EV Charging Station
Introduction
The GE EV Charging Station offers Level II charging capable of reducing charge
time from 12-18 hours to 4-8 hours with service needs of 208-240VAC at 40A,
assuming a 24kWh battery and a full-cycle charge. GE recognizes that this is an
industry that will develop and change over time and, as a result, the EV Charging
Station is designed to accommodate future changes and technological advances.
The EV Charging Station is “future proof” through a modular design, giving the
owner the ability to upgrade the unit with field installable modules without
replacing the charging station.
GE has over 40 years of experience in the manufacture of RV pedestals, which
provides knowledge and familiarity for the manufacture of EV charging stations.
In addition, a crucial component to the implementation of EV charging stations
is the upstream infrastructure needed for installation. GE has over 100 years
of experience in the manufacture of electrical distribution systems. As a result,
we are able to offer a complete EV infrastructure solution that includes the
EV Charging Station and the associated upstream infrastructure.

Product Details
The GE EV Charging Station has a list of features that are upgradeable, resulting in a robust and reliable solution
for the need of EV charging infrastructure.
• The cord holder serves to keep the cord organized and out of the way of parking spaces, sidewalks and streets
• LED light to display charger status
• Option for a Radio Frequency Identification (RFID) reader: users can gain charging authorization by swiping
RFID cards in front of the readers
• Ethernet network offered for RFID authorization service
• RFID software application registers usage of the EV Charging Station, enabling data collection, and will also
monitor status of communication between RFID and EVSE
• Vacuum Fluorescent Display (VFD) screen showing greetings, instructions and charging station messages
• Nuisance tripping avoidance and auto re-closure
• Vehicle ground monitoring circuit
• Single phase metering, displayed on included VFD
• A building ventilation interface signal can be provided to operate facility and garage fans when required
GE EV Charging Station – a closer look
Control Unit
• Provides user with charger status and messages
via LED bar, Vacuum Fluorescent Display (VFD) and
external communications
• Allows user configurable overload protection
• Performs CCID20 ground fault protection per UL 2231
• Provides single phase metering
• Handles SAE J1772 functions
Contactor
• Responsible for energizing and de-energizing the
connector
• Operates in conjunction with controller to meet
UL and NEC requirements
Connector
• Compliant with SAE J1772 standard
• UL listed for EVSE applications
Fuses
• Provides overload and short circuit protection
LED indication of charge status
Plug holder
RFID Reader
Base to accept connection
and fasten to concrete
Cord holder
Cord connection to unit
Vacuum Fluorescent Display (VFD)
Access panel (on side)

Specifications
Enclosure
The EV Charging Station features a NEMA 3R enclosure for all four mounting options.
SAE Compliant Level II per J1772
Vehicle Interface SAE J1772 EV connector
Cable Length 20’ cable
AC Charging Power Output 7.2kW (240VAC @ 30A)
Voltage and Current Rating 208-240VAC @ 30A
AC Power Input 208-240VAC requiring only Line 1, Line 2, and Earth ground
Recommended Service Panel Breaker Pole, Wall, Single Pedestal: 2-pole 40A breaker on dedicated circuit.
Double Pedestal: (Qty. 2) 2-pole 40A breaker on dedicated circuit
Ground Fault Protection Internal 20mA CCID with auto re-closure, does not require a GFCI in service panel
Cold Load Start Random start up between 0 and 15 minutes
Local Area Network CAT5 Ethernet
Network Communication Protocol TCP/IP
Network Security GE recommends that network be VPN and Firewall protected
Metering Accuracy 2% accurate on voltage and current; 4% accurate on power and energy
RFID Reader ISO 15693 compliant
Display Screen Vacuum Fluorescent Display
Standby Power 5W typ.
Indoor Ventilation Signal provided to turn on facility fans
Outdoor Rated NEMA 3R
Safety Compliance UL 2231, UL 2251, UL 2594, cUL 2231, cUL 2594, NEC 625, SAE J1772
Surge Protection 6kV @ 3,000A
EMI Compliance FCC Part 15 Class A
Operating Temperature -30°C to +50°C ambient
Operating Humidity Up to 95% non-condensing
Approximate Shipping Weights
Single Pedestal: 90 lbs
Double Pedestal: 90 lbs
Pole: 45 lbs
Wall: 45 lbs
Dimensions
Single Pedestal: 51.1"H x 14.9"W x 13.8"D
Double Pedestal: 51.1"H x 14.9"W x 13.8"D
Pole: 31.52"H x 11.82"W x 11.16"D
Wall: 31.52"H x 11.82"W x 11.16"D
Single pedestal
Free standing
pedestal with a
robust footing to
bolt the unit to
the ground
Double pedestal
Free standing
pedestal featuring
a back to back
design with a robust
footing to bolt the
unit to the ground
Wall mount
Surface mounted
unit
Pole mount
Wall mount design
with an additional
pole mounting kit

Control Unit
The control unit will integrate SAE J1772 Functions, Metering, Overload monitoring and will manage HMI and all
local monitoring.
• The SAE J1772 functions include the following:
• Energization and De-energization of the system
• Verification of vehicle connection; the EVSE de-energizes output when the connector is uncoupled
• Continuous monitoring of ground connection between the EV and the EV Charging Station
• Automatic De-energization of the cable in case of rupture or separation of the cable
• Continuous monitoring of EVSE current capacity with supply rating recognition by PWM 1kHZ signal
• Determination of ventilation requirements depending on battery type of vehicle
The GE EV Charging Station provides communications through the controller prompting proper cord management.
A message on the VFD screen instructs the operator to return the plug to the EVSE inlet, thereby reducing the
possibility of plug and cord damage. The proximity detection feature, which is part of the SAE J1772 connector,
enables the coupler to communicate the presence of the connector when it is inserted into the EVSE coupler.
Overload monitoring is provided by the control unit which features protection above 125% nominal current. This
threshold limit will be below the breaker protecting the EVSE’s limit to avoid local maintenance of the system during an
overload event. The control unit will include a 15-20 mA ground fault protection according to UL2231. An integrated
single phase meter will measure current and voltage in addition to calculating energy and power. The control unit also
performs monitoring of the contactor to ensure the contactor is in the correct state when charging or not charging.
User Interface
The GE EV Charging Station offers a user interface that is easy to operate and guides a user through charging their
vehicle. A Vacuum Fluorescent Display (VFD) screen features greetings, instructions, and charging station messages
as well as featuring communications for the single phase metering. The LED light located at the top of the charging
station displays charger statuses as follows:
• Green = Station active
• Blinking green = Vehicle connected, not charging
• Amber = Charging
• Red = Fault occurred
Radio Frequency Identification
GE EV Charging Stations offer the option for Radio Frequency Identification (RFID). The ISO 15693 compliant RFID
can be used with key cards provided by GE. Users will simply wave their key cards in front of the RFID reader at
the particular EV Charging Station intended for use and will be authorized to start charging. There are a few
benefits associated with implementing RFID:
• Ethernet network offered for RFID authorization service
• Provides security, enabling only authorized users to operate the charging station through RFID
• Secure software application offering different privilege levels for owner/operator of the EV Charging Station
RFID Software Application
The RFID software application is responsible for maintaining and processing authorization of users for the EV Charging
Stations it supports. EVSE operators will be able to control adding, removing, or suspending user authorization. The
software application also supplies reports on the EVSE usage, enabling data collection, and monitors the status of
communication between the RFID software and EV Charging Station. This is a local desktop application which runs
on a Windows®operating system, requiring Windows XP or Windows 7. The software desktop application, which
stores data in a relational database, communicates with the EV Charging Station controller over TCP/IP protocol.

Safety Features
• Ground Fault Protection
— 4 automatic retries before station lockout
— CCID 20- charging circuit interrupting device 20mA per UL2231
• Automatic self tests of CCID
• Vehicle Ground monitoring per UL 2231
• Contactor monitoring designed to alert the customer when the contactor fails to open or close
• Secondary overload protection to prevent breaker tripping on vehicle faults
• Automatic energizing and de-energizing of charging circuit per NEC 625 and SAE J1772
• Support for personal lock on EVSE connector; enabling driver to lock the connector when charging their EV
• Secured key entry on service door of EVSE
• Control user authorization with RFID option
• Handle holder securely locks EVSE connector into place when not being used
• Visible Vacuum Fluorescent Display and light indicator to communicate fault alerts
• Instruction displayed on VFD to return plug to the EVSE socket when not in use to prevent damage to the plug
Dimensions
Wall and Pole Mounted Units Single and Double Pedestal Units
14.9
14.6
10.8
11.8 13.8
13.8
11.8
29.8
16.3
8.0
10.1
9.0
7.0 6.5
6.4
57.5
49.0
14.91
(378,7)
11.81
(300,0)
13.27
(337,0)
13.11
(333,0)
15.11
(383,7)
9.76
(248,0)
10.83
(275,1)
11.08
(281,5)
16.52
(419,6)
18.37
(466,7)
12.31
(312,8)
12.15
(308,6)
31.53
(800,7)

Wiring Diagram
Catalog Numbers
Preferred Architectures
Example 1 Example 2 Example 3
Adding 1 GE EV Charging Station to a Adding 3 EV Charging Stations to a Adding 12 EV Charging Stations to a
single-family residence retail outlet hotel, parking garage, etc.
Type Enclosure Output No. of
Connectors
Single Phase
Integrated Meter RFID Cat #
Single Pedestal NEMA 3R 208-240V 30A 1 phase 1Yes No EVSN3
Yes EVSRN3
Double Pedestal NEMA 3R 208-240V 30A 1 phase 2Yes No EVDN3
Yes EVDRN3
Pole NEMA 3R 208-240V 30A 1 phase 1Yes No EVPN3
Yes EVPRN3
Wall NEMA 3R 208-240V 30A 1 phase 1Yes No EVWN3
Yes EVWRN3
EV Charger
Utility Meter
2 pole 40A 120/240 Breaker
#8 AWG Cu THWN Conduit
EV Charger
Utility Meter
2 pole 40A 120/208 Breaker
#8 AWG Cu THWN Conduit
EV Charger
12 – 2 pole 40A
120/208 Breakers
#8 AWG Cu THWN Conduit
400AT/400AF
2 – 250 AL kcmil THWN
175AT/250AF
112.5 kVA
From
Power Panel Board
Switchboard
MCC Switchgear
480 120/208Y
Y
Note
Verify capacity of panel board and service are not exceeded.
Select conductor size according to the NEC.

imagination at work
GE Energy
41 Woodford Avenue, Plainville, CT 06062
www.geindustrial.com
© 2010 General Electric Company
DET-743 (12/10)
Information provided is subject to change without notice. Please verify all details with GE. All values are design or typical
values when measured under laboratory conditions, and GE makes no warranty or guarantee, express or implied, that
such performance will be obtained under end-use conditions.
Upstream Infrastructure
As EV infrastructure extends beyond just the charging station, upstream electrical distribution equipment is critical
to ensuring a safe, reliable EV infrastructure system is built and maintained. Whether it is installing brand new
equipment or making upgrades to already existing infrastructure, GE has the domain expertise and channel partners
to perform the type of upgrades that may be required to support the use of EV Charging Stations. The following
information is a brief overview of upgrades in this space.
Spectra Series™ Switchboards
Spectra Series Switchboards offer a design that provides the high quality and reliability that has long been associated
with GE group-mounted switchboards. All GE switchboards can incorporate our full line of circuit breakers, power
management components, transient voltage suppressors and meters. Similar to our EV Charging Stations, the
Spectra Series Switchboards are designed and manufactured to meet GE internal standards along with NEMA,
NEC, UL and CSA requirements. In addition, Spectra RMS Circuit Breakers meet all applicable NEMA, NEC, UL and
CSA requirements, plus those for JIS and IEC.
Spectra Series™ Power Panelboards
GE Power Panelboard interiors are offered in two different styles: plug-in and bolt-on. Spectra Plug-In interiors are
designed for use with either fusible switches or molded case circuit breakers. A combination of the devices can be
used on a common interior. Spectra Bolt-On interiors are designed for use with circuit breakers only. Main or branch
devices (fusible switch or circuit breaker), as well as lugs only, can be installed at the factory or at the construction
site providing application flexibility. Unique to GE, the design approach makes field reconfiguration possible, as
well as having a universal platform that offers interchangeable boxes, fronts and interiors. All panelboards are
manufactured in accordance with UL standards 50 and 67 and conform to the latest requirements of the NEC and
NEMA standards.
A Series Panelboards
Our A-Series design is an extremely flexible Lighting Panel with over 12,000 combinations, most available within
a 10 day production cycle. NEMA 3R, 12 and 4x enclosures are all available options. The panel’s comprehensive
design and ease of installation are two reasons why contractors turn to this panelboard. All GE A Series panelboards
meet UL standards, as well as NEMA PB1, and NEC article 384.
General Purpose Transformers
GE has been building transformers for almost 100 years, but we continue to innovate and improve the reliable QL
design. GE Type QL transformers meet NEMA TP-1 efficiency standards. Available in aluminium and copper and in
all three temperature rise ratings, QL transformers utilize a UL recognized 220°C insulation system and are UL
listed. The transformers are 100% factory tested for shorts and coil integrity, current and loss, voltage, impedance
and noise.
