Gallo Acoustics ROOMSUB User manual

ROOMSUB
OWNER’S GUIDE

CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
PRODUCT DISPOSAL
INTRODUCTION AND RUN-IN
PLACEMENT OF SUBWOOFER
CONTROLS AND CONNECTIONS
2.1 SET-UP
MULTI-CHANNEL SET UP
SPECIFICATION - ROOMSUB 8
SPECIFICATION - ROOMSUB 10
WARNING AND WARRANTY
TECHNICAL SUPPORT
3
4
4
5
6
7
9
10
11
12
13
14

4
IMPORTANT SAFETY INSTRUCTIONS
All safety instructions should be read and followed
before the product is operated.
WARNING
DO NOT OPEN OR REMOVE ANY COMPONENTS -
DANGER OF ELECTRICAL SHOCK. THERE ARE NO
USER SERVICEABLE PARTS INSIDE.
ALWAYS PROVIDE ADEQUATE VENTILATION AS THIS
PRODUCT MAY BECOME HOT DURING USE. DO NOT
PLACE NEAR A HEAT SOURCE OR COVER.
FURTHER ADVICE
Do not use this product near water or moisture,
or heat sources like radiators.
Only use the power cable supplied.
Route the power cable away from areas where it
could be damaged or walked on.
Do not overload wall sockets or extension cords.
If there is any damage or failure, unplug the
subwoofer from the wall socket immediately
and consult qualified sources for advice.
In the event of a failure, contact your dealer,
distributor or Gallo Acoustics directly to arrange repair.
PRODUCT DISPOSAL INSTRUCTIONS
(WEEE DIRECTIVE)
The symbol shown here means that it is classed as
Electrical or Electronic Equipment and should not be
disposed with other household or commercial waste
at the end of its working life.
The Waste of Electrical and Electronic Equipment
(WEEE) Directive (2002/96/EC) has been put in place
to recycle products using best available recovery and
recycling techniques to minimise the impact on the
environment, treat any hazardous substances and
avoid the increasing landfill.
For more information please contact your local
authority or the retailer where the product was
purchased.

INTRODUCTION
Thank you for choosing Gallo Acoustics.
Please take the time to read and understand this
guide thoroughly before installing your RoomSub.
This will ensure that you achieve optimal
performance without the risk of causing damage to
your subwoofer, speakers or amplifier.
ROOMSUB FRONT ROOMSUB BACK
RUN-IN PERIOD
Your Gallo Acoustics RoomSub utilises technologies
that only reach their optimum performance levels
after a period of 20 - 40 hours of use. During this
run-in process the loudspeaker driver will loosen-up,
and your subwoofer will develop the acoustic
characteristics that are our signature.
5

RoomSub
RoomSub
PLACEMENT
The placement of your RoomSub subwoofer within
the room is not as critical as speaker placement, since
frequencies of 80Hz and below are non-directional. This
allows you to place the subwoofer wherever you want
in the room.
• Ensure that the PHASE control is used properly.
As a general rule, if the subwoofer is in front of the
listening position have the PHASE control at 0º.
If the subwoofer is behind the listening position,
then set the PHASE to 180º.
• Disconnecting your loudspeakers so you are only
listening to bass playback will help as you try to
find areas of the room where bass is overpowering,
or where bass is lacking.
Another tactic would be to select several positions that
will suit the aesthetics of the room, and try each
position in turn to see which position provides the best
response. The settings of the subwoofer can then be
tailored to suit the position.
6

CONTROLS AND CONNECTIONS
7
FRONT CONTROL PANEL
REAR CONNECTOR PANEL

CONTROLS
CROSSOVER
The CROSSOVER control is variable from 50Hz to
180Hz. In simple terms, the subwoofer will play all
frequencies below the CROSSOVER setting.
LEVEL
The LEVEL control sets the volume of the subwoofer
in relation to the main speakers. Once set, volume
will climb and decrease along with your main system
volume.
PHASE
The PHASE control allows you to adjust the phase
of the subwoofer relative to the main speakers. This
helps when positioning the subwoofer - in general, if
the subwoofer is in front of the listening position have
the PHASE set to 0º. If the subwoofer is behind the
listening position, then set the PHASE to 180º.
POWER SWITCH
Set to either OFF, AUTO or ON. When set to AUTO,
the RoomSub will automatically detect a signal from
the source amplifier and, in turn, will power up the
subwoofer. It will also return to its standby mode
automatically when the source is no longer detected.
AC SELECTOR
This should already be set to the voltage used in your
country. It can be adjusted should you wish to a use
this product in a country where a different AC voltage
is used. Please note that the internal fuse should be
changed to suit the new AC voltage.
CONNECTIONS
LINE IN/OUT
This is used to connect your RoomSub to your
amplifier using a coaxial (RCA) cable. Connect the
subwoofer pre-out or LFE (SUBWOOFER) output on
your amplifier to the LINE-IN on the subwoofer.
POWER CONNECTOR
Plug the AC power cable here, and then into a mains
supply, do this after all other connections have been made.
USB CONNECTOR
This can be used to power external equipment such
as a wireless signal receiver. The USB connector can
output a maximum of 1 amp at 5 volts.
FUSE
The fuse protects RoomSub from abnormal power
conditions. If the subwoofer fails to power, check
this fuse and only replace with the type noted below:
110-120V AC Supply - T4AL/250V fuse
220-240V AC Supply - T2AL/250V fuse
8

2.1 SET-UP
When using your RoomSub in a 2.1 set-up, connect as
follows :
• Run speaker cables from your amplifier to your
loudspeakers.
• If your amplifier has a dedicated subwoofer output,
then this can be used to connect your amplifier to
the subwoofer using a single coaxial (RCA) cable.
Connect to the L/LFE LINE-IN on the subwoofer.
• If your amplifier has pre-outs, then this can be used
to connect your amplifier to the subwoofer using a
set of coaxial (RCA) cables. Take care to ensure you
have the left and right connected correctly
• On the subwoofer adjust the CROSSOVER to
around 100Hz, once the system is playing music,
you can adjust this to suit your loudspeakers
performance capabilities.
• When music is playing, you can adjust the LEVEL
control to match the subwoofer and loudspeaker
volume.
AMPLIFIER
SPEAKER SPEAKER
ROOMSUB SUBWOOFER
9

MULTI-CHANNEL SET-UP
When using a multi-channel surround sound system, first
ensure that you are familiar with your amplifier’s functions
to ensure that the correct mode and settings are applied.
• Identify your AV amplifier’s SUBWOOFER or LFE output.
Connect this to the L/LFE LINE-IN on the subwoofer
using a coaxial (RCA) cable.
Please note - You can use a Y-splitter to split the signal
into both left and right LINE-IN on the subwoofer.
Alternatively, some amplifiers have two LFE (SUBWOOFER)
outputs, which allows direct connection to both LINE-IN
connectors on the subwoofer via a twin coaxial (RCA) cable.
• Make adjustments on your AV amplifier to ensure that
the correct frequency range is being distributed to your
speakers and subwoofer.
For Gallo Acoustics Micro and A’Diva loudspeakers, use a
small speaker setting on your amplifier, to protect the
loudspeakers from the lowest frequencies.
• Turn the crossover dial to its maximum, as the AV
amplifier will handle bass control and distribute the
frequencies accordingly.
• When audio is playing, adjust the LEVEL control so
the subwoofer volume matches the satellite speaker
volume.
Consult both your AV amplifier and loudspeaker owner’s
guides for more detailed set up instructions of these
components.
SPEAKERS
AV AMPLIFIER
ROOMSUB SUBWOOFER
10

SPECIFICATION
ROOMSUB 8
Frequency Response 32Hz to 150 kHz +/- 3db
Class D Digital Power Amp 200W
Active low pass filter 50Hz to 180Hz, continually variable
Woofer 8” woofer with PP cone and NBR surround
Weight 12Kg
Enclosure Material MDF (Medium Density Fibreboard)
Warranty 2 years
DIMENSIONS
H - 34.2cm (13.46”)
W - 28.6cm (11.26”)
D - 28.6cm (11.26”)
11

SPECIFICATION
ROOMSUB 10
Frequency Response 32Hz to 160 kHz +/- 3db
Class D Digital Power Amp 300W
Active low pass filter 50Hz to 180Hz, continually variable
Woofer 10” woofer with PP cone and NBR surround
Weight 19Kg
Enclosure Material MDF (Medium Density Fibreboard)
Warranty 2 years
DIMENSIONS
12
H - 38.1cm (15”)
W - 32.5cm (12.79”)
D - 32.5cm (12.79”)

WARRANTY
Anthony Gallo Acoustics Ltd warrants to the end
user that this product will be free from defects in
materials and workmanship in the course of normal
use for a period of two years from the date of
purchase.
This guarantee covers breakdowns due to
manufacturing faults and does not apply in cases
such as accidental damage, general wear and tear,
user negligence, modification or repair not by
Anthony Gallo Acoustics Ltd.
www.galloacoustics.com
WARNING
Care must be taken positioning the subwoofer to ensure
that it won’t be damaged or knocked over.
If you are in any way unsure of the correct
installation or use then please consult qualified sources
before taking unnecessary risks.
The manufacturer, distributor or their agents cannot be held
responsible for any injury as a result of improper use or
installation of this product.
13

TECHNICAL SUPPORT
Should you encounter problems using this product,
please contact your dealer or local distributor.
You can call Gallo Acoustics directly for technical
support on the following numbers:
UK
01555 666 883
Outside UK
[phone]
United States, Canada and South America
[phone]
Alternatively, email -
[email protected]
14

ANTHONY GALLO ACOUSTICS LTD
THE INOX BUILDING
CALDWELLSIDE
LANARK
SCOTLAND
UNITED KINGDOM
ML11 7SR WWW.GALLOACOUSTICS.COM
