Galanz GLFW22WEA5A User manual

Model# GLFW22WEA5A
WASHER INSTRUCTION MANUAL
Thank you for purchasing a Galanz product. Please read this manual carefully for correct usage and safety,
and keep for future reference. For service, support and warranty information, call 800-562-0738.
© 2021 Galanz Canada Ltd.

CONTENTS
CONTENTS
1
7
11
16
20
IMPORTANT SAFETY WARNINGS
INSTALLATION INSTRUCTIONS ....................................................................
OPERATING INSTRUCTIONS ........................................................................
MAINTENANCE INSTRUCTIONS ...................................................................
WARRANTY ....................................................................................................
.................................................................

IMPORTANT SAFETY WARNINGS
1
IMPORTANT SAFETY WARNINGS
This manual contains important information on the installation, use
and care of your appliance. Please take time to read this manual
to take full advantage of your washer’s many benefits and features.
What you need to know about the safety insrtuctions
Warnings and lmportant Safety lnstruvtions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your washer.
Because these following operating instructions cover various
models, the characteristics of your washer may differ slightly
fromthose described in this manual and not all warning signs may
be applicable. If you have any questions or concerns, contact your
nearest service center.
Important safety symbols
Hazards or unsafe practices that may result in severe personal
injury, death and/or property damage.
WARNING
To reduce the risk of fire, electric shock, or injury to persons
when using your appliance, follow basic precautions, including
the following:
1. Read all instructions before using the appliance.
2. Do not wash articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry-cleaning
solvents, or other flammable or explosive substances, as they
give off vapors that could ignite, or explode.
3. Do not add gasoline, dry-cleaning solvents, or other
flammable or explosive substances to the wash water. These
substances give off vapors that could ignite or explode.
4. Under certain conditions, hydrogen gas may be produced in
a hot-water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has
not been used for such a period, before using a washing
machine, turn on all hot-water faucets and let the water flow
from each for several minutes. This will release any accumulated
hydrogen gas. As the gas is flammable, do not smoke or use an
open flame during this time.
5. Do not allow children to play on or in the appliance, Close
supervision of children is necessary when the appliance is used
near children.
6. Before the appliance is removed from service or discarded,
remove the door.
WARNING
Hazards or unsafe practices that may result in personal injury
and/or property damage.
CAUTION
Indicate that a risk of personal injury or material damage eaists.
NOTE
These warning sings are here to prevent injury to yourself and
others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
Read all instructions before using the appliance.
As with any equipment that uses electricity and moving parts,
potential hazards exist.
To safely operate this appliance, familiarize yourself with its
operation and exercise care when using it.

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
2
WARNING
Do not let children (or pets) play on or in your washing machine.
The washing machine door does not open easily from the inside,
and children may be seriously injured if trapped inside.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience an knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance. If the plug (power supply cord) is damaged, it must
be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
Thus appliance should be positioned to be accessible to the
power plug, the water supply tabs and the drain pipes.
For washing machines with ventilation openings in the base,
ensure that the opening is not obstructed by carpet or any other
obstacles.
Use the new hose-sets and old hose-sets should not be reused.
SEVERE WARNING SIGNS FOR INSTALLATION
Failure to do so may result in electric shock, fire, an explosion,
problems with the product, or injury.
The appliance is heavy, take care upon lifting it.
Plug the power cord into an AC 120V/60Hz wall socket or higher
and use the socket for this appliance only. In addition, do not use
an extension cord.
Sharing a wall socket with other appliances using a power strip
or extending the power cord may result in electric shock or fire.
Ensure that the power voltage, frequency and current are the
same as those of the product
specifications. Failure to do so may result in electric shock or fire.
Plug the power plug into the wall socket firmly.
Remove all foreign substances such as dust or water from the
power plug terminals and contact points using a dry cloth on a
regular basis.
Unplug the power plug and clean it with a dry cloth.
Failure to do so may result in electric shock or fire.
Plug the power plug into the wall socket in the right direction so
that the cord runs towards the floor.
If you plug the power plug into the socket in the opposite direction,
the electric wires within the cable may be damaged and this may
result in electric shock or fire.
Keep all packaging materials well out of the reach lf children, as
packaging materials can be dangerous to children.
If a child places a bag over its head, it may result in suffocation.
When the appliance or power plug or power cord is damaged,
contact your nearest service centre.
7. Do not reach into the appliance if the tub or agitator is moving.
8. Do not install or store this appliance where it will be exposed
to the weather.
9. Do not tamper with controls.
10. Do not repair or replace any part of the appliance or attempt
any servicing unless specifically recommended in the user-
maintenance instructions or in published user-repair instructions
that you understand and have the skills to carry out.
SAVE THESE INSTRUCTIONS
The installation of this appliance must be performed by a qualified
technician or service company.

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
3
This appliance must be property grounded.
Do not ground the appliance to a gas pipe. plastic water pipe,
or telephone line.
This may result in electric shock, fire, an explosion, or problems
with the product.
Never plug the power cord into a socket that is not grounded
correctly and make sure that it is in accordance with local and
national codes.
Do not install this appliance near a heater, inflammable material.
Do not install this appliance in a humid, oily or dusty location, in
a location exposed to direct sunlight and water (rain drops).
Do not install this appliance in a location of low temperature.
Frost may cause tubes to burst.
Do not install this appliance in a location where gas may leak.
This may result in electric shock or fire.
Do not use electric transformer.
It may result in electric shock or fire.
Do not use a damaged power plug, damaged power cord or
loose wall socket.
This may result in electric shock or fire.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy
object on the power cord, insert the power cord between objects,
or push the power cord into the space behind the appliance.
This may result in electric shock or fire.
Do not pull the power cord, when unplugging the power plug.
Unplug the power plug by holding the plug.
Failure to do so may result in electric shock or fire.
Do not lay the power cord and tubes where you may fall over
them.
This appliance should be positioned in such a way that it is
accessible to the power plug.
Failure to do so may result in electric shock or fire due to electric
leakage.
Install your appliance on a level and hard floor that can support
its weight.
Failure to do so may result in abnormal vibrations, moves, noise,
or problems with the product.
CAUTION SIGNS FOR INSTALLATION
If the appliance is flooded, turn off the water & power supply I
mmediately and contact your nearest service centre.
Do not touch the power plug with wet hands.
Failure to do so may cause electric shock.
If the appliance generates a strange noise, a burning smell or
smoke, unplug the power plug immediately and contact your
nearest service centre.
Failure to do so may cause electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.),
ventilate immediately without touching the power plug. Do not
touch the appliance or power cord.
Do not use a ventilating fan.
A spark may result in an explosion or fire.
Do not let children play in or on the washer. In addition, when
disposing of the appliance, remove the washer door lever.
If trapped inside, the child may become trapped and suffocate
to death.
SEVERE WARNING SIGNS FOR USING

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
4
Do not attempt to repair, disassemble, or modify the appliance
yourself.
Do not use any fuse (such as cooper, steel wire, etc.) other than
the standard fuse.
When repairing or reinstalling the appliance is required, contact
your nearest service centre.
Failure to do so may result in electric shock, fire, problems with
the product, or injury.
If the water supply hose comes loose from the water tap and
floods the appliance, unplug the power plug.
Failure to do so may result in electric shock or fire.
Unplug the power plug when the appliance is not being used for
long periods of time or during a thunder/lightning storm.
Failure to do so may result in electric shock or fire.
When the washer is contaminated by a foreign substance such
as detergent, dirt, food waste, etc., unplug the power plug and
clean the washer using a damp and soft cloth.
Failure to do so may result in discolouration, deformation,
damage or rust.
The front glass may be broken by a strong impact. Take care
when using the washer.
When the glass is broken, it may result in injury.
After a water supply failure or when reconnecting the water
supply hose, open the Water Tap slowly.
Open the Water Tap slowly after a long period of non-use.
The air pressure in the water supply hose or the water pipe may
result in damage to apart or in water leakage.
If a drain error occurs during an operation, check if there is a
draining problem.
If the washer is used when it is flooded because of a draining
problem, it may result in electric shock of fire due to electric leakage.
Make sure to remove the packaging (sponge, styrofoam)
attached to the bottom of the washer before using it.
Do not wash items contaminated with gasoline, kerosene,
benzene, paint thinner, alcohol or other flammable or explosive
substances.
This may result in electric shock, fire or an explosion.
Do not open the washer door by force while it is operating (high-
temperature washing/spinning).
Water flowing out of the washer may result in burns or cause the
floor to be slippery.
This may result in injury.
Opening the door by force may result in damage to the product
or injury.
Do not insert your hand under the washer.
This may result in injury.
Do not touch the power plug with wet hands.
This may result in electric shock.
Do not turn the appliance off by unplugging the power plug while
an operation is in progress.
Plugging the power plug into the wall socket again may cause a
spark and result in electric shock or fire.
Do not let children or infirm persons use this washer
unsupervised. Do not let children climb in the appliance.
Failure to do so may result in electric shock, burns or injury.
Do not insert your hand or a metal under the washer while it is
operating.
This may result in injury.
Do not unplug the appliance by pulling at the power cord, always
grip plug firmly and pull straight out from the outlet.
Damage to the cord may cause short-circuit, fire and/or electric
shock.

IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
5
Insert the laundry into the washer completely so that laundry
does not get caught in the door.
If laundry gets caught in the door, it may result in damage to the
laundry or the washer, or result in water leakage.
Ensure that the Water Tap is turned off when the washer is not
being used.
Ensure that the screw on the water supply hose connector is
properly tightened.
Failure to do so may result in property damage or injury.
Check if the rubber seal is not contaminated by foreign
substances (waste, thread, etc). If the door is not closed
completely, it may result in water leakage.
Open the Water Tap and check if the water supply hose
connector is firmly tightened and that there is no water leaking
before using the product.
If the screws or the water supply hose connector are loose, it
may result in water leakage.
Do not stand on top if the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals,
metal objects, etc.) on the appliance.
This may result in electric shock, fire, problems with the product,
or injury.
Do not spray volatile material such as insecticide onto the
surface of the appliance.
As well as being harmful to humans, it ,ay also result in electric
shock, fire or problems with the product.
Do not place an object that generates a electromagnetic field
near the washer.
This may result in injury due to a malfunction.
Since the water drained during a high-temperature wash or
drying cycle is hot, do not touch the water.
This may result in burns or injury.
Do not wash, spin water-proof seats, mats or clothing (woollen
bedding, rain cover, fishing vests, ski pants, sleeping bags,
diaper covers, sweat suits, and bicycle, motor cycle and cars
covers, etc.) unless your appliance has a special program for
washing these items.
Do not wash thick, hard mats even if the washer mark is on the
care label. This may result in injury or damage to the washer,
walls, floor or clothing due to abnormal vibrations.
Do not operate the washer when the detergent box is removed.
This may result in electric shock or injury due to water leakage.
Do not torch the inside of the tub during or just after drying as it
is hot.
This may result in burns.
Do not insert your hand into the detergent box after opening it .
This may result in injury as your hand may be caught by the
detergent input device.
Do not place any objects (such as shoes, food waste, animals)
other than laundry into the washer.
This may result in damage to the washer, or injury and death in
the case of pets due to the abnormal vibrations.
Do not press the buttons using sharp objects such as pins,
knifes, fingernails, etc.
This may result in electric shock or injury.
Do not wash laundry contaminated by oils, creams or lotions
usually found in skincare shops or massage clinics.
This may result in the rubber seal becoming deformed and water
leakage.
Do not leave metal objects such as a safety pin or hair pin, or
bleach in the tub for long periods of time.
This may cause the tub to rust.

6
IMPORTANT SAFETY WARNINGS
IMPORTANT SAFETY WARNINGS
If rust starts appearing on the surface of the tub, apply a
cleansing agent (neutral) to the surface and use a sponge to
clean it. Never use a metal brush.
Do not use dry cleaning detergent directly and do not wash,
rinse, or spin laundry contaminated by dry cleaning detergent.
This may result in spontaneous combustion or ignition due to the
heat of the oxidation of the oil.
Do not use hot water from water cooling/heating devices.
This may result in problems with the washer.
Do not use natural hand-washing soap for the washer.
If it hardens and accumulates inside the washer, it may result in
problems with the product, discolouration, rust or bad odors.
Do not wash large laundry items such as bedding in the washing
net.
Place socks and brassieres into the washing net and wash them
with the other laundry.
Failure to do so may result in injury due to abnormal vibrations.
Do not use hardened detergent.
If it accumulates inside the washer, it may result in water leakage.
For washing machines with ventilation openings in the base,
ensure that the opening is not obstructed by carpet or any other
obstacles.
Make sure that the pockets of all clothing to be washed are empty.
Hard, sharp objects, such as coins, safety pins, nails, screws, or
stones can cause extensive damage to the appliance.
Do not wash clothing with large buckles, buttons, or other heavy
metal.
Sort the laundry by color on the basic of its colorfastness and
select the recommended cycle, water temperature, and additional
functions.
Failure to do this may result in discoloration or fabric damage.
Take care that children’s fingers are not caught in the door when
you close it.
Failure to do this may result in injury.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This
appliance is equipped with a cord having equipment-grounding
conductor and a grounding plug. The plug must be plugged into
an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with a qualified electrician
or serviceman if you are in doubt as to whether the appliance is
properly grounded.
Do not modify the plug provided with the appliance-if it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
WARNING

7
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
WARNING
Certain internal parts are intentionally not grounded and
may present a risk of electric shock only during servicing.
Service Personnel-Do not contact the following parts while
the appliance is energized: Electrical Valve, Door Lock,
Drain Pump, UI Board, Motor Controller and Reactor.
Remove all the packing(including the
foam base) or the vibration and noise
may occur.
Dispose all the wrappage safety and
keep them out of the reach of children.
Danger of suffocation!
It is normal that water drops appear on
the packing plastic bag and the door glass, which are resulted
from the water left in the tub for checking out.
Unpacking
Accessories
Make sure that you have received all of the items shown below.
Name Name
Inlet hose 1
4
Accessories Qty. Accessories Qty.
transit bolts
caps
“U” piece 1
Manual 1
Removing transit bolts
Remove all the transit bolts at the
rear of the machine with tools.
Plug the holes with the transit
bolts caps supplied.
Keep the transit bolts for future
transportation. Whenever the
machine is transported, the
transit bolts must be refitted.
Transit bolts
Strong vibration, noise or failures may occur if
the transit bolts are not removed.
NOTE
Installation place requirement
A concrete floor is the most suitable
installation surface for a washing
machine, being far less prone to
vibration during the spin cycle than
wooden floorboards or carpeted
surface.
The machine must be level and
securely positioned. The distance between the machine and wall
must be more than 10 cm .
To avoid vibrations during spinning. the machine should not be
installed on soft floor coverings.
Level adjustment
The machine must stand perfectly level on all four feet to ensure
safe and proper operation. Incorrect installation may increase
electricity and water consumption and may cause the machine
to move about.

INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
8
To do these when the machine
is not level:
Using the spanner turn
locknut in a anticlockwise
direction. Then turn locknuts
together with adjust feet to
unscrew.
Use a spirit level to check the machine is standing level.
Hold adjust feet securely with a pipe wrench. Turn locknut again
using the spanner until it sits firmly up against the housing.
Adjustable feet
Locknuts
Loose Locked
Low
High
NOTE Vibration and noise may occur if the locknuts
do not sit firmly up against the houses.
Drain hose connection
1.Direct into a sink
If the outlet spigot has not been used before, remove any
blanking plug that may be in place.
Push the drain hose onto the spigot and secure with a clip if
required, ensure a loop is formed in the drain hose to prevent
waste from the sink entering the washing machine.
If required, the drain hose can be extended to a length of 4 m.
2. Connected securely to a standpipe
Firstly form a hook in the end of the drain hose using the “U” piece
supplied.
Place the drain hose into your standpipe, which should have an
internal diameter of approximately 30mm thus ensuring there is
an air break between the drain hose and standpipe.
When discharging into a standpipe ensure that the top fo the
standpipe is no more than 90cm and no less than 60cm above
floor level.
“U” piece
supplied
Loop
Water inlet connection
Connect the inlet hose supplied with the
machine to a tap with a 3/4" thread.
Do not use previously employed hoses.
Installation should comply with local water
authority and building regulations
requirements.
There are two inlet valve, one is connected
to a cold water supply and the other is
connected to a hot water supply. Follow the
indication of the picture below to complete
the connection.

9
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Stacking Kit
In order to stack this dryer, an Galanz stacking kit is required.
Dryer
Washer
1"
(25mm)
5"
(127mm)
2"-5"
(50mm-127mm)
1"
(25mm)
Only an Galanz
DO NOT attempt to stack this dryer on any other washer, as
damage, injury or property damage could result.
dryer can be stacked on top of This washer.
INSTALLATION INSTRUCTIONS
TOOLS AND PARTS
Installation Requirements
Gather the required tools and parts before starting installation
Tools Needed:
Flat-blade screwdriver #2 Phillips screwdriver
Min. 8" long
screwdriver
TORX®T20®†
1/4" and 5/16" nut driver
(recommended)
Channel locks Wire stripper (direct wire
installations)
Pliers Tape measure
Level Utility knife
inlet valve for cold water
inlet hose for cold water with a white nut
inlet hose for hot water with a white nut
inlet valve for hot water

INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
10
WASHER DIMENSIONS
Front view Side View
The maximum weight the shelf can support is 26 lbs. (12 kg).
The stacked washer/dryer must be installed directly on the floor
and not elevated with a pedestal.
Max.26lbs
Stacking kit×1
Bracket×2Screw×6
Stacking Kit (GLSK24WE01)
Contents
TO USE STACKING SHELF AND HANGING
RACKIMPORTANT:
23.4"
33.3 "
26.2"
43.5"
0.3"
Adjustable wrench that
opens to 1" (25 mm) or
hex-head socket wrench

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
11
Product Overview
Knob
Drawer (for detergent or
fabric softener)
Door glass
Door
Drainage pump damper
Drain pump filter
Top cover
Control panel
Case body
Door seal
Drain hose
Adjustable feet
Unscrew the drain pump filter to let water run out
when the machine is not used for a long time.
NOTE
Connection Cable
Cold water inlet valve
Hot water inlet valve
Transit bolts
Back cover
The drawing of machine in the manual is only used
for instruction.
It may be vary from the model you buy.
NOTE
To reduce the risk of fire, electric shock ,or injury to persons,
read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
WARNING
Press this button to start or pause a wash cycle.
Press this button repeatedly to change the spin speed.
The detail is in the form on page 12.
1. Start/Pause
3. Speed
2. Rinse+
Press this button repeatedly to change the rinse times.
The detail is in the form on page 12.
4. Temp
Press this button repeatedly to change the wash temperature.
The detail is in the form on page 12.

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
12
Press this button repeatedly to set the delay time of the starting of
a wash cycle form 1 hour to 24 hours.
5. Delay
6. Knob
Turn the knob clockwise or anticlockwise to select the required
wash program. Once you press the Start/Pause button and the
machine is running, the program can not be changed. The details
of programs are in form on page 12.
(Note: At the end of a wash cycle, the knob must be turned to
the position“ ”)
NOTE
For your safety, please not turn the knob to the
position “ ” and get clothes while the machine
is running. Because the temperature of water
may be high and it may scald you. The door lock
will open automatically at the end of a wash cycle
while the tem-perature of the drum is cool down.
Child lock (“Rinse+ ” + “Speed”)
Mute ( )“ ”Rinse+
The function of “Mute” is to close all the prompt tones and alert sounds.
How to start this function: Press the “Temp” button for 3 seconds.
How to cancel this function: Press the “Temp” button for 3 seconds again.
The function of “Child lock” is to lock the control panel to prevent
the misuse by children.
1. press the “Temp” and “Speed” buttons at the same time for 3
seconds.
When the icon “ ” is lighted up on the screen, the function
works. This function can be selected during a washing cycle.
2. When this function works, all keys and knob are not available,
except for the knob turn to the position “ ”
Options and functions for programs
Normal
Deep Clean
Eco Wash
Allergen
Denim
Bulky
Tub Clean
Spin
Rinse+Spin
Night Wash
Quick
Mixed Fabrics
Delicate
Wool
Perm Press
Program X-hot Hot
Temp
Warm Cold High Med Low
Spin speed
No spin Extra rinse Delay
The capacity of this washing machine is 2.22cuft.
Do not wash more than 22lbs of clothes at one time.
NOTE

Diagram 2
Diagram 1
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
13
Display icon explanation
X-hot
Digital display: This icon shows the time, speed, rinse times, Error code.
Use this setting for heavily soiled colorfast fabrics such as towels, bedding, and children’s
clothing.
Hot Use this setting for heavily soiled white or colorfast cottons and blends.
Warm Use this setting for normally soiled white or colorfast cottons and blends.
Cold Use this setting for lightly soiled non-colorfast items, knits, delicates, an hand washables.
High High spinning speed. Used for underwear, t-shirts, jeans, and sturdy cottons.
Med Medium spinning speed. Used for jeans, wrinkle-free or wash-and-wear items and synthetics.
Low Low spinning speed. Used for delicate items that requires a lower spinning speed.
No spin The drum does not spin after the final drain process.
Child lock: this icon will shinning once child lock function is selected, otherwise will gone.
Door lock: this icon will shinning when door lock is working, otherwise will gone.
Main wash: The logo will be bright in standby condition when selected the program with main
wash function, the logo will be flicked when machine during operation, and the logo will stay
bright when machine in parse condition, the logo will be turn off when machine finishes
operation.
Rinse: The logo will be bright in standby condition when selected the program with rinse
function, the logo will be flicked when machine during operation, and the logo will stay bright
when machine in pause condition, the logo will be turn off when machine finishes operation.
Final spin: The logo will be bright in standby condition, the logo will be flicked when machine
during operation, and the logo will stay bright when machine in pause condition, the logo will
be turn off when machine finishes operation.
Once you select the “Night Wash” program, the machine will not execute the last
drain unless the “Start/Pause” button is pressed, and the screen show “Iron”.
(Note: the max running time of this function is 12 hours . If it exceeds 12 hours,
the machine will drain and spin automatically).
NOTE
It can remove the water which is left
in the tub because of manufacturer’s
checking out.
Before washing clothes for the
first time, you must run a complete
cycle without clothes.
To do these:
1.Connect the power and turn on the tap.
2.Turn the knob to position “Normal”.
3.Press “Start/Pause”.
Washing preparation
1.Connect the inlet hoses well and turn
on the tap.
2.After making sure the power socket is
grounded reliably, insert the power plug
into the power socket.
3.Place the drain hose well.
1.Sort the laundry by colour
and by care label. Most
garments have a textile care
label in the collar or side seam.
2.Make sure all the pockets
are empty, Foreign objects
(e.g. nails, coins, paper clips,
etc.) can cause damage to
garments and components
in the machine.
Preparation of clothes

OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
14
3.Close any zips, fasten hooks and eyes etc before
washing.
4.Dark textiles often contain excess dye and should
be washed separately several times before being
included in a mixed load. Always wash whites and
coloureds separately.
5.Badly soiled areas, stains etc. should be pre-treated with liquid
detergent, stain removers etc.
6.Turn over the clothes which pill easily and is with woolen
surface before putting them into the machine.
Diagram 3
Unfold the laundry and load loosely in the drum. Mixing both large
and small items gives better wash results and also helps distribute
the load evenly during spinning. The most efficient use of energy
and water is achieved when a full load is washed. However, do not
overload as this causes creases and reduces cleaning efficiency.
Put clothes into the washer
Make sure that no garments
are caught between the door
and the seal.
NOTE
Using the detergent drawer
1.Open the drawer and add adequate detergent into main wash
compartment marked “ ” or “ ”.
2.Add the fabric softener into compartment marked “ ” or “ ” .
Do not exceed the maximum level mark.
3.Add the detergent into the pre-wash compartment marked
“ ” or “ ”
Only some models have pre-washing function.
4.Close the drawer.
The right amount to dispenser will depend on the following:
The quantity of laundry
The soiling level of the laundry
- Lightly soiled
No visible dirt or stains.
Possibly slight body odour.
- Normally soiled
Visibly dirty and/or just a few
slight stains.
- Heavily soiled
Visible dirt and stains and/or dried on soiling.
The water hardness level.
Main wash compartment
Fabric softener compartment
Pre-wash compartment
It is recommended to use low foaming powder for all
washing temperature programs.
NOTE
Washing steps
1.Turn on the water tap, and connect the power.
2.Open the door, and put the cloth into the drum one by one.
3.Close the door, and put suitable amount of detergent and fabric
softener into the dispenser, then close the drawer.
4.Choose a programme you need by turning the knob .
5.Press the “Temp” button and select a washing temperature.
6.Press “ Start/Pause” button to start the washing machine.
7.When the cycle is finished, there is a warning tone sounds.
When washing cycle is finished, the machine will
change into standby mode. And the machine will
be sleeping after 10 minutes without any control on
the control panel.
NOTE

15
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Washing programme chart
Normal
Deep Clean
Eco Wash
Allergen
Denim
Tub Clean
Rinse+Spin
Night Wash
Mixed Fabrics
Delicate
Perm Press
Programme
Bulky
Spin
Quick
Wool
Washing symbol Fabric
Cottons, linens or cotton mix fabrics, e.g. table linen, towelling,
underwear, T-shirts etc.
Cottons, linens or cotton mix fabrics, e.g. table linen, towelling,
underwear, T-shirts etc.
Machine-washable or hand-washable wool or wool blend fabrics.
If the care label does not specify a temperature, wash using the
cold setting. Also suitable for hand-washable silks.
Reduce the spin speed.
Small loads of items which require freshening up and which can
be washed in a Cotton programme.
Separate spin for cotton and linen items
Synthetic or mixed fabrics, underwear, coloured garments,
non-shrink shirts
This programme can be used for rinsing items which can be
washed in a Cotton programme. Do not add any detergent.
Cottons, linens or cotton mix fabrics, e.g. table linen, towelling,
underwear, T-shirts etc.
Wash clothes at 85°C, which would help for sterilization and
disinfection.
Clothes with large volume.
Cottons, linens or cotton mix fabrics, e.g. table linen, towelling,
underwear, T-shirts etc.
Jeans, denim or denim mix fabrics.
This programme is used for cleaning the drum. Do not put any
clothes in the drum while running this programme.
Sheer fabrics, bras, lingerie (silk), and other handwash fabrics.
Wash-and-weau, synthetic fabrics, and lightly to normally soiled
items.
NOTE
The machine is fitted with a balance control
device, which ensures the machine is stable
during the spin. To protect the machine, it will
cut in if the laundry is not evenly distributed in
the drum. The laundry is redistributed by
reverse rotation of the drum. This may happen
several times before the unbalance disappears
and normal spinning can resume. If, after 15
minutes, the laundry is still not evenly
distributed in the drum, the machine will not
spin. In this case, redistributed the load
manually and reselect the spin programme.
Door lock
When the machine is started, the door lock is
locked. The door can be opened if you press the
“Start/Pause”button during a cycle except the
following two cases.
When the temperature inside the drum is above
60℃, the door lock is locked.
When the water is above a certain level, the door
lock is locked.
Important:
Do not try to open the door when the
washing cycle is not finished or power
supply is cut off during the washing cycle,
because the temperature may be high and
you may be scalded.

MAINTENANCE INSTRUCTIONS
MAINTENANCE INSTRUCTIONS
16
Certain internal parts are intentionally not grounded and
may present a risk of electric shock only during servicing.
Service Personnel-Do not contact the following parts while
the appliance is energized: Electrical Valve, Door Lock,
Drain Pump, UI Board, Motor Controller and Reactor.
WARNING
To reduce the risk of electric shock, disconnect this
appliance from the power supply before attempting
any user maintenance. Turning the controls to the
OFF position does not disconnect this appliance
from the power supply.
Do not clean the appliance by spraying water directly onto it.
Do not use benzene, thinner or alcohol to clean the appliance.
This may result in discolouration, deformation, damage, electric
shock or fire.
Before cleaning or performing maintenance, unplug the
appliance from the wall socket.
Failure to do so may result in electric shock or fire.
Cleaning the exterior
Clean the exterior with a mild non-abrasive cleaning agent or soap
and water using a well wrung-out cloth. Wipe dry with a soft cloth.
Do not use solvents, abrasive cleaners, glass cleaners or
all-purpose cleaning agents.
These might damage plastic surfaces and other
components because of the chemicals they contain.
The washing drum
Clean the drum every 3 months by using the “Drum clean” programme.
Cleaning the drawer
Remove detergent residues regularly.
Clear the drawer following these:
Pull out the drawer until a resistance is
felt. Press down the release catch and
at the same time pull the drawer right
out of the machine.
Remove the siphon from compartment
and clean it.
Clean the dispenser using a brush and
warm water.
Cleaning the drawer housing
Use a bottle brush to remove
detergent residues inside the
drawer housing.
Use pointed nose pliers to withdraw
the plastic filter. Clean, put back and
secure. These filter should be checked
every 6 months or so, or more often if
there are frequent interruptions to the
water supply.
Cleaning the water inlet filter
Warning The filter must be put back in place after cleaning.

17
MAINTENANCE INSTRUCTIONS
MAINTENANCE INSTRUCTION
Cleaning the drain pump filter
The filter should be cleaned every 2 months
or when there is fault that the “E03” is on
the screen.
1. Disconnect the machine
from the mains electricity
supply and open the lower
cover with a screwdriver.
2. Place a container
under the pump.
Unscrew and remove
the filter.
3. Clean the filter
carefully.
NOTE
1. Change the water inlet.
2. Check the connection and
ensure it is secure.
3. Change the water sensor.
1. The water inlet valve is
damaged.
2. The connection between
the water sensor and wire is
not secure.
3. The water sensor is
damaged.
Possible Cause
The machine
fills overtime.
There is
a Door
lock alarm.
1. Water tap is not open.
2. Drain hose is put down.
3. Water inlet valve is damaged.
1. Open the water tap.
2. Hook up the hose.
3. Change the water inlet valve.
“E01” is
on the
screen.
Problem Error Code
The machine
drains
overtime.
Water
overflows
the machine./
Water sensor
works
abnormal.
1. Check the drain hose.
2. Clean the filter.
3. Check the drainage system
and clean it.
1. The drain hose is squashed
or kinked.
2. The drain pump filter is block.
3. The drainage system pipes
are blocked.
1. Lock the door well.
2. Put the garment into the
drum.
3. Change the door lock.
1. The door is not locked well.
2. Garments is caught between
the door and seal.
3. Door lock is damaged.
Solutions
“E02” is
on the
screen.
“E03” is
on the
screen.
“E04” is
on the
screen.
Important:
If the machine is exposed to temperatures below 0°C, certain precautions should be taken.
1. Turn off the water tap.
2. Unscrew the inlet hose.
3. Unhook the drain hose from the rear support and position the end of this hose and that
of the inlet hose in a bowl. Run the spin programme.
4. Disconnect the appliance.
5. Screw the inlet hose and reposition the drain hose.
6. When you intend to start the machine up again, make sure that the room temperature
is above 0°C.

18
1. Check the connection and
ensure it is secure.
2. Change the temperature
sensor.
1. The connection between the
temperature sensor and wire is
not secure.
2. The temperature sensor is
damaged.
“E07” is
on the
screen.
There is a
temperature
sensor fault.
1. Check the connection and
ensure it is secure.
2. Change the heating tube.
1. The connection between
the heating tube and wire is
not secure.
2. The heating tube is
damaged.
1. Check the connection and
ensure it is secure.
2. Check if the machine is
overloaded. Switch off the
machine, and retry when the
motor becomes cool.
3. Change the motor.
1. The connection between the
motor and wire is not secure.
2. The motor is protected
because of over-heat.
3. The motor is damaged.
The motor
does not
work.
“E05” is
on the
screen.
There is a
heating tube
fault.
“E06” is
on the
screen.
MAINTENANCE INSTRUCTIONS
MAINTENANCE INSTRUCTIONS
Specification and Parameters
1200
69/74
595 X 665 X 845mm
120V, 60Hz
Water pressure (MPa) 0.02-0.8
Washing/spin Capacity (cu. ft.)
Dimensions (W*D*H)
Rated Voltage (AC V/Hz)
Rated power (W)
Weight (kg)
2.2
Note:
Data can vary from the nominal values given depending on water pressure,
water hardness, water inlet temperate, room temperature, type and volume
of load, fluctuations in the electricity supply and any extra options seleceted.
