Gardman Easy Obelisk User manual

Easy Obelisk
Assembly Instructions
07701
Components Supplied Tools Required (not supplied)
Phillips cross-head screwdriver
Mallet
Tape Measure
Before You Start
•Layout all of the component parts and
make sure you have all of the parts listed.
•When you are ready to start, make sure
that you have the right tools to hand,
plenty of space and a clean dry area for
assembly. Always try to assemble the
product as close as possible to the
intended location.
•Remove all plastic bags and dispose of
safely.
•Retain the instructions for future use.
Caution
This pack contains small items which should
be kept away from children.
Ref Description Illustration Qty
ATop curved 3
tubes
BCentral leg 3
tubes
CLower leg 3
tubes
DRings 3
EFinial 1
FAssembly 15
screws
GFinial retaining 1
screw
Consumer Helpline
If you have any problems or queries with
this product then please contact our
helpline number: 01406 372227,
or write to: Gardman Ltd. High Street,
Moulton, Spalding, Lincs, PE12 6QD.
Fax: [phone].

1. Assemble the three sides as shown
(A, B and C).
2. Fit the finial (E) with the retaining
screw (G).
3. Attach the three rings (D) with
the assembly screws (F).
4. Place assembled obelisk in desired
location. If the ground is soft the
obelisk can be pushed into the ground.
Where the ground is particularly hard
fitting can be aided by either watering
the ground or pushing a suitable rod or
spike in first. A depth of approximately
0.30m (1') is recommended.
Helpful hints:
You may find it easier to assemble your
obelisk horizontally on its side and then
carefully stand it upright to install.
If the screw holes on the poles are
covered with a thin layer of the
protective coating, carefully remove this
by pushing a small nail through the
coating.
Assembly
0.33m
(1'1")
1.63m
(5'4")
0.30m
(1')
All sizes approx.
BELOW GROUND
HEIGHT ABOVE
GROUND
WIDTH
TOTAL HEIGHT BEFORE FITTING: 1.93m (6'4")
A
B
C
E
D
G
E
