DIMENSIONS AND INSTALLATION INFORMATION
For answers to your Monogram, GE Café™Series, GE Profile™Series or
GE Appliances product questions, visit our website at geappliances.com
or call GE Answer Center®Service, 800.626.2000.
CGP9536SLSS
GE Café™Series 36" Built-In Gas Cooktop
Specification Revised 6/17
Cooktop 3-11/16"13" MAX
depth
30" MIN. to
unprotected
cabinet
12" MIN.
clearance to
side wall
from cut-out
18" MIN.
to cabinet
3-3/8" to
rear wall
36" MIN.
Base Cabinet
Electrical junction
box 16" MIN.
below countertop
Cut should
not interfere
with cabinet
structure at
front
12" MIN.
clearance to
side wall
from cut-out
Electrical
cord
Electrical
outlet
Shut-off
valve
Pressure
regulator
1/2" pipe
Coupling
Gas Connection
Dimension and installation information are shown in inches.
36" 21"
33-7/8"
19-1/8"
2-1/2"
Min
AGA REQUIREMENT: All gas cooktop models require
7/16" free area below cooktop height to combustible
material. Requires 18" minimum from countertop to
adjacent overhead cabinets.
NOTE: If installing with a GE ProfileTM Telescopic
Downdraft System, consult both cooktop and
downdraft installation instructions packed with
product before installing. Cooktop gas/electric supply
may need to be re-routed to install downdraft.
ELECTRICAL RATING: 120V, 60Hz, 5A
INSTALLATION WITH SINGLE WALL OVEN
INFORMATION:
30" Gas Cooktops are approved for use over select GE
27" and 30" Wall Ovens and Warming Drawers. 30" and
36" Gas cooktops are approved for use over select 30"
Wall Ovens and Warming Drawers. Refer to cooktop
and wall oven/warming drawer installation instructions
packed with product for current dimensional data.
INSTALLATION INFORMATION: Before installing,
consult installation instructions, packed with product,
for current dimensional data.
Dimension and installation information are shown in inches.
*Allow 5-3/4" depth at rear for electrical and gas connections
ADA
COMPLIANT

CGP9536SLSS
GE Café™Series 36" Built-In Gas Cooktop
Specification Revised 6/17
FEATURES AND BENEFITS
20,000 BTU tri-ring burner - Offers the flexibility of three different burners
30" cooktop with 5 burners - Enjoy ultimate cooktop flexibility and more cooking
space with 5 sealed burners
Extra-large, integrated cooktop griddle - Eliminate the need for extra cookware and
enjoy a built-in cooking surface for pancakes, grilled cheeses and other favorites.
Heavy-cast, edge-to-edge grates - Allow for easy movement of pans between burners
White LED backlit heavy-duty knobs - Durable knobs are back-lit with white LED
lighting that lend a sleek appearance and let you know if burners are on
Control lock capability - Protects against unintended activation
Precise Simmer burner - Delicate foods don’t burn with low, even heat
Sealed cooktop burners - Contains spills and make cleaning quick and easy
Heavy-duty, dishwasher safe grates - Easily and safely clean grates in the dishwasher
Model CGP9536SLSS - Stainless Steel
CGP9536SLSS
GUARANTEED FIT
Replacing a similar cooktop from GE or another brand? GE cooktops
are guaranteed for an exact fit to make replacement easy
Visit geappliances.com for more info
