UVD-XP3DNR(-P) Camera
Installation Sheet
EN DE ES FR IT NL PL PT RU TR
2
1
3
4
5
© 2009 GE Security, Inc.
1 of 4
P/N XP3DNR092009• REV 01.00 • ISS 03SEP09

6
EN: Installation Sheet
2 of 4 P/N XP3DNR092009 • REV 01.00 • ISS 03SEP09
Description
The UVD-XP3DNR(-P) camera consists of the following parts:
• The camera assembly (Figure 1)
Table 1: Description of camera parts
1. Lens body
2. Bubble
3. Video monitor output
4. OSD control pad
5. Camera body
• Monitor output cable (Figure 2)
1. Monitor output BNC; 2. Monitor output RCA
• Mounting screws, wall anchors, and hex key
Use the video output BNC and power jack for normal
system operation. Use the monitor output cable for
installation and maintenance.
OSD control pad
The onscreen display (OSD) control pad (Figure 3: 1. OSD
control pad) is a five-direction joystick that provides the
ability to manually control the camera functions. Table 1
lists the OSD control pad functions and describes their use.
Table 2: OSD control pad functions
Pad directions Description
Up Moves the cursor upward to select an item.
Left Moves the cursor left to select or adjust the
parameters of the selected item.
Right Moves the cursor to the right to select or
adjust the parameters of the selected item.
Down Moves the cursor downward to select an
item.
Pad directions Description
Enter Press the center of the control pad to
display the Setup menu. If the selected item
has its own menu, press the control pad to
enter a submenu. Press the control pad for
2 seconds to save all settings and exit the
Setup menu.
Installation
Complete all the necessary programming before you install
the camera. This section provides information on how to
install the camera and adjust camera angle and focus.
WARNING: To reduce the risk of fire or electronic shock, do
not expose the camera to rain or moisture and do not
remove the cover or back.
Cable connection
To make cable connections, do the following:
1. Connect a coaxial cable from the camera’s BNC
connector to a CCTV monitor or video recording device.
2. Connect a 12 VDC or 24 VAC power supply to the
power input. The label on the camera gives the
following information:
Red cable. Power in.
Black cable. Power in.
White cable. Video out.
Black cable. Video ground.
Note: For AC24V or DC12V, Black or Red may be used for ground.
Camera installation
To mount the camera, attach the camera to the mounting
surface using the appropriate fasteners
Angle adjustment
To adjust the horizontal angle of the platform up to 180
degrees, turn the platform (Figure 4, number 1).
To adjust the horizontal angle of the rotor up to 350
degrees, turn the rotor on the platform (Figure 4, number 3).
To adjust the vertical angle of the platform up to 90
degrees, turn the platform (Figure 4, number 3).

Focus adjustment
To adjust the camera zoom and focus, see Figure 5 and do
the following:
Table 3: Description of zoom and focus adjustment in Figure 5
1. Zoom ring thumbscrew for VA2 and focus ring for VA9
lens.
2. Focus ring thumbscrew for VA2 and zooming ring for VA9
lens.
1. Loosen the zoom ring thumbscrew.
2. Turn the zoom ring to set the desired zoom.
3. Tighten the zoom ring thumbscrew.
4. Loosen the focus ring thumbscrew.
5. Turn the focus ring to set the desired focus.
6. Tighten the focus ring thumbscrew.
Connect the monitor
Program the cameras by attaching a standard video
monitor to the system.
To connect the monitor, do the following:
1. Plug the monitor output cable (Figure 2) to the video
monitor output connector (Figure 1).
2. Connect the BNC cable to the video monitor.
3. Press Enter (Figure 3) to display the Setup menu.
Programming
The camera is configured through the setup menus which
appear on-screen. See Figure 6.
To access and navigate the menus, press and hold the
center of the OSD control pad (Figure 3). Press Up or Down
on the control pad to move between items, and press Enter
(center of the control pad) to select the item. Press Right or
Left on the control pad to select the different options
available for the item.
You can return to the previous menu from any of the
menus (except the Main menu) by selecting the Previous
page option.
The menu map is shown on the back page.
Refer to the User Manual for detailed programming
instructions.
Table 4: Main menu options
Menu option Description
Preset Preset settings.
Setup Camera ID, Line Lock, motion detection, and
WDR settings.
Viewing Flip and resolution settings
Exposure AGC, AE preferences, range control, shutter limit,
frame RPT, and B/W control settings.
White balance White balance settings.
Save/Restore Save and restore user and factory settings.
Specifications
Electrical
Power Input 12 VDC or 24 VAC
Power consumption 3W (DC); 2.4 W (AC)
Environmental and physical
Weight 33.8 oz. (958 g)
Dimensions 5.22 x 4.11 in. (133 x 105 mm)
Operating Temperature -58 to +122°F ( + -50 to +50°C)
Weather resistant IP66
Regulatory information
Certification N0000
FCC compliance This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and
used in accordance with the instruction
manual, may cause harmful interference to
radio communications.
You are cautioned that any changes or
modifications not expressly approved by the
party responsible for compliance could void
the user ’s authority to operate the equipment.
European Union
directives
1999/5/EC (R&TTE directive): Hereby, GE
Security declares that this device is in
compliance with the essential requirements
and other relevant provisions of Directive
1999/5/EC.
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European
Union. For proper recycling, return this
product to your local supplier upon the
purchase of equivalent new equipment, or
dispose of it at designated collection points.
For more information see:
www.recyclethis.info.
2004/108/EC (EMC directive): Non-European
manufacturers must designate an authorized
representative in the Community. Our
authorized manufacturing representative is:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands.
Contact information
For contact information, see our Web site:
www.gesecurity.com
EMEA: For contact information, see our Web site:
www.gesecurity.eu
P/N XP3DNR092009 • REV 01.00 • ISS 03SEP09 3 of 4
