FXLuminaire Luxor ZD User manual

LUXOR®
CONTROLLER
Quick Start Guide

fxl.com/luxorhelp
2
➊
➋
➌
➍➎
➏➐
➑
➒
10 11
12
13
14
Luxor Components
➊Core Cover
➋Chassis
➌Facepack Connection (RJ-11)
➍Chassis LED
➎Terminal Blocks
➏Fuse Cover
➐Linking Ports (RJ-45)
➑ Facepack
➒ LCD Screen
Home Button
Help Button
Clickable Scroll Wheel
Fixture Assignment Ports
SD Card/Battery Slot
General Information
• SCROLL WHEEL
• Pressing scroll wheel allows eld to be selected or editable
• FIRMWARE FILES
• FXL.com -> Products -> Power & Control -> Luxor ZD/ZDC -> Documents tab
• File Name(s):
• ZD Facepack: fx_fpack.e
• ZDC Facepack: zdcfpack.e
• Chassis (Luxor Linking): fx_ch024.e
• Chassis (non-linking): fx_chass.e
• Flash: fx_ash.e
• SUPPORT VIDEOS: www.fxl.com/luxorvideos
13
14
10
11
12

3
13
Location Setup
• Select SETUP
• Select LOCATION using scroll wheel
• Select LATITUDE (Lat)/LONGITUDE (Long) using scroll wheel
• Long = Up/Down
• Lat = Le/Right
Fixture Group Assignment
• Insert integrated xture or Luxor Accessory leads into
ASSIGMENT PORTS located on front of facepack
• ASSIGNMENT screen will appear once xture or
accessory is recognized
• Select desired Group for xture or accessory
• Scroll to PROGRAM and press scroll wheel
• “Assignment Successful” conrms xture or
accessory has been assigned to the desired group
Creating Colors
• Select COLOR
• Scroll to desired color label (C1 – C250)
• Scroll to COLOR and press scroll wheel to enter COLOR SELECTION screen
• Set HUE (0°-360°) using scroll wheel
• Set SAT (0%-100%) using scroll wheel
• If necessary, adjust HUE and SAT values by selecting desired values
and adjust using scroll wheel

Creating Themes
• Select THEMES
• Select desired Theme letter (A-Z)
• Enter desired groups, including intensity and color (ZDC only),
for the selected Theme
• Select TEST THEME to preview desired Theme
Creating Programs
• Select PROGRAMS
• Select desired Program letter (A-F), Program run days (Mon – Sun), and Event time
• For desired Event time, select Group, Theme, or All Lights
• Select Color (ZDC only) for desired Group or Theme
• Set Intensity (o or 1-100%) for Groups or All Lights and set Intensity (on/o) for Themes
Firmware Updates
• Locate latest rmware on Luxor product page located under RESOURSE tab on fxl.com
• Save desired rmware (Facepack, Chassis, Flash, Fixture) onto SD Card
• Insert SD CARD into facepack
• Simultaneously press HOME and ? (“HELP”) to enter DIAGNOSTIC screen
• Press scroll wheel to enter FIRMWARE LOAD screen
• Select desired update type (Facepack, Chassis, Flash, Fixture)
• “Firmware update complete” conrms rmware was successfully updated
fxl.com/luxorhelp 1-800-733-2823
Find more information about your product, including tips on installation, programming, and more.
FX-221 QG US 8/17
