Garmin GIA 63 User manual

The following files have been archived under the aboce ARCHIVE FILENAME.
Filename File Contents
Date:
Drafter:
Checker:
Project Engineer:
Released By:
TITLE:
PART NO:
SIZE
A
Scale: N/A
REV.
Sheets of
REVISIONS
SPECIFICATION
CONTROL
DRAWING
REV. DATE DESCRIPTION ECO NO.
Garmin Ltd. or its subsidiaries
c/o Garmin International, Inc.
1200 E. 151st Street
Olathe, Kansas 66062 U.S.A.
CONFIDENTIAL
This drawing and the specifications contained herein are the property of Garmin
Ltd. or its subsidiaries and may not be reproduced or used in whole or in part as
the basis for manufacture or sale of products without written permission .
39
190-00303-05.pdf
190-00303-05.pdf
John Sherman
190-00303-05
GIA 63/GIA 63W Installation Manual
H
1 49
GIA 63/GIA 63W Installation Manual
9
Daniel Cobb
Craig Parker
SDT
11/17/03
11/17/03
11/17/03
11/18/03
F 7/21/06 Corrected WAAS TSO 39172
G 9/19/06 Added RTCA/DO-229C deviation 40285
H 10/18/06 Added Comant Antennas 40905
NOTES:
1. DESCRIPTION: G1000 Installation Documentation -
2. PAGE SIZE: Letter: Width = 8.5 inches, Height = 11 inches
Tabloid: Width = 11.0 inches, Height = 17.0 inches
3. PAGINATION: double-sided letter sheets. single-sided tabloid sheets.
4. MATERIAL: 24 pound bond. Approved equivalents allowed.
5. COLOR: Black Ink on White Paper Stock.
6. BINDERY: Three-hole punch, shrink-wrap. Digital output preferred
7. FOLDS: Z-Fold tabloid sheets at end of document.
8. ELECTRONIC ARTWORK: Shall Conform to Garmin Archive, Filename:
Portable Document Format, contains Installation Manual and Release Specification
release.indd Adobe InDesign Format, Release Specification
Manual Elements Word 97 for PC, Formatted Files and Figures
*.* Various supporting illustrations, drawings, and artwork.
8.5"
11"
3-Hole
Punch
GIA 63/GIA 63W
Installation Manual
DER REVIEW REQUIRED

190-00303-05 October, 2006 Revision H
GIA 63/GIA 63W
Installation Manual

Page A GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
© Copyright 2003-2006
Garmin Ltd. or its subsidiaries
All Rights Reserved
Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted,
disseminated, downloaded or stored in any storage medium, for any purpose without the express prior
written consent of Garmin. Garmin hereby grants permission to download a single copy of this manual
and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed and
to print one copy of this manual or of any revision hereto, provided that such electronic or printed copy of
this manual or revision must contain the complete text of this copyright notice and provided further that
any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.
Garmin International, Inc.
1200 E. 151st Street
Olathe, KS 66062 USA
Telephone: [phone]
Aviation Dealer Technical Support Line (Toll Free): [phone]
www.garmin.com
Garmin (Europe) Ltd.
Unit 5, The Quadrangle
Abbey Park Industrial Estate
Romsey, SO51 9DL U.K.
Telephone: [phone]
RECORD OF REVISIONS
Revision Revision
Date
Description ECO #
A 11/15/04 Production Release 28320
B 3/16/05
Updated pinout list, removed EQF and ETSO 2C37e
deviation 30643
C 6/23/05
Added additional interconnects, TSO-C9c, and TSO-
C52b 31908
D 10/26/05 Added TSO-C151b and boot block instructions 34307
E 6/8/06 Edited document to include the GIA 63W 38321
F 7/21/06 Corrected WAAS TSO 39172
G 9/19/06 Added RTCA/DO-229C deviation 40285
H 10/18/06 Added Comant antennas 40905
DOCUMENT PAGINATION
Section Page Range
Table of Contents i - vi
Section 1 1-1 – 1-22
Section 2 2-1 – 2-10
Section 3 3-1 – 3-4
Section 4 4-1 – 4-30
Appendix A A-1 – A-4
Appendix B B-1 – B-4
Appendix C C-1 – C-14

GIA 63/GIA 63W Installation Manual Page i
190-00303-05 Revision H
This manual reflects the operation of main software version 4.00 for the GIA 63 and main software
version 5.00 for the GIA 63W. Some differences in operation may be observed when comparing the
information in this manual to earlier or later software versions.
INFORMATION SUBJECT TO EXPORT CONTROL LAWS
This document may contain information which is subject to the Export Administration Regulations
("EAR") issued by the United States Department of Commerce (15 CFR, Chapter VII, Subchapter C) and
which may not be exported, released, or disclosed to foreign nationals inside or outside of the United
States without first obtaining an export license. A violation of the EAR may be subject to a penalty of up
to 10 years imprisonment and a fine of up to $1,000,000 under Section 2410 of the Export Administration
Act of 1979. Include this notice with any reproduced portion of this document.
WARNING
This product, its packaging, and its components contain chemicals known to the State of
California to cause cancer, birth defects, or reproductive harm. This Notice is being
provided in accordance with California's Proposition 65. If you have any questions or
would like additional information, please refer to our web site at
www.garmin.com/prop65.
WARNING
Perchlorate Material –special handling may apply, See
www.dtsc.ca.gov./hazardouswaste/perchlorate.

Page ii GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
This page intentionally left blank

GIA 63/GIA 63W Installation Manual Page iii
190-00303-05 Revision H
TABLE OF CONTENTS
PARAGRAPH PAGE
1 GENERAL DESCRIPTION..............................................................................................................1-1
1.1 Introduction........................................................................................................................................1-1
1.2 Equipment Description ......................................................................................................................1-1
1.3 Interface Summary.............................................................................................................................1-2
1.4 Technical Specifications ....................................................................................................................1-3
1.5 License Requirements........................................................................................................................1-9
1.6 Certification .......................................................................................................................................1-9
1.7 Referenced Documents ....................................................................................................................1-21
1.8 Limited Warranty.............................................................................................................................1-22
2 INSTALLATION OVERVIEW ........................................................................................................2-1
2.1 Introduction........................................................................................................................................2-1
2.2 Installation Considerations ................................................................................................................2-4
2.3 Rack Considerations ..........................................................................................................................2-6
2.4 Cabling and Wiring............................................................................................................................2-6
2.5 Cooling Air ........................................................................................................................................2-7
2.6 GIA 63 Minimum Installation Requirements ....................................................................................2-7
2.7 GIA 63W Minimum Installation Requirements ................................................................................2-8
2.8 Mounting Requirements ....................................................................................................................2-9
3 INSTALLATION PROCEDURE......................................................................................................3-1
3.1 Unpacking Unit..................................................................................................................................3-1
3.2 Wiring Harness Installation ...............................................................................................................3-2
3.3 Antenna Installation...........................................................................................................................3-2
3.4 Cable Installation ..............................................................................................................................3-2
3.5 Backshell Assembly...........................................................................................................................3-3
3.6 Unit Installation .................................................................................................................................3-3
3.7 Post Installation Configuration & Checkout......................................................................................3-4
3.8 Continued Airworthiness ...................................................................................................................3-4
4SYSTEM INTERCONNECTS..........................................................................................................4-1
4.1 Pin Function List................................................................................................................................4-1
4.2 Power and Antennas ........................................................................................................................4-13
4.3 GIA System ID Program..................................................................................................................4-14
4.4 Serial Data .......................................................................................................................................4-14
4.5 Discrete I/O......................................................................................................................................4-17
4.6 COM/VOR/ILS/Digital Audio ........................................................................................................4-18
4.7 VOR/ILS Indicator ..........................................................................................................................4-20
4.8 RMI/OBI..........................................................................................................................................4-22
4.9 DME Tuning and ADF ....................................................................................................................4-23
4.10 Auto Pilot.........................................................................................................................................4-24

Page iv GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
PARAGRAPH PAGE
APPENDIX A GIA 63 MAIN BOOT BLOCK UPLOADING INSTRUCTIONS................................. A-1
A.1 Introduction.......................................................................................................................................A-1
A.2 Determining Current Boot Block......................................................................................................A-1
A.3 Loading Boot Block Version 4.01 ....................................................................................................A-2
A.4 Loading GIA Main Software (only if GIA main software was cancelled in Section A.2) ............... A-3
APPENDIX B OUTINE & INSTALLATION DRAWINGS.................................................................. B-1
APPENDIX C INTERCONNECT EXAMPLES..................................................................................... C-1
LIST OF FIGURES
FIGURE PAGE
2-1 GPS Antenna and Unit Installation Considerations...........................................................................2-5
2-2 GIA 63(W) Unit Rack........................................................................................................................2-9
3-1 Coaxial Cable Installation..................................................................................................................3-2
B-1 GIA 63(W) Outline Drawing............................................................................................................ B-1
B-2 GIA 63(W) Installation Drawing...................................................................................................... B-3
C-1 GIA 63(W) Example Interconnect (Sheet 1 of 7)............................................................................. C-1
C-1 GIA 63(W) Example Interconnect (Sheet 2 of 7)............................................................................. C-3
C-1 GIA 63(W) Example Interconnect (Sheet 3 of 7)............................................................................. C-5
C-1 GIA 63(W) Example Interconnect (Sheet 4 of 7)............................................................................. C-7
C-1 GIA 63(W) Example Interconnect (Sheet 5 of 7)............................................................................. C-9
C-1 GIA 63(W) Example Interconnect (Sheet 6 of 7)........................................................................... C-11
C-1 GIA 63(W) Example Interconnect (Sheet 7 of 7)........................................................................... C-13
LIST OF TABLES
TABLE PAGE
3-1 Pin Contact Part Numbers..................................................................................................................3-1
3-2 Recommended Crimp Tools ..............................................................................................................3-1

GIA 63/GIA 63W Installation Manual Page v
190-00303-05 Revision H
GIA 63 HARDWARE MOD LEVEL HISTORY
The following table identifies hardware modification (Mod) Levels for the GIA 63. Mod Levels are listed
with the associated service bulletin number, service bulletin date, and the purpose of the modification.
The table is current at the time of publication of this manual (see date on front cover) and is subject to
change without notice. Authorized Garmin Sales and Service Centers are encouraged to access the most
up-to-date bulletin and advisory information on the Garmin Dealer Resource web site at
www.garmin.com using their Garmin-provided user name and password.
MOD
LEVEL
SERVICE
BULLETIN
NUMBER
SERVICE
BULLETIN
DATE
APPLICABLE
GARMIN
PART
NUMBER
PURPOSE OF MODIFICATION
1 0416 9/13/2004 010-00335-00
This modification consists of
modifying the voice alert audio output
circuit, enabling it to power down
when not in use.
2 0418 9/8/2004 010-00335-00
This Service Bulletin consists of
visually inspecting the GIA 63 Main2
board for incorrectly installed
capacitors.
3 0505 1/19/2005 010-00335-00
This modification addresses a
potential GIA 63 COM transceiver
interference condition.

Page vi GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
GIA 63W HARDWARE MOD LEVEL HISTORY
The following table identifies hardware modification (Mod) Levels for the GIA 63W. Mod Levels are
listed with the associated service bulletin number, service bulletin date, and the purpose of the
modification. The table is current at the time of publication of this manual (see date on front cover) and is
subject to change without notice. Authorized Garmin Sales and Service Centers are encouraged to access
the most up-to-date bulletin and advisory information on the Garmin Dealer Resource web site at
www.garmin.com using their Garmin-provided user name and password.
MOD
LEVEL
SERVICE
BULLETIN
NUMBER
SERVICE
BULLETIN
DATE
APPLICABLE
GARMIN
PART
NUMBER
PURPOSE OF MODIFICATION

GIA 63/GIA 63W Installation Manual Page 1-1
190-00303-05 Revision H
1GENERAL DESCRIPTION
1.1 Introduction
This manual presents mechanical and electrical installation requirements for installing the GIA 63(W) as
part of the G1000 Integrated Flight Deck. The GIA 63(W) can be integrated into a variety of airframes
under an appropriate TC or STC. Each airframe installation may vary. Use only approved (type or
supplemental type) data for specific installation instructions in a particular aircraft.
1.2 Equipment Description
The GIA 63(W) is a microprocessor-based input/output Line Replaceable Unit (LRU) used in the G1000
Integrated Flight Deck. The GIA 63(W) communicates with the GDU via Ethernet high-speed data bus
(HSDB), and with other LRUs using RS-232, RS-485/422, and ARINC 429. All configuration is done
through the GDU. The GIA 63(W) contains the following sub-assemblies:
•A main processor that interfaces with all LRUs in the G1000 sub-system and performs
calculations for the GFC 700 autopilot (if equipped).
•A twelve channel parallel GPS receiver that simultaneously tracks and uses up to 12 satellites.
The GIA 63W includes a 15 channel WAAS certified GPS receiver.
•A VHF COM transceiver that provides tuning from 118.00 to 136.975 MHz in 25 kHz or
8.33 kHz spacing for 760 or 3040 channel configuration respectively.
•A VOR/ILS localizer receiver that provides tuning from 108.00 to 117.95 MHz in 50 kHz
increments.
•An ILS glideslope receiver that provides tuning from 328.6 to 335.4 MHz as paired with the
frequency tuned on the VOR/ILS localizer receiver.
CAUTION
The operation of unapproved cellular telephones or other unapproved cellular devices
aboard aircraft while airborne is prohibited by FCC rules. Due to the potential for
interference with onboard systems, the operation of unapproved cellular communication
devices while onboard an aircraft that is on the ground is subject to FAA regulations
14 CFR 91.21.
FCC regulation 47 CFR 22.925 prohibits airborne operation of unapproved cellular
telephones installed in or carried aboard aircraft. Unapproved cellular telephones must
not be operated aboard any aircraft while the aircraft is off the ground. When any aircraft
leaves the ground, all unapproved cellular telephones on board that aircraft must be
turned off.
Unapproved cellular telephones that are on, even in a monitoring state, can disrupt GPS
performance.

Page 1-2 GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
1.3 Interface Summary
1.3.1 Primary Interfaces
The GIA 63(W) is designed as an open architecture system that provides the following interfaces:
•1 dedicated Ethernet High-Speed Data Bus (HSDB) input/output channel
•2 Controller Area Network (CAN) I/O channels
•8 Main ARINC 429 inputs
•3 Main ARINC 429 outputs
•1 VOR/ILS ARINC 429 input
•1 VOR/ILS ARINC 429 output
•5 RS-485 input/output channels (2 channels are configurable to RS-422)
•9 RS-232 input/output channels
•41 Discrete inputs
•14 Discrete outputs
1.3.2 Additional Interfaces
The GIA 63(W) can provide interfaces for the following additional equipment:
•Autopilot
•Altitude encoder/serializer
•Fuel management systems
•Lightning detection systems
•Traffic awareness systems
•Data link systems
•External annunciators
•DME (including King Serial)
•ADF

GIA 63/GIA 63W Installation Manual Page 1-3
190-00303-05 Revision H
1.4 Technical Specifications
1.4.1 Environmental Qualification Form
It is the responsibility of the installing agency to obtain the latest revision of the GIA 63(W)
Environmental Qualification Form. This form is available directly from Garmin under the following part
number:
GIA 63 Environmental Qualification Form, Garmin part number 005-00148-02
GIA 63W Environmental Qualification Form, Garmin part number 005-00235-00
To obtain a copy of this form, see the dealer/OEM portion of the Garmin web site (www.garmin.com).
1.4.2 Physical Characteristics
Characteristics Specifications
Width w/rack 3.83 inches (9.73 cm)
Height w/rack 7.26 inches (18.44 cm)
Depth w/rack 9.73 inches (24.71 cm)
Unit Weight 5.3 lbs. ( 2.40 kg)
Rack & Connector Weight 1.9 lbs. ( 0.86 kg)
1.4.3 General Specifications
For detailed specifications, see the Environmental Qualification Form.
Characteristics Specifications
Operating Temperature Range -40°C to +65°C. For more details see Environmental
Qualification Form.
Humidity 95% non-condensing
Altitude Range -1,500 ft to 50,000 ft
Software Compliance RTCA/DO-178B Level B, C, D
CLD (Custom Logic Devices)
Compliance* RTCA/DO-254 Level B and C
*GIA 63W (WAAS) only
1.4.4 GPS Specifications (GIA 63 only)
Characteristics Specifications
Acquisition Time a) Search-the-Sky (without almanac, without initial position
or time): 5 minutes
b) AutoLocate™(with almanac, without initial position or
time): 5 minutes
c) Cold Start (position known to 300 nm, time known to 10
minutes, with valid almanac): 45 seconds
d) Warm Start (position known to 10 nm, time known to 10
minutes, with valid almanac and ephemeris): 15 seconds
Max Velocity 1000 knots
Dynamics 6 g
Antenna power supply 20 mA typical, 40 mA max at 4.6 VDC

Page 1-4 GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
1.4.5 WAAS Specific GPS Specifications (GIA 63W only)
Characteristics Specifications
Number of channels 15 (12 GPS and 3 GPS/WAAS/SBAS)
Frequency 1575.42 MHz L1, C/A code
Sensitivity (acquisition) -116 dBm to -134.5 dBm GPS
-116 dBm to -135.5 dBm WAAS
Sensitivity (drop lock) -144 dBm
Lat/Long position frequency <1 meter RMS typical with WAAS (horizontal/vertical)
Velocity 1000 knots maximum (above 60,000 ft)
TTFF (time to first fix) 1:45 min. typical with current almanac, position, and time
Reacquisition 10 seconds typical for signal outages of 30 seconds or less
Position update interval 0.2 sec (5 Hz)
1 pps (pulse per second) ±275 nsec of UTC second during steady-state navigation
Datum WGS-84
SATCOM compatibility Compatible on aircraft equipped with SATCOM (see Section
2.1.3.2 for SATCOM compatible antennas)
Antenna power supply 35 mA typical, 40 mA max at 4.7 VDC

GIA 63/GIA 63W Installation Manual Page 1-5
190-00303-05 Revision H
1.4.6 COM Transceiver Specifications
Characteristics Specifications
Audio Output 100 mW minimum into a 500 Ωload.
Audio Response Less than 6 dB of variation between 350 and 2500 Hz.
Audio Distortion The distortion in the receiver audio output shall not exceed
25% at all levels up to 100 mW.
AGC Characteristics The audio output shall not vary by more than 6 dB when the
level of the RF input signal, modulated 30% at 1000 Hz, is
varied from 5 μV to 100,000 μV (hard).
Sensitivity (S+N)/N on all channels shall be greater than 6 dB when the
RF level is 2 μV (hard) modulated 30% at 1000 Hz at rated
audio.
Squelch 2 μv (hard) ±6 dB for 25 kHz channels.
3 μv (hard) ±6 dB for 8.33 kHz channels.
Selectivity 6 dB BW is greater than ±8 kHz for 25 kHz channeling.
60 dB BW is less than ±25 kHz for 25 kHz channeling.
6 dB BW is greater than ±2.778 kHz for 8.33 kHz
channeling.
60 dB BW is less than ±7.37 kHz for 8.33 kHz channeling.
Spurious Response Greater than 80 dB.
Transmitter Power At Least 16 watts.
Transmitter Duty Cycle Recommended 10% maximum.
Modulation Capability The modulation shall not be less than 70% and not greater
than 98% with a standard modulator signal applied to the
transmitter.
Carrier Noise Level Shall be at least 45 dB (S+N)/N.
Frequency Stability 0.0005%
Demodulated Audio Distortion Less than 10% distortion when the transmitter is modulated
at least 70%.
Sidetone 1.4 VRMS into a 500 Ωload when the transmitter is modulated
at least 70%.
Demodulated Audio Response Shall be less than 6 dB when the audio input frequency is
varied from 350 to 2500 Hz.

Page 1-6 GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
1.4.7 VOR Specifications
Characteristics Specifications
Receiver Audio Sensitivity At -103.5 dBm (S+N)/N shall not be less than 6 dB.
Course Deviation Sensitivity At –103.5 dBm deviation output shall not be less than 60%
of standard deflection (90 mV) when a VOR deviation test
signal is applied (10 degrees course difference).
Flag The VLOC Course Deviation Flag must be flagged:
a) in the absence of an RF signal.
b) in the absence of the 9960 Hz modulation.
c) in the absence of either one of the two 30 Hz
modulations.
d) When the level of a standard VOR deviation test signal
produces less than a 50% of standard deflection.
AGC Characteristics From -99 dBm to -13 dBm input of a Standard VOR Audio
Test Signal, audio output levels shall not vary more than
3 dB.
Spurious Response Greater than 60 dB.
VOR OBS Bearing Accuracy The bearing information as presented to the pilot shall not
have an error in excess of 2.7° as specified by
RTCA DO-196 and EuroCAE ED-22B.
Audio Output A minimum 100 mW into a 500 Ωload.
Audio Response Less than 6 dB of variation between 350 and 2500 Hz. In
voice mode, an ident tone of 1020 Hz shall be attenuated at
least 20 dB.
Audio Distortion The distortion in the receiver audio output shall not exceed
10% at all levels up to 100 mW.
Selectivity 6 dB BW is greater than 16.5 kHz.

GIA 63/GIA 63W Installation Manual Page 1-7
190-00303-05 Revision H
1.4.8 LOC Specifications
Characteristics Specifications
Receiver Audio Sensitivity At -103.5 dBm (S+N)/N shall not be less than 6 dB.
Course Deviation Sensitivity At –103.5 dBm, deviation output shall not be less than 60%
of standard deflection when a LOC deviation test signal is
applied.
Flag The VLOC Course Deviation Flag must be flagged:
a) When the level of a standard deviation test signal
produces 50% or less of standard deflection of the deviation
indicator.
b) In the absence of 150 Hz modulation.
c) In the absence of 90 Hz modulation.
d) In the absence of both 90 Hz and 150 Hz modulation.
e) In the absence of RF.
AGC Characteristics From –99 dBm and –13 dBm input of a Standard VOR
Audio Test Signal, audio output levels shall not vary more
than 3 dB.
Selectivity 6 dB BW is greater than 9 kHz.
69 dB BW is less than 36 kHz.
Standard Deflection a) With a standard deflection ‘FLY LEFT’ condition (90 Hz
dominant), the output shall be +90 mV ± 9 mV.
b) With a standard deflection ‘FLY RIGHT’ condition (150 Hz
dominant), the output shall be -90 mV ± 9 mV.
Spurious Response Greater than 60 dB.
Centering Accuracy Typical 0 ±3 mV (Max error 9.9 mV per RTCA DO-195).
Audio Output A minimum 100 mW into a 500 Ωload.
Audio Response Less than 6 dB of Variation between 350 and 2500 Hz. In
voice mode, an ident tone of 1020 Hz shall be attenuated at
least 20 dB.
Audio Distortion The distortion in the receiver audio output shall not exceed
10% at all levels up to 100 mW.

Page 1-8 GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
1.4.9 Glideslope Specifications
Characteristics Specifications
Sensitivity At –93 dBm, deviation output shall not be less than 60% of
standard deflection when glideslope deviation test signal is
applied.
Centering Accuracy 0 ±.0091 ddm or 0 ±7.8 mV.
Selectivity 6 dB BW is greater than 17 kHz.
69 dB BW is less than 132 kHz.
Standard deflection a) With a standard deflection ‘FLY DOWN’ condition (90 Hz
dominant), the output shall be -78 mV ± 7.8 mV.
b) With a standard deflection ‘FLY UP’ condition (150 Hz
dominant), the output shall be +78 mV ± 7.8 mV.
Flag The GS Course Deviation Flag must be flagged:
a) When the level of a standard deviation test signal
produces 50% or less of standard deflection of the
deviation indicator.
b) In the absence of 150 Hz modulation.
c) In the absence of 90 Hz modulation.
d) In the absence of both 90 Hz and 150 Hz modulation.
e) In the absence of RF.
1.4.10 Power Requirements
Characteristics Specifications
Input Voltage Range 28 Vdc for J601
14/28 Vdc for J605
See the Environmental Qualification Form for details on
surge ratings and minimum/maximum operating voltages.
Power Requirements for P601
(COM Connector)
0.3 A max @ 27.5 Vdc (not transmitting);
4.3 A max @ 27.5 Vdc (transmitting)
Superflag Power
Requirements for P605
(Main 2 Connector)
Power depends upon loads present on Superflag output pins
(see Sections 4.7.2.1 and 4.10.7)
Power Requirements for P605
(Main 2 Connector)
1.0 A @ 27.5 Vdc (Without Superflags Active)
2.0 A @ 13.75 Vdc (Without Superflags Active)

GIA 63/GIA 63W Installation Manual Page 1-9
190-00303-05 Revision H
1.5 License Requirements
The Telecommunications Act of 1996, effective February 8, 1996, provides the FCC discretion to
eliminate radio station license requirements for aircraft and ships. The GIA 63(W) installation must
comply with current transmitter licensing requirements. To find out the specific details on whether a
particular installation is exempt from licensing, please visit the FCC web site
http://wireless.fcc.gov/aviation.
Transmitter Description: Aviation-band VHF transceiver with 25 and 8.33 kHz channel spacing.
Antenna Characteristics: Broad band, 50 ohm, vertically polarized.
Rated Power: 16 Watts
Emission Type: 6K00A3E
Frequency of Operation: 118.00 – 136.992 MHz
If an aircraft license is required, make application for a license on FCC form 404, application for Aircraft
Radio Station License. The FCC also has a fax-on-demand service to provide forms by fax. The GIA
63(W) owner accepts all responsibility for obtaining the proper licensing before using the transmitter.
International transmitter license procedures vary by country. Contact the local spectrum agency for
license requirements.
CAUTION
The VHF transmitter in this equipment is guaranteed to meet federal communications
commission acceptance over the operating temperature range. Modifications not
expressly approved by Garmin could invalidate the license and make it unlawful to
operate the equipment.
1.6 Certification
The GIA 63 GPS receiver is certified for IFR enroute, terminal, and non-precision approaches. The GIA
63W GPS receiver is WAAS certified.
The GIA 63(W) has been qualified to RTCA/DO-160 Section 20 RF susceptibility and Section 22
lightning requirements. Special installation considerations are required, refer to the Environmental
Qualification Form.
The GIA 63(W) meets the requirements for GPS as a Primary Means of Navigation for Oceanic/Remote
Operations per FAA Notice N8110.60.
The GIA 63(W) is eligible for B-RNAV in accordance with AMJ20X2.
Eligible for PRNAV in accordance with PRNAV requirements: JAA Administrative & Guidance
Material Section One: General Part 3: Temporary Guidance Leaflets, Leaflet No 10: Airworthiness and
Operational Approval for Precession RNAV Operations in Designated European Airspace 7.1 Required
Functions.
The conditions and tests required for TSO approval of this article are minimum performance standards. It
is the responsibility of those installing this article either on or within a specific type or class of aircraft to
determine that the aircraft installation conditions are within the TSO standards. TSO articles must have
separate approval for installation in an aircraft. The article may be installed only if performed under 14
CFR part 43 or the applicable airworthiness requirements. At the time of publication, installations of this
TSO approved article are only approved when installed in an aircraft as part of a Garmin G1000 system.

Page 1-10 GIA 63/GIA 63W Installation Manual
Revision H 190-00303-05
1.6.1 GIA 63 TSO/ETSO Compliance
Function TSO/ETSO Category
Applicable LRU SW
Part Numbers
Automatic Pilots TSO-C9c
All
006-B0190-()
except
006-B0190-00
through
006-B0190-19
Glideslope Receiver TSO-C34e
ETSO-2C34f 006-B0190-()
Localizer Receiver TSO-C36e
ETSO-2C36f Class A 006-B0190-()
VHF COM Transmitter TSO-C37d
ETSO-2C37e Class 3 and 5 006-B0190-()
VHF COM Receiver TSO-C38d
ETSO-2C38e Class C and E 006-B0190-()
VOR Receiver TSO-C40c
ETSO-2C40c 006-B0190-()
Flight Director Equipment TSO-C52b
All
006-B0190-()
except
006-B0190-00
through
006-B0190-19
GPS TSO-C129a
ETSO-C129a Class A1 006-B0190-()
TAWS TSO-C151b Class B
All
006-B0190-()
except
006-B0190-00
through
006-B0190-29

GIA 63/GIA 63W Installation Manual Page 1-11
190-00303-05 Revision H
1.6.2 GIA 63W TSO/ETSO Compliance
Function TSO/ETSO Category
Applicable LRU SW Part
Numbers
Applicable CLD Part
Numbers
All
006-C0084-()
except
006-C0084-00
006-C0072-()
006-C0085-()
Automatic Pilots TSO-C9c
All
006-B0544-()
except
006-B0544-00
through
006-B0544-09
All
006-C0039-()
except
00C-C0039-00
through
00C-C0039-02
All
006-C0084-()
except
006-C0084-00
006-C0072-()
006-C0085-()
Glideslope
Receiver TSO-C34e
All
006-B0544-()
except
006-B0544-00
through
006-B0544-09
All
006-B0083-()
except
006-B0083-00
through
006-B0083-01
All
006-C0039-()
except
00C-C0039-00
through
00C-C0039-02
All
006-C0084-()
except
006-C0084-00
006-C0072-()
006-C0085-()
All
006-C0039-()
except
00C-C0039-00
through
00C-C0039-02
Localizer Receiver TSO-C36e Class A
All
006-B0544-()
except
006-B0544-00
through
006-B0544-09
All
006-B0082-()
except
006-B0082-00
through
006-B0082-02
All
006-C0053-()
except
006-C0053-00
