GASLAND PHP40S User manual

3330-A Marathon Ct Charleston, SC 29418
1 [phone]
www.gaslandchef.com
[email protected]
Patio Heater
Installation Instructions
Available Model
PHP40S

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
01
Pyramid Heater
WARNING
FIRE OR EXPLOSION MAY RESULT
IF INSTRUCTIONS ARE IGNORED
It is the consumer's responsibility to see that the patio heater is properly
assembled installed, and taken care of. Failure to follow instructions in this
manual could result in bodily injury and/or property damage.
Precautions
• Leak test all connections after each tank refill.
• Never check for leaks with a match or open flame.
• Do not store or use gasoline or other flammable substances in the vicinity of this
or any other appliance.
• Any LP cylinder not connected for use should not be stored in the vicinity of this
or any other appliance.
For Your Safety If You Smell Gas
1. Turn off the gas supply at cylinder.
2. Extinguish all flames.
3. Do not operate any electrical appliances.
4. Ventilate the area.
5. Check for leaks as detailed in this manual.
6. If odor persists, contact your dealer or gas supplier immediately.
FOR OUTDOOR USE ONLY I USES LPG ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
RETAIN THIS MANUAL FOR REFERENCE
5000199

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
02
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing this equipment.
WARNING
For Outdoor Use Only
LPG Cylinders to be used must be constructed and marked in accordance with US
DOT specifications.
Storage of the heater indoors is permissible only if the gas cylinder is turned off and
removed.
NOTE
Use only 201b LP-Gas tank with size of 18.1 in/46cm(Height) x12.5 in/32cm(Width).
Do not use if the environment temperature is below 40 degrees F/ 4.4 degrees C.
The LP gas cylinder to be used must be provided with a listed overfilling prevention
device.
Do not store a spare LP-gas cylinder under or near this appliance.
Never fill the cylinder beyond 80 percent full.
The gas pressure regulator provided with this appliance must be used.
This regulator is set for an outlet pressure of 11 inches water column.
Tools needed
• Open end wrench 10 & 13mm (included)
NOT included
• Adjustable opening wrench 8" long
• Philips screwdrive rw/ medium blade
• Spray bottle of soapy solution for leak testing
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odour.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home. Keep
electrical supply cord away from the heated
surfaces.
DANGER

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
03
WARNING
This product can expose you to chemicals including carbon monoxide which is
known to the State of California to cause birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
Precautions
PLEASE READ THE FOLLOWING SAFETY RULES
WARNING
This heater must only be used outdoors.
Using this product in an enclosed area may cause injury, death or property
damage.
Read instructions before use.
This heater must be used in accordance with your local area's regulations and
bylaws.
• Installation and service should be done by a qualified person.
• Do not use the heater in an explosive atmosphere (i.e. areas where gasline or
other flammable liquids or vapors are stored).
• Before use, check the regulator.
• Disconnect LPG cylinder before moving the heater.
• Do not attempt to alter any part of heater.
Example: Using the heater without reflector or protection guard.
• The heater should not be used in basements or below ground level.
• The heater must always be placed on a solid and level surface.
• Never replace or substitute the regulator with a regulator that does not meet the
specifications on page 2.
• Do not clean the heater with cleaners that are combustible or corrosive.
• Do not paint any part of the heater.
• The LPG cylinder valve should be turned off and disconnected when the heater
is not in use.
• Do not use heater when it is raining, and do not let any liquid splash on the glass
tube when the heater is working.
• Keep children away from the heater. Always be careful not to knock over the
heater, as this could cause breakage of the glass tube and cause injury.
• Do not move the heater when in operation.
• After a long break of operation, the gas parts in the control box of the heater and
the hose should be inspected for spiders, spider webs or other insects.

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
04
• Check the heater immediately if any of the following exists:
1. There is smell of gas;
2. The heater is not burning properly;
3. The burner makes popping noise during use (a slight popping noise is normal
when the burner is extinguished after use).
• If you smell gas,turn off the valve immediately. If smell persists,contact your
dealer on gas supplier immediately.
• The hose with regulator assembly should be stored in a safe place to avoid
accidental damage.
• Children and adults should be aware of the hight surface temperature hazard of
the heater, and should keep a safe distance away to avoid clothes burning or
igniting.
• Young children should be carefully supervised when they are in the working area
of the heater.
• Clothing or other flammable material should not be hung from the heater, or
placed on or near the heater.
• Do not obstruct the ventilation holes of the cylinder housing.
• Shut off the valve of gas cylinder or the regulator before moving the appliance.
• The tubing or the flexible hose must be changed within the prescribed intervals.
• Use only the type of gas and the type of cylinder specified by the manufacturer.
• In case of violent wind particular attention must be taken against tilting of the
heater.
• Storage of the heater indoors is permitted only if the cylinder is disconnected
and removed from the appliance.
• Do not store a spare LPG cylinder under or near this heater.
• Never fill the cylinder beyond 80 percent full.
Heater Placement And Location
• The heater is for outdoor use only.
• Do not use it indoors or in enclosed areas.
• Always ensure that adequate fresh air
ventilation is provided.
• Always maintain proper clearance from
combustible materials (Top: 32 in Side: 26 in)
• Heater must be placed on level firm ground.
• Never operate heater in an explosive
atmosphere like in areas where gasoline or
other flammable liquids or vapors are stored.

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
05
DIAGRAMMATICAL REPRESENTATIONS OF OUTDOOR AREAS

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
06
Open side at least
25% of total wall area
30% or more in total of
remaining wall area is
open and unrestricted
30% or more in total of
remaining wall area is
open and unrestricted

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
07
Leak Testing
WARNING
DO NOT SMOKE WHILE LEAK TESTING
Gas connections on the heater are leak tested at the factory prior to shipment.
Possible mishandling of the heater during the shipment might contribute to
product integrity as a whole. A complete gas leakage test must be performed
again at the installation site.
Please follow the procedure below for leakage test.
1. Make a soapy solution of one part liquid detergent and one part water. The
soapy solution can be applied with a spray bottle, brush or rag. Soap bubbles
will appear where the leak is present.
2. Make sure the control tap is in the <<OFF>> position (full disk =.) on the control
panel.
3. Turn on the gas supply and check for bubbles on the hoses and connections. If
the solution starts to bubble that means that a leak is present.
4. If a leak is present, turn OFF the gas supply immediately, tighten any leaking
fittings carefully and recheck to see if it still continues to leak.
5. Never leak test while smoking.
Installation
Important Safety Rules:
This heater is for OUTDOOR USE ONLY
1. This heater shall not be installed or used indoors, in buildings, garages or any
other enclosed area.
2. DO NOT place articles on or against this heater.
3. DO NOT use or store flammable materials near this heater.
4. Children and adults should be aware of the high surface temperature
hazard, and should keep a safe distance away to avoid clothes burning or
igniting.
5. Children should be carefully supervised when they are in the area of the heater.
6. NEVER hang anything including clothes or other flammable items on the
heater.

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
08
7. DO NOT operate this heater unless it is fully assembled with the reflector in
place.
8. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS HEATER WHILE IT
IS IN OPERATION.
9. Installation and repair should be done by a qualified person. The heater must
be inspected before use and at least annually by a qualified person. More
frequent cleaning may be required as necessary. It is imperative that control
compartments, burners and circulating air passages of the heater and light be
kept clean and free from insect/spider infestation.
Part
Number
Part
Name
Bottom Plate x 11
2
3
4
Control Box x 1
Picture Remarks
Parts List
Middle Plate x 1
Plate Cover is
pre-assembled
to Middle Plate
Damper x 1 Pre-assembled
in the Upper Plate

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
09
5
6
Upper Support x 4
Lower Support x 4
Part
Number
Part
Name
7
8
9
10
11
Picture Remarks
Parts List
Glass Tube x 1
Reflector x 1
Lower Protection
Guard x 4
Wheels x 1
Propane Cylinder
Bracket x 3

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
10
12
13
14
15
Fixing Bracket x 4
Side Panel x 3
2 Side panels
with vents,
1 Side panel
without vents
Front Panel x 1
Handle x 1
Part
Number
Part
Name
16
17
18
19
Picture Remarks
Parts List
Not Provided
All pre-assembled
in relative parts
Chain x 1
AA Battery x 1
Rubber Ring x 1
Screw M5X8 x 66

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
11
3
6
1
3
4
5
1
10
Hardware Used: 4x Bolts and Nuts
(pre-assembled)
Hardware Used: 3x Bolts and Nuts
(pre-assembled to
Brackets)
1. Attach wheels (10) to bottom
plate (1) .
2. Locate the propane cylinder bracket
(11) and attach it on the bottom plate
with 3 bolts and nuts provided with
the bracket.Use the M8x45 screw to
secure the propane cylinder.
19
11
1
Hardware Used: 20x Screws Hardware Used: 12x Screws
3. Connect and fix the 4 lower support
(6) to the bottom plate(1) and middle
plate (3) with screws (19).
4. Connect 4 upper supports (5) to the
lower supports (6) with screw (19),
then fix the damper with screws (19).

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
12
16
17
27
18
Hardware Used: 1x AA Battery
4x Screws Hardware Used: 1x Rubber Ring
5. Unscrew the red igniter button on the
control box and insert the AA battery
(17) with the POSITIVE end facing
upward. Then attach the control box
(2) underneath the middle plate (3)
with screws (19).
6. Carefully put the glass tube (7) up
through the center of the hole in the
upper plate (4). Make sure the rubber
ring (18) is attached on the lower end
of the glass tube.
Now place the glass tube through the
hole on the middle plate (3). Check
to ensure the glass tube covers the
center hole of the middle plate.

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
13
8
12
9
Hardware Used: 3x Studs
3x Wing Nuts Hardware Used: 4x Screws
7. Attach the bolts onto the damper (4),
and put 3pcs washer onto the bolts,
then put the reflector (8) onto the
bolts, put 3pcs washer through the
bolts and fix with screws.
8. Attach the protection guards (9) to
the upper frame by inserting the
hooks at the top of the guards into
the holes on the supports. Repeat at
the bottom of the supports.
Secure the protection guards to the
top of the supports with the fixing
brackets(12) and screw in place.

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
14
13
Hardware Used: 12x Screws
9. Fix the sides panels (13) with the screws (19).
Note: Do not cover the side where the control knob is.

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
15
10. Screw the handle (15) on the front panel (14) - attach the panel by inserting
its two hooks into the holes on the bottom plate. Hook the chain (16) to the
hole in the control box, then close the panel to the middle plate - the panel
is attached by the magnets.
Tips: the chain can hole the panel while operating the control.
15
14

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
16
11. Connect gas hose to 20.Ib. LPG
cylinder (not included).
Attach regulator to cylinder. Tighten
securely Move cylinder to the plate
of base assembly. Attach the
cylinder to the base with 3pcs
M8x12 bolts and tighten it in order
to prevent the cylinder from moving
on the base.
Note: The regulator with gas hose
is supplied.
Completed

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
17
Operation
Preperation
You will need to purchase a standard 20 Ib.
LPG cylinder designed to be used with the
regulator purchased or supplied. For correct
operation of the gas system follow the
instructions supplied with the regulator
supplied.Connect the hose to the hose
connector in the control box.
Warning: Always test the hose and connections
for leaks with soapy water at the end of all connections.
WARNING
• Never use the heater while it is raining. The glass tube will break when it comes
in contact with water.
• Never splash any liquid on the glass tube when the heater is working.
• The glass tube will be extremely hot when it is working. Never try to touch it and
do not allow children to try to touch the glass tube.
• Always ensure the heater is on firm, level ground. The glass tube will break if the
heater falls and hits objects or the ground.
• Never use the heater if the glass tube has a crack or chip.
Lighting instructions
Check and ensure that a AA battery is inside the ignition chamber.
The anode (+) side of the battery must face out.
Hose
connector

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
18
1. Make sure the Control Knob is in the OFF
position. Slowly open the LPG cylinder valve.
2. Press and turn the Control Knob to PILOT ( )
position (counterclockwise). Press the Red
igniter button.
3. Check for the pilot flame through the glass tube.
If the pilot does not light, press and turn the
Control Knob clockwise to the OFF position.
Repeat steps 1-2.
4. Once the pilot flame is lit, turn the Control Knob
counterclockwise to LO position.
5. For maximum heat, turn the Control Knob
counterclockwise to Hl position.
6. To turn the heater off, turn the Control Knob
clockwise to PILOT ( ) position. Then depress
the Control Knob and turn clockwise to OFF
Position. Close the valve on your LPG cylinder
when the heater is not in use.
Maintenance/ storage
CLEANING & MAINTENANCE:
To enjoy years of outstanding performance from your heater make sure you
perform the following maintenance routines on a regular basis:
• Keep exterior surfaces clean:
- Use warm soapy water for cleaning. Never use flammable, corrosive or
abrasive cleaners
- While washing your unit, be sure to keep the area around the burner and pilot
assembly dry at all times. If the gas control is exposed to water in any way, do
NOT try and use it. It must be replaced .
• At least once a year, the unit should be inspected for spiders, spider webs or
other insects air flow might be obstructed
• Keep controls, burner and circulating air passageways clean. Signs of possible
blockage include:
- Gas odour with extreme yellow tipping of flame.
- Heater does not reach the desired temperature.
- Heater glow is excessively uneven.
- Heater makes popping noises.
• Spiders and insects can nest in burners or orifices. This dangerous condition
can damage the heater and render it unsafe for use. Clean burner holes by
using a heavy duty pipe cleaner. Compressed air may help clear away smaller
particles.
OFF
PILOT
LO
HI
HI
LO
OFF

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
[email protected]
1 [phone]
19
• Carbon deposits may create a fire hazard. Clean reflector and glass tube with
soapy water if any carbon deposits develop. Always be careful when cleaning
the glass tube.
Storage:
Between Uses:
• Turn the control knob to <<OFF>> position
• Turn the LP cylinder to the <<OFF>> position
• Store the heater upright in an area sheltered away from weather conditions such
as rain, sleet, hail and snow.
• If desired, cover heater to protect exterior surfaces and to help prevent dust and
debris collecting in air passages. Do not apply cover until heater has completely
cooled.
During Periods Of Extended Inactivity Or When Transporting:
• Turn the control knob to <<OFF>> position
• Disconnect LP cylinder and move to a secure, well ventilated location outdoors.
Do NOT store in a location that will exceed 120 degrees farenheit.
• Store heater upright in an area sheltered away from weather conditions such as
rain, sleet, hail and snow.
• If desired, cover heater to protect exterior surfaces and to help prevent dust and
debris collecting in air passages.
• DO not apply cover until heater has completely cooled.
WARNING FOR YOUR SAFETY
• DO NOT touch or move heater for at least 45 minutes after each use
• Allow all burner elements to cool before touching
NOTE
• In a salt air environment(such as near an ocean) corrosion occurs more quickly
than normal.
• Frequently check for corroded areas and repair them promptly.
• Wait until heater is cool before covering.
