I
Istallatio structio S36" Induction Cooktop
PHP960, ZHU36
[] If you have questions, call 800.GE.CARESor visit our website at GEApplionces.com
BEFORE YOU BEGIN
Read these instructions completely and carefully.
, IMPORTANT - Savetheseinstructions
for local inspector's use.
, IMPORTANT - Observeollgoverning
codes and ordinances.
, Note to Installer- Be sure to leave these
instructions with the Consumer.
, Note to Consumer - Keep these instructions
for future reference.
, Product failure due to improper installation is
not covered under the Warranty.
A WARNING - This appliance must be
properly grounded.
. ATTENTION INSTALLER - ALL
COOKTOPS MUST BE HARD WIRED IDIRECT
WIRED} INTO AN APPROVED JUNCTION BOX.
A "PLUG AND RECEPTACLE" IS NOT PERMITTED
ON THESE PRODUCTS.
, Proper installation is the responsibility of the
installer and product failure due to improper
installation is NOT covered under warranty.
PARTS INCLUDED
Baffle
(For all installations
except over an oven.) 2 Hold-Down Brackets
6 Hex-Head Screws
2 Thumbscrews
Foam Tape
MATERIALS YOU WILL NEED
Junction Box Large Size
(Sizedfor conduit Wire Nuts
per local electrical
codes.)
90° or Straight
Squeeze Connector
for !" Conduit
TOOLS YOU WILL NEED
Pencil
Phillips Head
Screwdriver
1/4" Nut Driver
Saber Saw
1/8" Drill Bit & Electric or
Hand Drill
Ruler or Straightedge
Safety Glasses
31-i0668-i (06-12 GE) 1

Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
w
FOR YOUR SAFETY
. For Personal Safety, remove house fuse or open
circuit breaker before beginning installation.
Failure to do so could result in serious injury or
death.
. Be sure your cooktop is installed properly by a
qualified installer or service technician.
. To eliminate the risk of burns or fire due to
reaching over heated surface elements, cabinet
storage located above the surface units should
be avoided. If cabinet storage space is to be
provided, the risk can be reduced by installing a
range hood that projects horizontally a minimum
of 5" beyond the bottom of the cabinets. Cabinet
installation above the cooktop may be no deeper
than 13".
. Make sure the cabinets and wall coverings
around the cooktop can withstand the
temperatures (up to 200°F) generated by the
cooktop.
. The cooktop should be easy to reach and lighted
with natural light during the day.
. Always disconnect the electrical service to
the cooktop before repairing or servicing the
cooktop. This can be done by disconnecting the
fuse or circuit breaker. Failure to do this could
result in a dangerous or fatal shock. Know where
your main disconnect switch is located. If you do
not know, have your electrician show you.
ELECTRICAL REQUIREMENTS
This appliance must be supplied with the proper
voltage and frequency, and connected to an
individual, properly grounded branch circuit,
protected by a circuit breaker or a time delay fuse
as noted on name plate.
We recommend you have the electrical wiring and
hookup of your cooktop connected by a qualified
electrician. After installation, have the electrician
show you where your main cooktop disconnect is
located.
Wiring must conform to National Electrical Code
and all local electrical codes. You can get a copy
of the National Electrical Code, ANSI/NFPA No.
70-Latest Edition, by writing:
National Fire Protection Association
Batterymarch Park
Quincy, MA 02269
In Canada, wiring must conform to Canadian
Electrical Code (CEC).
The cooktop conduit wiring is approved for copper
wire connection only, and if you have aluminum
house wiring, you must use special UL approved
connectors for joining copper to aluminum. In
Canada, you must use special CSA approved
connectors for joining copper to aluminum.
You must use a two-wire, three conductor 208/240
VAC, 60 Hertz electrical system. A white (neutral)
wire is not needed for this unit.
Refer to the name plate on your cooktop for the
KW rating for your cooktop.
These cooktops require SOamp service.
TName plate location

Installation Instructions
PRE-INSTALLATION CHECKLIST
BEFORE YOU BEGIN
A WARN ING - Theelectricalpowerto
the cooktop supply line must be shut off while
connections are being made. Failure to do so
could result in serious injury or death.
DWhen preparing cooktop opening, make sure
the inside of the cabinet and the cooktop do
not interfere with each other. (See section on
preparing the opening.)
Remove packaging materials and literature
package from the cooktop before beginning
installation.
E] Remove Installation Instructions from the
literature pack and read them carefully before
you begin.
Be sure to place all literature, Owner's Manual,
Installations, etc. in a safe place for future
reference.
Hake sure you have all the tools and materials
you need before starting the installation of the
cooktop.
Your home must provide the adequate
electrical service needed to safely and
properly use your cooktop. (Refer to section on
electrical requirements.)
When installing your cooktop in your home,
make sure all local codes and ordinances are
followed exactly as stated.
Hake sure the wall coverings, countertop and
cabinets around the cooktop can withstand
heat (up to 200°F) generated by the cooktop.
ADVANCE PLANNING
Combination Installations
These cooktops may be installed in combination
with an approved downdraft vent or a single oven.
Cooktop and a Downdraft Vent
The countertop must have a deep flat surface
to accommodate the combined installation of
the cooktop and vent.
Consideration must be given to the separate
electrical supply locations.
Allow 12" clearance between the inlet air ports
on the cooktop bottom toward the rear to any
obstruction.
- Both the cooktop and the vent must be installed
according to each specific product installation
instruction.
Cooktop with a Single Oven
- Consideration must be given to the separate
electrical requirements and locations.
- Both the cooktop and the oven must be installed
according to each specific product installation
instruction.
Installation Above Cabinet Drawers
Allow 12" clearance to combustibles below the
cooktop. A drawer directly below the cooktop
cannot be used to store items such as towels or
paper products. Use a false drawer front to obtain
clearance if necessary.

PREPARING THE
Installation
OPENING
Instructions
| The following MINIMUM clearance dimensions
must be maintained.
13" IVlAXDepth _._ _J__l _
of uprotected 2" IVllN.Clearance
overhead from cutout to
cabinets side wall on the
right of the unit
Clearance from lS" IV]IN,Height
countertop to countertop to
unprotected nearest cabinet on
overhead either side of unit
surface
2" MIN. Clearance from
cutout to side wall on the
left of the unit
If a 30" clearance between the cooking surface and
overhead combustible materials or metal cabinets
cannot be maintained, a minimum clearance of 24"
is required and the underside of the cabinets above
the cooktop must be protected with not less than
1/4" insulating millboard covered with sheet metal
not less than 0.0122" thick.
r_ OVERALL COOKTOP DIMENSIONS
18-7/8" ,_,.,_ _ 336/8"
4-5/8" at front
baffle
3-1/4" at rear air
intake
r_ VERTICAL CLEARANCES
Allow 12" minimum vertical -_
clearance from the cooktop 14-1/_,
!
bottom (or 14-1/4" minimum
depth from the countertop) to
any combustible surfaces, such
as a cabinet drawer.
IMPORTANT: To ensure long life
of the electronic components,
allow a minimum of 12" free
space for air circulation below
the cooktop bottom. (Except
installation over a single oven.)
The cooktop bottom has air
intake ports and exhaust ports
that help cool the components.
Do not install a shelf or partition
beneath the cooktop that is
more than 18" deep.
DRAWER 1
12"
18" Hax.
Deep Shelf
CUTOUT DIMENSIONS OF THE
COUNTERTOP
To insure accuracy, it is best to make a template
when cutting the opening in the counter.
!
1-3/4" IVlin.Between
cutout and the wall
behind the cooktop
2-1/2" Min. from
front edge of cutout
and front edge of
eountertop
19-1/8" depth of cutout
Use a 36" or wider cabinet base.
r_ Make sure the wall coverings, countertop and
cabinets around the cooktop can withstand
heat (up to 200°F) generated by the cooktop.
Wall coverings,
cabinets and
countertop must
withstand heat
up to 200°F. J
r6] FOR AMERICANS WITH DISABILITIES
ACT (ADA} FORWARD APPROACH
INSTALLATION ON LY:
Allow 5" minimum
depth between the
countertop and an
enclosure.
__
NOTE:The enclosure must be made of wood
material. Also, an access panel is required for the
junction box, hold-down brackets, and service.

Installation Instructions
INSTALLING OPTIONS
COOKTOP INSTALLATION WITH
A GE OR GE MONOGRAM 30"
DOWNDRAFT VENT
The installation of the downdraft vent with this
cooktop requires careful consideration. Both the
cooktop and the vent must be installed according
to each specific installation instruction.
COOKTOP REQUIREMENTS
The countertop must have a deep flat surface to
accommodate the cooktop and vent. Countertops
with a rolled front edge and backsplash will not
provide the flat surface area required.
, Review the illustration to determine the countertop
surface requirements.
- All cutout clearances for this installation must
be observed.
1-3/4"Min. Cool<topCutoutto Rear
VerticalCombustibleSurface
f 2-3/4"
21-3/4"
Cutout
Depth 19-1/8"
Cooktop
Cutout
Depth
FrontEdge
of Countertop
36-1/8"(SS)
36"(B,W)
34"
Cool<topandVentCutout
"1/4"Overlap
.._1/8" Gap
23"(SS)
1-1/32"at Center
2-1/2"Min.
Clearanceto Cutout
22-7/8"(B,W)
Total Flat
Surface
Required
2" Min. Cutout
to SideWalls
BASE CABINET REQUIREMENTS
The combined installation will fit in astandard
24" deep bose cabinet. Use a36" or wider bose
cabinet.
- The vent housing, blower and ductwork will
occupy the bose cabinet.
2-1/2" to
Cutout 1-7/8"
/
22-3/4" Inside
.....22"to Support Rail.......................
I
3/4"
Thick
Support
Rail

Installation Instructions
INSTALLING OPTIONS
COOKTOP INSTALLATION OVER A
GE OR GE MONOGRAM SINGLE OVEN
These cooktops may be installed over a single oven.
Both the cooktop and the oven must be installed
according to each specific installation instruction.
- Allow 4" Hin. clearance from the top of the
countertop to the top of the oven cutout.
POWER SUPPLY
The oven requires a separate, properly grounded
20 Amp, ]-wire 208 or 240 volt, 60 Hz power supply.
The cooktop requires a separate 50 Amp, ]-wire,
208 or 240 volt, 60 Hz power supply.
23-1/2"min.
Cooktop
33-7/8"
28-l/2"min.
28-5/8"max.
3/4"support
platform
required
1-1/2"cabinettop
36" countertop
4"min. height
27-1/4"min.
27-5/16"max.
Mustmatch
toekickheight
Use a 36" or wider base cabinet.
, For best appearance, the cooktop should be
centered over the oven.
. The baffle on the underside of the cooktop is not
necessary for this combination installation. If the
baffle is attached, remove it.
, This cooktop is only approved to be installed over
the specific models listed on the label of this unit.

Installation Instructions
ELECTRICAL CONNECTIONS
NEW CONSTRUCTION AND BRANCH
CIRCUIT CONNECTION
A WARNING: Improper connection
of aluminum house wiring to copper leads
can result in an electrical hazard or fire. Use
only connectors designed for joining copper
to aluminum and follow the manufacturer's
recommended procedure closely.
When making the wire
connections, use the
entire length of conduit
provided. The conduit
must not be shortened
(unless required by local
codes). The conduit length
is 4 ft. With the cooktop
in place, open the front of
the cabinet door. Insert
the wires from the conduit
through the opening of
the junction box. The
116"
Install junction box
so that it can be
reached through
the front of the
cabinet.
1
conduit strain relief clamp must be securely
attached to the junction box and the flexible
conduit must be securely attached to the clamp.
• When installing in new construction, or
• When installing in a mobile home, or
• When installing in a recreational vehicle, or
• When local codes do not permit grounding
through neutral:
a. Insert conduit through strain relief and tighten.
b. Attach the appliance grounding lead (green
or bare copper)in accordance with local
codes. If the residence grounding conductor is
aluminum, see WARNING.
Strain Relief ___,,
Junction Box Cover
Ground Wire
THREE-CONDUCTOR BRANCH CIRCUIT
CONNECTION
When connecting to a three-conductor branch
circuit, if local codes permit:
a. Connect the cooktop green ground conductor
lead to the branch circuit ground (green) using
a wire nut.
b,
C°
[_ G_round and
Neutral Wires
Junction Box Cover
Connect the cooktop red lead to the branch
circuit red lead in accordance with local
codes, using a wire nut.
Connect the cooktop black lead to the
branch circuit black lead in accordance with
local codes, using a wire nut. If the residence
red, black or white leads are aluminum
conductors, see WARNING.
d. Install Junction Box Cover.

Installation Instructions
INSTALLING THE COOKTOP
r_ PROTECT SURFACE OF COOKTOP
Place a towel or tablecloth onto the countertop.
Lay the cooktop upside down onto the protected
surface.
Bottom of Cooktop
Cloth under Cooktop
ATTACH FOAM TAPE
Apply the foam tape around the outer edge of the
glass. Do not overlap the foam tape.
Bottom of Cooktop
" - -1 Foam Tape -- ................."
'" -...... i--"""'" @
._--_i_....
Cooktop -"- ........
NOTE: On stainless steel models, apply foam tape
on the sides and rear.
[_] INSTALL BAFFLE
Secure the baffle to the cooktop with screws.
NOTE: Do not install the baffle when the cooktop
is installed over a single oven.
? ?
[_ INSTALL HOLD-DOWN BRACKETS
Start one screw through the bracket and into
the cooktop. (Both sides.) Do not tighten. Turn
the bracket inwards to avoid interference when
dropping the cooktop into the countertop.

Installation Instructions
INSERT COOKTOP INTO CUTOUT
Insert the cooktop centered into the cutout opening.
Make sure the front edge of the countertop is
parallel to the cooktop. Hake final check that all
required clearances are met.
[]_] ATTACH HOLD-DOWN BRACKETS
TO CABINET
Open the cabinet door. Install the second screw
through the bracket and tighten. Then tighten the
first screw. Install thumbscrew until it touches the
bottom of the countertop.
oooIL
L I
i
Countertop
IMPORTANT: Turn the thumbscrew until it touches
the bottom of the countertop. Do not overtighten.

Installation Instructions
CHECKLISTS
[]
D
[]
[]
PRE-TEST CHECKLIST
Remove all protective film, if present, and any
stickers.
Check to be sure that all wiring is secure and
not pinched or in contact with moving parts.
Check level of appliance.
Check that the cooktop is properly grounded.
[_ OPERATION CHECKLIST
D
D
D
Remove all items from the top of the cooktop
surface.
Turn on the power to the cooktop.
(Refer to your Owner's Manual.) Verify that all
surface burners operate properly.
Check that the circuit breaker is not tripped
nor the house fuse blown.
Check that conduit is securely connected to
the junction box.
See Owner's Manual for troubleshooting list.
NOTE TO ELECTRICIAN:
The power leads supplied with this appliance are
UL recognized for connections to larger gauge
household wiring. The insulation of these leads
is rated at temperatures much higher than the
temperature rating of household wiring. The current
carrying capacity of a conductor is governed by the
wire gauge and also the temperature rating of the
insulation around
the wire.
NOTE: ALUMINUM WIRING
, WARNING:
IMPROPER CONNECTION OF ALUMINUM
HOUSE WIRING TO THE COPPER LEADS CAN
RESULT IN A SERIOUS PROBLEM.
, Splice copper wires to aluminum wiring using
special connectors designed and UL approved
for joining copper to aluminum and follow
the manufacturer's recommended connector
procedure closely.
NOTE: Wire used, location and enclosure of splices,
etc., must conform to good wiring practice and
local codes.
10
