GE JP910 User manual

JP910
JP930
JP940
JP960
JP970
Owner’s Manual
Cooktop
Radiant
49-80277 12-04 JR
Safety Instructions . . . . . . . 2–4
Operating Instructions
Bridge Surface Element . . . . . .8
Control Lock-Out . . . . . . . . . . . 8
Cookware Tips . . . . . . . . . . .9, 10
Dual Surface Element . . . . . . . 8
Features of Your Cooktop . . . 5, 6
Surface Elements . . . . . . . . . 7, 8
Tri-Ring Surface Element . . . . .8
Care and Cleaning
Control Knobs . . . . . . . . . . . . 11
Glass Cooktop . . . . . . . . . . 12, 13
Troubleshooting Tips . . . . . . 14
Consumer Support
Consumer Support . . Back Cover
Product Registration . . . . . 17, 18
Warranty . . . . . . . . . . . . . . . . . 19
www.GEAppliances.com
Write the model and serial
numbers here:
Model # ________________
Serial # ________________
You can find them on a label
under the cooktop.

Safety Instructions
Operating Instructions
Care and CleaningTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
When using electrical appliances, basic safety precautions should be followed, including
the following:
■Use this appliance only for its intended use
as described in this manual.
■Do not attempt to repair or replace any
part of your cooktop unless it is specifically
recommended in this manual. All other
servicing should be referred to a qualified
technician.
■Before performing any service, disconnect
the cooktop power supply at the household
distribution panel by removing the fuse or
switching off the circuit breaker.
■Be sure your appliance is properly installed
and grounded by a qualified technician in
accordance with the provided installation
instructions.
■Have the installer show you the location of
the circuit breaker or fuse. Mark it for easy
reference.
■Do not leave children alone—children
should not be left alone or unattended
in an area where an appliance is in use.
They should never be allowed to sit or
stand on any part of the appliance.
■Teach children not to play with the
controls or any other part of the cooktop.
■Do not allow anyone to climb, stand or
hang on the cooktop.
■CAUTION: Items of interest to
children should not be stored in cabinets
above a cooktop—children climbing on
the cooktop to reach items could be
seriously injured.
■Always keep combustible wall coverings,
curtains or drapes a safe distance from
your cooktop.
■Always keep dishtowels, dish cloths, pot
holders and other linens a safe distance
away from your cooktop.
■Always keep wooden and plastic utensils
and canned food a safe distance away from
your cooktop. They may become hot and
could cause burns.
■Never wear loose-fitting or hanging
garments while using the appliance.
Flammable material could be ignited
if brought in contact with hot surface
elements and may cause severe burns.
■Use only dry pot holders—moist or damp
pot holders on hot surfaces may result in
burns from steam. Do not let pot holders
touch hot surface elements. Do not use a
towel or other bulky cloth. Such cloths can
catch fire on a hot surface element.
■For your safety, never use your appliance
for warming or heating the room.
■Do not use water on grease fires. Never
pick up a flaming pan. Turn the controls
off. Smother a flaming pan on a surface
element by covering the pan completely
with a well-fitting lid, cookie sheet or flat
tray. Use a multi-purpose dry chemical or
foam-type extinguisher.
■Flaming grease outside a pan can be
put out by covering with baking soda or,
if available, by using a multi-purpose dry
chemical or foam-type fire extinguisher.
■When preparing flaming foods under the
hood, turn the fan on.
■Do not let cooking grease or other
flammable materials accumulate on
the cooktop.
SAFETY PRECAUTIONS
2

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
COOK MEAT AND POULTRY THOROUGHLY…
Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F and poultry
to at least an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against
foodborne illness. 3
www.GEAppliances.com
■Do not touch surface elements. These
surfaces may be hot enough to burn even
though they are dark in color. During and
after use, do not touch, or let clothing or
other flammable materials contact the
surface elements or areas nearby the
surface elements; allow sufficient time
for cooling first.
■Potentially hot surfaces include the
cooktop and areas facing the cooktop.
■To minimize the possibility of burns,
ignition of flammable materials and
spillage, the handle of a container
should be turned toward the center
of the cooktop without extending over
any nearby surface elements.
■Always turn the surface element control to
off before removing the cookware.
■Use proper pan size—select cookware
having flat bottoms large enough to cover
the surface heating element. The use of
undersized cookware will expose a portion
of the surface element to direct contact
and may result in ignition of clothing.
Proper relationship of cookware to surface
element will also improve efficiency.
■Never leave surface elements unattended at
high heat settings. Boilovers cause smoking
and greasy spillovers that may catch on fire.
■Only certain types of glass, glass/ceramic,
earthenware or other glazed containers are
suitable for cooktop cooking; others may
break because of the sudden change in
temperature.
■Keep an eye on foods being fried at high
or medium-high heat settings.
■Foods for frying should be as dry as
possible. Frost on frozen foods or moisture
on fresh foods can cause hot fat to bubble
up and over the sides of the pan.
■Use little fat for effective shallow or
deep-fat frying. Filling the pan too full
of fat can cause spillovers when food is
added.
■If a combination of oils or fats will be used
in frying, stir together before heating, or as
fats melt slowly.
■Always heat fat slowly, and watch as it heats.
■Use a deep fat thermometer whenever
possible to prevent overheating fat beyond
the smoking point.
■Never try to move a pan of hot fat,
especially a deep fat fryer. Wait until
the fat is cool.
■Do not store flammable materials near
the cooktop.
■Keep the hood and grease filters clean
to maintain good venting and to avoid
grease fires.
■Do not store or use combustible materials,
gasoline or other flammable vapors and
liquids in the vicinity of this or any
appliance.
■Clean only parts listed in this Owner’s
Manual.
■Do not leave paper products, cooking
utensils or food on the cooktop when
not in use.
■Keep cooktop clean and free of
accumulation of grease or spillovers
which may ignite.
■Never heat unopened food containers.
Pressure buildup may make container
burst and cause injury.
■Never leave jars or cans of fat drippings
on or near your cooktop.
■Never use your appliance for warming or
heating the room.
SAFETY PRECAUTIONS

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Use care when touching the cooktop. The glass surface of the cooktop will retain heat after the
controls have been turned off.
RADIANT SURFACE ELEMENTS
■Avoid scratching the glass cooktop.
The cooktop can be scratched with items
such as sharp instruments, rings or other
jewelry and rivets on clothing.
■Never use the glass cooktop surface as
a cutting board.
■Do not place or store items on top of the
glass cooktop surface when it is not in use.
■Be careful when placing spoons or other
stirring utensils on glass cooktop surface
when it is in use. They may become hot
and could cause burns.
■Avoid heating an empty pan. Doing so may
damage the cooktop and the pan.
■Do not allow water, other liquids or grease
to remain on the cooktop.
■To minimize the possibility of burns, always
be certain that the controls for all surface
elements are at the off position and the
entire glass surface is cool before
attempting to clean the cooktop.
■Do not operate the glass surface elements
if the glass is broken. Spillovers or cleaning
solution may penetrate a broken cooktop
and create a risk of electrical shock.
Contact a qualified technician immediately
should your glass cooktop become broken.
■Clean the cooktop with caution. If a wet
sponge or cloth is used to wipe spills on
a hot surface element, be careful to avoid
steam burns. Some cleansers can produce
noxious fumes if applied to a hot surface.
■NOTE: We recommend that you avoid
wiping any surface element areas until they
have cooled and the indicator light has
gone off. Sugar spills are the exception
to this. Please see the Cleaning the Glass
Cooktop section.
■When the cooktop is cool, use only
CERAMA BRYTE®Ceramic Cooktop
Cleaner and the CERAMA BRYTE®
Cleaning Pad to clean the cooktop.
■To avoid possible damage to the cooking
surface, do not apply the cleaning cream
to the glass surface when it is hot.
■After cleaning, use a dry cloth or paper
towel to remove all the cleaning cream
residue.
■Read and follow all instructions and
warnings on the cleaning cream labels.
■Use care when touching the cooktop. The
glass surface of the cooktop will retain heat
after the controls have been turned OFF.
■Do not stand on the glass cooktop.
■Large scratches or impacts to glass
cooktops can lead to broken or
shattered glass.
4
Safety Instructions
Operating Instructions
Care and CleaningTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!

5
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Throughout this manual, features and appearance may vary from your model.
Features of your cooktop. www.GEAppliances.com
Feature Index (Features and appearances may vary.) Explained on page
Radiant Surface Elements 7
Dual Surface Element 8
Tri-Ring Surface Element 8
Left Rear Surface Element Control Knob 7
Left Front Surface Element Control Knob 7
Control Lock Indicator Light 8
Surface Element ON Indicator Light 7
Center or Tri-Ring Surface Element Control Knob 8
Tri-Ring Cooking Area Selector Knob 8
Dual Element Control Knob 8
Dual Element Selector Knob 8
Right Rear Surface Element Control Knob 7
Control Lock Knob 8
Left Front and Bridge Element 8
Bridge Element Selector Knob 8
JP960
JP970

6
Safety Instructions
Operating Instructions
Care and CleaningTroubleshooting TipsConsumer Support
Throughout this manual, features and appearance may vary from your model.
Features of your cooktop.
Feature Index (Features and appearances may vary.) Explained on page
Radiant Surface Elements 7
Dual Surface Element 8
Left Rear Surface Element Control Knob 7
Left Front Surface Element Control Knob 7
Control Lock Indicator Light 8
Surface Element ON Indicator Light 7
Dual Element Control Knob 8
Dual Element Selector Knob 8
Right Rear Surface Element Control Knob 7
Control Lock Knob 8
Left Front and Bridge Element 8
Bridge Element Selector Knob 8
JP930
JP910
JP940

7
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Throughout this manual, features and appearance may vary from your model.
Never cook directly on the glass.
Always use cookware.
About the radiant surface elements…
The radiant cooktop features heating
elements beneath a smooth glass surface.
NOTE: A slight odor is normal when a new
cooktop is used for the first time. It is caused by
the heating of new parts and insulating materials
and will disappear in a short time.
NOTE: On models with light colored glass
cooktops, it is normal for the cooking zones to
change color when hot or cooling down. This is
temporary and will disappear as glass cools to
room temperature.
The surface element will cycle on and off
to maintain your selected control setting.
It is safe to place hot cookware (from the
oven or surface) on the glass cooktop
when the surface is cool.
Even after the surface elements are
turned off, the glass cooktop retains
enough heat to continue cooking. To
avoid overcooking, remove pans from
the surface elements when the food
is cooked. Avoid placing utensils that
could become hot or plastics that could
melt on the surface element until it has
cooled completely.
■Water stains (mineral deposits) are removable
using the cleaning cream or full strength white
vinegar.
■Use of window cleaner may leave an
iridescent film on the cooktop. The cleaning
cream will remove this discoloration.
■Don’t store heavy items above the cooktop.
If they drop onto the cooktop, they can cause
damage.
■Do not use the surface as a cutting board.
;;;;
;;;;;;;;
;;;;;;;;;;;
;;;;;;;;;;
;;;;;;;
;;;
SURFACE
COOKING
;;;;
;;;;;;;;
;;;;;;;;;
;;;;;;;;;;
;;;;;;;;;
;;;;;;;
;;;
OFF CENTER
Always center the pan on the surface
element you are using.
;;
;;;;;
;;;;;;;;;
;;;;;;;;;;;
;;;;;;;;;;
;;;;;;;
;;;;
DRAGGING
Do not slide cookware across the
cooktop because it can scratch the
glass. The glass is scratch-resistant,
not scratchproof.
How to Set
Push the knob down and turn in either
direction to the setting you want. When
the control is in any position other than
OFF, it may be rotated without pushing
it down.
At both OFF and HI the control
clicks into position. You may hear
slight clicking sounds during cooking,
indicating the control is keeping the
power level you set.
The controls for the radiant surface
elements can be set anywhere between
LO and HI for an unlimited number of
heat settings. With the infinite switch the
element cycles on and off to maintain
your selected control setting.
The ELEMENT ON indicator light will
glow when any surface element is on.
A HOT SURFACE indicator light will glow
when any radiant element is turned on
and will remain on until the surface is
cooled to approximately 150°F.
NOTE:
■It comes on when the element is hot to the
touch.
■It stays on even after the element is turned off.
■It glows brightly until the element is cooled to
approximately 150°F.
■Be sure you turn the control knob to OFF when
you finish cooking.
Using the surface elements. www.GEAppliances.com

Bridge Surface Element (on some models)
You can create an oblong heated area by using
the left rear element in addition to the front
element bridge combination.
Make sure the pan rests flat on the glass
cooktop.
When the SELECTOR knob points to ,
the control knob controls both the left
front surface element and the bridge
area.
Choose pans that match the
circle/bridge area as closely as possible.
When the SELECTOR knob points to ,
the control knob controls the left front
surface element only.
Dual Surface Element (on some models)
The right front surface element has 2 cooking
sizes to select from so you can match the size of
the element to the size of the cookware you are
using.
To use the large surface element, turn
the SELECTOR knob to . Push in and
turn the control knob to the desired
setting. The element will heat the entire
area contained by the larger circle.
To use the small surface element, turn
the SELECTOR knob to . Push in and
turn the control knob to the desired
setting. The element will only heat
the area inside the smaller circle.
Small
surface
element
setting
Large
surface
element
setting
Surface Elements Cycle On and Off
Surface elements will cycle on and off
to maintain the temperature you have
selected.
All radiant surface elements have a
temperature limiter that protects the
glass cooktop from getting too hot.
The temperature limiter may cycle the
elements off while cooking if:
■The pan boils dry.
■The pan bottom is not flat.
■The pan is off-center.
■There is no pan on the element.
8
Safety Instructions
Operating Instructions
Care and CleaningTroubleshooting TipsConsumer Support
Using the surface elements.
Tri-Ring Surface Element (on some models)
The rear center surface element offers 3 cooking
areas to match the size of the cookware you
are using.
To use the largest cooking area, push in
and turn the SELECTOR knob to .
Push and turn the control knob
to the desired setting.
To use the medium cooking area, press
and turn the SELECTOR knob to .
Push down and turn the control knob to
the desired setting.
To use the smallest cooking area, turn
the
SELECTOR knob to . Push and turn
the control knob to the desired setting.
This will activate only the smallest inside
heating area.
Control Lock-Out
To lock the cooktop and prevent
unwanted use, turn the control lock
knob to LOCK. An indicator light will
glow to show that the cooktop is locked.
To unlock, press and turn the knob to
UNLOCK.
In the locked position, the cooktop will
produce an audible sound if any control
knob is set to a position other than OFF.

9
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Selecting types of cookware. www.GEAppliances.com
The following information will help you choose cookware which will give good performance on glass cooktops.
Stainless Steel:
recommended
Aluminum:
heavyweight pans recommended
Good conductivity. Aluminum residue
sometimes appears as scratches on the
cooktop but can be removed if cleaned
immediately. Because of its low melting
point, thin weight aluminum should not
be used.
Copper:
recommended
Copper Bottoms:
usable, but not recommended
Pans with copper bottoms may leave
residue appearing as scratches. Remove
any residue immediately after use. Do not
let a pot boil dry. Overheated metal can
bond to the glass cooktop and leave a
permanent stain if it is not removed
immediately.
Porcelain Enamel-Covered Cast Iron:
recommended
As long as the cookware is covered
completely with porcelain enamel, this
cookware is recommended. Caution is
recommended for cast-iron cookware
that is not completely covered with
smooth porcelain enamel, since it may
scratch the glass ceramic cooktop.
Glass-Ceramic:
usable, but not recommended
Poor performance. May scratch the
surface.
Stoneware:
usable, but not recommended
Poor performance. May scratch the
surface.
Use pans that match the diameter of the
surface element. Cooking performance
will not be as good if the cookware is
either smaller or larger than the
surface element.
Check pans for flat bottoms by
using a straight edge.
Pans with rounded, curved, ridged
or warped bottoms are not
recommended.
For Best Results
■Place only dry pans on the surface
elements. Do not place lids on the
surface elements, particularly wet lids.
■Do not use woks that have support
rings. This type of wok will not heat on
glass surface elements.
■We recommend that you use only a
flat-bottomed wok. They are available
at your local retail store. The bottom
of the wok should have the same
diameter as the surface element
to ensure proper contact.
■Some special cooking procedures
require specific cookware such as
pressure cookers, deep fat fryers, etc.
All cookware must have flat bottoms
and be the correct size.
Do not place wet pans
on the glass cooktop.
Do not use woks with support
rings on the glass cooktop.
Use flat-bottomed woks
on the glass cooktop.

10
Safety Instructions
Operating Instructions
Care and CleaningTroubleshooting TipsConsumer Support
Note: Flat-bottomed canners are
required for glass cooktops.
Pots that extend beyond 1″ of the
surface element’s circle are not
recommended for most surface
cooking. However, when canning with
water-bath or pressure canner, larger-
diameter pots may be used. This is
because boiling water temperatures
(even under pressure) are not harmful
to the cooktop surfaces surrounding the
surface elements.
HOWEVER, DO NOT USE LARGE-
DIAMETER CANNERS OR OTHER
LARGE-DIAMETER POTS FOR
FRYING OR BOILING FOODS OTHER
THAN WATER. Most syrup or sauce
mixtures—and all types of frying—cook
at temperatures much higher than
boiling water. Such temperatures
could eventually harm the glass
cooktop surfaces.
Be sure the canner fits over the
center of the surface element.
If your cooktop or its location
does not allow the canner to be
centered on the surface element,
use smaller diameter pots for good
canning results.
Flat-bottomed canners must be
used. Do not use canners with
flanged or rippled bottoms (often
found in enamelware) because
they don’t make enough contact
with the surface elements and take
a long time to boil water.
When canning, use recipes
and procedures from reputable
sources. Reliable recipes and
procedures are available from
the manufacturer of your canner;
manufacturers of glass jars for
canning, such as Ball and Kerr
brand; and the United States
Department of Agriculture
Extension Service.
Remember that canning is a
process that generates large
amounts of steam. To avoid burns
from steam or heat, be careful
when canning.
NOTE: If your house has low voltage,
canning may take longer than expected,
even though directions have been carefully
followed. The process time will be
shortened by:
(1) using a pressure canner, and
( 2) starting with HOT tap water for fastest
heating of large quantities of water.
CAUTION:
■Safe canning requires that harmful
microorganisms are destroyed and
that the jars are sealed completely.
When canning foods in a water-bath
canner, a gentle but steady boil must be
maintained for the required time. When
canning foods in a pressure canner, the
pressure must be maintained for the
required time.
■After you have adjusted the controls,
it is very important to make sure the
prescribed boil or pressure levels are
maintained for the required time.
■Since you must make sure to process the
canning jars for the prescribed time, with
no interruption in processing time, do not
can on any cooktop surface element if
your canner is not flat.
Observe the Following Points in Canning
Wrong!
Right!
Selecting types of cookware.

11
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Care and cleaning of the cooktop. www.GEAppliances.com
Be sure electrical power is off and all surfaces are cool before cleaning any part of the cooktop.
Control Knobs
The control knobs may be removed for easier
cleaning.
Make sure the knobs are in the OFF
positions and pull them straight off the
stems for cleaning.
The knobs can be cleaned in a
dishwasher or they may also be washed
with soap and water. Make sure the inside
of the knobs are dry before replacing.
Replace the knobs, in the OFF position to
ensure proper placement.
Clear groove
Spring
clip
Molded rib
How to Remove Protective Shipping Film and Packaging Tape
Carefully grasp a corner of the protective
shipping film with your fingers and slowly
peel it from the appliance surface. Do not
use any sharp items to remove the film.
Remove all of the film before using the
appliance for the first time.
To assure no damage is done to the
finish of the product, the safest way to
remove the adhesive from packaging tape
on new appliances is an application of a
household liquid dishwashing detergent.
Apply with a soft cloth and allow to soak.
NOTE: The adhesive must be removed from all
parts. It cannot be removed if it is baked on.
Stem

12
Safety Instructions
Operating Instructions
Care and CleaningTroubleshooting TipsConsumer Support
Cleaning the glass cooktop.
Allow the cooktop to cool.
Use a single-edge razor blade
scraper at approximately a 45°
angle against the glass surface
and scrape the soil. It will be
necessary to apply pressure to
the razor scraper in order to
remove the residue.
After scraping with the razor
scraper, spread a few drops of
CERAMA BRYTE®Ceramic
Cooktop Cleaner on the entire
burned residue area. Use the
CERAMA BRYTE®Cleaning Pad to
remove any remaining residue.
For additional protection,
after all residue has been
removed, polish the entire
surface with CERAMA BRYTE®
Ceramic Cooktop Cleaner
and a paper towel.
Burned-On Residue
WARNING: DAMAGE to your glass surface
may occur if you use scrub pads other than the
pad included with your cooktop.
Allow the cooktop to cool.
Spread a few drops of CERAMA
BRYTE®Ceramic Cooktop Cleaner
on the entire burned residue area.
Using the included CERAMA
BRYTE®Cleaning Pad for Ceramic
Cooktops, rub the residue area,
applying pressure as needed.
If any residue remains, repeat the
steps listed above as needed.
For additional protection, after all
residue has been removed, polish
the entire surface with CERAMA
BRYTE®Ceramic Cooktop Cleaner
and a paper towel.
The CERAMA BRYTE®Ceramic
Cooktop Scraper and all
recommended supplies are
available through our Parts Center.
See instructions under “To Order
Parts” section on next page.
NOTE: Do not use a dull or
nicked blade.
Heavy, Burned-On Residue
Use a CERAMA BRYTE®Cleaning
Pad for Ceramic Cooktops.
Normal Daily Use Cleaning
ONLY use CERAMA BRYTE®Ceramic
Cooktop Cleaner on the glass cooktop.
Other creams may not be as effective.
To maintain and protect the surface of
your glass cooktop, follow these steps:
Before using the cooktop for the
first time, clean it with CERAMA
BRYTE®Ceramic Cooktop Cleaner.
This helps protect the top and
makes cleanup easier.
Daily use of CERAMA BRYTE®
Ceramic Cooktop Cleaner will help
keep the cooktop looking new.
Shake the cleaning cream well.
Apply a few drops of CERAMA
BRYTE®Ceramic Cooktop Cleaner
directly to the cooktop.
Use a paper towel or CERAMA
BRYTE®Cleaning Pad for Ceramic
Cooktops to clean the entire
cooktop surface.
Use a dry cloth or paper towel
to remove all cleaning residue.
No need to rinse.
NOTE: It is very important that you DO NOT
heat the cooktop until it has been cleaned
thoroughly.
Clean your cooktop after
each spill. Use CERAMA
BRYTE®Ceramic Cooktop
Cleaner.

To order CERAMA BRYTE®Ceramic
Cooktop Cleaner and the cooktop
scraper, please call our toll-free number:
National Parts Center 800.626.2002.
CERAMA BRYTE®Ceramic
Cooktop Cleaner . . . . . . . . . . .# WX10X300
CERAMA BRYTE®Ceramic
Cooktop Scraper . . . . . . . . . . .# WX10X0302
Kit . . . . . . . . . . . . . . . . . . . . . . . .# WB64X5027
(Kit includes cream and cooktop scraper)
CERAMA BRYTE®Cleaning Pads for
Ceramic Cooktops . . . . . . . . .# WX10X350
13
Safety Instructions Operating Instructions Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
www.GEAppliances.com
Turn off all surface elements.
Remove hot pans.
Wearing an oven mitt:
a. Use a single-edge razor blade
scraper (CERAMA BRYTE®
Ceramic Cooktop Scraper) to
move the spill to a cool area on
the cooktop.
b. Remove the spill with
paper towels.
Any remaining spillover should be
left until the surface of the cooktop
has cooled.
Don’t use the surface elements
again until all of the residue has
been completely removed.
NOTE: If pitting or indentation in the glass
surface has already occurred, the cooktop glass
will have to be replaced. In this case, service will
be necessary.
Damage from Sugary Spills and Melted Plastic
Our testing shows that if
you are cooking high sugar
mixtures such as jelly or
fudge and have a spillover,
it can cause permanent
damage to the glass surface
unless the spillover is
immediately removed.
Be careful not to slide pots and pans
across your cooktop. It will leave
metal markings on the cooktop
surface.
These marks are removable using
the CERAMA BRYTE®Ceramic
Cooktop Cleaner with the CERAMA
BRYTE®Cleaning Pad for Ceramic
Cooktops.
If pots with a thin overlay of
aluminum or copper are allowed
to boil dry, the overlay may leave
black discoloration on the cooktop.
This should be removed
immediately before heating
again or the discoloration may
be permanent.
WARNING: Carefully check the bottom of pans
for roughness that would scratch the cooktop.
Metal Marks and Scratches
To Order Parts
Glass surface—potential for permanent damage.

14
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Problem Possible Causes What To Do
Surface elements will not Improper cookware •Use pans which are flat and match the diameter
maintain a rolling boil being used. of the surface element selected.
or cooking is slow
Surface elements do A fuse in your home may be •Replace the fuse or reset the circuit breaker.
not work blown or the circuit breaker
tripped.
Cooktop controls •Check to see the correct control is set for the surface
improperly set. element you are using.
•Check to be sure that the Control Lock Selector is
turned to UNLOCK.
Cooktop making an Cooktop is locked. •Check to be sure the Control Lock Selector is turned
audible sound to UNLOCK.
Tiny scratches or metal Incorrect cleaning •Use recommended cleaning procedures.
marks or abrasions on methods being used.
Cookware with rough •Be sure cookware bottoms and cookware are clean
radiant cooktop glass
bottoms being used or before use. Use cookware with smooth bottoms.
surface
coarse particles (salt Tiny scratches are not removable but will become
or sand) were between less visible in time as a result of cleaning.
the cookware and the
surface of the cooktop.
Cookware has been
slid across the cooktop
surface.
Areas of discoloration Improper cookware •Marks from aluminum and copper pans as well as
or dark streaks on the being used. mineral deposits from water or food can be removed
cooktop with the cleaning cream.
Hot surface on a model •This is normal. The surface may appear discolored
with a light colored cooktop. when it is hot. This is temporary and will disappear
as the glass cools.
Food spillovers not cleaned •See the Cleaning the glass cooktop section.
before next use.
Incorrect cleaning methods •Use recommended cleaning procedures.
being used.
Plastic melted to Hot cooktop came into •See the Glass surface—potential for permanent damage
the surface contact with plastic placed section in the Cleaning the glass cooktop section.
on the hot cooktop.
Pitting (or indentation) Hot sugar mixture spilled •Call a qualified technician for replacement.
of the cooktop on the cooktop.
Frequent cycling off and Improper cookware •Use only flat cookware to minimize cycling.
on of surface elements being used. See the Surface elements cycle on and off section.
Control knob will Cooktop controls •When the knob is in the OFF position, it must be
not turn improperly set. pushed in before it can be turned. When the knob
is in any other position, it can be turned without
being pushed in.

15
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
Notes.

16
Notes.
Safety Instructions
Operating Instructions
Care and CleaningTroubleshooting TipsConsumer Support

General Electric Company
Warranty Registration Department
P.O. Box 32150
Louisville, KY 40232-2150
GE Service Protection Plus™
GE, a name recognized worldwide for quality and dependability, offers you
Service Protection Plus™—comprehensive protection on all your appliances—
No Matter What Brand!
Benefits Include:
•Backed by GE
•All brands covered
•Unlimited service calls
•All parts and labor costs included
•No out-of-pocket expenses
•No hidden deductibles
•One 800 number to call
You will be completely satisfied with our service protection or you may request your money back
on the remaining value of your contract. No questions asked. It’s that simple.
Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!
Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker
coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable
household products are protected against expensive repairs.
Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224
for more information.
*All brands covered, up to 20 years old, in the continental U.S.
We’ll Cover Any Appliance.
Anywhere. Anytime.*
Please place in envelope and mail to:
✁Cut here
17

18
Consumer Product Ownership Registration
Important
Mail
Today!
GE Appliances
GE Consumer & Industrial
Louisville, Kentucky
www.GEAppliances.com
First
Name
Mr. ■■Ms. ■■Mrs. ■■Miss ■■
Street
Address
City State
Date Placed
In Use
Month Day Year
Zip
Code
Apt. #
Last
Name
Phone
Number __
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your confidence in us.
We are proud to have you as a customer!
Follow these three steps to protect your new appliance investment:
Important: If you did not get a registration card with your
product, detach and return the form below to
ensure that your product is registered, or register
online at www.GEAppliances.com.
123
Model Number Serial Number
✁Cut here
Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of
mind of knowing we
can contact you in
the unlikely event of
a safety modification.
After mailing the
registration below,
store this document
in a safe place. It
contains information
you will need should
you require service.
Our service number is
800.GE.CARES
(800.432.2737).
Read your Owner’s
Manual carefully.
It will help you
operate your new
appliance properly.
Model Number Serial Number
E-mail Address*
* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important
communications from GE Appliances (GEA).
■■ Check here if you do not want to receive communications from GEA’s carefully selected partners.
FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR
WARRANTY RIGHTS.
For information about GEA’s privacy and data usage policy, go to www.GEAppliances.com and click on
“Privacy Policy” or call 800.626.2224.

19
Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support
GE Electric Cooktop Warranty.
For The Period Of: GE Will Replace:
One Year Any part of the cooktop which fails due to a defect in materials or workmanship. During this
From the date of the full one-year warranty, GE will also provide, free of charge, all labor and in-home service to
original purchase replace the defective part.
Five Years A replacement glass cooktop if it should crack due to thermal shock, discolor, or
From the date of the if the pattern wears off.
original purchase A replacement radiant surface element if it should burn out.
During this limited additional four-year warranty, you will be responsible for any labor or
in-home service.
■Service trips to your home to teach you how to use
the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or
used for other than the intended purpose or used
commercially.
■Damage to the glass cooktop caused by use of
cleaners other than the recommended cleaning
creams and pads.
■Damage to the glass cooktop caused by hardened spills
of sugary materials or melted plastic that are not cleaned
according to the directions in the Owner’s Manual.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
■Damage caused after delivery.
What GE Will Not Cover:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
All warranty service provided by our Factory Service Centers, or
an authorized Customer Care®technician. To schedule service,
on-line, 24 hours a day, visit us at www.GEAppliances.com, or
call 800.GE.CARES (800.432.2737).
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.

Printed in the United States
Consumer Support.
GE Appliances Website www.GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™”
your questions, and so much more...
Schedule Service www.GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at
your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal
business hours.
Real Life Design Studio www.GEAppliances.com
GE supports the Universal Design concept—products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen
design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
Extended Warranties www.GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.
GE Consumer Home Services will still be there after your warranty expires.
Parts and Accessories www.GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their
homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally
should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause
unsafe operation.
Contact Us www.GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance www.GEAppliances.com
Register your new appliance on-line—at your convenience! Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the preprinted registration card included in the packing material.
