Video Surveillance
DM2/DR2 Dome Camera
Overview
The DM2 and DR2 security cameras provide high-quality
surveillance images in a variety of discreet commercial
applications. DM2 and DR2 domes can be mounted in a variety
of positions including wall mount, ceiling mount, pendant mount
and ush mount (DR2 only). The camera can be rotated 360
degrees and tilted 90 degrees into the most desirable viewing
angle using the 3-axis gimble mounting system. Each housing
comes with a captive shroud that conceals the easy-to-position
camera.
The DM2 is a plastic housing designed for indoor use. The DR2 is
an aluminum vandal-resistant IP66-rated environmental housing
designed for indoor and outdoor use. Both housings feature a
polycarbonate dome for extra durability.
The DR2 and DM2 dome housings oer three great camera
options to choose from, making it easy to get the right camera
for the right situation.
Ultra-Wide Dynamic Range
The XP3 cameras use UltraView Xposure technology. Each pixel is
individually optimized to show details in shadows and highlights.
This ultra-wide dynamic range camera option will deliver usable
images in the most challenging high-contrast lighting conditions.
The improved low-light performance makes this option a true
high-performance WDR camera. These camera options deliver
an astounding 520 TVL of color resolution.
High Dynamic Range
The HDR cameras use a Sony double-speed CCD sensor with
a wide dynamic range that makes surveillance under various
critical backlighting environments possible. Micro-controllers in
each camera provide high-quality digital images. Excellent low-
light performance makes this a great choice for changing lighting
conditions. The optional Day/Night models feature a removable
IR cut lter, enabling the use of an external IR illuminator. These
versatile camera options deliver 500 TVL resolution in color.
General Purpose
The EVR cameras incorporate a Sony CCD, DSP and a micro-
controller to provide high-quality images with good color
reproduction and sharp pictures. These camera options deliver
540 TVL resolution color as well as feature an advanced auto-
exposure system for xed and autoiris lenses that optimizes the
available light.
Standard Features
Top-quality images
Digital signal processing•
Excellent performance in most lighting conditions •
Choice of sensor devices for any application•
UltraView Xposure technology available •
Housings for all applications
Uses a true “3-Axis Gimble” which allows for optimization of the •
eld of view level regardless of mounting location
Polycarbonate dome with captive shroud for easy installation,•
vandal resistance and to conceal camera position
Heavy-duty indoor/outdoor and lightweight indoor options•
(Rugged Dome housing is IP66 rated)
12 VDC/24 VAC •
Easy setup
The 3-axis gimble allows for wall mounting of the dome while •
maintaining a level viewing horizon
On-screen display menu walk users through options•
Secondary video output inside tvhe dome bubble for local test•
monitor during setup
DM2/DR2 Domes
high-performance dome cameras

Application
The DM2 and DR2 dome cameras are notable for their ability
to work in just about any environment. Because the available
camera options perform in extreme high and low-light situations,
it’s easy to nd a camera tailored to most security applications.
The discreet DM2 is ideal for indoor applications including retail
environments and healthcare facilities. The DR2, with its vandal
resistant and weather resistant characteristics, is well-suited
for exterior installations including shipping ports and banking
institutions as well as parking lots.
Dimensional Diagrams
The DM2 and DR2 housings are interchangeable – select the best housing for your environment and add an XP3, HDR or EVR camera.
Typical Camera Locations XP3 HDR EVR
Loading docks Y Y N
ATM kiosks Y Y N
Retail stores Y Y Y
Oce lobbies YYY
Automotive dealership showrooms Y Y N
Hospital hallways / surgical suites Y Y N
Parking garages N Y Y
Specications
DM2/DR2 Camera Models DRX/DMX (XP3) DRH/DMH (HDR) DRE/DME (EVR)
Features
Sensor 1/3-in. GE Xposure 1/3-in. interline transfer
Double Speed CCD
1/3-in. interline transfer
Super HAD CCD
Wide Dynamic Range 95 dB typical, 120 dB max 52 dB —
Signal System NTSC/PAL Selectable NTSC or PAL standard NTSC or PAL standard
Scanning System 525/60 (NTSC); 625/50 (PAL) 525/60 (NTSC), 625/50 (PAL);
2:1 Interlace
525/60 (NTSC), 625/50 (PAL);
2:1 Interlace
Digital Zoom — — —
Synchronization DC Internal/AC Line Lock DC Internal/AC Line Lock DC Internal/AC Line Lock
Eective Pixels (HxV) 720 x 540 (NTSC and PAL) 811 x 508 (NTSC);
795 x 596 (PAL)
811 x 508 (NTSC);
795 x 596 (PAL)
Horizontal Resolution 540 TVL 500 TVL color 540 TVL color
Sensitivity 0.5 lux @ f1.2, 30 IRE 0.5 lux @ f1.2, 30 IRE 1.0 lux @ f1.5, 30 IRE
S/N Ratio > 49 dB > 48 dB > 49 dB
AGC on/o, fully programmable 0 to 36 dB 0 to 32 dB
Gamma Compensation 0.45 NTSC; 0.36 PAL 8 Curves selectable 9 Curves selectable
Composite Output 1.0 V p-p @ 75 ohms 1.0 V p-p @ 75 ohms 1.0 V p-p @ 75 ohms
Frame Integration 2X~32X 2X~160X —
Privacy Masking —8 areas ON/OFF, color, position,
size adjustable
8 areas ON/OFF, 2 colors,
position, size adjustable
Mirror Horizontal Horizontal, Vertical, 180° —
White Balance ATW/ATW-Extend/Manual ATW/Manual ATW/AWB/Manual
D/N Switching — Lens with IR cut lter/auto —
Aperture Correction — 3 levels adjustable 0 to 9 steps adjustable
Lens Mount D-mount D-mount D-mount
Lens Options 3.3 to 12 mm Al f1.5
9 to 22 mm Al f2.0
3.3 to 12 mm Al f1.5
9 to 22 mm Al f2.0
3.3 to 12 mm Al f1.5
9 to 22 mm Al f2.0
Auto Exposure — 1/60 (1/50) sec 1/60 (1/50) sec
Manual Exposure — 1/60 (1/50), 1/120, 1/250,
1/500, 1/1000, 1/2000, 1/5000
1/10000 sec.
(only in normal light mode)
1/60 (1/50), 1/120, 1/250,
1/500, 1/1000, 1/2000, 1/5000
1/10000 sec.
Environmental
Operating Temperature (DM2) 32 to 104°F (0 to 40 °C) 32 to 104°F (0 to 40°C) 32 to 104°F (0 to 40°C)
Operating Temperature (DR2) -58 to 122°F (-50 to 50 °C) -22 to 122°F (-30 to 50°C) -22 to 122°F (-30 to 50°C)
Electrical
Input Voltage 12 VDC or 24 VAC 12 VDC or 24 VAC 12 VDC or 24 VAC
Power Consumption 3W (DC); 2.4 W (AC) 3.4W (DC);2.9 W (AC 4.5 W (DC); 3.6 W (AC)
Physical
Dimensions 5.32 x 4.30 in. (135 x 109 mm) 5.32 x 4.30 in. (135 x 109 mm) 5.32 x 4.30 in. (135 x 109 mm)
Weight DM2: 14.5 oz (411 g)
DR2: 33.4 oz (949 g)
DR2: 33.4 oz (949 g)
DM2: 14.5 oz (411 g)
DM2: 14.5 oz (411 g
DR2: 33.4 oz (949 g)
Regulatory Certications FCC, CE, C-TICK, UL FCC, CE, C-TICK, UL FCC, CE, C-TICK, UL
5.32 in. (135 mm)
2.15 in.
(54.5 mm)
2.15 in.
(54.5 mm)
4.30 in. (109 mm)
R1.95 in.
(49.5 mm)
5.32 in. (135 mm)
2.15 in.
(54.5 mm)
2.15 in.
(54.5 mm)
4.30 in. (109 mm)
R1.95 in.
(49.5 mm)
DM2 Dome Housing DR2 Dome Housing
DM2 Plastic Dome — 12VDC/24VAC
Coax
EVR
GEC-DMEP-VA3 540 TVL, PAL, 3.3-12mm Varifocal Autoiris
GEC-DMEP-VA9 540 TVL, PAL, 9-22mm Varifocal Autoiris
GEC-DME-VA3 540 TVL, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DME-VA9 540 TVL, NTSC, 9-22mm Varifocal Autoiris
HDR
GEC-DMHP-VA3 500 TVL WDR, PAL, 3.3-12mm Varifocal Autoiris
GEC-DMHP-VA9 500 TVL WDR, PAL, 9-22mm Varifocal Autoiris
GEC-DMH-VA3 500 TVL WDR, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DMH-VA9 500 TVL WDR, NTSC, 9-22mm Varifocal Autoiris
XP3
GEC-DMXP-VA3 540 TVL UltraView WDR, PAL, 3.3-12mm Varifocal
Autoiris
GEC-DMXP-VA9 540 TVL UltraView WDR, PAL, 9-22mm Varifocal
Autoiris
GEC-DMX-VA3 540 TVL UltraView WDR, NTSC, 3.3-12mm Varifocal
Autoiris
GEC-DMX-VA9 540 TVL UltraView WDR, NTSC, 9-22mm Varifocal
Autoiris
D/N
GEC-DMHDNP-VA3 500 TVL WDR, Day/Night , PAL, 3.3-12mm Varifocal
Autoiris
GEC-DMHDNP-VA9 500 TVL WDR, Day/Night , PAL, 9-22mm Varifocal
Autoiris
GEC-DMHDN-VA3 500 TVL WDR, Day/Night, NTSC, 3.3-12mm Varifocal
Autoiris
GEC-DMHDN-VA9 500 TVL WDR, Day/Night, NTSC, 9-22mm Varifocal
Autoiris
UTP
EVR
GEC-DMEUP-VA3 540 TVL, UTP, PAL, 3.3-12mm Varifocal Autoiris
GEC-DMEUP-VA9 540 TVL, UTP, PAL, 9-22mm Varifocal Autoiris
GEC-DMEU-VA3 540 TVL, UTP, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DMEU-VA9 540 TVL, UTP, NTSC, 9-22mm Varifocal Autoiris
HDR
GEC-DMHUP-VA3 500 TVL WDR, UTP, PAL, 3.3-12mm Varifocal Autoiris
GEC-DMHUP-VA9 500 TVL WDR, UTP, PAL, 9-22mm Varifocal Autoiris
GEC-DMHU-VA3 500 TVL WDR, UTP, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DMHU-VA9 500 TVL WDR, UTP, NTSC, 9-22mm Varifocal Autoiris
XP3
GEC-DMXUP-VA3 540 TVL UltraView WDR, UTP, PAL, 3.3-12mm
Varifocal Autoiris
GEC-DMXUP-VA9 540 TVL UltraView WDR, UTP, PAL, 9-22mm
Varifocal Autoiris
GEC-DMXU-VA3 540 TVL UltraView WDR, UTP, NTSC, 3.3-12mm
Varifocal Autoiris
GEC-DMXU-VA9 540 TVL UltraView WDR, UTP, NTSC, 9-22mm
Varifocal Autoiris
D/N
GEC-DMHDNUP-VA3 500 TVL WDR, Day/Night, UTP, PAL, 3.3-12mm
Varifocal Autoiris
GEC-DMHDNUP-VA9 500 TVL WDR, Day/Night, UTP, PAL, 9-22mm
Varifocal Autoiris
GEC-DMHDNU-VA3 500 TVL WDR, Day/Night, UTP, NTSC, 3.3-12mm
Varifocal Autoiris
GEC-DMHDNU-VA9 500 TVL WDR, Day/Night, UTP, NTSC, 9-22mm
Varifocal Autoiris
DR2 Rugged Dome — 12VDC/24VAC
Coax
EVR
GEC-DREP-VA3 540 TVL, PAL, 3.3-12mm Varifocal Autoiris
GEC-DREP-VA9 540 TVL, PAL, 9-22mm Varifocal Autoiris
GEC-DRE-VA3 540 TVL, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DRE-VA9 540 TVL, NTSC, 9-22mm Varifocal Autoiris
HDR
GEC-DRHP-VA3 500 TVL WDR, PAL, 3.3-12mm Varifocal Autoiris
GEC-DRHP-VA9 500 TVL WDR, PAL, 9-22mm Varifocal Autoiris
GEC-DRH-VA3 500 TVL WDR, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DRH-VA9 500 TVL WDR, NTSC, 9-22mm Varifocal Autoiris
XP3
GEC-DRXP-VA3 540 TVL UltraView WDR, PAL, 3.3-12mm Varifocal
Autoiris
GEC-DRXP-VA9 540 TVL UltraView WDR, PAL, 9-22mm Varifocal Autoiris
GEC-DRX-VA3 540 TVL UltraView WDR, NTSC, 3.3-12mm Varifocal
Autoiris
GEC-DRX-VA9 540 TVL UltraView WDR, NTSC, 9-22mm Varifocal
Autoiris
D/N
GEC-DRHDNP-VA3 500 TVL WDR, Day/Night , PAL, 3.3-12mm Varifocal
Autoiris
GEC-DRHDNP-VA9 500 TVL WDR, Day/Night , PAL, 9-22mm Varifocal
Autoiris
GEC-DRHDN-VA3 500 TVL WDR, Day/Night, NTSC, 3.3-12mm Varifocal
Autoiris
GEC-DRHDN-VA9 500 TVL WDR, Day/Night, NTSC, 9-22mm Varifocal
Autoiris
UTP
EVR
GEC-DREUP-VA3 540 TVL, UTP, PAL, 3.3-12mm Varifocal Autoiris
GEC-DREUP-VA9 540 TVL, UTP, PAL, 9-22mm Varifocal Autoiris
GEC-DREU-VA3 540 TVL, UTP, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DREU-VA9 540 TVL, UTP, NTSC, 9-22mm Varifocal Autoiris
HDR
GEC-DRHUP-VA3 500 TVL WDR, UTP, PAL, 3.3-12mm Varifocal Autoiris
GEC-DRHUP-VA9 500 TVL WDR, UTP, PAL, 9-22mm Varifocal Autoiris
GEC-DRHU-VA3 500 TVL WDR, UTP, NTSC, 3.3-12mm Varifocal Autoiris
GEC-DRHU-VA9 500 TVL WDR, UTP, NTSC, 9-22mm Varifocal Autoiris
XP3
GEC-DRXUP-VA3 540 TVL UltraView WDR, UTP, PAL, 3.3-12mm Varifocal
Autoiris
GEC-DRXUP-VA9 540 TVL UltraView WDR, UTP, PAL, 9-22mm Varifocal
Autoiris
GEC-DRXU-VA3 540 TVL UltraView WDR, UTP, NTSC, 3.3-12mm Varifocal
Autoiris
GEC-DRXU-VA9 540 TVL UltraView WDR, UTP, NTSC, 9-22mm Varifocal
Autoiris
D/N
GEC-DRHDNUP-VA3 500 TVL WDR, Day/Night, UTP, PAL, 3.3-12mm Varifocal
Autoiris
GEC-DRHDNUP-VA9 500 TVL WDR, Day/Night, UTP, PAL, 9-22mm Varifocal
Autoiris
GEC-DRHDNU-VA3 500 TVL WDR, Day/Night , UTP, NTSC, 3.3-12mm
Varifocal Autoiris
GEC-DRHDNU-VA9 500 TVL WDR, Day/Night , UTP, NTSC, 9-22mm Varifocal
Autoiris
Brackets
DR-FM Flush ceiling mount bracket
DR-RWM Wall mount bracket
Ordering Information

GE Security EMEA
Kouterveldstraat, 2
B -1831 Diegem Belgium
Phone : [phone]
Fax : [phone]
www.gesecurity.eu
© 2008 GE Security. As a company of innovation, GE Security
reserves the right to change product specications without notice.
For the latest product specications, visit GE Security online
at www.GESecurity.com or contact your GE Security sales
representative. DM2-DR2_A4_Brochure.indd
