Stelpro SPDH Series User manual

INSSPDH0219
USER’S GUIDE
SPDH SERIES
MINI PATIO DOOR HEATER
REPLACEMENT COMPONENT LIST INCLUDED
S
Y
S
T
È
M
E
Q
U
A
L
I
T
É
C
E
R
T
I
F
I
É
-
R
E
G
I
S
T
E
R
E
D
Q
U
A
L
I
T
Y
S
Y
S
T
E
M
This unit
complies with
the CSA and
UL standards
For further information or to consult this guide online, please visit our website at www.stelpro.com

INSSPDH0219
2
Before installing and operating this product, the user and/or installer must read, understand and follow these instructions and keep them handy for future refer-
ence. If these instructions are not followed, the warranty will be considered null and void and the manufacturer deems no further responsibility for this product.
This product must be installed by a qualied person and connected by a certied electrician, according to the electrical and building codes
effective in your region.
The following instructions must be adhered to in order to avoid personal injuries or property damages, serious injuries and potentially fatal electric shocks.
Protect the heating unit with the appropriate circuit breaker or fuse, in accordance with the nameplate.
Make sure the line voltage (volt) is consistent with that indicated on the unit’s nameplate.
This unit must be grounded.
Switch off the power at the circuit breaker/fuse before installing, repairing and cleaning the unit.
Make sure the unit is appropriate for the intended use (if needed, refer to the product catalog or a representative).
RECOMMENDED HEATING CAPACITY:
1,25 W/cubic foot (0.03 m³).
It corresponds to 10 W/square foot (0.09 m²) based on a standard ceiling height of 8 feet (2.44 m). The recommended capacity is usually sufcient
for normal heating needs. Please note that the insulation quality of walls and windows are some of the factors that inuence heat losses, which modify the
required capacity to heat a room. If needed, refer to a specialist (industrial and commercial buildings) who will be able to calculate these heat losses and
optimize the required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings).
Do not install the unit where objects or pieces of furniture could be heat damaged.
If the unit capacity is insufcient for the size of the room, it will be in operation continuously, and may become defective earlier and turn yellow.
Respect distances and positions indicated in the installation section.
If the installer or the user modies the unit, he will be held responsible for any damage resulting from this modication, and the CSA certication could be void.
When cutting or drilling into a wall, do not damage electrical wiring and other hidden utilities.
Do not install this product on oors made of synthetic material such as, but not limited to, carpet.
When starting up the unit for the rst time or after a long period, it is normal that it produces some temporary odours and whitish smoke.
Because this unit is hot when in use, it may pose risks even in normal operation. Therefore, be careful and responsible when using it. To avoid burns, do
not let bare skin touch hot surfaces. The unit must cool down for few minutes since it will stay warm for some time after shut-down. If provided, use handles
when moving this heater.
Leave at least 3 inches (7.5 cm) between the front of the unit and objects that have a ground clearance of at least 1 inch (2.5 cm) such as, but not limited
to, beds, tables, armchairs, curtains, etc. If these objects are located directly on the oor, leave at least 6 inches (15 cm) between them and the front of
the unit. Leave at least 6 inches (15 cm) of space between the top of the unit and objects such as, but not limited to furniture, pillows, curtains, blankets,
towels, laundry baskets, clothing, papers, etc. Furthermore, certain materials are more sensitive to heat than others, you must assure that these materials are
located at a proper proximity where they can handle the heat released.
Do not install on a wall behind a door.
Never block unit air vents. This obstruction could lead to overheating, which could result in a re. Do not use on soft surfaces, like a bed, where openings
may become blocked.
Do not insert or allow foreign objects to enter any air vent as this may cause electric shocks, res, or damages to the unit.
This unit has hot and arcing or sparking parts inside. It is not designed to be used or stored in wet areas or areas containing ammable liquids, combustible
materials or corrosive, abrasive, chemical, explosive and ammable substances such as, but not limited to, gasoline, paint, chlorine, sawdust and cleaning
products.
Some areas are dustier than others. Thus, it is the user’s responsibility to evaluate if the unit must be cleaned based on the amount of dirt accumulated
on and inside air vents. Accumulated dirt can lead to a component malfunction or discoloration (yellow). It may cause a re hazard if not installed and main-
tained in accordance with these instructions.
The thermal protection activation indicates that the unit has been subjected to abnormal operating conditions. If the thermal protection remains activated or
activates and deactivates repeatedly, it is recommended that a qualied electrician or a certied repair centre examine the unit in order to make sure it is not
damaged. (Refer to the limited warranty)
If the unit is damaged or defective, cut off power supply at circuit breaker and call a certied repair centre. (Refer to the limited warranty)
SAVE THESE INSTRUCTIONS
WARNING
Note: When a part of the product specication must be changed to improve operability or other functions, priority is given to the product specication itself. In such
instances, the instruction manual may not entirely match all the functions of the actual product. Therefore, the actual product and packaging, as well as the name
and illustration, may differ from the manual.
IMPORTANT INSTRUCTIONS

INSSPDH0219
3
SPECIFICATIONS
SPDH SERIES
TYPE WATTS MM IN. KG LB
SPDH603 300 600 23 5/8 2.7 6
SPDH904 450 900 35 7/16 3.6 8
SPDH1206 600 1200 47 1/4 4.5 10
SPDH1507 750 1500 59 1/16 5.4 12
SPDH1809 900 1800 70 7/8 6.8 15
SPDH2110 1050 2100 82 11/16 8.2 18
SPDH2412 1200 2400 94 1/2 9.5 21
SPDH2713 1350 2700 106 5/16 10.4 23
TECHNICALS DRAWINGS
FRONT
SIDE
3"
77mm
1"
25mm
1"
25mm
Ø7/8"
22mm
KO
1 9/16"
39mm
1 1/16"
27mm
3 1/2"
89mm6 5/16"
160mm
2 3/16"
56mm
TYP.
TOP
1 9/16"
39mm
1 1/2"
39mm
3 5/16"
84mm
7/8"
22mm
Ø
7/8"
22mm
KO
LENGTH
2 1/16"
52mm
7/8"
22mm
Ø7/8"
22mm
KO
3 1/16"
78mm
Ø3/8"
10mm
KO
Ø7/8"
22mm
KO
2"
50mm1 3/8"
35mm
Ø3/8"
10mm
KO
1 9/16"
40mm
INSTALLATION
N.B. Cut off power supply at circuit breaker/fuse before proceeding to the installation.
1. Remove the cover.
2. Screw the heater onto the wall (using the existing holes in the casing).
3. Make the required connections (see paragraph below).
4. Replace the cover.
N.B. The illustration indicates the airow generated by the baseboard heater.
This air corridor must remain clear in order to allow the unit to operate efciently ; to ensure good air circulation and to avoid
a re hazard.
Leave at least 3 inches (7.5 cm) between the front of the unit and objects that have a ground clearance of at least 1 inch (2.5
cm) such as, but not limited to, beds, tables, armchairs, curtains, etc. If these objects are located directly on the oor, leave at
least 6 inches (15 cm) between them and the front of the unit. Leave at least 6 inches (15 cm) of space between the top of the
unit and objects such as, but not limited to furniture, pillows, curtains, blankets, towels, laundry baskets, clothing, papers, etc.
Furthermore, certain materials are more sensitive to heat than others, you must assure that these materials are located at a
proper proximity where they can handle the heat released. Do not install the baseboard under an electrical outlet.
SPECIFICATIONS, TECHNICAL DRAWINGS & INSTALLATION
CAUTION - HIGH TEMPERATURE, KEEP ELECTRICAL CORDS,
DRAPES, AND OTHER FURNISHINGS AWAY FROM UNIT.
Keep drapes at a distance of at least 6 inches (15 cm) from unit.
Do not to install unit against combustible low-density cellulose berboard surfaces or below an electrical convenience
receptacle.
To reduce the risk of re, do not store or use gasoline or other ammable vapors and liquids in the vicinity of the unit. Do not
install unit in contact with combustible materials.
6 in. (15 cm)
3 in. (7.5 cm)
1 in. (2.5 cm)
Clearance required
Between the front of the unit
and objects that have a ground clearance
of at least 1 inch (2.5 cm)
Between the front of the unit
and objects located directly on the oor.
Add Wfor white or SW for silica white
Add 1 = 120 V ; 2 = 240 V ; 3 = 347 V ; 5 = 480 V ; 6 = 600 V ;
7 = 277 V ; 8= 208 V
Please consult our product catalog to know the other available options.

INSSPDH0219
4
N.B. The unit should be cleaned at least once a year. All
other servicing is to be done by qualied service personnel.
This unit must be cleaned regularly In order for the warranty
to be valid. Make sure the power has been turned off at
the circuit breaker panel and that the heating element has
cooled before cleaning the unit or before removing grill for
cleaning and lubrication. WARNING: if the unit is equipped
with a circuit breaker, the power supply at the main breaker
must be turned off before removing the cover of the junction
box or to open or close the unit’s circuit breaker.
Use a soft rag for dusting. When cleaning, use only a damp rag and non-
abrasive dish soap. If you use a cleaning product, always wipe the product off
properly to avoid the discoloration of the unit. Do not use abrasive or chemical
cleaners because they may damage the nish. If the unit is used in a very dusty
location, use a vacuum brush to remove dust and other foreign objects from the
grilles. If needed, vacuum out the dust inside the unit. Note that cigarette smoke
could yellow the discharge grille, the best way to prevent that is to clean the unit
on a regular basis.
Don’t forget to replace front grille (with the screws that were removed) if it was
removed for cleaning.
Restore the power when cleaning or lubrication work is complete.
Do not use cleaning products identied with these symbols:
N.B. Note that there is electrical current linked to the unit
even if the thermostat is set off. This means that there is a
risk of electric shock as long as the unit is energized.
N.B.: If you do not solve the problem after checking these points, cut off the power supply at the main electrical panel and contact our customer service (see the
“Limited warranty” section to obtain the phone numbers).
PROBLEM DEFECTIVE PART OR PART TO CHECK
The unit does not work
• Open circuit breaker or fuse
• Thermal protection has been activated
• Faulty connections
The unit becomes extremely hot • Unit cycles under control of the thermal protection or the latter is defective
• Blocked air vents
The unit cycles under control of the thermal protection (overheat
indicator) • Blocked air vents
The breaker trip when the heater is turned on • Faulty connections
• Voltage lower than that written on the nameplate
MAINTENANCE
TROUBLESHOOTING
ELECTRICAL WIRING
• This unit must be connected to an electrical power source according to the voltage of the unit chosen.
• To ground the heater, you must connect the green wire coming from the circuit breaker panel to the green screw located inside the junction box of the heater.
OPERATION
WARNING : the unit must be properly installed before being used.
ELECTRICAL DIAGRAM
OPERATION, MAINTENANCE & TROUBLESHOOTING
Element
Thermal
protection
Element
Thermal
protection
Thermostat
single pole
(optional)
Disconnect
switch
(optional)
Element
Thermal
protection
Thermostat
double pole
(optional)
Disconnect
switch
(optional)
Relay
(optional)
L1
L2/
N
L1
L2
L1
L2/N

INSSPDH0219
5
REF. # PART # DESCRIPTION
1EA0300-06-1 ELEMENT SPDH6031
1EA0300-06-2 ELEMENT SPDH6032
1EA0300-06-8 ELEMENT SPDH6038
1EA0450-09-1 ELEMENT SPDH9041
1EA0450-09-2 ELEMENT SPDH9042
1EA0450-09-8 ELEMENT SPDH9048
1EA0600-12-1 ELEMENT SPDH12061
1EA0600-12-2 ELEMENT SPDH12062
1EA0600-12-3 ELEMENT SPDH12063
1EA0600-12-8 ELEMENT SPDH12068
1EA0750-15-1 ELEMENT SPDH15071
1EA0750-15-2 ELEMENT SPDH15072
1EA0750-15-3 ELEMENT SPDH15073
1EA0750-15-6 ELEMENT SPDH15076
1EA0750-15-8 ELEMENT SPDH15078
1EA0900-18-1 ELEMENT SPDH18091
1EA0900-18-2 ELEMENT SPDH18092
1EA0900-18-3 ELEMENT SPDH18093
1EA0900-18-6 ELEMENT SPDH18096
1EA0900-18-8 ELEMENT SPDH18098
1EA1050-21-1 ELEMENT SPDH21101
1EA1050-21-2 ELEMENT SPDH21102
1EA1050-21-3 ELEMENT SPDH21103
1EA1050-21-6 ELEMENT SPDH21106
1EA1050-21-8 ELEMENT SPDH21108
1EA1200-24-1 ELEMENT SPDH24121
1EA1200-24-2 ELEMENT SPDH24122
1EA1200-24-3 ELEMENT SPDH24123
1EA1200-24-6 ELEMENT SPDH24126
1EA1200-24-8 ELEMENT SPDH24128
REF. # PART # DESCRIPTION
1EA1350-27-1 ELEMENT SPDH27151
1EA1350-27-2 ELEMENT SPDH27152
1EA1350-27-3 ELEMENT SPDH27153
1EA1350-27-6 ELEMENT SPDH27156
1EA1350-27-8 ELEMENT SPDH27158
2G-SPDH06A GRILL COVER ALMOND (300 W)
2 G-SPDH06W GRILL COVER WHITE (300 W)
2G-SPDH09A GRILL COVER ALMOND (450 W)
2 G-SPDH09W GRILL COVER WHITE (450 W)
2G-SPDH12A GRILL COVER ALMOND (600 W)
2 G-SPDH12W GRILL COVER WHITE (600 W)
2G-SPDH15A GRILL COVER ALMOND (750 W)
2 G-SPDH15W GRILL COVER WHITE (750 W)
2G-SPDH18A GRILL COVER ALMOND (900 W)
2 G-SPDH18W GRILL COVER WHITE (900 W)
2G-SPDH21A GRILL COVER ALMOND (1050 W)
2 G-SPDH21W GRILL COVER WHITE (1050 W)
2G-SPDH24A GRILL COVER ALMOND (1200 W)
2 G-SPDH24W GRILL COVER WHITE (1200 W)
2G-SPDH27A GRILL COVER ALMOND (1350 W)
2 G-SPDH27W GRILL COVER WHITE (1350 W)
3 PROT-185 PROTECTION CUT OUT 300 W
3 PROT-186 PROTECTION CUT OUT 450 W
3 PROT-179 PROTECTION CUT OUT 600 W
3 PROT-180 PROTECTION CUT OUT 750 W
3 PROT-181 PROTECTION CUT OUT 900 W
3 PROT-182 PROTECTION CUT OUT 1050 W
3 PROT-183 PROTECTION CUT OUT 1200 W
3 PROT-183 PROTECTION CUT OUT 1350 W
3
1
2
REPLACEMENT COMPONENT LIST
REPLACEMENT COMPONENT LIST

INSSPDH0219
6
STELPRO DESIGN INC. | Saint-Bruno-de-Montarville | Québec | J3V 6L7
This limited warranty is offered by Stelpro Design inc. (“Stelpro”) and applies to the following product made by Stelpro: model SPDH. Please read
this limited warranty carefully. Subject to the terms of this warranty, Stelpro warrants its products and their components against
defects in workmanship and/or materials for the following periods from the date of purchase: 3 years. This warranty applies only to the original
purchaser; it is non-transferable and cannot be extended.
CLAIM PROCEDURE
If at any time during the warranty period the unit becomes defective, you must cut off the power supply at the main electrical panel and contact 1) your
installer or distributor, 2) your service center or 3) Stelpro’s customer service department. In all cases, you must have a copy of the invoice and
provide the information written on the product nameplate. Stelpro reserves the right to examine or to ask one of its representatives to
examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price
or repair a defective part. Please note that repairs made within the warranty period must be authorized in advance in writing by Stelpro and carried out
by persons authorized by Stelpro.
Before returning a product to Stelpro, you must have a Stelpro authorization number (RMA). To obtain it, call the customer service department at:
1-800-363-3414 (electricians and distributors - French), 1-800-343-1022 (electricians and distributors - English), or 1-866-766-6020 (con-
sumers). The authorization number must be clearly written on the parcel or it will be refused.
CONDITIONS, EXCLUSIONS AND DISCLAIMER OF LIABILITY
This warranty is exclusive and in lieu of all other representations and warranties (except of title), expressed or implied, and Stelpro expressly disclaims
and excludes any implied warranty of merchantability or implied warranty of tness for a particular purpose.
Stelpro’s liability with respect to products is limited as provided above. Stelpro shall not be subject to any other obligations or liabilities whatsoever,
whether based on contract, tort or other theories of law, with respect to goods or services furnished by it, or any undertakings, acts or omissions relat-
ing thereto. Without limiting the generality of the foregoing, Stelpro expressly disclaims any liability for property or personal injury damages, penalties,
special or punitive damages, damages for lost prots, loss of use of equipment, cost of capital, cost of substitute products, facilities or services, shut-
downs, slowdowns, or for other types of economic loss or for claims of a dealer’s customers or any third party for such damages. Stelpro specically
disclaims all consequential, incidental and contingent damages whatsoever.
This warranty does not cover any damages or failures resulting from: 1) a faulty installation or improper storage; 2) an abusive or abnormal use, lack of
maintenance, improper maintenance (other than that prescribed by Stelpro) or a use other than that for which the unit was designed; 3) a natural disas-
ter or an event out of Stelpro’s control, including, but not limited to, hurricanes, tornadoes, earthquakes, terrorist attacks, wars, overvoltage, ooding,
water damages, etc. This warranty does not cover any accidental or intentional losses or damages nor does it cover damages caused by negligence
of the user or owner of the product. Moreover, it does not cover the cost of disconnection, transport, and installation.
The warranty is limited to the repair or the replacement of the unit or the refund of its purchase price, at the discretion of Stelpro. Any parts
replaced or repaired within the warranty period with the written authorization of Stelpro will be warranted for the remainder of the original warranty
period. This warranty will be considered null and void and Stelpro will have the right to refuse any claims if products have been altered without
the written authorization of Stelpro and if the nameplate numbers have been removed or modied. This warranty does not cover scratches, dents,
corrosion or discoloration caused by excessive heat, chemical cleaning products and abrasive agents. It does not cover any damage that occurred
during the shipping.
Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages and some of them do not allow limitations
on how long an implied warranty lasts, so these exclusions or limitations may not apply to you. This warranty gives you specic legal rights and you
may have other rights which vary from state to state or from province to province.
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY LIMITED WARRANTY
LIMITED WARRANTY
STELPRO DESIGN INC. | Saint-Bruno-de-Montarville | Québec | J3V 6L7
