Gardenline GLPHT26 User manual

GLPHT26PETROL
HEDGE TRIMMER
THE
POWER
GUIDE
Now you have purchased a Gardenline®
product you can rest assured in the
knowledge that as well as your 3 year
parts and labour warranty you have the
added peace of mind of dedicated
helplines and web support
+90˚-90˚
52cm
CUTTING
LENGTH
19mm
500ml
0151 6491500
1890 946244
9053
:
REBMUNLEDOM
MONTH ON SALE: 05/2008 36
THIS BOX INCLUDES:
1 x HEDGE TRIMMER, SPANNER,
PLUG SPANNER, MIXING BOTTLE,
BLADE GUARD, 1 X BOTTLE OF OIL
26cc PETROL HEDGE TRIMMER
GLPHT26 User Guide Artwork.qxd 28/1/08 9:22 am Page 2

03 Introduction
04 General Information & Safety Instructions
10 Assembly and Parts List
12 Getting Started
13 Features
14 Instructions
25 FAQ
26 Other Useful Information
29 Warranty Card
Packaging
The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material and
can therefore be reused or can be returned to the raw
material system.
Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
02
Contents
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 3

Introduction 1
Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 03
Congratulations on choosing to buy a Gardenline®
product. By doing so you now have the assurance
and peace of mind that comes with purchasing a
product made by one of Europe’s leading
manufacturers.
All products brought to you by Gardenline®
are manufactured to the highest standards
of performance and safety, and, as part of our
philosophy of customer service and satisfaction,
are backed by our comprehensive 3 Year Warranty.
Great care has gone into the manufacture of this
product and it should therefore provide you with
years of good service when used properly. In the
event of product failure within its intended use
over the course of the first 3 years after date of
purchase, we will remedy the problem as fast
as possible once it has been brought to our
attention. In the unlikely event of such an
occurrence, or if you require any information
about the product, please contact us via our
helpline support services, details of which are
to be found both in this manual and on the
product itself.
Please fill in and return the Warranty Card to the
address provided.
We hope you will enjoy using your purchase for
many years to come.
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 4

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
04
General Information
& Safety Instructions 2
Caution! When using tools it is imperative to
take the following basic safety precautions
in order to reduce the risk of injury and fire.
Read and take note of these instructions
before you use this tool.
General safety regulations
Explanation of the information plates on the machine
(See below)
1 Warning!
2 Read the instructions for use before use.
3 Protect from rain or wet conditions.
4 Wear eye protection and ear defenders.
5 Wear safety gloves.
6 Wear solid footwear.
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 5

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 05
1 This machine can cause serious injuries. Read the
instructions for use carefully to discover how to use
it correctly:
•preparation
•maintenance
•starting and stopping the machine
Make yourself familiar with all the adjusters on the
machine and how to use it properly.
2 Children must never be allowed to use the hedge
trimmer.
3 Take care near overhead power cables.
4 Do not use the hedge trimmer when people are
nearby, particularly children.
5 Wear suitable clothing. Do not wear loose
clothing or jewelry as it may get caught in moving
parts. We recommend that you wear strong gloves,
non-slip shoes and always wear safety goggles.
6 Stop the engine or pull the mains plug before the
following:
•Cleaning or removing a blockage
•Inspection, maintenance or other work on
the machine
•Adjusting the working position of the cutter.
7 If the angles of the cutter and/or the length of the
shaft can be adjusted on the hedge trimmer, do not
hold the blades when adjusting the working position
of the cutter. Always make sure that the cutter is in
the correct working position before you start the
engine or connect the plug to the mains supply.
8 Always stand in a safe position whilst using the
machine, particularly if you are using steps or a
ladder. Do not over reach.
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 6

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
06
9 Handle fuel with care, it is highly inflammable. Never
place fuel in a machine whose engine is running or
hot. Do not inhale fuel vapors, they
are toxic.
10 Do not carry out any repair work on the machine
unless you have been trained to do so.
11 Do not use the machine if it has a damaged or
excessively worn cutter.
12 To reduce the risk of fire ensure that the engine
and silencer are clear of deposits, leaves and
lubricants.
13 The machine may exceed 85 db (A) at the
workplace. The operator will require noise
protection measures and defenders if this is
the case.
14 Always make sure that all the handles and safety
equipment are fitted whilst you are using the
machine. Never attempt to use an incomplete
machine or one that has been modified illegally.
15 Always use both hands if the hedge trimmer is fitted
with more than one handle.
16 Always place the cover over the cutter when
transporting or storing the machine.
17 Important. This hedge trimmer is suitable for cutting
hedges, bushes and shrubs. Any use which is not
expressly permitted in manual may result in damage
to the hedge trimmer and place the user
in serious danger.
18 If it becomes necessary to stop the machine
immediately, set the ON/OFF switch to “Stop”
or “0”
19 Make yourself familiar with your surroundings and
watch for possible dangers that you may not be able
to hear due to the noise generated by the machine.
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 7

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 07
Keep these safety instructions in a safe place.
Specific safety information
1 Store the machine in a safe place. Carefully
open the fuel tank cap beforehand to release
any pressure that may have built up in the tank.
2 Start the machine at least 3 m away from the
refueling site to avoid the possible risk of fire.
3 Keep the handles dry, clean and free from the
fuel mixture, oil and grease.
4 Do not use any fuel other than that recommended in
the instructions for use. Always follow the
instructions in the section entitled “Fuel and oil”.
Never use pure petrol, always use the specified
petrol and oil mixture. Otherwise the machine would
suffer permanent damage and the manufacturer’s
warranty would be voided.
5 Do not smoke whilst refueling or working with
the machine.
6 Do not use the machine without the silencer
and/or screen for the silencer.
7 Never touch the silencer after you have used the
machine. Leave the machine to cool down for a while
before carrying our maintenance or adjustment work.
8 Do not use the hedge trimmer near inflammable
liquids or gases. This could result in an explosion
and/or fire.
9 Switch the machine off before you place it on
the ground.
10 Check all screws and seals at regular intervals to
ensure that they are tight and tighten them if
necessary. Never use the machine if it has not
been properly adjusted or has not been fully or
safely assembled.
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 8

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
08
11 Always clear items such as bottles, stones, etc.
away from where you are working. Thrown out
items may cause serious injuries to the user or
people nearby and may also damage the machine.
If you strike an item by accident, switch off the
machine immediately and check it. Never work
with a damaged or broken machine.
12 Do not modify, remove or add any things to any
components of this machine. This could cause
injuries or damage the machine and void the
manufacturer’s warranty.
13 Do not use the machine when you are tired or for
lengthy periods without breaks.
14 Do not use the machine if you have consumed
alcohol, drugs or strong medication.
15 Always hold the machine with both hands so that
your fingers and thumbs are hooked around the
handles.
16 Only use the machine outdoors. Exhaust fumes
are toxic.
Proper use
Important. This hedge trimmer is suitable for cutting
hedges, bushes and shrubs. Any use which is not
expressly permitted in manual may result in damage
to the machine and place the user in serious danger.
Be sure to observe the restrictions in the safety
instructions. Please note that our machines are not
designed for commercial, trade or industrial use.
Our warranty will be voided if the machine is used
in commercial, trade or industrial businesses or for
equivalent purposes.
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 9

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 09
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 10

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
10
Layout and items supplied (see Figs.1/2)
Installation
The hedge trimmer is supplied fully assembled.
No assembly work is required.
To make it easier to control, the machine is fitted with
a rotary handle that can be adjusted as required into
positions at angles of -90°/-45°/0°/+45°/+90°. To do
this, pull the lever (Fig. 5/Item B) backwards, turn the
rotary handle into the required position and then allow
the lever to lock at the front again. The various
adjustable positions facilitate working above head
height or in other places with different access.
Important: The rotary handle may only be adjusted
when the engine is switched off.
Assembly & Parts List 3
1 Cutting blade
2 Cutting blade
safety cover
3 Protection Guard
4 Front handle
5 Choke lever
6 ON/OFF switch
7 Locking knob for
throttle lever
8 Locking knob for
rotary handle
9 Fuel pump (primer)
10 Air filter cover
11 Starter handle
12 Rear handle
13 Throttle lever “release”
14 Throttle lever
15 Silencer cover
16. Tank for fuel mixture
17 Spark plug boot
18 Spark plug wrench
19 8 mm / 10 mm
open-ended spanner
20 Oil and petrol mixing
bottle
21 Cutter rail cover
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 11

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 11
1
2
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 12

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
12
Getting Started 4
Before starting the machine
Recommended fuels
Use only a mixture of normal unleaded petrol and
special 2-stroke engine oil. Mix the fuel mixture as
indicated on the fuel mixing table.
• Start the machine at least 3 m away from the
refueling site to avoid the possible risk of fire.
• Do not smoke whilst refueling or working with
the machine.
• Do not use the hedge trimmer near inflammable
liquids or gases. This could result in an explosion
and/or fire.
Important: Do not use a fuel mixture which has been
kept for longer than 90 days.
Important: Do not use 2-stroke oil with a
recommended mixing ration of 100:1. If inadequate
lubrication causes engine damage, the manufacturer’s
engine warranty will be voided.
Important: Only use containers designed and approved
for the purpose to transport and store fuel. Pour the
correct quantities of petrol and 2-stroke oil into the
mixing bottle (see scale printed on the bottle). Then
shake the bottle well.
Fuel mixing table
Mixing procedure: 40 parts petrol to 1 part oil
Petrol (unleaded) 2-stroke oil
1 litre 25 ml
5 litres 125 ml
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 13

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 13
supplied with blade guard
Counter rotating, double cutting blade action
19mm maximum cutting diameter
Rotating rear handle
500ml fuel tank
Features 5
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 14

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
14
Operation
Please note that the statutory regulations governing
noise abatement may differ from town to town.
Starting the engine from cold (Fig. 3-5)
Filling tank with a reasonable amount of petrol and oil
mixture.
1 Place the machine on a hard, level surface.
2 Set the choke lever (Fig. 4/Item 5) to “| |”.
3 Press the fuel pump (primer) (Fig. 4/Item 9)
10 times.
4 Move the ON/OFF switch (Fig. 3/Item 6) to “I”
5 Secure the throttle lever. To do this, press the
throttle lever lock (Fig. 3/Item 13) and then press
the throttle lever (Fig. 3/Item 14) and lock the
throttle lever by pressing the locking knob
(Fig. 3/Item 7) at the same time.
6 Hold the machine by the front handle in your right
hand and pull the starter cable (Fig. 5/Item A) up to
the first resistance point (approx. 10 cm). Now pull
the starter cable four times quickly.
The machine should start.
Important: Do not release the starter cable so that it
whips back by itself. This may cause damage.
7 If the engine has started, set the choke lever
immediately to “| |” and allow the machine to warm
up for approx. 10 seconds.
Instructions 6
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 15

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 15
Important: The cutting blades will start to work when
the engine starts because the throttle lever is locked.
Then release the throttle lever by simply pressing it
(the engine will return to idling speed).
8 If the engine does not start, repeat steps 6-7.
Please note: If the engine does not start up even
after several attempts, read the section “Engine
Troubleshooting”.
Please note: Always pull the starting cable out in a
straight line. If it is pulled out at an angle, then friction
will occur on the eye. As a result of this friction, the
cable will become frayed and will wear away faster.
3 4
5
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 16

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
16
Starting the engine when warm (the machine has not
been switched off for more than 15 – 20 minutes)
1 Place the machine on a hard, level surface.
2 Set the ON/OFF switch to “I”
3 Lock the throttle lever (as described in “Starting the
engine from cold”).
4 Hold the machine by the front handle in your right
hand and pull the starter cable up to the first
resistance point (approx. 10 cm). Now pull the
starter cable quickly. The machine should start after
1 – 2 pulls. If the machine does not start after 6 pulls,
repeat steps 1 – 7 of the procedure for starting the
engine from cold.
Switching off the engine
Emergency Stop procedure:
If it becomes necessary to stop the machine
immediately, set the ON/OFF switch to “Stop” or “0”
Normal procedure:
Let go of the throttle lever and wait until the engine
has changed to idling speed. Then set the ON/OFF
switch to “Stop” or “0”.
Practical tips
Never allow the machine to run at low speed for
starting or for cutting.
Cutting for dense growth
The most effective method is to use wide, sweeping
movements, guiding the cutting edge of the blade
straight through the branches. A slight incline of the
blade downwards towards the movement will produce
best cutting results.
It is recommended to tie a guide line of string or the like
along the hedge so that you cut the hedge to a level
height. The branches above it will be cut off. (Fig. 6)
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 17

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 17
Cutting the side of a hedge
Cut the sides of the hedge with curve-shaped movements
from the bottom up. (Fig. 7)
Important: As a result of its design, if you work with the
machine on its side for a lengthy period and the tank
not completely filled, the motor may stall.
6
7
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 18

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
18
Check
Ignition
Switch Is On
If Yes
Check
Sufficient
Fuel In
Tank
If Yes
Check If
Primer
Has Been
Pushed 10
Times
If Engine
Is Cold
Check
Choke
Setting
If So Then
Switch On
If No
Then Fill
Tank With
Correct
Fuel/Oil
Mix
If Yes
Check If
Primer
Has Been
Pushed 10
Times
If Engine
Is Cold
Check
Choke
Setting
Continue
With Starting
Procedure
If after trying all of the above procedures please
call the help line for further assistance
Continue
With
Starting
Procedure
Continue
With
Starting
Procedure
Continue
With
Starting
Procedure
Pull
Start
Cord
Min. 5
Times
Petrol Engine Starting Procedure/Check List
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 19

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053 19
Maintenance
Always switch off the hedge trimmer and remove the
spark plug boot before carrying out any maintenance
work.
1 The cutter blades are high quality, made of tempered
steel and in normal use there is no need to sharpen
the blades. If you accidentally strike a wire, stone,
glass or other hard object, this may cause a notch in
the blade. There is no need to remove the notch as
long as it does not adversely affect the movement of
the cutting edges. If it does adversely affect this
movement, switch off the machine and use a fine file
or a fine grinding stone to remove the notch. Ensure
that the blade’s cutting edge is always well oiled
(see Fig. 8).
2 If you drop the hedge trimmer, check whether it
has suffered any damage. If it is damaged contact
an authorized customer service outlet or send the
machine to ISC GmbH to have it repaired.
3 Only clean the machine after it has been switched
off. Use only mild soap and a damp cloth to clean it.
Never allow fluid to get into the machine. Do not
use caustic cleaning products.
8
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 20

Helpline No. UK/Northern Ireland 0151 6491500
Rep. Ireland 1890 946244
Model Number: 9053
20
Maintenance of the air filter (Figs. 9/11)
Soiled / blocked air filters reduce the air intake to the
engine and this will also reduce the engines output.
Regular checks are therefore essential. The air filter
should be checked after every 25 hours of use and
cleaned if necessary. If the air contains a lot of dust,
the air filter should be checked more frequently.
1. Remove the air filter cover (Fig. 9-10)
2 Remove the filter element (Fig. 11)
3 Clean the filter element by tapping it or blowing it.
4 Assemble in reverse order.
Important: Never clean the air filter with petrol or
inflammable solvents. Clean the air filter with
compressed air or by tapping it.
Maintenance of the spark plug (Figs. 12/14)
Spark plug gap = 0.025 inch (0.635 mm). Tighten the
spark plug with a torque of 12-15 Nm.
Check the spark plug for dirt and grime after 10 hours
of operation and if necessary clean it with a copper wire
brush. Thereafter service the spark plug after every
50 hours of operation.
1 Pull off the spark plug boot (Fig. 13) by twisting.
2 Remove the spark plug (Fig. 14) with the supplied
spark plug wrench.
3 Assemble in reverse order.
GLPHT26 User Guide Artwork.qxd 28/1/08 9:11 am Page 21
