fuel station.

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
11
8. Overview of the device
1. Spark plug
2. On / off switch
3. Throttle lever
4a. Choke lever
4b. Primer pump
5. Air filter cover
6. Pull starter (start rope)
7. Tank with lid
8. Lower handle
9. Two-piece blowpipe
10. Air intake grille
11. Air intake grille locking
12. Throttle lock lever
13. Chopper claw
14. Two-piece suction pipe
(suction pipe device)
15. Curved intake pipe
16. Leaf bag
Leaf blower
Leaf Vacuum Cleaner

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
12
9. Assembly as leaf blower
Caution: Always switch off the engine when carrying out assembly and/or maintenance work!
Wear protective gloves during assembly to protect yourself from cuts.
Mount the two blowpipes into each other and position them on the main device. Make sure that
they are screwed on all the way and fix them with screw A. Using the blowing attachments:
10. Assembly as leaf vacuum
1. Insert the conical suction pipe 15A through the large opening of the leaf bag 16B and
push the tapered side of the pipe through the narrow opening 16A (see illustration on
page 14)
2. Connect the bent suction pipe 15B to the conical nipple 15A as shown in the figure. Bring
the two parts together and turn the bent intake pipe until the hole for the screw matches.
Screw the two parts together.
15A
15B
Rib
Small opening 16A
Large opening 16B

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
13
3. Twist the bent suction pipe 15, now connected to the leaf collection bag 16, on the main
device.
4. Now open the lock 11 of the air intake grille 10.
5. Now fit the two-part suction pipe 14 into each other and position it on the main device
with the air intake grille 10 open.
6. Ensure that the suction pipe device 14 is properly seated and turn it until it stops.

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
14
11. Commissioning - refuelling, 2-stroke engine oil
The device is not delivered filled with fuel mixture.
Fill the device as described in this chapter under "Refuelling".
The device is operated with a 40:1 mixture of normal petrol (unleaded) and two-stroke engine
oil.
When handling petrol, increased attention is required. Avoid smoking and naked
flames at all costs because of the danger of explosion.
Gasoline:
Octane number at least 91 RON, lead free
•Do not fill with leaded petrol, diesel or other non-approved fuels.
•Do not use petrol with an octane number lower than 91 RON. This can lead to engine damage
due to increased engine temperatures.
•If you work continuously in the higher speed range, use petrol with a higher octane rating.
•For environmental reasons, the use of unleaded petrol is recommended. The use of E10 fuels
is not permitted.
2-stroke engine oil
Do not use four-stroke or two-stroke oils for water-cooled outboard engines, or ready-mixed
fuel from petrol stations.
Mixing ratio 40:1
•Ensure that the oil quantity is measured exactly, as a small deviation in the oil quantity has a
strong effect on the mixing ratio for small quantities.
•Do not change the mixing ratio, as this will result in increased combustion residues, increased
fuel consumption and reduced performance, or damage to the engine.
Mix the petrol and oil in a clean, petrol approved and marked container with overfill protection.
1. First fill in half of the petrol to be mixed
2. Then fill in the entire quantity of oil.
3. Shake the mixture.
Gasoline
Two-stroke engine oil
(40:1)
Gasoline
Two-stroke engine oil
(40:1)
1 litre
0.025 litres
5 litres
0,125 litres
2 litres
0.050 litres
10 litres
0.250 litres

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
15
4. Fill in the rest of the fuel.
Fuels can only be stored for a limited time as they age. Superimposed fuels and fuel mixtures can
cause problems when starting. Therefore, only mix as much fuel as you use in one month.
Store fuels in dry and safe conditions in approved and marked containers.
Ensure that the fuel tanks are kept out of the reach of children.
Refuelling the leaf blower
Switch off the engine, let the device cool down!
- Wear protective gloves!
- Avoid skin and eye contact (wear protective goggles)!
- It is essential to observe "Handling of fuel".
1. Only refuel the device outdoors or in sufficiently ventilated rooms.
2. Clean the area around the filling area. Dirt in the tank causes malfunctions.
3. Shake the container with the fuel mixture again before refuelling.
4. Open the closure (10) carefully so that any excess pressure can be released.
5. Carefully fill the mixture up to the lower edge of the filler neck.
6. Close the fuel filler cap again.
7. Make sure that the fuel filler cap is tight.
8. Clean the fuel cap and the surrounding area.
9. Check for leaks in the tank and fuel lines
10. Operate the primer pump (24) if necessary.
11. Remove yourself appropriately from the fuelling station before starting the engine

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
16
12. Start/Stop the leaf blower
The device must not be put into operation until you have read this operating manual,
observed all the manual given and the device has been completely and correctly installed!
•Only start the device when it is completely assembled.
•Support the device on the ground for starting and hold it firmly.
1. Maintain a distance from flammable materials.
2. Take a safe stand.
3. Place the device on the ground in front of you
4. Hold the device by the upper bracket with your left hand.
5. Grasp the pull starter with your right hand
Starting with cold engine
1. Slide the ON / OFF switch 2 to position 1.
2. Gently press the primer pump 4B below the choke lever 4A several times until fuel enters the
pump.
3. Slide the choke lever 4A to
4. You can pull the throttle lock lever 12 to the rear for assistance.
5. Pull out the starting cord 6 at the starting handle slowly until the resistance is reached.
6. Pull quickly on the start cord and then release it slowly.
Do not pull out the starting cord completely and do not let the starting handle snap back
on the engine.
7. Pull the throttle slightly and the choke will automatically return to its original position.
8. The engine rotates at idle speed.
9. Before starting work, let the appliance warm up at idle for about 2-3 minutes and
slowly start to pull the throttle lever 3.
Starting with warm engine
1. Move ON / OFF switch 2 to position 1.
2. Leave the choke lever 4A on
3. Pull the starting cable on the starting handle until the engine starts.
Stop the engine
1. Release throttle 3.
2. Set the ON / OFF switch to position 0

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
17
13. Working notes
Perform the following checks regularly before commissioning and during operation:
•Always hold the device with both hands on the front and rear handle.
•Is the device complete and correctly installed?
•Make sure that all nuts and bolts are tightened.
•Is the device in good and safe condition?
•Are all safety functions in order?
•Is the gas tank full?
•Are the engine and muffler free of deposits, leaves or lubricants?
•Is the handle clean and dry (no oil, grease or resin)?
•Is the workplace free of obstacles that you could trip over?
•Are you wearing the necessary protective device?
•Have you read and understood the manual?
•Are throttle levers smooth and throttle lock levers functional?
•Is the ON/OFF switch functional?
•Make sure that the gear device has sufficient lubrication (see "Maintenance").
•IMPORTANT: To avoid burning the leaf bag with the exhaust pipe, make sure to turn the whole
body when turning in the suction position and not only with your hands. Twisting the hip will
cause the heat of the exhaust to point towards the leaf bag, creating the risk of a burn hole.
•Ensure that there are no foreign objects such as stones in the working area which could be
blown away or sucked up. This can cause serious injury to persons due to flying parts or
damage to the device when vacuuming.

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
18
14. Maintenance and care
Before any maintenance and cleaning work
•Switch off the engine
•Wait until the engine has come to a standstill
•Disconnect spark plug connector (except when adjusting the idle speed)
Beware of rotating parts! Danger!
Due to the risk of fire, do not carry out maintenance work in the vicinity of open flame.
Maintenance and cleaning work not described in this chapter may only be carried out by customer
service.
Safety devices that have been removed for maintenance and cleaning must be properly checked
and reattached before use.
Only use original parts. Other parts may cause unforeseeable damage or pose a danger to the
user.
Maintenance
Wear gloves to avoid injury.
To ensure a long and reliable use of the device, carry out the following maintenance work
regularly.
Check the device for obvious defects such as
•loose fastenings
•worn or damaged components
•Tank cap and fuel lines for their tightness
Check the device for wear after each use.
Clean or replace the air filter
Clean the air filter every 25 hours of operation or every 3 months to remove dust and dirt and to
prevent:
-performance losses,
-startup problems,
-too high fuel consumption
Clean the air filter approx. every 8 operating hours, or even
more often in particularly dusty conditions.
1. Set the starting lever (choke) to open, so that no
dirt gets into the carburettor.
2. Remove the air filter cover 5 by opening the wing nut
3. Remove the foam air filter
4. Wash the air filter in lukewarm soapy water

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
19
Do not blow out the dirt, there is a danger of eye injuries!
5. Clean the inside of the air filter with a brush.
6. Allow the air filter to dry thoroughly and replace it.
7. Replace the air filter cover
replace the air filter regularly.
Damaged air filters must be replaced before starting work.
Clean or replace the fuel filter
Check the fuel filter every 100 hours of operation / every 12 months. A dirty fuel filter hinders the
fuel supply.
Open the fuel filler cap and pull the fuel filter through the opening with a wire hook.
•light soiling ➜remove the fuel filter from the fuel line and clean the filter in cleaning gasoline
•heavy dirt ➜ replace the fuel filter
Change or check spark plug
High voltage! Do not touch the spark plug or the spark plug connector while the engine is running.
Danger of burns when the engine is hot. Wear protective gloves!
Check the spark plug and the distance between the electrodes regularly.
Proceed as follows:
1. remove the spark plug connector from the spark plug
2. unscrew the spark plug with the spark plug wrench provided.
Filter housing
and filter
insert

Original User Manual FUXTEC Petrol Leaf vacuum cleaner / blower FX-LBS126P_rev09
20
The electrode gap should be between 0.6 and 0.7 mm.
Clean the spark plug if it is dirty.
Replace the spark plug:
•if it has a damaged insulation body
•in case of heavy burn-up of the electrodes
•for very dirty or oily electrodes
•every month in regular operation
Use one of the following spark plugs: Torch BMR6A
Check ignition sparks
1. Remove the spark plug connector from the spark plug
2. Unscrew the spark plug with the spark plug wrench provided.
3. Insert the spark plug connector firmly.
4. Press the spark plug against the engine casing (not near the spark
plug hole) with insulated pliers.
5. Slide the on / off switch to the "start" position.
6. Pull strongly the starting rope at the starting handle.
A spark must be visible between the electrodes if the system is functioning properly.
Muffler/outlet opening
Do not tighten the muffler screws when the engine is hot.
1. Check regularly that the screws (D) of the muffler have not become loose ➜ If they are loose,
hand-tighten them.
2. Regularly clean the outlet opening (E).
Care
Clean the device carefully after each use to ensure that it continues to function properly.
•Clean the housing with a soft brush or dry cloth.
Water, solvents and polishing agents must not be used.
•Make sure that the ventilation slots for cooling the engine remain free (danger of overheating).
•Clean and oil all moving parts regularly.
Do not use grease! Use environmentally friendly oil.
Warning: failure to carry out maintenance regularly can cause serious damage to the device and
persons.
Warning: Transport the device only in the switched off state. All suction/blowing pipes as well as
the leaf bag must be dismantled for your safety.
11.5mm
0,6 - 0,7mm
