Gatorback Mudflaps GCR43R Guide

Page 1 of 2
OR
2015-2018 Ford Edge
Mud Flap Set, Rear
Mounting Diagram & Instructions
GCR43R
766627 / 766538 / 766633/ 766639
IMPORTANT:
Manufacturer is not responsible for negligent use of vehicle with mud flaps installed, including
over-tightening of screws and bolts causing damage to vehicle or mud flaps.
TOOLS REQUIRED-
Electric or re-chargeable ¼” Drill Bit Socket or Open Wrench Phillips Screw Driver
Drill
FLAPS
(1)Flap Assembly, (1)Flap Assembly
Front, DS Front, PS
Part #766543 Part #766544
PARTS BAG # 766550
a) (2) Screw, Machine b) (8) Washer, Flat c) (2) Washer, Lock d) (2) Nut, Hex
SS, #18-8, 10-24 x 1” Hex 0.203” x 1” 18g SS 18-8SS, 10 Helicoil SS, #10-24
Part #012022 Part #018031 Part #024001 Part #025003
INSTALLATION (For ease of installation it is suggested that the wheel be removed)
1. Before you install your Mud Flap Set, see the diagram and parts list for all necessary parts. Start on the driver’s
side.
2. Remove the factory screws on the inner fender.
3. Loosely install the mud flap through holes #1 & #2 into the factory holes #4 & #5 using (2) factory screws and (2)
stainless steel washers. (See Diagram)
May 13, 2020

Page 2 of 2
4. With a square or other levelling tool, ensure that the flap is level.
5. Carefully tighten all screws and double-check that the flap has remained level.
6. With a ¼” drill bit, drill through the inner mud flap hole #3 and through the plastic liner #6.
7. Install a stainless steel bolt through the inner mud flap hole #3 into the inner liner hole #6 using (2) stainless steel
washers, (1) lock washer, and (1) hex nut. (See Diagram)
8. Repeat the procedure on the passenger side.
Please check out our YouTube channel to see an install video for this application.
Factory Screw
#1
#2
#3
#4
#5
#6
