Gardenline HL6500 User manual

Dok./Rev.-Nr. 63736_20181105
3
31 24
13
76
1
12
5
11
89
10
23
45
Explanation of the symbols on the equipment..................07
Introduction .......................................................................09
Layout ................................................................................. 10
Scope of delivery ............................................................... 10
Intended use .......................................................................11
Safety regulations ...............................................................12
Setup ....................................................................................21
Before starting the equipment ..........................................21
Operation ............................................................................21
Cleaning .............................................................................. 23
Maintenance and repair .................................................... 23
Technical Data .................................................................... 25
Storage ...............................................................................25
Transport ............................................................................26
Electrical connection .......................................................... 26
Disposal and recycling ....................................................... 27
Troubleshooting ................................................................28
Warranty Details ..................................................................31
Repair and Refurbished Goods or Parts Notice ................ 32
Contents
User Manual
LOG SPLITTER
YEARS
WARRANTY
5
Made in China
GARDENLINE®is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
AUS
ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifications. If you are not entirely satisfied with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
after sales support by calling the supplier’s Customer Service Hotline.
Original instructions
MODEL:
HL650o
suppor[email protected]
1300 855 831
AFTER SALES SUPPORT
AUS
63736
04/2019

AFTER SALES SUPPORT 7
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Explanation of the symbols on the equipment
Explanation of the symbols on the equipment
Caution - Read the operating instructions to reduce the
risk of injury!
Wear safety goggles. Sparks generated during working or
splinters, chips and dust emitted by the device can cause
loss of sight.
Wear working gloves!
Wear working shoes!
Wear a safety helmet!
Do not remove or modify protection and safety devices.
Dispose of waste oil correctly (waste oil collection point
on site). Do not dump waste oil in the ground or mix it
with waste.
Beware of electrical voltage!

8AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Explanation of the symbols on the equipment
Observe caution and safety notes!
Do not reach into the machine without
any protection!
Caution! Moving parts!
Danger of bruising and injury from sharp edges; never
touch danger areas when the cleaver is moving.
Risk of injury!
Disconnect the mains plug prior to the repair, cleaning,
and maintenance of the splitter!
Only the operator is allowed in the work area of the ma-
chine. Keep other people and animals (minimum distance
5 m) at a distance.
Electric shock can cause fatal injury. Keep a distance of
at least 10 m from power cables.
Keep all children, bystanders and helpers 5 meters away
from the tool!

AFTER SALES SUPPORT 9
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
I. INTRODUCTION
Congratulations on choosing to buy a GARDENLINE®product.
All products brought to you by GARDENLINE®are manufactured to the highest
standards of performance and safety, and as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 5 Years Warranty.
We hope you will enjoy using your purchase for many years to come.
Note:
According to the applicable product liability law the manufacturer of this device is not
liable for damages which arise on or in connection with this device in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non-authorised skilled workers,
• installation and replacement of non-original spare parts,
• improper use.
• failures of the electrical system due to the non-compliance with the electrical
specications and regulations.
Recommendations:
Read the entire text of the operating instructions prior to the assembly and operation
of the device.
These operating instructions are intended to make it easier for you to get familiar
with your device and utilise its intended possibilities of use.
The operating instructions contain important notes on how to work safely, properly
and economically with your machine and how to avoid dangers, save repair costs,
reduce downtime, and increase the reliability and working life of the machine.
In addition to the safety regulations contained herein, you must in any case comply
with the applicable regulations of your country with respect to the operation of the
machine.
Keep the operating instructions in a clear plastic folder to protect them from dirt
and humidity; store them near the machine. The instructions should be read and
carefully understood by each operator prior to using the machine. Only persons who
have been trained in the use of the machine and are aware of the related dangers
and risks should be allowed use the machine. The local required minimum age must
be met.
In addition to the safety notes contained in these operating instructions and any
specic regulations in your country, the generally recognised technical rules for the
operation of identically constructed machines must be observed.
AUS
Introduction

10 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Layout/Scope of delivery
II. L AYOUT (Fig. 1)
1 Oil Tank
2 Log Pusher
3 Work Table
4 Splitting Wedge
5 Lift Handle
6 Support Leg
7 Switch
8 Motor
9 Transport Wheel
10 Hydraulic Lever
11 Oil Drain Bolt / Dipstick
12 Venting Screw
13 Hoist Limiting Ring
III. SCOPE OF DELIVERY
Log Splitter (1x)
Instruction Manual (1x)
Warranty Card & Details (1x)
• Open the packaging and take out the equipment with care.
• Remove the packaging material.
• Check that all listed contents are present.
• Inspect the equipment and parts for any damage. Please contact the helpline if
anything is missing.
• If possible, keep the packaging until the end of the guarantee period.
• Read the operating instructions fully to familiarise yourself with the tool prior to
using it.
• Only use original accessories and spare parts. Spare parts are available by con-
tacting the helpline.
• Specify the part numbers when you contact the helpline.
m ATTENTION!
The device and packaging materials are not toys!
Children must not be allowed to play with plastic bags, lm and small parts!
There is a risk of swallowing and su󰀨ocation!

AFTER SALES SUPPORT 11
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Intended use
IV. INTENDED USE
The hydraulic log splitter may only be used in a horizontal position.
Wood may only be split in a horizontal position along the bre.
The maximum split wood length is 52 cm.
1. The equipment is to be used only for its prescribed purpose. Any other use is
deemed to be a case of misuse.
2.The user / operator and not the manufacturer will be liable for any damage or
injuries of any kind caused as a result of this.
3.To use the equipment properly you must also observe the safety information, the
assembly instructions and the operating instructions to be found in this manual.
4. All persons who use and service the equipment have to be acquainted with this
manual and must be informed about the equipment’s potential hazards.
5.It is also imperative to observe the accident prevention regulations in force in your
area.
6.The same applies for the general rules of health and safety at work.
7. The manufacturer will not be liable for any changes made to the equipment nor for
any damage resulting from such changes.
Even when the equipment is used as prescribed it is still impossible to eliminate
certain residual risk factors. The following hazards may arise in connection with the
machine’s construction and design:
• Dry and dried-up wood may jump up when being split and injure the face of the
operator. Adequate protective clothes to be worn!
• Wooden pieces produced during splitting may fall down and injure legs of the
operator.
• When splitting wood, parts of body may be crushed or separated due to hydraulic
knife lowering.
• There is a risk of branchy wood getting stuck when being split. Please be advised
that wood being separated is under heavy pressure and your ngers may get
squeezed in the gap.
• Caution! Pieces of wood cut at the right angle to be split only! Diagonally cut piec-
es of wood may slip when cutting! This may cause personal injury or damage to
the splitter knife especially when using the gap extension by Splitting Wedge!
This product is for private domestic use only and is not intended for commercial,
industrial or trade use. Our warranty will be voided if the equipment is used in com-
mercial, trade or industrial businesses or for equivalent purposes.

12 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Safety regulations
V. SAFETY REGULATIONS
These operating instructions provide places concerning your
safety which are marked with this indication: m
mGENERAL SAFETY NOTES
You must read the complete instruction and maintenance manual
before you use the machine.
• You must wear safety shoes at all times to protect yourself against
the risk of falling trunks.
• You must wear work gloves at all times to protect your hands from
chips and splinters generated while you work.
• You must wear safety goggles or a visor to protect yourself from
chips and splinters generated while you work.
• It is prohibited to remove or modify any protective equipment or
safety equipment.
• No one apart from the operator is permitted to stand within the
working radius of the machine. No other person or animal is permit-
ted to be within a radius of 5 meters of the machine.
• It is prohibited to allow used oil to be discharged to the environment.
The oil must be disposed of in accordance with the regulations of
the country in which the machine is used.
mRisk of hands being cut or crushed
Never touch any dangerous areas while the Splitting Wedge is mov-
ing.
mWARNING!
Keep an eye on the movement of the log pusher at all times.
mWARNING!
Never attempt to remove a trunk which has got stuck on the Splitting
Wedge by hand.
mWARNING!
Always unplug the power plug prior to starting any of the maintenance
work described in this manual.

AFTER SALES SUPPORT 13
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Safety regulations
mWARNING!
The voltage must be the same as the voltage specied on the rating
plate.
Keep these regulations in a safe place!
1. WORK AREA
• Keep your work area clean and tidy. Disorder and insu󰀩ciently illu-
minated work areas can lead to accidents.
• Do not use this tool in a potentially explosive environment containing
combustible liquids, gases or dust. Electric tools generate sparks,
which can in turn ignite dust or vapors.
• Keep children and other persons away from the electric tool while it
is being used. Allowing yourself to get distracted can cause you to
lose control of the tool.
2. ELECTRICAL SAFETY
Attention! The following basic safety measures must be observed
when using electric tools for protection against electric shock, and
the risk of injury and re. Read all these notices before using the
electric tool and keep the safety instructions for later reference.
• The tools connector plug must be able to t into the socket outlet.
Do not modify the plug in any way! Do not use adapter plugs in
conjunction with electrically grounded tools. Unmodied plugs and
matching socket outlets reduce the risk of an electric shock.
• Avoid touching grounded surfaces, such as those of pipes/tubes,
heaters, cookers and refrigerators. There is an increased risk of
getting an electric shock if you are electrically grounded.
• Keep the tool away from rain and moisture/wet conditions. Pene-
tration of water into an electric tool increases the risk of an electric
shock.
• Do not use the cable to carry the tool, hang it up or pull the plug out
of the socket. Keep the cable away from sources of heat, oil, sharp
edges and moving tool parts. Damaged or tangled cable increases
the risk of an electric shock.
• If you intend to use an electric tool outdoors, ensure that you only

14 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Safety regulations
use extension cable that is approved for outdoor applications. Using
extension cable that is approved for outdoor applications reduces
the risk of an electric shock.
• Connect the electric tool to the mains power supply (220 - 240 V~,
50Hz) via a socket-outlet with earthing contact. We recommend that
you t a residual-current protection device with a maximum nominal
tripping current of 30 mA. Seek the advice of your electrician.
3. PERSONAL SAFETY
• Be alert, work conscientiously and exercise appropriate caution
when using the electric tool. Do not use the tool if you are tired or
are under the inuence of drugs/medication or alcohol. One moment
of carelessness or lack of attention when using the electric tool can
cause serious bodily injury!
• Always wear personal protective equipment (PPE), including safety
goggles. Wearing personal protective equipment such as a dust
mask, non-slip footwear, protective headgear and ear mu󰀨s (de-
pending upon the type of electric tool and the particular application)
reduces the risk of sustaining injury.
»Wear ear-mu󰀨s. The impact of noise can cause damage to hear-
ing.
»Wear safety goggles. Sparks generated during working or splin-
ters, chips and dust emitted by the device can cause loss of sight.
• Physically touching the switch with your nger when carrying the
tool or connecting the tool to the power supply switched on can lead
to accidents.
• Remove adjusting tools/wrench(es) prior to switching on the power
tool. A tool or wrench that is positioned inside a rotating power tool
part can cause injury.
• Do not overestimate your abilities. Make sure you stand squarely
and keep your balance at all times. This way, you will be able to
have better control over the tool in unexpected situations.
• Wear suitable clothes. Never wear loose tting clothes or jewelry.
Keep hair, clothes and gloves away from moving parts. Loose cloth-
ing, dangling jewelry and long hair can be caught by moving parts.

AFTER SALES SUPPORT 15
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Safety regulations
4. CAREFUL HANDLING AND USE OF ELECTRIC TOOLS
• Do not overload your tool. Only use suitable electric tools to perform
your work. Using the right electric tool allows you to work better and
safer within the tool’s quoted capacity range.
• Do not use an electric tool whose switch is defective. An electric
tool that no longer can be switched on or o󰀨 is dangerous and must
be repaired.
• Always pull the plug out of the socket outlet before making any
adjustments, changing accessories, or storing power tools. This
precaution eliminates the possibility of inadvertently starting the tool.
• When not in use, store electric tools out of the reach of children. Do
not allow those persons to use this tool who are unfamiliar with it or
who have not read these instructions. Electric tools are dangerous
when they are used by inexperienced persons.
• Take good care of your tool. Check that moving parts properly func-
tion and do not jam, that parts are not broken o󰀨 or damaged in any
way and that the tool can be used to its full capacity. Have damaged
parts repaired prior to using the tool. The cause of many accidents
can be traced back to poorly maintained electric tools.
• Use electric tools and plug-in tools, etc. in compliance with these
instructions and in the manner that is prescribed for the model at
hand. In so doing, pay due attention to working conditions and the
job to be performed. Using electric tools for applications other than
those intended can lead to dangerous situations.
• If the power cable of the electric tool is damaged, it must be re-
placed by a specially prepared connection lead which can be ob-
tained from the customer service center.
5. SERVICE
Have your tool repaired only by authorized specialists using original
replacement parts. This will ensure that your tool remains safe to use.

16 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Safety regulations
SPECIAL SAFETY INSTRUCTIONS FOR THE LOG SPLITTER
mDANGER!Keep clear of moving parts! Never reach into the split-
ting zone.
mWARNING!
The use of this powerful machine can give rise to special types of
danger. Take particular care to protect both yourself and all other
persons in the vicinity. You should comply with basic precautionary
measures at all times in order to minimise the risk of injuries and
danger.
The machine must never be operated by more than one opera-
tor.
• Never attempt to split any trunks which are larger than the recom-
mended trunk capacity.
• The trunks must be free of any nails or wire which may be ung out
or might damage the machine during operation.
• The trunks must be cut at at the ends and have had all branches
removed from them.
• The wood must always be split along the direction of the grain.
Never insert the piece of wood crosswise to the splitter and then
attempt to split it as this could damage the splitter
• The operator must operate the machine controls with both hands
and must not use any other kind of device as a substitute for the
controls.
• The machine may be operated only by adults who have read the op-
erating instructions prior to starting operation. No one is permitted
to use the machine without reading the manual rst.
• Never attempt to split two trunks in a single operation as this may
cause pieces of wood to be ung out, which is dangerous.
• Never add more wood or replace a piece of wood while the machine
is in the middle of an operation as this would be extremely danger-
ous.

AFTER SALES SUPPORT 17
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Safety regulations
• All persons and animals must be kept at least 5 meters from the
machine while it is working.
• Never modify the protective equipment on the wood splitter or carry
out any work without such equipment attached.
• Never attempt to force the wood splitter to split excessively hard
pieces of wood under cylinder pressure for more than 5 seconds.
Overheated oil under pressure may cause damage to the machine.
Stop the machine, turn the trunk through 90° and then try to split it
again. If the wood still fails to split this means that it is too hard for
the capacity of the machine and must be removed to avoid damag-
ing the wood splitter.
• Never leave the machine unattended while running. Stop the ma-
chine and unplug the power plug whenever you are not using it.
• Never use the machine near natural gas, petrol channels or other
inammable materials.
• Never open the control box or the motor cover. If necessary, contact
a qualied electrician.
• Make sure that the machine and the cable never come into contact
with water. Handle the power cable with care and never pull or tug it
with a jolt to unplug it. Keep all cables away from excessive heat, oil
and sharp-edged objects.
• Please take note of the temperature conditions whilst you work.
Extremely low and extremely high ambient temperatures may cause
malfunctions.
• Before using the wood splitter for the rst time, users should be giv-
en practical training by an experienced operator and should initially
work with it under supervision.
Before starting work check the following:
• Do all the functions of the tool function correctly?
• Does all the safety equipment function correctly?
• Can the tool be switched o󰀨 correctly?
• Is the tool adjusted correctly (truck support, trunk holding plates,
splitter height)?

18 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Safety regulations
Keep the working area free of obstructions (for example pieces of
wood) whilst working.
SPECIAL WARNINGS RELATING TO THE USE OF THE LOG
SPLITTER
Special types of danger can arise during the use of this powerful
machine. Take particular care to protect both yourself and all other
persons in the vicinity.
Hydraulic system
Never use the machine if there is ever any danger from hydraulic uid.
Check for leaks in the hydraulic system every time before you start
using the machine. Check that the machine and your work area are
clean and free of any patches of oil.
Hydraulic uid may be the cause of danger because it can cause you
to slip and fall, may make your hands slip while operating the machine
or may cause a re.
Electrical safety
• Never use the machine if there is any risk of an electrical hazard.
• Never use an electrical device in moist conditions.
• Never use this machine with an unsuitable cable or extension ca-
ble. Never use this machine if you are not connected to a properly
earthed connection which provides the power required as specied
on the label and is protected by a 16 amp fuse.
Mechanical hazards
Wood splitting is associated with particular mechanical hazards.
• Never use this machine if you are not wearing proper safety gloves,
shoes with steel caps and certied eye protection.
• Be cautious of splinters generated while working; avoid stab-like
injuries and the possibility of the machine seizing up.
• Never attempt to split any trunks which are either too long or too
small and do not t in the machine properly.

AFTER SALES SUPPORT 19
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Safety regulations
• Never attempt to split any trunks which contain nails, wire or any
other objects.
• Clear up while you work; collections of split wood and wood chips
can make your work area dangerous. Never continue working if your
work area is full to the extent that you could slip, trip or fall over.
• Keep onlookers well away from the machine and never permit unau-
thorized persons to operate the machine.
ACCIDENT PREVENTION STANDARDS
1) The machine may only be operated by people who are well familiar
with the contents of this manual.
2) Before use, check the intactness and perfect function of the safety
devices.
3) Before use, make yourself also familiar with the control mecha-
nisms of the machine, following the operating instructions.
4) The capacity of the machine indicated may not be surpassed. In no
way may the machine be used for any other purposes than splitting
rewood.
5) In agreement with your country’s laws, the personnel must wear
adequate, close-tting working clothes. Jewelry like watches, rings
and necklaces must be taken o󰀨. Long hair must be protected by a
hair net.
6) The work place should always be tidy and clean. Tools, accesso-
ries and wrenches should lie within reach.
7) During cleaning or maintenance work, the machine may never be
connected to the mains.
8) It is strictly prohibited to use the machine with the safety devices
removed or switched o󰀨.
9) It is strictly prohibited to remove or modify the safety devices.
10) Before undertaking any maintenance or adjusting work, carefully
read and understand the present operating instructions.
11) For a good performance of the machine as well as for safety rea-
sons, the plan given herein must be adhered to.
12) In order to prevent accidents, the safety labels must always be kept

20 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Safety regulations
clean and legible, and they must be strictly observed. Any missing
labels must be reordered from the manufacturer and be attached to
the correct place.
13) In case of re, only re-ghting powder may be used. Water is not
allowed to extinct the re because of the risk of short circuit.
14) If the re cannot be extinct immediately, pay attention to leaking
liquids.
15) In case of a longer re, the oil tank or the pressure lines can ex-
plode. Be careful not to get injured by bursting o󰀨 parts
mREMAINING HAZARDS
The machine has been built using modern technology in accordance
with recognized safety rules. Some remaining hazards, however, may
still exist.
• The splitting tool can cause injuries to ngers and hands if the wood
is incorrectly guided or supported.
• Thrown pieces can lead to injury if the work piece is not correctly
placed or held.
• Injury through electric current if incorrect electric connection leads
are used.
• Danger due to particular properties of the log (branches, irregular
shape etc)
Even when all safety measures are taken, some remaining hazards
which are not yet evident may still be present.
Remaining hazards can be minimized by following the safety instruc-
tions as well as the entire operating manual.

AFTER SALES SUPPORT 21
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Setup/Before starting the equipment/Operation
VI. SETUP
Prepare the workplace where the machine is to be placed.
Ensure su󰀩cient room to allow safe work without malfunctions.
The machine is designed to operate on a level surface and must be placed se-
curely on stable plain ground.
VII. BEFORE STARTING THE EQUIPMENT
Make sure the machine is completely and expertly assembled.
Check before every use:
• The connection cables for any defective spots (cracks, cuts etc.).
• The machine for any possible damage.
• The rm seat of all bolts.
• The hydraulic system for leakage.
• The oil level.
VENTING, FIG. 7 / 8
mATTENTION!
Before working with the log splitter, vent the hydraulic system.
• Release the Venting Screw (12) by a few revolutions so the air can escape from
the oil tank.
• Leave the Venting Screw (12) open during the operation.
• Before you move the log splitter, close the Venting Screw (12) again in order not to
lose any oil.
If the hydraulic system is not vented, the enclosed air will damage the gas-
kets and with it the complete log splitter.
VIII. OPERATION
Only split plain cut logs.
SWITCHING "ON" AND "OFF"
mATTENTION!
Loosen the Venting Screw (12) two revolutions, before starting work.
Close before transport. FIG. 7 / 8
1. Place the splitting material in horizontal direction to the Work Table (3).
2. Your machine is equipped with Two-hands Control System that requires opera-
tion by both hands of the user
– left hand controls the Hydraulic Lever (10) while

22 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Operation
– right hand controls the Switch (7).
3. Simultaneously push the Hydraulic Lever (10) and the Switch (7) to start splitting
action.
4. Wait until the splitting process is ended and release then the Hydraulic Lever
(10) and the Switch (7). The Splitting wedge (4) is returned to the home position.
5. Afterwards you can remove splitting material.
The log splitter will freeze upon absence of either hand.
If you release the Switch (7) the Motor (8) stops.
The release of both hands means that the Log Pusher (2) will be retracted.
mATTENTION!
Check the function of the "ON-/OFF" unit before every use by switching on
and o󰀨 once, as described above (Switching "ON" and "OFF").
Never force your machine for more than 5 seconds by keeping pressure on it to
split excessively hard wood. After this time interval, the oil under pressure will be
overheated and the machine could be damaged.
For such an extremely hard log, rotate it by 90° to see whether it can be split in a
di󰀨erent direction. In any case, if you are not able to split the log, this means that
its hardness exceeds the capacity of the machine and thus should be discarded to
protect the log splitter.
END OF WORK
• Release hands from Two-hands Control System.
• Pull the power plug.
• Close the venting screw (12).
• Observe the general maintenance instructions.
HOIST LIMITING, FIG. 1
For short splitting material it is possible to shorten the return movement of the
Splitting Wedge (4). To do so, press the Hydraulic Lever (10) and the Switch (7)
and let the Log Pusher (2) move just in front of the splitting material.
Release the Switch (7) now and mount the Hoist Limiting Ring (13) to the housing
and tighten it. Afterwards you can release the Hydraulic Lever (10).
The Log Pusher (2) will now be resting in the selected position.
WRONGLY PLACED LOG, FIG. 2
Always set logs rmly on the work table. Make sure logs will not twist, rock or slip
while being split. Do not force the blade by splitting logs on the upper part. This
will break the blade or damage the machine.
Do not attempt to split 2 pieces of logs at the same time. One of them may y up
and hit you.

AFTER SALES SUPPORT 23
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Operation/Cleaning/Maintenance and repair
JAMMED LOG, FIG. 3 / 4
Do not try to knock the jammed log o󰀨. Knocking about will damage the machine
or may launch the log and cause accident.
1. Release both controls.
2. After the Log Pusher (2) moves back and completely stops at its starting posi-
tion, insert a wedge wood under the jammed log as shown in the gure.
3. Start the log splitter to push the wedge wood under the jammed one.
4. Repeat above procedure with sharper slope wedge woods until the log is com-
pletely freed.
IX. CLEANING
m IMPORTANT!
Always pull out plug each time before carrying out any cleaning.
Keep all safety devices, air vents and the motor housing free of dirt and dust as
far as possible.
Wipe the equipment with a clean cloth or blow it with compressed air at low pres-
sure - Attention! Wear safety glasses for this work.
We recommend that you clean the device immediately each time you have n-
ished using it.
Clean the equipment regularly with a moist cloth and some soft soap. Do not use
cleaning agents or solvents - these could attack the plastic parts of the equip-
ment. Ensure that no water can seep into the device.
X. MAINTENANCE AND REPAIR
Carry out retting, setting and cleaning work only when the motor is switched o󰀨.
Pull the power plug.
An experienced worker can carry out minor repairs on the machine alone.
Repair and maintenance work on the electrical system may only be carried
out by a qualied electrician.
All protective and safety devices must be reattached immediately after completed
repair and maintenance work.
We recommend:
• The Splitting Wedge is a wearing part that needs to be sharpened or replaced
after wear.
• The combined gripping and controlling device must remain smooth running. Lubri-
cate with a few drops of oil when necessary.
• Keep Splitting Wedge drive clean of dirt, wood shavings, bark, etc.
• Lubricate slide rails with grease.

24 AFTER SALES SUPPORT
 [e-mail]  1300 855 831
MODEL: HL650o PRODUCT CODE: 63736 04/2019 AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider.
AUS
Maintenance and repair
SHARPEN THE SPLITTING WEDGE FIG. 1
If the Splitting Wedge (4) is worn out, use an angle grinder and sharpen the edg-
es. If you are not condent contact a professional repair person.
OIL CHANGE FIG. 5 - 7
The hydraulic system is a closed system with oil tank, oil pump and control valve.
The system is complete when the machine is delivered, and may not be changed
or manipulated.
Check hydraulic connections and ttings regularly for air tightness.
Tighten when necessary.
The oil tank has been lled with high quality oil at the factory.
Replace hydraulic oil after 150 hours of use.
1. Make sure all moving parts stop and the log splitter is unplugged.
2. Unscrew Oil Drain Bolt / Dipstick (11) to remove it.
3. Tip the log splitter on the support leg end as shown in g. 5 over a 4 litre capaci-
ty container to drain the hydraulic oil. Recycle carefully!
4. Tip your machine on the motor end as shown in Fig. 6 to rell about 3.5 L fresh
oil.
5. Clean the surface of the dipstick on the Oil Drain Bolt (11) and put it back into
the oil tank while keeping the log splitter vertical.
Make sure the level of the relled oil is just between 2 grooves around the dip-
stick.
6. Clean the Oil Drain Bolt (11) before threading it back. Make sure it is tightened
to avoid leakage before placing the log splitter horizontally. Afterwards, run the
machine through several splitting cycles without logs on the work table.
Regularly check the oil level.
Too low an oil level damages the oil pump.
Regularly check the hydraulic connections and bolts for tightness.
Re-tighten if necessary.
Upon low oil level, oil relling is required.
Dispose of the used oil in a correct manner at a public collection facility.
It is prohibited to drop old oil on the ground or to mix it with waste.
We recommend the following hydraulic oils:
• Aral Vitam gf 22
• BP Energol HLP-HM 22
• Mobil DTE 11
• Shell Tellus 22
or oils of same quality.
Do not use any other types of oil as they would inuence the function of the hy-
draulic cylinder.

AFTER SALES SUPPORT 25
 1300 855 831  [e-mail]
AUS Hotline Costs: Local rate for landline calls*
*Charges may vary dependent upon network operator or mobile network provider. MODEL: HL650o PRODUCT CODE: 63736 04/2019
AUS
Maintenance and repair/Technical Data/Storage
Before undertaking any maintenance or checking work, the working area must be
cleaned. Keep the necessary tools within the reach of your hand.
The intervals mentioned herein are based on normal conditions of use. An exces-
sive use of the machine shortens the intervals accordingly.
Clean the switch box and control levers with a soft cloth. The cloth should be dry
or slightly humid with a neutral cleaning agent. Do not use any solvents like alco-
hol or benzene as they could damage the surfaces.
Store oil and grease outside the reach of unauthorized personnel. Strictly follow
the instructions on the bins. Avoid direct contact with the skin. Rinse well after
use.
XI. TECHNICAL DATA
Dimensions L x W x H mm 950 x 270 x 500
Wood ø mm 50-250
Wood length mm 250-520
Weight kg 44.5
Motor
Motor V~/Hz 220 - 240/50
Input W 2200
Rating S3/25%
Splitting Power t max. 5.0
Cylinder rise mm 375
Cylinder speed (fast fwd.) cm/sec 3.1
Cylinder speed (return) cm/sec 6.0
Hydraulic uid capacity L 3.5
Operating pressure bar 220
Motor speed rpm 2800
Subject to technical changes!
XII. STORAGE
Store the device and its accessories in a dark, dry and frost-proof place that is in-
accessible to children. The optimum storage temperature is between 5 and 30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from dust and moisture.
Store the operating manual with the electrical tool.
