Gardenline GEHM28 User manual

1000W
Hover Mower
GEHM28
Spend a little Live a lot
User Manual
Essentials

Product images and parts list .................................................................3
General information.................................................................................7
Reading and storing the instruction manual.......................................7
Explanation of symbols............................................................................7
Safety .......................................................................................................11
Proper use..................................................................................................11
Safety notes ..............................................................................................12
Checking the hover mower and product contents .................................16
Assembly ..................................................................................................17
Mounting the lower handle ....................................................................17
Mounting the cord strain relief ...............................................................17
Mounting the upper handle ...................................................................17
Fit the cables clips .....................................................................................18
Operation .................................................................................................19
Switching on/off .......................................................................................19
Height adjustment ...................................................................................19
Mowing .....................................................................................................20
Maintenance ...........................................................................................22
Cleaning ..................................................................................................27
Troubleshooting......................................................................................28
Storage ....................................................................................................30
Disposal....................................................................................................31
Technical data..........................................................................................32
EC Declaration of Conformity
Warranty
Warranty Card
Warranty Conditions
Contents

GB IRE Product images and parts list
3
A
1
2
3
4
5
6
7
8
9
11
10
12
13
14

IREGB
Product images and parts list 4
B
D
C
E

GB IRE Product images and parts list
5
H
J K
I
step 2step 1
11
10
2
1
2
1
F G

IREGB
Product images and parts list 6
1Switch Box
2Upper Handle
3Cable Clip
4Mains Cable
5Handle Clamp
6Lower Handle
7Motor Housing
8Lower Handle Securing Bolt
9Mower Deck
10 Switch Lever
11 Lock-off Button
12 Power Cord
13 Plug
14 Cord Strain Relief

AFTER SALES SUPPORT
[phone]
[phone]
www.coreservice.co.uk
7
1000W Hover Mower
GB
IRE
GB IRE
Reading and storing the instruction manual
This instruction manual accompanies this hover mower.
It contains important information on assembly, start-up
and handling. Before using the hover mower, read the
instruction manual carefully. This particularly applies
to the safety notes. Failure to heed this instruction
manual may result in severe injury or damage to the
hover mower. The instruction manual is based on the
standards and rules in force in the European Union.
Store the instruction manual for future use. If you
pass the hover mower on to third parties, please be
absolutely sure to include this instruction manual.
You can request an electronic version of these
instructions from our customer service.
Explanation of symbols
The following symbols and signal words are used in this
instruction manual, on the hover mower or on the packaging.
Read the user manual before using the machine.
Warning! Danger!
General information

AFTER SALES SUPPORT
[phone]
[phone] www.coreservice.co.uk
8
1000W Hover Mower
GB
IRE
GB IRE
You must always wear safety goggles to guard your
eyes from flying debris, ear plugs or similar ear
defenders to protect your hearing and respiratory
protection to protect breathing.
IMPORTANT! Wear gloves to protect your hands.
Wear safety boots to protect your feet.
Guaranteed sound power level value in dB.
The product complies with the applicable European
directives and an evaluation method of conformity for
these directives was carried out.
WEEE symbol. Waste electrical products should not be
disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or local
store for recycling advice.
Do not expose the product to rain or wet conditions.
General information

AFTER SALES SUPPORT
[phone]
[phone]
www.coreservice.co.uk
9
1000W Hover Mower
GB
IRE
GB IRE
This product is constructed using protection class II.
That means it is equipped with enhanced or double
insulation and does not need to be earthed.
Objects thrown by the product could hit the user or
other bystanders. Always ensure that other people and
pets remain at a safe distance from the product when it
is in operation. In general, children must not come near
the area where the product is in operation.
Beware of sharp blades. Blades continue to rotate after
the motor is switched off. Remove the plug from the
mains before maintenance or if the cord is damaged.
Cutting device continues to rotate after the product is
switched off. Wait until all components have completely
stopped before touching the product.
Switch the product off and disconnect it from the
power supply before assembly, cleaning, adjustments,
maintenance, storage and transportation.
General information

AFTER SALES SUPPORT
[phone]
[phone] www.coreservice.co.uk
10
1000W Hover Mower
GB
IRE
GB IRE
WARNING!
This appliance should be connected to your mains
supply using an RCD (Residual Current Device). The
operating current of this device must be less then
30mA. Contact an electrician if you are unsure of how to
proceed.
For safety reasons, this lawnmower is not to be used
by children, young people under 16 years of age, or
any other persons who are not acquainted with these
operating instructions.
For extension cables up to 15metres, use a wire cross
section of 1.5mm2. For extension cables over 15meters
but less than 40 meters, use a wire cross section of
2.5mm2.
General information

AFTER SALES SUPPORT
[phone]
[phone]
www.coreservice.co.uk
11
1000W Hover Mower
GB
IRE
GB IRE
Safety
Proper use
1. Operate the product only in daylight or in good artificial light.
2. Avoid operating the product in wet grass.
3. Always be sure of your footing on slopes.
4. Walk, never run.
5. Do not use this appliance in wet conditions, e.g., rain etc.
6. Mow across the face of slopes, never up and down.
7. Exercise extreme caution when changing direction on slopes.
8. Do not mow excessively steep slopes.
9. Use extreme caution when reversing or pulling the product
towards you.
10. Stop the blades if the product has to be tilted for
transportation when crossing surfaces other than grass, and
when transporting the product to and from the area to be
used.
11. Switch on the motor carefully according to the instructions
and with your feet well away from the blades.
12. Do not tilt the product when switching on the motor except if
the product has to be tilted for starting. In this case do not tilt
it more than absolutely necessary and lift only the part which
is away from the operator.
13. Do not put hands or feet near or under rotating parts. Keep
clear of the discharge opening at all times.
14. Do not transport the product while the power source is
Safety

AFTER SALES SUPPORT
[phone]
[phone] www.coreservice.co.uk
12
1000W Hover Mower
GB
IRE
GB IRE
running.
15. Stop the product, and remove the plug from the socket. Make
sure that all moving parts have come to a complete stop:
− Whenever you leave the product.
− Before clearing blockages or unclogging the chute.
− Before checking, cleaning or working on the product.
− After striking a foreign object. Inspect the product for
damage and make repairs before restarting and operating
the product.
16. If the product starts to vibrate abnormally (check
immediately):
− Inspect for damage.
− Replace or repair any damaged parts.
− Check for and tighten any loose parts.
17. Keep extension cords away from moving hazardous parts to
avoid damages to the cords which can lead to contact with
live parts.
Safety notes
WARNING!
DO NOT TOUCH THE ROTATING BLADES.
−This machine can cause serious injuries. Read the instruction
manual carefully for the correct handling, preparation,
maintenance, starting and stopping of the appliance. Be
familiar with the controls and the proper use of the appliance.
Safety

AFTER SALES SUPPORT
[phone]
[phone]
www.coreservice.co.uk
13
1000W Hover Mower
GB
IRE
GB IRE
Read and understand the operator’s manual and observe the
warnings and instruction labels affixed to the appliance.
−Never allow children or people unfamiliar with these
instructions to use the appliance. Never operate this appliance
when tired or under the influence of alcohol, medication or
drugs.
−Use appropriate tools. This product is intended for private use
only, not for any commercial applications. It may not be used for
any purposes other than those described.
Work Area Safety
−Keep work areas clean. Cluttered areas can cause accidents.
−Keep all bystanders, children, and pets at least 5 metres away.
The operator or user is responsible for accidents or hazards
occurring to other people or the property.
Personal Safety
−Use personal protective equipment (PPE). Always wear eye
protection. Protective equipment such as a dust mask, non-
skid safety shoes or gloves used for appropriate conditions will
reduce personal injuries.
−Dress appropriately. Do not wear loose clothing or jewelry, as
these can be caught in moving parts. Preferably wear nonslip
SafetySafetySafety

AFTER SALES SUPPORT
[phone]
[phone] www.coreservice.co.uk
14
1000W Hover Mower
GB
IRE
GB IRE
footwear when working outdoors. Wear a protective hair
covering to keep long hair out of the way.
−Stay alert and use caution and common sense when operating
the tool. A moment of lapsed concentration while operating the
tool may result in serious personal injury.
−This appliance can be used by persons aged 16 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
−Children should be supervised to ensure that they do not play
with the product.
−Read the instructions carefully. Be familiar with the controls and
the correct use of the product.
−Never allow children or people unfamiliar with these
instructions to use the product. Local regulations can restrict the
age of the operator.
−Never operate the product while children, other people or pets
are nearby.
−Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their property.
Operational Safety
−Be certain the parts are fully tightened before operating the
tool. Check it periodically for tightness during use to avoid
serious injury.
SafetySafetySafety

AFTER SALES SUPPORT
[phone]
[phone]
www.coreservice.co.uk
15
1000W Hover Mower
GB
IRE
GB IRE
−While operating the product always wear substantial footwear
and long trousers. Do not operate the product when barefoot
or wearing open sandals. Avoid wearing clothing that is loose
fitting or that has hanging cords or ties.
−Thoroughly inspect the area where the product is to be used
and remove all objects which can be thrown by the product.
−Before using, always visually inspect to see that the blade,
blade bolt and the blade assembly are not worn or damaged.
−Replace worn or damaged components in sets to preserve
balance. Replace damaged or unreadable labels.
−Before use check the supply and extension cord for signs of
damage or aging. If the cord becomes damaged during use,
disconnect the cord from the supply immediately. DO NOT
TOUCH THE CORD BEFORE DISCONNECTING THE SUPPLY.
−Do not use the product if the cord is damaged or worn. If the
cord requires replacement this should only be carried out by
the Service Agent or a similarly qualified person.
−Keep all nuts, bolts and screws tight to be sure the product is in
a safe working condition.
−Never replace the plastic blade with metallic cutting means.
−Be careful during adjustment of the product to prevent
entrapment of the fingers between moving blades and fixed
parts of the product.
−When servicing the blades be aware that, even though the
power source is switched off, the blades can still be moved.
−Replace worn or damaged parts for safety. Use only genuine
replacement parts and accessories.
Safety

AFTER SALES SUPPORT
[phone]
[phone] www.coreservice.co.uk
16
1000W Hover Mower
GB
IRE
GB IRE
Checking the hover mower and product contents
Checking the hover mower and product contents
WARNING!
RISK OF DAMAGE!
If you are not cautious when opening the packaging
with a sharp knife or other pointed objects, you may
easily damage the hover mower. Therefore, be very
careful when opening.
1. Take the hover mower out of the packaging and check
whether the appliance or the individual parts exhibit
damage. If this is the case, do not use the hover mower.
Contact the manufacturer at the service address specified on
the warranty card.
2. Check to make sure that the delivery is complete (see Fig A).

AFTER SALES SUPPORT
[phone]
[phone]
www.coreservice.co.uk
17
1000W Hover Mower
GB
IRE
GB IRE
Assembly
Assembly
Mounting the lower handle
1. To attach the lower handle insert it into the slots on either
side of the mower deck (see Fig B). Make sure that the holes
in the handle are lined up with the holes in the mower deck.
2. Push the handle fixing bolts through the lower handle holes
and into the threaded hole in the mower deck, then turn
the fixing bolt in a clockwise direction by hand to secure the
handle to the mower. You may find it difficult to fit the screw
end into the threaded hole.
Mounting the cord strain relief
1. To fit the upper handle first slide the cable restraint up and
over the handle (see Fig C).
2. Double the extension cord back, about a foot from the end.
Lead the loop through the cord strain relief (14) and hang the
loop over the hook.
3. Gently pull on the cord to ensure that it is fastened (see Fig D
and Fig E).
Mounting the upper handle
1. Attach the upper handle to the lower handle with the safety

AFTER SALES SUPPORT
[phone]
[phone] www.coreservice.co.uk
18
1000W Hover Mower
GB
IRE
GB IRE
Assembly
button on the switch box facing up. You will have to flex the
upper handle slightly to fit it over the lower handle.
2. Line up the holes and secure together using the handle
clamp wheels, washers and bolts (see Fig F). Tighten the
clamps by hand.
Fit the cables clips
1. The clips should all be fitted on the same side as the power
lever. Fit one clip above the handle clamp and two below (see
Fig G).

AFTER SALES SUPPORT
[phone]
[phone]
www.coreservice.co.uk
19
1000W Hover Mower
GB
IRE
GB IRE
Operation
Operation
Switching on/off
1. Ensure the start lever (10) is released.
2. Press the lock-off button (11) and hold it in position (Fig H, step
1).
3. Squeeze the start lever (10) towards the handle (2) to switch
the product on. Hold the start lever (10) in position during
operation (Fig H, step 2).
4. Release the lock-off button (11) once the product is running.
5. Release the start lever (10) to switch the product off.
NOTE! The product can only be started by pressing the lock-off
button (11) first followed by squeezing the start lever (10). Reverse
operation will not start the product.
NOTE! The cutting device will continue to rotate for a short period
after the product has been switched off.
Height adjustment
WARNING!
Make sure that the hover mower is switched off
unplugged and that the blades have stopped rotating
before attempting to adjust the cutting height.

AFTER SALES SUPPORT
[phone]
[phone] www.coreservice.co.uk
20
1000W Hover Mower
GB
IRE
GB IRE
Operation
WARNING!
Do not touch the rotating blade.
1. Turn the hover mower over and remove the blades (see
replacing the blades).
2. Fit the blades onto the blade holder pegs on the upper side
of the blade holder for the lowest cut (see Fig I) or onto the
lower side for the highest cut (see Fig J).
Mowing
1. Never cut off more than one-third of the total length of the
grass for a healthy lawn. In the autumn, lawns should only be
cut as long as there is growth.
2. Slowly push the product forward.
3. Mow in slightly overlapping rows. The most effective pattern
for mowing lawns is straight lines along one of the sides. This
will keep the rows even and ensures that all the lawn is cut
without missing any spots.
