Balkene Home FireSense Bessemer Patio Fireplace User manual

Bessemer Patio Fireplace Item#:01471
WARNING
FOR YOUR SAFETY
1. Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage.
2. Read the installation, operation, and
maintenance instructions thoroughly
before installing or servicing this
equipment.
3. Failure to follow these instructions
could result in fire or explosion, which
could cause property damage, personal
injury, or death.
WARNING
For Outdoor Use Only
Comfort, Quality & Style Since 1998
ATTACH YOUR
RECEIPT HERE
Keep a copy of your proof of
purchase or order confirmation
which will be needed if you
need to contact us about
warranty coverage.
Purchase Date:
U.S. Patents 5,836,298 and D420,115
WARNING
This product can expose you to chemicals
including carbon monoxide which is known to the
State of California to cause birth defects or other
reproductive harm. For more information go to
www.P65Warnings.ca.gov.
11182019
Questions, problems, missing parts?
Before returning to your retailer, our exceptional customer service is available.
Call toll-free (866)866) 985-7877 9 a.m. – 9 p.m., EST
Email [email protected]
Live chat www.wtliving.com 9 a.m. - 4 p.m., EST, Monday - Friday

Contact us for assistance: [phone] | www.wtliving.com 2
www.wtliving.com
TABLE OF CONTENTS
Table of Contents Page 2
Before You begin Page 2
Safety Information Page 3
Package Contents Page 4
Hardware Contents Page 4
Assembly Page 5-8
Care and Maintenance Page 9
Warranty Information Page 10
BEFORE YOU BEGIN
Please read and understand this entire manual before attempting to assemble, operate or install
this appliance. If you have any questions regarding the product, please contact Customer Service:
Call toll-free
Email
Live chat
[phone]
[email protected]
www.wtliving.com
9 a.m. - 9 p.m., EST
9 a.m. – 4 p.m., EST, Monday – Friday
This manual contains important information about the assembly, operation and maintenance of this patio
fireplace. General safety information is presented in the first few pages and is also located throughout this manual.
Keep this manual for future reference and to educate new users of this appliance.

Contact us for assistance: [phone] | www.wtliving.com 3
SAFETY INFORMATION
1. This appliance is for outdoor use only, and
should NOT be used in a building, garage, or
any other enclosed area.
heating. TOXIC carbon monoxide fumes can
accumulate and cause asphyxiation.
use.
by children.
boats or recreational vehicles.
6. Always use in accordance with all applicable
local, state and national codes. Contact your
burning.
the same precautions you would with any
8. The use of alcohol, prescription or non‐
prescription drugs may impair the consumer’s
ability to properly assemble or safely
reading the entire “Owner’s Manual”.
seasoned hardwood. It will burn hotter, more
completely and create less smoke.
11. Do NOT burn charcoal briquets, lump
charcoal, manufactured logs, driftwood, trash,
leaves, paper, cardboard, plywood, painted,
stained or pressure treated wood. Avoid
using softwoods such as pine or cedar that
can throw sparks. Before using this outdoor
manner.
is COMPLETELY assembled and all parts are
securely fastened and tightened.
14. Do NOT store or use gasoline or other
this or any other appliance.
15. Do NOT store or use an LP gas cylinder
while it is in operation.
automobiles, trucks, vans or recreational
vehicles,
17. Do NOT use in an explosive atmosphere.
from combustible materials, gasoline and other
any overhead or near any unprotected
combustible constructions. Avoid using near or
under overhanging trees and shrubs.
hard, level non-combustible surface such as
concrete, rock or stone. An asphalt or blacktop
surface may not be acceptable for this
purpose. Do NOT use on wooden decks.
each use. Leave a thin layer of ash to protect
the bottom.
22. Do NOT use in windy conditions.
spark guards are securely in place.
24. Do NOT use gasoline, kerosene, diesel fuel,
25. Keep all electrical cords away from hot
hot when in operation. To avoid burns, do NOT
unless you are wearing protective gear (pot
holders, gloves, BBQ mittens, hot pads, etc).
Never touch ashes or coals to see if they are
hot.
unattended, especially around children and
pets.
28. Do NOT attempt to move or store this
completely extinguished.
29. Do NOT remove ashes or coals until they
are completely and fully extinguished.
30. Use heat-resistant gloves or hot pads
when contacting handles.
adding or moving logs.
32. Do NOT place wood directly into bottom of
wood grate.
NOTICE: If any portion of the bowl, lid or spark
red it is overloaded.
when lighting or when in use.
35. Do NOT place a hot spark guard or hot
as grass, wooden deck or furniture.
avoid getting it into your eyes.
inspected and cleaned on a regular basis.
38. After a period of storage and/or non-use,
check for signs of damage and creosote build-
up. Do NOT operate until necessary repairs
and/or cleanup are executed.
39. Deaths, serious injury or damage to
property may occur if the above is not
followed exactly
40. CAUTION: It is not recommended to use
combustible surface or any surface that is
not entirely resistant to high heat. However,
if you intend to use this item on a wooden
deck other combustible surface or any surface
that is not entirely resistant to high heat, you
material such as concrete pavers, brick or
surface.
WARNING
FOR YOUR SAFETY

Contact us for assistance: [phone] | www.wtliving.com 4
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
Handle 2
Lid 1
Lid Retainer 3
Screens/Screen Door 3/1
Door Latch 1
Grate 1
Bowl 1
Air Vent 1
Leg Stand 2
Axle 1
U-Leg 1
Wheels 2
M6x15
Screw/Nut
Qty: 28
M6x18
Washer
Qty: 34
M12x22
Washer
Qty: 2
M6x9 Lock
Washer
Qty: 34
M10 Lock Nut
Qty: 2
Connecting
Bracket
Qty: 8
(Not in blister pack)
HARDWARE CONTENTS
1
al
2
3
4
5
6
7
8
9
au
al
am
am
am AD
M5x10
Screw/Lock Nut
Qty: 1
C
B
M6x35
Screw/Nut
Qty: 6
EF G I
M5x10
Screw/Nut
Qty: 1
H
1
7
8
9
5
4
6

1
2
3
TOOLS REQUIRED
(Not included)
•Adjustable Wrench
(or 10mm and 8mm Wrenches)
•Pliers
•Phillips-head Screwdriver

Contact us for assistance: [phone] | www.wtliving.com 5
1
Align holes in Lid Retainer to interior holes in Lid .
Slide M6x18 Washer C onto M6x15 Screw A, then
insert through holes and secure with M6x9 Lock Washer B
and M6x15 Nut A. Repeat with remaining 2 Lid Retainers.
Tighten hardware.
Hardware Used: 6x M6x15 Screw/Nut,
M6x9 Lock Washer,
M6x18 Washer
2
Align holes in Handle with exterior holes in Lid .
Slide M6x18 Washer Conto M6x15 Screw A, then insert
through holes and secure with M6x9 Lock Washer B
and M6x15 Nut A.Tighten hardware.
Hardware Used: 2x M6x15 Screw/Nut,
M6x9 Lock Washer,
M6x18 Washer
PREPARATION
1
2
Before beginning assembly, be sure to empty contents of carton and make sure all parts are present. If any parts are
missing, please contact Customer Service.
Place all parts on a soft, level surface for assembly. You will need a 10mm wrench, an 8mm wrench,and a Phillips screwdriver
for assembly.
ASSEMBLY

Contact us for assistance: [phone] | www.wtliving.com 6
3Align holes in Connecting Brackets Iwith the Screens and
the Screen Door 4. (Note: Connecting brackets should be
placed on INSIDE of screens). Slide M6x18 Washer Conto M6x15
Screw Aand through the hole in the Connecting Bracket and
Screen. Secure with M6x9 lock Washer Band M6x15 Nut A.
Repeat with remaining Connecting Brackets.
Hardware Used: 8x Connecting Brackets
16x M6x15 Screw/Nut,
M6x9 Lock Washer,
M6x18 Washer
4To attach the Door Latch , align the hole in the Door
Latch with the hole in the Screen Door and insert
M5x10 Screw Dand secure with M5x10 Lock Nut D.
Tighten all hardware.
Hardware Used: 1x M5x10 Screw/Lock Nut
Hardware Used: 2x M6x35 Screw,
M6x9 Lock Washer,
M6x18 Washer, M6x35 Nut,
M12x22 Washer, M10 Lock Nut
ASSEMBLY
3
3
4
5
5Insert the U-Leg into the ends of the 2 Leg Stands and align holes. Slide M6x18 Washer Conto M6x35
Screw E, then insert through holes and secure with M6x9
Lock Washer Band M6x35 Nut E. Repeat for other side.
Insert
Axle through the holes on one leg Stand, then
bend back other Leg Stand and insert other end of axle.
Slide Wheel
over end of Axle. Place M12x22 Washer F
over end of Axle. Secure Wheel with M10 Lock Nut G.
Repeat for other side. Tighten all hardware.

Attach Air Vent to Bowl using M5x10 Screw/Nut H.
NOTE: When the fire bowl is in use, it is best to keep the air vent
closed as opening the air vent will decrease the air circulation and
cause your fire to diminish.
Contact us for assistance: [phone] | www.wtliving.com 7
6Attach Handle to bowl . Slide M6x18 Washer Conto M6x15 Screw A, then insert through holes and secure with
M6x9 Lock Washer Band M6x15 Nut A.
Hardware Used: 2x M6x15 Screw/Nut,
M6x9 Lock Washer,
M6x18 Washer
8Place Bowl on leg assembly. Be sure the Handle is
directly above the U-Leg . Align holes in bowl with the
holes in the leg stand assembly. Slide M6x18 Washer Conto
M6x35 Screw E, then insert through holes in the bowl and
Leg Assembly and secure with M6x9 Lock Washer B and
M6x35 Nut E. Repeat for other side. Tighten all hardware.
Hardware Used: 4x M6x35 Screw/Nut,
M6x9 Lock Washer,
M6x18 Washer
6
7
8
7
Hardware Used: 1x M5x10 Screw/Nut
ASSEMBLY

Contact us for assistance: [phone] | www.wtliving.com 8
9Secure assembled spark screen by aligning holes in front
(near Handle) and rear of bowl with holes in center of
Screen Door and the Screen opposite it. Slide M6x18
Washer Conto M6x15 Screw A, then insert through holes
and secure with M6x9 Lock Washer Band M6x15 Nut A.
Hardware Used: 2x M6x15 Screw/Nut,
M6x9 Lock Washer,
M6x18 Washer
10 Place Grate in the Bowl and place the l id on top.
9
ASSEMBLY

Contact us for assistance: [phone] | www.wtliving.com 9
CARE AND MAINTENANCE
CLEANING AND CARE:
Congratulations on your purchase of this patio fireplace. This product is
comprised of steel with an enameled surface and mesh wire screen. Be sure
to read ALL safety and operating instructions contained in this manual.
INSPECTING:
This outdoor fireplace should be inspected on a regular basis to ensure product
safety and longer product life. Do NOT attempt to inspect this outdoor fireplace
until the fire is COMPLETELY out.
1. Check handles to make sure they are secure.
2. Check components for any signs of damage or rust.
3. If damage to any component is detected, do NOT operate until repairs are
executed.
CLEANING:
• This outdoor fireplace should be cleaned on a regular basis to promote safer
use and longer product life.
• NOTE: After repeated use, a slight discoloration of the finish may occur.
• Do NOT attempt to clean this outdoor fireplace until the fire is COMPLETELY
out.
• Do NOT use over cleaner or abrasive cleaners as they will damage this
product.
• Do NOT clean any part of this outdoor fireplace in a self cleaning oven as it
may damage the finish.
1. Wipe exterior surfaces with a mild dishwashing detergent or baking soda.
2. For stubborn surfaces use a citrus based degreaser and a nylon scrubbing
brush.
3. Rinse clean with water.
4. Remove build�up creosote from components with a chimney cleaning
product.
STORAGE:
Do NOT move or store this
outdoor fireplace until the fire
is COMPLETELY out.
1. Once the fire is out, coals are
cold and the outdoor fireplace is
cool to the touch, remove ashes
and properly dispose.
2. Cover outdoor fireplace with a
durable vinyl cover designed to
fit this unit. Do not cover until
unit is completely cooled.
3. Store assembled in a location
away from children and pets.
NOTE: If you do not use a cover,
store this outdoor fireplace
in a dry location to maximize
product life.

LIMITED WARRANTY
Customers in the Contiguous US
This product is warranted for a period of 1 year from original purchase date
against defects in materials and workmanship under normal use. This
warranty does NOT cover normal wear/weathering, exposure to water,
freezing temperatures, oils, fluids, or chemicals, OR use in a commercial
application if model is not designated as a commercial model. At Well
Traveled Living’s sole discretion, products under warranty will be repaired
and/or replaced at no charge to the customer. Returns sent back to Well
Traveled Living must be sent via prepaid freight in the original retail packaging.
For warranty service, contact Well Traveled Living at the address, phone
numbers or website and email listed in this owner’s manual. Be sure to have
your sales receipt, date of purchase and catalogue/model numbers available
when calling. All warranty service will be coordinated by Well Traveled
Living’s, Amelia Island, Florida service center. This warranty is extended only
to the original owner. Proof of purchase will be required before warranty
service is rendered. The sales receipt is the only valid proof of purchase. This
warranty only covers failures due to defects in materials or workmanship
which occur during normal use. Failures and/or damage which result from
accident, negligence, misuse, abuse, neglect, mishandling, alteration or
modification, failure to maintain, improper assembly or maintenance, service
by unauthorized agency or use of unauthorized components or damage that is
attributable to acts of God are NOT covered.
This limited warranty gives you specific legal rights and you may also have
other rights which vary from jurisdiction to jurisdiction. The provisions of the
United Nations Convention on Contracts for the Sales of Goods shall not apply
to this limited warranty or the sale of products covered by this limited
warranty.
• THERE ARE NO EXPRESS WARRANTIES EXCEPT AS
LISTED
• PURCHASER ASSUMES ALL RISKS IN THE
ASSEMBLY AND OPERATION OF THIS UNIT
• FAILURE TO FOLLOW WARNINGS AND
OPERATIONAL INSTRUCTIONS CONTAINED IN
THIS MANUAL CAN RESULT IN SEVERE PROPERTY
DAMAGE AND/OR PERSONAL INJURY
• IN NO EVENT WILL WELL TRAVELED LIVING, OR
ITS DIRECTORS, OFFICERS OR AGENTS BE LIABLE
TO THE PURCHASER OR ANY THIRD PARTY,
WHETHER IN CONTRACT, IN TORT, OR ON ANY
OTHER BASIS, FOR ANY INDIRECT, SPECIAL,
PUNITIVE, EXEMPLARY, CONSEQUENTIAL, OR
INCIDENTAL LOSS, COST, OR DAMAGE ARISING
OUT OF OR IN CONNECTION WITH THE SALE,
MAINTENANCE, USE, OR INABILITY TO USE THE
PRODUCT, EVEN IF WELL TRAVELED LIVING OR
ITS DIRECTORS, OFFICERS OR AGENTS HAVE BEEN
ADVISED OF THE POSSIBILITY OF SUCH LOSSES,
COSTS OR DAMAGES, OR IF SUCH LOSSES, COSTS,
OR DAMAGES ARE FORESEEABLE. IN NO EVENT
WILL WELL TRAVELED LIVING, OR
ITS OFFICERS, DIRECTORS, OR AGENTS BE LIABLE
FOR ANY DIRECT LOSSES, COSTS OR DAMAGES
THAT EXCEED THE PURCHASE PRICE OF THE
PRODUCT.
• SOME JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO
THE PURCHASER.
by
Important Notice
Do NOT return to place of purchase—for customer service and warranty issues:
Call toll-free [phone] 9 a.m. – 9 p.m., EST
Email [email protected]
Live chat www.wtliving.com 9 a.m. - 4 p.m., EST, Monday - Friday
Distributed by:
Well Traveled Living
716 S 8th Street, Amelia Island, FL 32034
wtliving.com | [e-mail]
[phone]
Fire Sense®, Patio Sense,® Avalon Home,® Mojave Sun®, Vulcan®, Balkene Home® and Well Traveled Living® are registered trademarks of
Well Traveled Imports, Inc®. All assembly instruction presentations are the property of Well Traveled Imports, Inc.
® and are protected by
U.S. copyrights and trademarks. All rights reserved.
EXTEND YOUR WARRANTY
When you purchase a Fire Sense or Balkene Home product, you'll have peace of mind in
knowing that it comes with a one-year warranty. Extend your warranty for an additional year
when you write a review of your purchase on www.wtliving.com within 365 days of purchase.
