Garelli PRIMABICI User manual
CONTENTS:
REQUIRED TOOLS:
BALANCE BIKE USER MANUAL
BE CAREFUL
2-5 YEARS
maximum load.
50kg/110lbs
First verify the following parts are complete.
Please contact the retailer if parts are missing.
Using tools and performing mechanical work always poses
a risk of injury. Therefore always use suitable high-quality
tools. Be careful when assembling/disassembling the
product to prevent injuries.
1 xFRAME, FORK AND
REAR WHEEL
1 xFRONT WHEEL 1 xHANDLEBAR
1 xMANUAL2 xFOOT ANTI-SLIP
STICKER
HEXAGON KEY
KEY-WIDE 6/8
1 xSADDLE
ASSEMBLY:
SADDLE
HANDLE-
BAR
ERGONOMICALLY-PADDED
SEAT ADJUSTABLE WITH
EASY-ADJUST CLAMP.
ADJUSTABLE RISER HANDLEBAR WITH GRIPS FOR
CHANGING HANDLE GRIP POSITION, WHETHER YOUR
LITTLE BABY NEEDS A LONGER REACH OR A PERFECT
POSITION.
[Fig. 1]
[Fig. 2]
[Fig. 3] [Fig. 4] [Fig. 5]
The saddle height must be adjusted in such a way that the
child’s feet can be placed on the ground with the legs slightly
bent.
Please observe the “Minimun Insert” on the seatpost, as this
marks the minimum insertion depth. Under no circumstances
may the saddle be attached at a higher position than this.
Position the saddle on the seat tube at a height which is suitable
for the child. Ensure that the saddle does not shift. Unlock the quick
release and adjust the saddle to the desired position and then lock the
quick release.
The saddle must be secure and not be able to move.
1.
2.
Turn the handlebar stem including the front wheel by 180 degrees, until
the stem clamp points forward [Fig. 2]. The two bolts on the stem clamp
and the front wheel should point straight forward. If this is not the case,
loosen the bolt on the fork stem [Fig. 3] using a hex key [6mm] and take
out of the screw and cap.
Place the handlebar and be sure that the handlebar is positioned in the
center. Place the cap the screw onto the handlebar [Fig. 4] and tighten
the two screws [Fig. 5] with a hex key [6 mm].
All components must be secure and the handlebar can’t move
independently of the front wheel!
12 INCH BMX STYLE WHEELS WITH EVA (FOAM)
OR AIR (PNEUMATIC) TYRES
ALWAYS WEAR A HELMET
AND PROTECTIVE EQUIPMENT!
CAUTION: This product contains small parts which are necessary for assembly. Prior
to and during assembly of this product, keep small pats out of children’s reach. Small
parts pose a choke hazard to children under 2 years.
ADULT ASSEMBLY REQUIRED
[Fig. 6]
[Fig. 8] [Fig. 9]
[Fig. 7]
Take out the screws (2 sets) [Fig. 6], turn the bike upside down and put
on the ground.
Put the wheels into the front fork leg. Two wheels are identical, please
make sure each tyre pattern is in the right direction [Fig. 7].
Then align the screw at the screw holes of the fork [Fig. 8] and use the
hexagon wrench to tighten each screw [Fig. 9].
TYRE
3.
WARNING:
• Regularly check that nuts / bolts for tightness
• EVA (FOAM) tyres don’t need inflating and maintenance.
• This balance bike should only be cleaned using a damp cloth – please do
not use any chemical cleaners as these may damage the bike
• This balance bike should be protected from rain and snow
• Do not store the item in a damp environment as this will be detrimental
to quality.
• This balance bike does not contain a braking system. Your child should
carefully use their feet to stop the bike.
• This balance bike is designed to carry the weight of only one child at a
time, weighing less than 50kg.
• Rough use can cause damage to the paintwork.
• Do not use this balance bike if any parts are broken or missing and use
only replacement parts supplied by the manufacturer or distributor.
SAFETY:
ALWAYS: make sure your child wears a helmet, gloves, elbow and
kneepads can help too.
ALWAYS: before each ride, ensure that the balance bike is safe. Are the
wheel axle bolts tight?
ALWAYS: ensure that your child understands the dangers of roads and
crowded areas.
ALWAYS: allow use of the balance bike under adult supervision only.
ALWAYS: ensure that you understand the dangers of the environment
where your child is using the balance bike.
NEVER: on the road or on narrow pavements.
NEVER: near a swimming pool, lake or river.
NEVER: anywhere near staircase or steps.
NEVER: on gravel, sand or slippery floors.
NEVER: using electronic devices or mobile phones.
NEVER: anywhere near to downhill or jumps.
MADE IN CHINA UNDER GARELLI PRIMABICI QUALITY STANDARD AND SUPERVISION.
DESIGNED IN ITALY
www.primabici.com
Dolomeet SrL
Loc. Zona Industriale, 21 - Innovation Center - 38027 Malè - TN
P.IVA: 02413740222 | C.F.: 02413740222
