Galvin Safe-Cell 50101C Instruction sheet

Version 2, 13 June 2017, Page 1 of 4
Safe-Cell® Manual Prison Tapware
PRODUCT CODES:
- 50101C - 50104C
- 50107C - 50112C
SPECIFICATIONS
Designed for maximum protection against vandalism, Safe-Cell® basin/sink assemblies are made
from heavy duty components and can be installed from the rear.
The basin/sink assembly is made of chrome plated brass.
Quarter turn ceramic disc.
Machined cold or hot identification button.
Anti-ligature design.
Available with either Ezy-Grip or Multi-Grip handle (as shown above).
IMPORTANT: All Safe-Cell® wall top assemblies are tested in accordance with AS/NZS 3718 and leave our
premises in good working order.
TECHNICAL DATA
Inlet ½” CU/BSP
Outlet ½” CU/BSP
Headwork Ceramic
Working Pressure Range (kPa) Min 50
Max 500
Working Temperature Range (°C) Min 5
Max 75
Nominal Flow Rate (LPM) N/A
Finish Chrome
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without notice.
TOOLS REQUIRED
Power drill
Spanner and hex key
Thread tape

Version 2, 13 June 2017, Page 2 of 4
PRE-INSTALLATION - MOUNTING DETAILS
− If the mounting holes do not already exist, mark out
and drill the hole in the bench/trough to suit your
requirements.
Note: Before installation, all lines must be flushed.
We recommend that a line strainer be installed
prior to drinking taps to eliminate any foreign material.
Ezy-Grip
Multi-Grip
INSTALLATION
INSTALLATION COMPLIANCE: Galvin Specialised products must be installed in accordance with these
installation instructions and in accordance with AS/NZS 3500, the PCA and your local regulatory requirements.
Water and/or electrical supply conditions must also comply to the applicable national and/or state standards.
Failing to comply with these provisions shall void the product warranty and may affect the performance of the
product.
IMPORTANT: Whilst our product designs take into account a broad range of installation types and surfaces, it is
important that surfaces which fixtures are mounted to are flat and free from defect. This is especially important
when installing product ranges that have been designed for correctional and health facilities, where special
attention is required to minimise ligature points and areas for concealment of contraband. In addition to ensuring
the products are fitted securely and in accordance with the following instructions, consideration shall be given to
the use of non-pick mastics such as BASF Sonolastic “Ultra” to ensure a high quality and safe installation.
DRILL
33mm
1/2" CU/BSP
115
NOM
59
67
NOM
NOM
115
59
67
NOM
1/2" CU /BSP

Version 2, 13 June 2017, Page 3 of 4
1. Disassembly
Disassemble components, leaving bottom
nut on the body.
Do not remove the ceramic cartridge
2. Fit basin body
Insert the basin body assembly up through the pre-
cut hole.
3. Fit dress flange
Fit onto dress flange and hand tighten.
Tighten bottom nut
Tighten nuts holding the breach piece.
4. Fit dress flange with Anti-Rotation pin
If the anti-rotation option is required, fit dress flange
onto body and mark the basin/sink, remove the flange
and drill 3/16” hole
Replace the flange and screw in the grub screw to
lock.
5. Fit lock sleeve
Fit lock sleeve and tighten to lock entire
unit in position.
6. Assemble handle and test
Fit handle with tamper proof screw, ensure the correct
water temperature identification button is in the handle
Screw must be tightened before the unit is tested
Once temperature indicator is fitted, check the
operation of the unit and inspect for any leaks.

Version 2, 13 June 2017, Page 4 of 4
TROUBLESHOOTING
PROBLEM CAUSE RECTIFICATION
Taps are dripping water
Ceramic cartridge is worn or
damaged
Remove and inspect the cartridge,
remove debris and /or replace cartridge
if damaged
Tap seat is damaged Refurbish tap seat usiing a reseating
tool
Water is not flowing from tap Water is turned off Turn on water
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty
Ltd. With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied.
Galvin Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including
but not limited to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download
from www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free
from operational defects in workmanship and materials for the warranty period as shown on the schedule in
the manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any
defective products manufactured by Galvin Engineering without charge, so long as the terms of the
Manufacturer’s warranty are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy
for breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other
property which is damaged if this product does not work properly, other costs resulting from labour charges,
delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions,
chemical, electrical or any other circumstances over which Galvin Engineering has no control. This warranty
shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or
alteration of the product.
