Galcon Fertijet Assembly instructions

Revision 1.0 - May 2019
Fertigation Control System
Fertijet
Installation Guide
User Manual

2Fertijet- Installation Guide and User Manual
Table of content
Introduction ���������������������������������������������������������������������������������������������������������� 3
Safety ������������������������������������������������������������������������������������������������������������������� 4
Installation requirements �������������������������������������������������������������������������������������� 5
Fertilizer and acids types & concentration ����������������������������������������������������������� 7
Assembly�������������������������������������������������������������������������������������������������������������� 8
Maintenance������������������������������������������������������������������������������������������������������� 16
Troubleshooting ������������������������������������������������������������������������������������������������� 19
Illustrated part list����������������������������������������������������������������������������������������������� 21
Appendix 1 ��������������������������������������������������������������������������������������������������������� 24

3Fertijet- Installation Guide and User Manual
INTRODUCTION
We thank you for trusting the core of your growing success in our hands�
We in Galcon are fully aware how critical the performance and the reliability of your machine is
for your yields, and we are fully committed for supporting and serving this product�
In this manual you will nd general information on how to unpack, connect, adjust
and operate your new Fertijet machine. Fertijet machines comes with variety
of booster pumps, Dosing channels, dosing valves and even pipe dimensions�
Those components are subject for occasional changes as technology advances,
and therefor will only be described here in a general�
Fertijet can be operated either by Galileo Greenhouse app or Open-Field app,
and even by other, non-Galcon controllers. For operation please refer to the
specic applications guiding book.
Multi-channel fertigation machines are needed because some fertilizers cannot
be mixed with others�
Study your fertilizers and avoid wrong mixing� Failing it will result a quick ceramic
sedimentation in the system that is very hard to remove�
Follow the instructions hereby step by step and don’t hesitate to contact our
local representative if necessary�

4Fertijet- Installation Guide and User Manual
SAFETY
All hazardous electric voltage jobs must be conducted by a local qualied
electrician and according to local regulations�
Do not leave the electric cabin, the motor cover or any junction box
opened while the machine at work or while you are away�
Some fertilizers and all acids are hazardous:
a� Store them in a locked place, away from reach of children and animals�
b� Always wear rubber-gloves and protecting-glasses when handling
them�
c� Never pour water or other liquids into concentrated acid!
d� Wear a full-face mask when mixing acids.
e� Mark your stock tanks clearly, stating the danger in each�
f� Install a hands-free eye washing sink within a range of 15m from
where the fertilizers are prepared�
All possible out-takes downstream the Fertijet must be
clearly marked NOR FOR DRINK�

5Fertijet- Installation Guide and User Manual
Main line inlet:50mm (1½”) + Ball valve�
Length of inlet: 1,500mm (60”) to Ensure good mixing
(2 elbows or mixing chamber)�
Main line outlet: 50mm (1½) + ball valve� Keep minimal length of the
connecting pipes�
Foundation: Concrete plate or pavement 4000*4000 mm.
anchor the Fertijet frame to the base.
Environment: Shaded and protected from rain and hail�
Power supply: EU, Africa, Asia, Oceania: ~1 220v, ~3 400V 50Hz
Americas: ~1 120v, ~3 220V, 400V, 480V 60Hz
Japan: ~ 3 200V 60Hz
LT tested: 5Ωor less�
Max elevation above dosing valves: 2,500mm (top of tank)
Min elevation below dosing valves: 1,000mm (Bottom of tank)
100μ (130 mash) lter size ¾” or larger.
Ensure that any excess or leak of fertilizer is properly handled according to local regulations�
Nominal working pressure: Dene at ordering
Minimum working pressure: Standard - 3.5 bar
Maximum static pressure: 7�5 bar
Hammer shock prevent setting: 9�5 bar
INSTALLATION REQUIREMENTS

6Fertijet- Installation Guide and User Manual
To avoid the injection of chemicals to pipelines when not irrigating -
Verify on each installation:
A� Water meter with electric pulse is mandatory on the pipe-line that
the Fertijet is connected, before any distribution. The pulse size
must enable reading (2 pulses) in less than 1 minute�
B� Verify the validity of the water meter and its pulse daily�
C� We strongly recommend an additional pressure switch to be
connected to the controller as a delay condition element�
D� Backow preventer must always be installed upstream the Fertijet,
unless direct pumping from irrigation-dedicated lagoon.

7Fertijet- Installation Guide and User Manual
FERTILIZER AND ACIDS
TYPES & CONCENTRATION
a� All soluble fertillizer are permitted as liquids only�
b� Maximum viscosity 20 cPa∙s.
c� Acids:
TypeRaw productDilute in water
1:898%Sulphuric Acid H2SO4
1:585%Phosphoric Acid H3PO4
1:360%Nitric Acid HNO3
d� Mixture limitation table:
Ammonium
Nitrate
Ammonium
Phosphate
MAP
MKP
Potassium
Nitrate
Potassium
Chloride MOP
Potassium
Sulfate
Calcium
Nitrate
Calcium
Chloride
MAG
Magnesium
Sulfate
Urea
Ammonium
Nitrate
Ammonium
Sulfate
MAP
MKP
Potassium
Nitrate
Potassium
Chloride MOP
Potassium
Sulfate
Calcium Nitrate
Calcium Chloride
Explanation for the table above:
a� Red or Gray combinations do not mix in the same stock tank!
b� In most cases 1 kg fertilizer per 3 litters of water will allow complete dissolve�
If temperature drop below 15°C (56°F) 1:3�5 is complementary�

8Fertijet- Installation Guide and User Manual
ASSEMBLY

9Fertijet- Installation Guide and User Manual

10 Fertijet- Installation Guide and User Manual

11 Fertijet- Installation Guide and User Manual

12 Fertijet- Installation Guide and User Manual

13 Fertijet- Installation Guide and User Manual

14 Fertijet- Installation Guide and User Manual

15 Fertijet- Installation Guide and User Manual

16 Fertijet- Installation Guide and User Manual
MAINTENANCE
End of
season
QuarterlyMonthlyWeekly
1 month after
the rst
operation
ActionComponent
Pull down the key of
Fertijet׳s main thermo
magnetic switch supply
and tighten all the screws
of the electrical board�
Check the insulation and
sulfation of the cables
and terminals�
Check the electrical oset
between the supply lines
and the electro pump�
Check the protection
breaker of the electro
pump�
Electrical
Connections
Cleaning with water�
Cleaning with acid�
Fertilizer
tanks lters
Flow clean water for 5
minutes�
Chek the gaskets and
gears�
Measure the insulation of
the electropump motor�
Fertijet
electropump
Wash out the crystallized
minerals and lubricate the
plunger with silicon oil�
Electrovalves
24v
Wash out the crystallized
minerals in veturis and
owmeters.
Chek the regulation of the
owmeters knobs.
Venturi
fertilizer
injectors
Cleaning electrodes and
sampling cells�
Electrodes calibration�
Change of electrodes�
Ec/ph
electrodes

17 Fertijet- Installation Guide and User Manual
winterization
Winter time in frost-tend area may become harmful for all irrigation components
if not well prepared�
The following steps guide you to safe winterizing� Follow them strictly�
The best time to begin winterization actions is the morning following the last
day of the irrigation Season�
Winterizing
1� Wash all remains of corrosive materials� Fill fresh water in the fertilizer tanks
(in case you have some Fertilizer left for next season, ll a bucket with water
and place it instead of the tank) and operate The system with a program
that will use all the injectors. Ensure a leach of 20 liters (4 gallons) atleast for
each injector.
2� Close all manual valves and turn o all pumps switches. Dene the Elgal
controller “not active”�
3� Disconnect the machine inlet and outlet pipes from the main pipe and tip
their content o.
4� Apart all the available records and bleed any remains of water from the
venturi injectors, electric Valves, check valves and other parts.
5� If main fertilizer nc valves exist – make sure to dry all the 8 mm command
hoses, the solenoid Valve, and both upper and lower chambers of each
valve�
6� Open the booster pump’s draining cork and leave it opened for one hour�
7� Verify draining of all pipes�
8� Remove one of the probes from the ec-ph sampling cell and drip-in 50cc
(2 oz) of concentrated antifreeze material� Return the probe to its place and
fasten its bolt�
9� Clean the machine of all external remains of corrosive materials� Cover the
machine with a sheet�
Do not shut down the controller’s power supply, leaving the elgal
controller powered o for long Time may cause extensive use of the memory
and shorten its life�

18 Fertijet- Installation Guide and User Manual
EC/PH Electrodes
Clean the EC/pH electrodes on a weekly basis� Thus it is recommended to
remove any impurity on the electrodes for 10 minutes with the acid solution
prepared in the acid tank�
Use 4.0 and 7.0 Buer solutions for the pH, and the 1.4 mS/cm solution for
the EC�
For the pH electrode, measure how long it takes the electrode to reach a
reading of 4�0 to 7�0� For this exercise use the pH 4�0 and 7�0 solutions; Whereas
if the time elapsed exceeds 30 seconds, the pH electrode should be replaced to
assure control�

19 Fertijet- Installation Guide and User Manual
TROUBLESHOOTING
Symptom Possible reason Sulution
The booster pump
doesn’t start when
commanded�
a� Check the main
power�
b� Check the ~24v
breaker in the Fertijet.
c� Check the ~24V fuse
in the Galileo�
d� Make sure line
pressure is above the
stated value of the
pump�
The booster pump
rotates but no suction
power�
a� Check the motor
direction� It must be
as indicated by the
arrow on the motor or
on the pump body�
b� Open the union (or
ange) at the pump
inlet and verify the
free ow of water into
the pump�
a� Change the
sequence between
2 phases (By
electrician)
Dierence between the
line pressure and the
suction pressure is less
than 25 m
Check if the venturi
blocks orice has been
deformed and replace
them if necessary�

20 Fertijet- Installation Guide and User Manual
Symptom Possible reason Sulution
The pressure gauge
between the Venturi and
the pump often indicates
-5 m or less.
Increase the line
pressure or adjust the
PSV at the pump outlet
to higher pressure�
Dosing valve doesn’t
respond to command�
Replace the dosing
valve�
Dosing valve ‘ticks’ but
no ow is detected.
a� Check the fertilizer
supply� Saturated
fertilizer sometimes
crystalizes at cold
environment�
b� Check the inner parts
of the dosing valves�
c� Check the non-
return valve and the
venturi inlet for chips
of plastic that may
escaped the tank’s
lter
a� Dissolve with water
b� Some of the valve
parts, like spring
and diaphragm are
replaceable�
