GE Profile JP346 Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
321358
Specification Created 10/06
Listed by
Underwriters
Laboratories
JP346WM/CM/BM
GE® 30" Built-In CleanDesign Electric Cooktop
Dimensions and Installation Information (in inches)
Note: If installing with a GE Profile™Telescopic
Downdraft System, consult both cooktop and
downdraft installation instructions packed with
product before installing. Cooktop gas/electric supply
may need to be re-routed to install downdraft.
Note: Consult cabinet and countertop
manufacturer’s specs for flush mount installation
prior to install.
Installation Information: Requires a 5" free
area between the bottom of the cooktop to any
combustible material, i.e., shelving. Free area not required when installing
wall oven underneath cooktop. Refer to installation instructions. Requires
a 15" minimum from cooktop to adjacent overhead cabinets. Units are
furnished with a 48" flexible armored cable.
Before installing consult installation instructions, packed with product, for
current dimensional data. 36" Ribbon cooktops are approved for use over GE
30" Single Wall Ovens only. 30" Ribbon cooktops are approved for use over
select GE 27" and GE 30" Single Wall Ovens. Refer to cooktop and wall oven
installation instructions packed with product for current dimensional data.
Filler Trim Kit
When replacing an old GE 30" cooktop (with larger opening) use the following
one-piece trim kit to fill in the over-size hole. Available at additional cost.
JXTR32B (Black glass with black, white or bisque pattern)
3-1/4*
Cooktop
2-1/2**
Required
28-1/2
19-5/8
29-3/4
30_color_cktp_install.eps
21-3/8
Electrical junction box 16" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure
at front
1-1/2 " MIN.
clearance to
side wall
from cut-out
1-1/2 " MIN.
clearance to
side wall
from cut-out
1-3/4 " to
rear wall
13" MAX.
depth
*Depth of unit at conduit connection location (rear) is
6-1/2" on models PP980/950 and 4-5/8" on models
PP975/972/962/945/942/932/912, JP655/356/346.
**Raised bull nose countertops may require up to
3/8" additional clearance to prevent interference
with curved front.
15" MIN.
to cabinet
KW Rating
240V 7.6
208V 5.7
Breaker Size
240V 40 Amps
208V 30 Amps

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
321358
Specification Created 10/06
Listed by
Underwriters
Laboratories
JP346WM/CM/BM
GE® 30" Built-In CleanDesign Electric Cooktop
JP346SM
Features and Benefits
• Ceramic Glass Cooktop - A smooth cooktop surface makes
cleaning quick and easy
• Ribbon Heating Elements - Provide powerful heat beneath
a smooth glass surface to ensure even heat and fast
warm-up times
• PowerBoil™Element - Provides up to 3,000 watts of power to
speed the boiling process
• Frameless Design - A smooth and seamless cooktop surface
makes cleaning quick and easy
• Melt Setting - Optimized for melting chocolate, this setting
delivers the low gentle heat needed
• Dishwasher-Safe Knobs - Feature a robust construction for safe
and easy cleaning
• Hot Surface Indicator Lights - Illuminate when the cooking
surface is active and hot, adding convenience and safe caution
• Model JP346WMWW – White on white
• Model JP346CMCC – Bisque on bisque
• Model JP346BMBB – Black on black
