Gardena Filter Set 5000 User manual

GARDENA
®
DGebrauchsanweisung
Filter-Set 5000
GB Operating Instructions
Filter Set 5000
FMode d’emploi
Kit de filtrage 5000
NL Gebruiksaanwijzing
Filterset 5000
SBruksanvisning
Filtersats 5000
IIstruzioni per l’uso
Set filtro 5000
EManual de instrucciones
Set de filtro 5000
PInstruções de utilização
Conjunto de filtragem 5000
DK Brugsanvisning
Filtersæt 5000
Art. 7919
www.devicemanuals.eu

11
G
10
G
In Austria power cables should correspond to ÖVE-EM 42,
T 2 (2000)/1979 § 22 according to § 2022.1. According to this
standard pumps used in swimming pools and ponds should
only be operated via an isolating transformer.
vPlease contact your electrician.
In Switzerland mobile appliances which are used outdoors,
must be connected via a residual-current device.
Before operating the pump, look to see if there is any damage
of the pump (esp. regarding power cable and plug). A damaged
pump must not be used. In case of damage, please have the
pump checked by our GARDENA Service Centre or by an
authorised electrician.
Data indicated on the type plate must match technical data of
the mains supply.
The pump must not be operated when there are people in the
water.
Swimming pools and garden ponds should be designed
according to international and national design regulations.
vPlease consult a professional electrician.
Do not use the power cable to carry the pump or to pull the
plug out of the socket. Protect the power cable from heat, oil
and sharp edges.
Always unplug the equipment when dismantling the set, when
it is not in use and before maintenance.
vAlways disconnect the pump from the mains before under-
taking any work on it.
vPlease follow the safety and assembly instructions in these
operating instructions.
The temperature of the liquid used must not be below 4°C
or above 35°C.
Sand and other abrasive substances in the liquid cause
increased wear and reduce the output of the pump.
vPlace the filter in a stable position alongside or in your
garden pond.
If the filter is placed alongside the pond, it must be set up
above the surface of the pond.
For Austria
For Switzerland
Visual check
Check line voltage
Do not operate pump
when there are people
in the water
Swimming pools
and garden ponds
Do not use power cable
to carry the pump
Disconnect plug
Temperature of the liquid
used
Wear and reduced
output
Positioning the filter
Intended purpose
Please note
GARDENA Filter Set 5000
Welcome to GARDENA aquamotion...
Please read these operating instructions carefully and follow the
instructions. Use the instructions to familiarise yourself with the
Filter Set, using it correctly and the safety information.
For safety reasons, children and young people under 16 years
of age and people who are not acquainted with these operating
instructions should not use this Filter Set.
vPlease keep these operating instructions in a safe place.
1. The Applications Range of Your GARDENA Filter Set . . . . . . . 10
2. For Your Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Mode of Operation of the Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4. Putting into Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6. Trouble-Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
7. Putting out of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9. Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1. The Applications Range of Your GARDENA Filter Set
The GARDENA filter set is intended for domestic use in your
garden where it should only be used alongside or in your garden
pond for cleaning garden ponds up to 5 m3in size with and
without fish.
The GARDENA Filter Set is not suitable for industrial use or in
combination with chemicals, food, easily combustible and explo-
sive substances. It is not intended for operating watering equip-
ment and systems.
Contents
2. For Your Safety
The pump should be operated via a residual current device
with a residual current rating of ≤30 mA (DIN VDE 0100-702
and 0100-738).
vPlease ask your electrician for his advice.
The pump must be placed on solid, even ground.
Mains power cables should not have a smaller cross-section
than a rubber sheathed cable of the designation H05 RNF.
Extension cables must meet the requirements of DIN VDE
0620.
Operating the pump
Mains power cables
www.devicemanuals.eu

13
G
12
G
Starting up the filter set :
A
E
D
C
B
1
A
C
1
B
ED
Filter set up alongside the pond:
1. Place the filter container Ain a stable position alongside the
garden pond.
2. Set up the pump 1in a stable position in the garden pond so
that the pump is completely covered with water.
3. Connect the pump pressure hose Bto the upper filter con-
nection C(max. 50 cm above the surface of the pond).
4. Connect the discharge hose Dto the lower filter connection E
(at least 5 cm above the surface of the pond) and route into
the pond.
5. Plug mains plug into a 230 V AC socket.
Warning: The pump will start immediately!
Filter set up in the pond:
1. Connect the pressure hose of the pump Bto the upper con-
nection Cof the filter and the discharge hose Dto the lower
connection of the filter E.
2. Unscrew filter cover 0so that the filter container is filled with
water and does not float.
3. Set up the pump 1and filter container Ain a stable position
in the garden pond so that both are completely covered with
water and screw the filter cover 0on again under water.
4. Plug mains plug into a 230 V AC socket.
Warning: The pump will start immediately!
Do not allow the pump to run without water:
Do not allow the pump to run without water because dry-running
leads to an undesirable build up of heat and will destroy the pump.
5. Maintenance
The GARDENA filter is largely maintenance-free. However, it must
be cleaned when necessary.
1. Unplug the pump.
2. Remove the filter cover 0.
3. Remove the foam filter mat 9and clean it under running water.
4. Remove the net containing the filter pellets 8and place it in
a solution of cooking salt (20 g salt / litre) for approximately
24 hours.
5. Then rinse the net 8with fresh lukewarm water.
6. Place the bio-surface filter 7in clean water.
Do not clean under running water because this will destroy
the micro-organisms.
7. Empty the filter container completely and clean under running
water.
8. Reassemble filter in reverse order.
9. Start the filter up again
(see 4. Putting into Operation:
“Starting up the filter set” ).
We recommend cleaning the filter pellets approximately every
6 months (e.g. in salt water) or replacing them to guarantee that
the filter pellets are still able to work properly.
Please contact GARDENA Service about replacing the filter
pellets.
Cleaning the filter:
8
7
9
0
A
3. Mode of Operation of the Filter
!Water intake
Connection for the hose to the pump in the pond.
"Mechanical filtering
Foam filter mat for filtering out coarse dirt particles.
§Biological filtering
The pollutants and surplus nutrients are bonded to the filter
pellets and broken down.
$Bio-surface filters
The basis for biological water treatment by building up micro-
organisms.
%Water outlet
Connection for the hose to return the purified water to the
pond.
4. Putting into Operation
1. Unscrew the filter cover 0from the filter container Aand
remove the contents.
2. Insert both connection pieces 3from outside into the filter
container and place both sealing rings 4on to the connection
pieces from inside.
3. Screw filter 5on to the lower connection piece 3from inside.
4. Screw the threaded section with outlet 6from inside on to
the upper connection piece 3.
The outlet should point upwards.
5. Place bio-surface filters 7into the filter container.
6. Place the filter pellets in the net 8and spread the net over
the bio-surface filters 7.
7. Place the foam filter mat 9in the filter container in such
a way that the foam filter mat covers the net 8completely.
The outlet
6
is now above the foam filter mat
9
.
8. Screw the filter cover 0on to the filter container A.
9. Screw the connection piece 2on to the pump 1.
10. Decide on the location for the filter.
11. Decide on the length of the pressure hose Band the dis-
charge hose D.
12. Cut the hose supplied to correspond to the two hose lengths.
13. Connect the pressure hose to the connection piece 2.
Assemble the filter set:
2
1
"
§
$
!
%
8
7
A
9
0
34
5
6
www.devicemanuals.eu

15
G
14
G
Wintering / Storage:
7. Putting out of Operation
1. Before frosts commence, remove the Filter Set from the pond,
take the hose off the pump and empty the filter completely.
2. Clean the Filter Set.
3. Store filter and pump in a frost-free place.
4. Store the pump in a container filled with water so that the
pump does not dry out.
Ensure that the mains plug is not in the water.
Store out of reach of children.
8. Technical Data
Art. No. 7919
Rated power 14 W
Flow 900 l/h
Max. delivery head 1.5 m
Max. submersion depth 1.0 m
Power cable 10 m H05 RNF
Fitting G 1/2
Max. media temperature 35 °C
Mains voltage / Frequency 230 V / 50 Hz
Noise level L WA 1) 48 dB (A)
1) Measuring method according to EN 60335-1
9. Service
GARDENA guarantees this product for 2 years (from date of
purchase). This guarantee covers all serious defects of the unit
that can be proved to be material or manufacturing faults. Under
warranty we will either replace the unit or repair it free of charge
if the following conditions apply:
•The unit must have been handled properly and in keeping
with the requirements of the operating instructions.
•Neither the purchaser or a non-authorised third party have
attempted to repair the unit.
The impeller unit and the filter pellets are wearing parts and are
not covered by the guarantee.
This manufacturer’s guarantee does not affect the user’s existing
warranty claims against the dealer/ seller.
If you have any problems with your pump, please contact our
Customer Service or return the defective unit together with
a short description of the problem directly to one of the
GARDENA Service Centres listed on the back of this leaflet.
Warranty
Cleaning the pump filter housing:
The water intake slots on the water feature pump must be free
from dirt.
1. Unplug the pump from the mains.
2. Remove the pump from the pond.
3. Unscrew threaded sleeve Fand connection piece 2.
4. Open up the pump filter housing Gand spray clean with
a jet of water.
5. Clean the water intake slots of the filter housing Gwith
a brush.
Note:
Do not use any hard objects or powerful detergents for cleaning
the set!
Remove dirt deposits in the pump:
1. Unplug the pump from the mains.
2. Remove the pump from the pond.
3. Unscrew threaded sleeve Fand connection piece 2.
4. Open up pump filter housing Gand remove the pump.
5. Open the snap hook band take the pump cover Hoff the
motor housing J.
6. Draw the impeller unit Iout of the motor housing J.
7. Remove any dirt deposits from pump components.
8. Replace the impeller unit Iin the motor housing J.
9. Press the pump cover Hinto the motor housing Juntil the
connection is heard to snap into place.
6. Trouble-Shooting
Fault Possible Cause Remedy
The water is not clear. The pond is extremely dirty 1. Check nitrate concentration
and rich in nutrients. (e. g. with the GARDENA
Pond Test Set, Art. No.
7920)
2. If necessary, change the
water and clean the pond.
Filter pellets dirty. vClean filter and filter pellets.
Too many fish and creatures vAdd up the estimated length
in the pond. of the fish.
There should only be “80 cm
fish” per m3water in the pond.
Pump does not work. Connections are faulty. vCheck connections.
Impeller unit blocked. vRemove dirt deposits in the
pump (see 5. Maintenance).
If any other faults arise, please contact GARDENA Service.
Cleaning the pump:
2
F
G
J
H
b
I
www.devicemanuals.eu

16
G
We expressly point out that, in accordance with the product
liability law, we are not liable for any damage caused by our
units if it is due to improper repair or if parts exchanged are not
original GARDENA parts or parts approved by us, and, if the
repairs were not carried out by a GARDENA Service Centre or
an authorised specialist. The same applies to spare parts and
accessories.
Product Liability
EU Certificate of Conformity
The undersigned
GARDENA Kress + Kastner GmbH · Hans-Lorenser-Str. 40 · D-89079 Ulm
hereby certifies that, when leaving our factory, the unit indicated below is in accordance with the
harmonised EU guidelines, EU standards of safety and product specific standards.
This certificate becomes void if the unit is modified without our approval.
Description of the unit: Pump
Type: 1543
Art. No. : 7919
EU directives: Low Voltage Directive 73 / 23 / EC
Electromagnetic Compatibility 89/336/EC
Harmonised
European standards: EN 55014-1 / EN 55014-2
EN 60335-1 / EN 60335-2-41
EN 61000-3-2 / EN 61000-3-3
Year of CE marking: 2001 Ulm, 28.11.2001
Thomas Heinl
Technical Dept. Manager
www.devicemanuals.eu

Deutschland
GARDENA Kress + Kastner GmbH
GARDENA Service
Hans-Lorenser-Straße 40
D-89079 Ulm
Produktfragen: (07 31) 490- 123
Reparaturen: (07 31) 490 -290
Argentina
Argensem S.A.
Venezuela 1075
(1618) El Talar - Buenos Aires
Australia
NYLEX Consumer Division
76-88 Mills Road
P.O. Box 722
Braeside 3195
Melbourne, Victoria
Austria
GARDENA Österreich Ges. m.b.H.
Stettnerweg 11-15
2100 Korneuburg
Belgium
MARKT (Belgium) NV/SA
Sterrebeekstraat 163
1930 Zaventem
Brazil
M. Cassab
Av. das Nações Unidas, 20.882
Santo Amaro, CEP 04795-000
São Paulo - S.P.
Bulgaria / България
ДЕНЕКС ООД
Бул. ”Г.М.Димитров” 16 ет.4
София 1797
Canada
GARDENA Canada Ltd.
100, Summerlea Road
Brampton, Ontario
Canada L6T 4X3
Chile
Antonio Martinic Y CIA. LTDA.
Gilberto Fuenzalida 185 Loc.
Las Condes - Santiago de Chile
Costa Rica
Compania Exim
Euroiberoamericana S.A.
350 Sur del Automercado
Los Yoses
San Pedro
Cyprus
FARMOKIPIKI LTD
P.O. Box 7098
74, Digeni Akrita Ave.
1641 Nicosia
Czech Republic
GARDENA spol. s.r.o.
Шнpskб 20a, и.p. 1153
62700 Brno
Denmark
GARDENA Danmark A / S
Naverland 8
2600 Glostrup
Finland
Habitec Oy
Martinkyläntie 52
01720 Vantaa
France
GARDENA France
Service Après-Vente
BP 50080
95948 ROISSY CDG Cedex
Great Britain
GARDENA UK Ltd.
27-28 Brenkley Way
Blezard Business Park
Seaton Burn
Newcastle upon Tyne NE13 6DS
Greece
Agrokip G. Psomadopoulos & Co.
33a, Ifestou str.
Koropi 194 00
Athens
Hungary
GARDENA Magyarország Kft.
Késmárk utca 22
1158 Budapest
Iceland
Heimilistaeki hf
Saetun 8
P.O. Box 5340
125 Reykjavik
Republic of Ireland
Michael McLoughlin & Sons
Hardware Limited
Long Mile Road
Dublin 12
Italy
GARDENA Italia S.r.l.
Via Donizetti 22
20020 Lainate (Mi)
Japan
KAKUDAI Mfg. Co. Ltd.
1-4-4, Itachibori Nishi-ku
Osaka 550
Luxembourg
Magasins Jules Neuberg
Grand Rue 30
Case Postale No. 12
Luxembourg 2010
Netherlands
GARDENA Nederland B.V.
Postbus 50176
1305 AD ALMERE
Neth. Antilles
Jonka Enterprises N.V.
Sta. Rosa Weg 196
P.O. Box 8200
Curaçao
New Zealand
NYLEX New Zealand Limited
Private Bag 94001
South Auckland Mail Centre
10 Offenhauser Drive
East Tamaki, Manukau
Norway
GARDENA Norge A/S
Postboks 214
2013 Skjetten
Poland
GARDENA Polska Sp. z o.o.
Szymanów 9 d
05-532 Baniocha
Portugal
MARKT (Portugal), Lda.
Recta da Granja do Marquês
Edif. GARDENA
Algueirão
2725-596 Mem Martins
Russia / Россия
АО АМИДА ТТЦ
ул. Моcфилмовcкая 66
117330 Моcква
Singapore
Variware
Holland Road Shopping Centre
227-A 1st Fl., Unit 29
Holland Avenue
Singapore 1027
Slowenia / Croatia
Silk d.o.o. Trgovina
Brodišče 15
1236 Trzin
South Africa
GARDENA South Africa (Pty.) Ltd.
P.O. Box 11534
Vorna Valley 1686
Spain
ANMI Andreu y Miriam S.A.
Calle Pere IV, 111
08018 Barcelona
Sweden
GARDENA Svenska AB
Box 9003
20039 Malmö
Switzerland
GARDENA Kress + Kastner AG
Bitziberg 1
8184 Bachenbülach
Ukraine / Украина
АОЗТ АЛЬЦЕСТ
ул. Гайдара 50
г. Киев 01033
Turkey
Dost Diþ Ticaret Mümessillik A.Þ.
Yeþilbaðlar Mah. Baþkent
Cad. No. 26
Pendik - Ýstanbul
USA
GARDENA
3085 Shawnee Drive
Winchester, VA 22604
7919- 20.960.08 /0021
©GARDENA Kress + Kastner GmbH
Postfach 27 47, D-89070 Ulm
http: //www.gardena.com
www.devicemanuals.eu
