Gardenline LT26 User manual

After Sales Support
Now you have purchased a Gardenline®
product you can rest assured in the
knowledge that as well as your
3 year parts and labour guarantee
you have the added peace of
mind of dedicated helplines
and web support
26cc Petrol Line Trimmer
User Guide
AFTER SALES SUPPORT
1800 909 909
www.powertoolsupport.com
MODEL: LT26 PRODUCT CODE: 43670 10/2014
YEAR WARRANTY
2
AUS

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
2
Contents
03 Warranty
03 Introduction
03 Environmental protection
04 Description of symbols
05 Specifications
06 Safety instructions
08 Additional safety rules for petrol line trimmers
09 Parts list
10 Unpacking
10 Contents of carton
10 Assembly
13 Mixing the fuel
14 Filling the tank
15 Starting the line trimmer
16 Stopping the line trimmer
17 Running in the engine
17 Use of the petrol line trimmer
17 Operating the line trimmer
18 Feeding the line
19 Advancing the llne manually
19 Tips for cutting
19 Replacement of the cutting line
20 Maintenance
22 Storage and maintenance after use
23 Problems
22 Service Support
23 Accessories & Problems

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
3
Introduction
Your new Gardenline®line trimmer will more than satisfy
your expectations. It has been manufactured under stringent
Gardenline®Quality Standards to meet superior performance
criteria.
You will find your new line trimmer easy and safe to operate, and, with proper
care, it will give you many years of dependable service.
CAUTION. Carefully read through this entire instruction manual before using
your new Gardenline®line trimmer. Take special care to heed the Cautions and
Warnings.
Your Gardenline®line trimmer has many features that will make your job faster
and easier. Safety, performance, and dependability have been given top priority
in the development of this tool, making it easy to maintain and operate.
Environmental protection
Recycle unwanted materials instead of disposing of them as waste.
All tools, hoses and packaging should be sorted, taken to the local
recycling centre and disposed of in an environmentally safe way.
1
What your 3 year warranty means
Great care has gone into the manufacture of this product and it should
therefore provide you with years of good service when used properly.
In the event of product failure within its intended use over the
course of the first 3 years after the date of purchase, we will remedy
the problem as quickly as possible once it has been brought to our
attention. In the unlikely event of such an occurrence, or if you require
any information about the product please contact us via our after sales
support services, details of which can be found in this manual and on
the product itself.
After Sales Support TEL: [phone]
YEAR WARRANTY

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
4
Description of symbols
The rating plate on your tool may show symbols. These represent important
information about the product or instructions on its use.
Conforms to relevant standards for electromagnetic compatibility.
Wear hearing protection. Wear eye protection.
Wear breathing protection.
Wear safety footwear.
Wear safety gloves.
Warning.
Read these instructions for use carefully.
Choke control
Start position (choke closed).
Run position (choke open).
Use at a distance of at least 15m from other people.
Thrown objects and rotating line can cause severe injury. Do not operate
the unit without the safety guard in place. Keep away from rotating cutter.
Sharp blade on the safety guard, do not touch the cut off knife.
Explosive material.
Extremely hot surface. Do not touch a hot muffler, gear box or cylinder,
you may get burned. These parts get extremely hot from operation and
remain hot for a short time after the unit is turned off.
Noise label rating 85dBA (taken at 7.5 metres) you must wear ear
protection at all times.
General Information & Safety Instructions
NOI SE dB
A
85
2

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
5
2
General Information & Safety Instructions
Specifications
Engine: 26cc, 2 stroke
Max. speed: 8500min-1
Cutting diameter (swathe): 380mm
Line thickness: 2mm
Spool type: Bump feed, twin line
Fuel tank capacity: 700ml
Fuel type: Unleaded petrol
Fuel mixture: Unleaded petrol:
2-Stroke oil (40:1)
Spark Plug: Torch L7RTC
Equivalent spark plugs: NGK BPMR7A
CHAMPION RCJ6Y
Net Weight: 4.5kg
Noise label rating 85dBA (taken at 7.5 metres) you must wear ear protection
at all times.

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
6
2
Safety instructions
WARNING Read and understand all instructions. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious injury. The term
“power tool” in all of the warnings below refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
Save these instructions
Work area
• Keepworkareacleanandwelllit.Clutteredanddarkareasinviteaccidents.
• Donotoperatepowertoolsinexplosiveatmospheres,suchasinthepresenceof
flammable liquids, gases, or dust. Power tools create sparks which may ignite the
dust or fumes.
• Keepchildrenandbystandersawaywhileoperatingapowertool.Distractions
can cause you to lose control.
Personal safety
• Stayalert,watchwhatyouaredoingandusecommonsensewhenoperatinga
power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol, or medication. A moment of inattention while operating power
tools may result in serious personal injury.
• Usesafetyequipment.Alwaysweareyeprotection.Safetyequipmentsuchas
a dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
• Removeanyadjustingkeyorwrenchbeforeturningthetoolon.Awrenchor
a key that is left attached to a rotating part of the power tool may result in
personal injury.
• Donotoverreach.Keepproperfootingandbalanceatalltimes.Thisenables
better control of the power tool in unexpected situations.
• Dressproperly.Donotwearlooseclothingorjewellery.Keepyourhair,clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
• Ifdevicesareprovidedfortheconnectionofdustextractionandcollection
facilities ensure that these are connected and properly used. Use of these devices
can reduce dust-related hazards.
General Information & Safety Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
7
2
Power tool use and care
• Donotforcethepowertool.Usethecorrectpowertoolforyourapplication.
The correct power tool will do the job better and safer at the rate for which it was
designed.
•Donotusethepowertooliftheswitchdoesnotturnitonandoff.Anypowertool
that cannot be controlled with the switch is dangerous and must be repaired.
• Turntooloffcompletelybeforemakinganyadjustments,changingaccessories,or
storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
• Storeidlepowertoolsoutofthereachofchildrenanddonotallowpersons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
• Maintainpowertools.Checkformisalignmentorbindingofmovingparts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
• Keepcuttingtoolssharpandclean.Properlymaintainedcuttingtoolswithsharp
cutting edges are less likely to bind and are easier to control.
• Usethepowertool,accessoriesandtoolbitsetc.,inaccordancewiththese
instructions and in the manner intended for the particular type of power tool, taking
into account the working conditions and the work to be performed. Use of the power
tool for operations different from intended could result in a hazardous situation.
Service
• Haveyourpowertoolservicedbyaqualiedrepairpersonnelusingonlyidentical
replacement parts. This will ensure that the safety of the power tool is maintained.
General Information & Safety Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
8
Additional safety rules for petrol line trimmers
• Donotoperateinahazardouslocation.Suchareasincludewherethereisarisk
of explosion of petrol fumes, leaking gas or explosive dust.
• Donotoperateinaconnedarea.Exhaustgases,smokeorfumescouldreach
dangerous concentrations.
• Protectyourtool.ThislinetrimmerisNOTWEATHERPROOFandshouldnotbe
exposed to direct sunlight, high ambient temperature and damp, wet or high
humidity conditions.
• Donotsmokewhilerefuelling.Thisispotentiallydangerousasitmayignite
the fuel and cause an explosion.
• Takecarenottospillfuel.Whenrefuellingthelinetrimmerensurethatthe
motor has been switched off. Prevent the spilling of fuel as this may also ignite
with the hot motor. Never refuel whilst the engine running.
• Becarefulwhereyoustorethelinetrimmer.Storethelinetrimmerinadryarea
away from flammable liquids.
• Keepyourdistance.Thelinetrimmeremitsexhaustfumes.Ensurebystanders
keep a safe distance.
• Ensureyouuseoil-mixfuel.Ensurethatyoumix40partsunleadedfuelto1
part 2-stroke oil. If not, the engine will overheat and cause damage to your line
trimmer. Do not use ethanol fuel (E10). Use fresh 91 Octane unleaded petrol.
• Usegoodqualityaircooled2-strokeengineoil.
• Neverllfueltankindoors.Neverllfueltankwhenengineisrunningorhot.
Do not smoke when filling fuel tank.
Wear goggles
Wear earmuffs
Wear a breathing mask
General Information & Safety Instructions
2

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
9
1. Cutting line spool
and assembly
2. Cut off knife
3. Safety guard
4. Handle
5a. Upper shaft
5b. Lower shaft
6. Recoil starter
7. Ignition On/Off switch
8. Fuel tank
9. Throttle trigger
10. Primer
11. Spark plug
12. Filter cover
13. Safety lever
14. Choke lever (red)
15. Handle locking screws x 2
16. Spark plug wrench
17. Carry strap
18. Bump knob
19. Hex key
20. Throttle lock button
21. Shaft locking knob
Parts List
62
15
1
18
21
11
12
14
13
7
3
5a
4
9
5b
8
3
Note. Before operating ensure
that the protective cover is
removed from the cut-off knife.
10
7
20
16
17
19

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
10
Getting Started 4
Unpacking
Due to modern mass production techniques, it is unlikely that your petrol line
trimmer is faulty or that a part is missing. If you find anything wrong, do not
operate the tool until the parts have been replaced or the fault has been rectified.
Failure to do so could result in serious personal injury.
Contents of carton
•Uppershaftwithmotor
•Lowershaft
•Safetyguardwithattachingboltandnut
•Hexkey
•Sparkplugwrench
•Bumpfeedspool
•Fuelmixingcanister
•Carrystrap
Assembly
Prior to use, it is necessary to assemble the safety guard (3) and cutting spool (1)
to the lower shaft (5b) and join the lower shaft (5b) to the upper shaft (5a).
Before assembling the line trimmer, ensure the protective plastic sleeve is
removed from the shaft of the trimmer.
Fitting the safety guard
Note. If the bump feed knob is fitted, remove the bump feed knob on the end
of the spindle prior to fitting the guard. To remove the bump feed knob, turn the
bump knob (18) in an anti-clockwise direction.
1. Slide the safety guard (3) on from the bottom of the lower
shaft (5b). The guard should slide upward so the bracket fitted
on the end of the shaft locates on the inside of the guard.
Ensure the holes of the safety guard line up with the fixing
mount holes on the shaft bracket.
Note. If you require replacement spool and line, this is
available for purchase. Please refer to page 23 for
further detail.

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
11
2. Place the hex nut into the hex shape recess
on the guard. Slide the screw through the
side of the safety guard and tighten with
the hex key provided.
Joining the shaft
1. Depress the location pin and insert the
lower shaft (5b) into the upper shaft (5a).
Rotate the lower shaft until the pin locates
positively into the hole in the upper shaft.
2. Tighten the shaft locking knob (21) to
secure both shafts in place.
Fitting the spool
Note. The spool assembly is contained
with shrink plastic to assist in the assembly.
Keep this plastic wrap intact while you assemble. When fitting
the spool on the shaft, the shaft will pierce through the thin
plastic wrap.
1. Slide the raised section of the spool (1) onto the end of the
shaft. Ensure the large hex recess on the rear of the spool fits
fully over the large hex drive on the base of the spindle.
2. With your fingers, push the spool fully into the housing and
screw the bump knob (18) onto the end of the shaft by turning
it in a clockwise direction. Screw the bump knob onto the
shaft until it’s tight whilst holding the spool.
Note. Ensure to remove any packing tape and plastic wrap
from the spool at this stage.
3. Once the spool is fully inserted and the lines are fully through
the eyelets, pull firmly on each line to disengage the lines from the spool notches.
Ensure the lines are fully clear of the spool notches and the line is passing through
the eyelets directly to the spool.
Note. If you require replacement spool and line, this is available for purchase.
Please refer to page 23 for further detail.
5
Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
12
5
Fitting and adjusting the secondary handle
WARNING. Before each use, ensure the secondary handle
cannot swivel by checking the two handle clamp screws are
tight and the handle is firm.
1. The line trimmer has been pre-packed with the secondary
handle facing in the opposite direction to where it must sit
during use.
2. Rotate the secondary handle by 180°.
3. After locating the handle in the
operational position, tighten the two
handle clamp screws (15) to the point
where the handle is firm on the shaft
4. After the first use, you may find the
handle needs to be adjusted. To move
or rotate the handle, loosen the two
handle clamp screws (15), and rotate or
slide the handle up or down the shaft.
When the desired position is found, re
tighten the two handle clamp screws so
the handle is firm on the shaft.
Instructions
pre-packed
position
operational
position
rotate 180º

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
13
5
Mixing the fuel
MOTOR FUEL: MIX AT 40:1 ONLY
For example: For 1 litre of unleaded petrol add 25ml of oil.
For 5 Litres of unleaded petrol add 125ml of oil.
IMPORTANT. Use good quality air cooled 2-stroke engine oil.
This product is powered by a 2-stroke engine and requires
pre-mixing fuel with 2-stroke oil.
1. Use fresh unleaded petrol. Do not use ethanol fuel (E10). Use
fresh 91 Octane unleaded petrol. You must use 2-stroke oil
specifically made for heavily stressed two-stroke engines.
2. Mix the petrol and oil in an approved container. Never mix fuel
directly in the line trimmer fuel tank. Use the fuel mixing bottle
included with this product.
Note. Mixing has been made easy by including markings on the container
included. For example, if unleaded fuel is filled to the ‘400’ mark in the “GAS”
column of the container, place oil in the container until it reaches the next mark
(in the 40:1 OIL markings of the container). Therefore, 400ml of fuel would mean
10ml of oil must be added.
WARNING. Never use any type of pre-mixed fuel/oil direct from fuel stations.
This may include special blends intended for use in mopeds, motorcycles, etc.
3. Mix the fuel thoroughly and also each time before fuelling.
4. Always pre-mix in small quantities. Never mix quantities larger than what will be
used in a 30-day period.
Note. The mixing bottle provided is NOT for the storage of fuel. This container is
solely for mixing of fuel only.
Ensure to keep this container in a safe storage location, empty of fuel and out of
reach of children.
Instructions
40:1

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
14
SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
Filling the tank
WARNING. Always shut off the engine before fuelling. Never add fuel to a
machine with a running or hot engine. Move at least 9 m (30 ft.) away from
the refuelling site before starting engine. Do not smoke when refuelling or
operating the line trimmer.
Note. It is normal for smoke to be emitted from a new engine during and after
first use.
1. Place the line trimmer upright on the ground or on a sturdy
bench and wipe any debris from around the fuel cap.
2.
Unscrew the fuel tank cap and pour the mixture into the tank
with the aid of a funnel.
3. Be careful not to spill any mixture. If this happens, wipe the
spill with a clean rag.
4. Start the engine at least nine metres (30ft) away from the area
where the fuel tank has been filled up in order to avoid any risk of fire.
• Alwaysuseextremecarewhenhandlingfuel!Fuelishighly
flammable.
• Neverattempttofuelthelinetrimmerifthefuelsystem
components are damaged or are leaking.
• Neverattempttherefueltheenginewhileitisrunningorstill
warm, allow it to cool before fuelling.
• Neversmokeorlightanyresnearthelinetrimmerorfuels.
• Alwaystransportandstorefuelsinanapprovedcontainer.
• Neverplaceammablematerialclosetotheenginemufer.
• Neveroperatethelinetrimmerwithoutaproperlyfunctioningmuferand
spark plug cover installed.
• Neveroperatethelinetrimmerunlessitisproperlyassembledandingood
working condition.
• Donotusepetrolwhichcontainsethanolormethanolasitmaydamagethe
fuel lines and other engine parts.
• Mixonlyenoughfuelforyourimmediateneeds.Donotstorepre-mixedfuel.
5
Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
15
Starting the line trimmer
Choke control
Start position (choke closed).
Run position (choke open).
1. Press the ignition switch (7) to the ‘on’
position marked with an “I”.
2. Move the red choke lever (14) upwards to
the start position (cold start).
Note. This is not required if the engine is
already warm.
3. Push the primer bulb 6-10 times, until the
primer bulb fills with fuel/oil mixture.
4. Squeeze the safety lever (13) and the
throttle trigger (9) and engage the throttle
lock button (20). The throttle lock button
should engage with the trigger approx
half pressed. Release the throttle trigger.
With the throttle lock button engaged, the
throttle trigger will be partially depressed
ready for starting.
Note. For cold starting this is an important step.
5 Pull the recoil starter until you hear the engine starting or
trying to start. (Under full choke it may only run for 1 or 2
seconds).
6 Push the choke (red lever) half way down and allow the motor
to warm up. Restart if the motor stops.
5
Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
16
7. Once the engine is fully warm ensure the choke (red lever)
is down fully to the run position (warm start) and pull the
throttle trigger and release. This will release the throttle lock.
8. To increase the speed of the cutting line, squeeze the safety
lever (13) first, and then squeeze the throttle trigger.
To reduce the speed of the cutting line release the throttle
lever.
Note. The cutting spool and line is directly connected to the motor and will
always be rotating when the motor is operating.
Warm Start
When re starting the line trimmer after it has been used and the motor is hot,
there is no need to engage the choke (red lever).
Follow steps 4, 5 6 and 7 above.
Stopping the line trimmer
WARNING. The spool and line will rotate whenever the motor
is operating.
1. Release the throttle trigger (9) and allow the engine to idle
for a few moments.
2. Move the ignition switch (7) to the off position marked
with an “O”.
3. The engine will now stop.
5
Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
17
Running in the engine
1. During the first 2–3 hours of work, run the engine at a moderate RPM.
2. We advise you in any case not to maintain your engine at a high speed as the
different components must settle with each other during the process of running
in the engine.
3. It is at the end of the running in period that the engine will reach its maximum
power.
4. After the first two hours of work, stop and make sure that all nuts and screws
are securely fastened, and tighten them if necessary.
Use of the petrol line trimmer
This petrol line trimmer is only made to cut grass.
• Alwaysusetheshoulderstrap(17),whenusingthelinetrimmertoavoid
serious personal injury.
• Performafewaccelerationsofthemotorwithoutreachingmaximumspeed
and without working to make sure that everything is in good working order.
• Starttheengineonlywhenyouareclosetotheworkingarea.
• Placeyourselfinawellbalancedposition,stableonbothfeet.
Operating the line trimmer
IMPORTANT. Petrol line trimmers transmit vibrations to the operator during
use. These vibrations can generate increased fatigue. For this reason, we
recommend taking regular breaks during work. We also recommend taking
a break after a few hours of work to rest the engine. If abnormal noise or
vibration occurs during operation, turn the line trimmer off immediately and
have the problem corrected.
1. Keep a firm grip on the line trimmer with both hands while in operation.
The line trimmer should be held at a comfortable position with the rear handle
about hip height.
2. Always operate the line trimmer at full throttle. Cut tall grass from the top
down to prevent grass from wrapping around the spool which may cause the
line trimmer to overheat.
5
Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
18
Note. If grass becomes wrapped around the spool, stop the engine, disconnect
the spark plug wire, and remove the grass.
Note. Prolonged cutting not at full throttle may result in oil dripping from
the muffler.
Feeding the line
WARNING. The engine of the petrol line trimmer must be at a complete stop
during assembling, repair and cleaning operations that could be necessary.
The line trimmer has a bump feed mechanism which releases the line without
having to stop the engine.
1. To release additional line, lightly tap the bump knob (18) on the ground
while operating the unit at high speed.
Note. Always keep the line fully extended. Line release becomes more difficult
as the cutting line becomes shorter.
2. Each time the head is bumped it releases approximately 2cm of line. Release the
line until it strikes the cut off knife (2). This may require several taps.
Note. The cut off knife (2) on the safety guard (3) will automatically cut off
any excess line. For best results tap the head on hard soil or bare ground. Never
bump the spool head on concrete as it may crack the spool housing.
IMPORTANT. Do not hit stones (even small ones), piles of earth, and small
pieces of wood or anything else that could be hidden or poorly visible in the
grass. If you hit a large object by accident, or if you block the cutting tool due
to overloading or having the cutter jammed with grass, you must stop the
engine.
Note. All protective devices of the machine as well as protective equipment
must be maintained in good operation condition during the period of use.
Note. If the line is too short you may not be able to advance the line by
tapping it on the ground. If this is the case, stop the engine and manually
advance the line.
5
Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
19
Advancing the line manually
1. Push the bump knob in while pulling on both lines to manually advance the line.
2. Release the bump knob and again pull on both lines to advance the line further.
3. If the line still does not advance remove the spool and check the lay of the line.
It may be twisted or trapped under over laying line.
Tips for cutting
WARNING. Beware of bystanders at all times
• Cutthegrasslikeyouareinacorridorabout1.5mwide.Movestepbystep,
moving the machine from left to right and vice-versa. Make sure at each step
that you are still well balanced on your feet
• Keepthelinetrimmertiltedtowardstheareabeingcut
• Letthetipofthelinedothecutting.Neverforcethespoolintouncutgrass.
• Runningthelineintofences,stoneandbrickwalls,curbs,andwoodcauses
extra line wear, even breakage.
Replacement of the cutting line
1. Stop the engine.
2. Put the petrol line trimmer on the floor in a way that the cutting line and spool
assembly (1) is facing up.
3. Open the cutting line and spool assembly (1) by holding the spool housing
firmly while rotating the bump knob anti-clockwise.
4. Remove the bump knob completely and remove the spool from the spool shaft.
Discard any short lengths of remaining cutting line.
5. Take a 4 metre length of Ø2mm line and halve it.
6. Place the half way mark of the line into the notch in the spool.
7. Wrap the line around the inside of the spool in an anti
clockwise direction (following the directional arrows on the
spool). Ensure the line is wrapped tightly and neatly.
8. When there is approximately 150mm of line left, lock one of
the lines into one of the line location notches in the spool head
and the other into the opposing notch.
5
Instructions

SUA 1800 909 909 www.globalpowerbrands.com email: [email protected]
AFTER SALES SUPPORT 43670
20
9. With the spring fitted onto the shaft of the spool holder insert
the spool back into the holder. As you insert the spool, thread
the lines through the eyelets and pull firmly to disengage from
the notch in the spool.
Note. When inserting the spool into the housing, the spool
may need to be rotated slightly so as to locate into the
housing. Before the spool is fully inserted into the housing,
ensure the lines are free of the notches.
10.Once the spool is fully inserted and the lines are fully through
the eyelets, pull firmly on each line to disengage the lines from
the spool notches. Ensure the lines are fully clear of the spool
notches and the line is passing through the eyelets directly to
the spool.
11.To install the spool, line and housing, refer to ‘Fitting the
spool’ section of this manual.
Note. On start up test the operation of the bump feed to ensure the line feeds
correctly.
CAUTION. After changing the line spool, run the petrol line trimmer under
no load for at least a minute to make sure that the line and the tool are
both operating correctly. Use only the line spool as recommended by the
manufacturer.
WARNING. Never use steel threads and/or three teeth blade other than those
provided by the manufacturer. Always use tools in perfect condition, free of
damage.
WARNING. In high-speed rotation, parts could be projected at very high speed
and could involve serious injury and damages to persons and property.
Maintenance
Air filter
Accumulated dust in the air filter will reduce engine efficiency. Increase fuel
consumption and allow abrasive particles to pass into the engine. Remove the
air filter as often as necessary to maintain a clean condition.
• Removeltercover(12)bypressinginthesidesandliftingitoff.
• Lightsurfacedustcanreadilyberemovedbytappingthelter.
5
Instructions
