Gardena Select 1891 User manual

Select Art. 1891
EN Operator’s manual
Water Control
EN

Battery Condition*
Soil Moisture
0–3 drops = very dry/
rather dry/humid/very humid
Schedules
max. 1 year
min. 4 weeks
max. 4 weeks
too weak for
opening again
Time
Connected
sensor
Start Time
(0-23) hrs (0-59) min.
Run Time
(0-7) hrs (1-59) min
Frequency
(weekdays)
Today
D
F
ABC
1x 9V
Ø 26,5mm G3/4"
+ Ø 33,3mm G1"
E
Sensor
Mo Tu We Th Fr Sa Su
hrs min
ON
P1 P2 P3
OFF
Water Now
on/off
ON OFF
hrs min
Mo Tu We Th Fr Sa Su
Sensor
P1 P2 P3
Active Watering
Schedule active/ deactive
*
Back
3 sec. Key Lock
3 sec. Reset
Next
O.K.
A video of the
setting processes
is available here:
2
EL PT ES IT NL FR EN DE

J1 Active watering
I
G1 Set clock (hrs) 2 Set clock (min.) 3 Set day (Mon ‒ Sun)
Mo Tu We Th Fr Sa Su
4 Ready for time plan
P1 P2 P3
1 Choose any time plan
P1 P2 P3
2 Set time plan
P1
4 Device programmed
3 Confirm time plan
P1
hrs min
ON
H
hrs min
Sensor
hrs min
Mo We Fr Sa
ON
P1 P2 P3
hrs min
Mo We Fr Sa
ON
P1 P2 P3
2 Change Duration
1 min. – 59 min. 3 Stop Active
Watering anytime
hrs min
hrs min
ON
P1 P2 P3
Mo We Fr Sa
Mo We Fr Sa
Art. 1867
DE
3

GARDENA Water Control Select
Translation of the original instructions.
For safety reasons, children and young
people under 16 as well as anyone who is
not familiar with these operating instruc-
tionsshould not use the product. Persons with
reduced physical or mental abilities may use the
product only if they are supervised or instructed by
a responsible person. Children must be supervised
to ensure that they do not play with the product.
Never operate the product when you are tired, ill or
under the influence of alcohol, drugs or medicine.
Intended use:
The GARDENA Water Control is intended for private
use in domestic and hobby gardens, exclusively
for outdoor use, to control sprinklers and watering
systems. The Water Control can be used for auto-
matic watering during holidays.
DANGER! The GARDENA Water Control must
not be used for industrial purposes or in
conjunction with chemicals, foodstuffs, easily
flammable and explosive materials.
1. SAFETY
Important!
Read the operator’s manual carefully before use
and keep for future reference.
Battery:
To ensure the Water Control runs safely,
only a 9V alkaline manganese battery
(alkaline) type IEC 6LR61 must be used!
In order to stop the Water Control from failing
because of a weak battery if you are away for
along time, the battery must be replaced when
the battery symbol flashes.
Setting up:
The Water Control may only be set up vertically
with the sleeve nut to the top to prevent water
EN
13

penetrating into the battery compartment.
The minimum water output to ensure that the
Water Control functions correctly is 20 – 30 l/h.
For example, at least 10 x 2-litre Drip Heads are
required to control the Micro-Drip-System.
At high temperatures (over 70 °C at the display)
the LCD display may extinguish. This does not
affect the program in any way. When the com-
puter cools down the LCD display illuminates
again.
The max. temperature for the water flow is 40 °C.
Avoid tensile strain.
vDo not pull the hose connected to the
Water Control.
CAUTION! If the control section is
removed when the valve is open, the
valve remains open until the control section
is reattached.
DANGER! Cardiac arrest!
This product makes an electromagnetic
field while it operates. This field may under some
conditions interfere with active or passive medical
implants. To decrease the risk of conditions that
can possibly injure or kill, we recommend persons
with medical implants to speak with their physician
and the medical implant manufacturer before you
operate the product.
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There
is also a risk that the polybag can suffocate tod-
dlers. Keep toddlers away when you assemble the
product.
2. INITIAL OPERATION v(Fig. A– D)
A video of
the setting
processes
is available
here:
EN
14

4. PROGRAMMING v(Fig. G– J)
Fig. G: 1Set time (hours) | 2Set time (mins) |
3day setting (Mon ‒ Sun) | 4Ready for schedule
Fig. H: 1Select schedule | 2 Set schedule |
3 Confirm schedule | 4Device programmed
P1, P2, P3 denote watering schedules. You can
save up to 3 independent schedules. Irrigation
days must be selected and confirmed individually.
The current weekday will be underlined.
By pressing On/Off, schedules can be activated
or deactivated individually.
Soil Moisture Sensor v(Fig. D and I):
After a soil moisture sensor is connected, the
word “Sensor” will be displayed – this can take
up to 1minute.
Once the soil is sufficiently moist, awatering
operation is interrupted or a schedule is disabled
so that it cannot be activated. This does not affect
active (manual) watering.
Soil Moisture Sensor, Art.1867
(optionally available)
1Connecting the sensor
An operating point must then be defined.
This is the soil moisture level at or above which
watering is not to be carried out (see GARDENA
Soil Moisture Sensor Operating Instructions).
There are 3 levels to choose from.
3. FUNCTION v(Fig. F)
You can change the settings or move to the next
setting by turning the knob. You can confirm the
respective input by pressing the rotary knob.
Pressing the knob for a minimum of 3 seconds
locks or unlocks the display.
*
Battery
Condition*
Programs
Time
Connected
sensor
Start Time
(0–23) hrs (0–59) min.
Run Time
(0– 7) hrs (1–59) min.
Frequency
(weekdays)
Today
Active Watering
Schedule
active/
deactive
ON OFF
hrs min
Mo Tu We Th Fr Sa Su
Sensor
P1 P2 P3
Soil Moisture
0–3 drops =
very dry/
rather dry/
humid/
very humid
max. 1 year
min. 4 weeks
max. 4 weeks
too weak for opening again
If you will be away for long periods of
time, please replace the battery when
the battery symbol blinks – otherwise
the watering system may fail.
EN
15

5. MAINTENANCE v(Fig. E)
– During normal operation, the currently measured
level is displayed constantly.
– The switching point as of which the sensor sig-
nals that the soil is moist – thereby preventing
watering – is selected via the number of levels.
– 0 dots for loamy soil
v Sensor response when soil is quite dry.
– 3 dots for sandy soil
v Sensor response when soil is very moist.
Soil Moisture Sensor, Art. 1188,
(optionally available,
models up to 2020)
The soil moisture level at which a watering
will not be carried out as per the schedule
can be set using the switching point controller on
the soil moisture sensor (see GARDENA Soil Mois-
ture Sensor Operator’s manual).
Fig. J: 1Active watering | 2Change watering duration |
3Stop active watering at any time
By pressing the button, manual watering
can be started or stopped at a desired time.
A duration of between 1 minute and 59 minutes
can be selected.
6. STORAGE
To put into storage:
vThe product must be stored away from
children.
vTo preserve the battery, it should be removed
(fig. B).
vStore the controller and the valve unit in a dry,
enclosed and frost-free place.
Disposal: (in accordance with RL2012/19/EC)
The product must not be disposed of to
normal household waste. It must be dis-
posed of in line with local environmental
regulations.
IMPORTANT!
Dispose of the product through or via your
municipal recycling collection centre.
Disposal of the battery:
v Please return a flat battery to a GARDENA dealer
or dispose of it properly at your nearest recycling
centre.
Dispose of the battery only when discharged.
EN
16

7. TROUBLESHOOTING
Problem Possible Cause Remedy
No display appears Battery is inserted incorrectly. vCheck the polarity markings
match (+/–).
Battery is flat. vInsert a new (alkaline) battery.
Temperature on the display is higher
than 70 °C.
vDisplay appears after the temperature
has dropped.
Display shows
when button is activated
Buttons have been locked. v Press the button for 3 seconds.
Manual watering is
not possible using the
button
Low battery is continuously displayed. vInsert a new (alkaline) battery.
Tap is turned off. vTurn the tap on.
Controller is not connected. vMount the controller on housing.
Minimum pressure of 0.5 bar not available. vEnsure a pressure of at least 0.5 bar.
Watering program is
not being undertaken
(no watering)
Program entry/modification during or
just before the start pulse.
vMake program entry/modification out-
side the programmed start times.
Valve was opened manually previously. vAvoid possible program overlaps.
Tap is turned off. vTurn the tap on.
Soil moisture or rain sensor registers damp. vIf dry, check the setting/ location of the
soil moisture/rain sensor.
Controller is not connected. vMount the controller on housing.
Low battery is continuously displayed. vInsert a new (alkaline) battery.
EN
17

Problem Possible Cause Remedy
Watering program is
not being undertaken
(no watering)
Minimum pressure of 0.5 bar not
available.
vEnsure a pressure of at least
0.5 bar.
Water Control does
not close
Minimum quantity of water drawn is
less than 20 l/h.
vConnect more drip heads.
Valve soiled. v Flush in the opposite direction to the
normal flow direction.
NOTE: For any other malfunctions please contact the GARDENA service department.
Repairs must only be done by GARDENA service departments or specialist dealers
approved by GARDENA.
EN
18

8. TECHNICAL DATA
9. ACCESSORIES
Water Control Value /Unit
Min./max. operating
pressure 0.5 bar /12 bar
Operating temperature
range 5 °C to 50 °C
Flow medium Clear fresh water
Max. liquid temperature 40 °C
Program-controlled
watering sequences
per day
3
Water Control Value /Unit
Program-controlled
watering sequences
per week
max. 21
Watering duration 3 x 1 min. –
7 hrs 59 min.
Battery required 1 x 9V alkaline
manganese
Typ IEC 6LR61
Operating time of the
battery
approx. 1 year
GARDENA Soil Moisture Sensor Art.1867
GARDENA Anti-theft device Art. 1815-00.791.00 from the GARDENA Service
