Fx Bricks PFxBrick User manual

1 2 Remove the 1 x 2 transparent brick
from the top of the PFx Brick.
Carefully remove the IR sensor from IR
sensor connector by pulling upwards.
4Plug any speaker (M, XL, etc.) into the right-
most 2 pins of the IR connector as shown.
Power OFF the PFx Brick and remove any
external peripherals. 3
5Insert USB cable into the PFx Brick 6Launch the PFx App. You should see this
notification message indicating the PFx
Brick is in Service/Recovery mode.
If the PFx Brick no longer responds to USB connection to a host PC
with the PFx App, or from connections via Bluetooth, or becomes
unresponsive and/or behaves abnormally, it can be placed into
Service/Recovery mode.
Service/Recovery mode will allow the PFx Brick
firmware to be updated with the PFx App and
hopefully restore normal operation.
Follow this procedure carefully to put the PFx Brick into
Service/Recovery mode. This procedure should only
be used in extreme circumstances where normal
communication with the PFx Brick cannot be used.
Use caution when inserting/removing the IR
sensor. The IR sensor pins are delicate and
can be bent or damaged if mishandled.
Ensure the connector is plugged into the
right-most 2 pins of the 3-pin IR connector.
© 2018 Fx Bricks Inc. Rev A
Service / Recovery Mode

7
10
From the Tools menu, select “Check for
Firmware Updates…”8
A notification message should appear as
follows to update the PFx Brick.
9
Click “Yes” to reinstall the firmware.
The firmware update will proceed with
transferring and then restarting the PFx
Brick…
The PFx App will remain in Recovery
mode after the update has finished.
11
Unplug the speaker from IR sensor
connector.
Unplug the USB cable. 12
Plug the USB cable back into the PFx Brick.
Click the Refresh button on the PFx App.
You can verify the firmware version number from
the Settings tab of the PFx App.
© 2018 Fx Bricks Inc. Rev A
Service / Recovery Mode
Carefully reinstall the IR sensor and 1 x 2
transparent cover brick.
Ensure the IR sensor is plugged into the
connector with orientation shown.
