GE AF-600 FP Metasys User manual

GE Consumer & Industrial
Electrical Distribution
AF-600 FPTM
Metasys
Operating Instructions
The instructions do not purport to cover all details or variations in equipment nor to provide for every possible
contingency to be met in connection with installation, operation or maintenance. Should further information be
desired or should particular problems arise which are not covered suciently for the purchaser’s purposes, the
matter should be referred to the GE company.
AF-600 FP is trademark of the General Electric Company.
GE Consumer & Industrial
41 Woodford Avenue
Plainville, CT 06062
www.geelectrical.com/drives
130R0370 *MG12S102* DET-628a

Contents
1 Overview
3
Software Version 3
Introduction 3
Copyright, Limitation of Liability and Revision Rights 4
About this Manual 4
References 4
2 Instructions
5
Abbreviations and Definitions 5
Network Connection 5
Hardware Set-up 6
Drive Parameters 7
3 Appendix
21
Analog Inputs (AI) 21
Binary Inputs (BI) 22
Analog Outputs (AO) 25
Internal Integers (ADI) 26
Internal Floating Point (ADF) 27
Internal Integers (ADI) 30
AF-600 FP Metasys
1

AF-600 FP Metasys
2
1

1Overview
1.1.1 Software Version
AF-600 FP
Software version: 2.12
This guide can be used with all AF-600 FP frequency converters with
software version 2.12 or later
The actual software version number can be read from
par. ID-43 Software Version.
1.1.2 Introduction
The frequency converter control board is program selectable for use with the Johnson Controls Metasys N2 protocol.Metasys N2is a master/slave control network.
The physical layer is RS485 compatible, half duplex 9600 baud shielded twisted pair.The N2 software protocol is designed to be general in nature to accommodate
the unique properties each device type may have. Every device connection to the N2 network can be thought of as a small data manager. Data points in the
database are classified as analog I/O (floating point), binary I/O or integer data points - floats, integers or bytes. Each data type has its own unique structure
defined in the Metasys N2 system Protocol Specification for Vendors.
The information in this manual is intended to provide you with comprehensive information on how to install and set up the frequency converter for communication
over a Metasys network.
For specific information on operation of the drive, refer to the AF-600 FP Operating Instructions
AF-600 FP Metasys
3
1

1.1.3 Copyright, Limitation of Liability and Revision Rights
This publication contains information proprietary to GE. By accepting and using this manual the user agrees that the information contained herein will be used
solely for operating equipment from GE or equipment from other vendors provided that such equipment is intended for communication with GE equipment over
a serial communication link. This publication is protected under the Copyright laws of Denmark and most other countries.
GE does not warrant that a software program produced according to the guidelines provided in this manual will function properly in every physical, hardware or
software environment.
Although GE has tested and reviewed the documentation within this manual, GE makes no warranty or representation, neither expressed nor implied, with respect
to this documentation, including its quality, performance, or fitness for a particular purpose.
In no event shall GE be liable for direct, indirect, special, incidental, or consequential damages arising out of the use, or the inability to use information contained
in this manual, even if advised of the possibility of such damages. In particular, GE is not responsible for any costs, including but not limited to those incurred as
a result of lost profits or revenue, loss or damage of equipment, loss of computer programs, loss of data, the costs to substitute these, or any claims by third
parties.
GE reserves the right to revise this publication at any time and to make changes to its contents without prior notice or any obligation to notify former or present
users of such revisions or changes.
It has been assumed that all devices will be sitting behind a firewall that does packet filtering and the environment has well-implemented restrictions on the
software that can run inside the firewall. All nodes are assumed to be "trusted" nodes.
1.1.4 About this Manual
This manual is for both instructional and for reference purposes. This manual can also serve as a guideline when you specify and optimize your communication
system.
It is highly recommended that you read this manual in its entirety before initiating any programming. It is assumed that the user has full knowledge of the
capabilities and limitation of the controller node in addition to full knowledge of the frequency converter.
1.1.5 References
In addition to this manual, the following two manuals should be consulted: AF-600 FP Operating Instructions and Johnson Controls METASYS N2 System Protocol
Specification for Vendors, Johnson Controls number 04-3402-22, rev A.
AF-600 FP Metasys
4
1

2 Instructions
2.1.1 Abbreviations and Definitions
Abbreviations and definitions
ACK Acknowledge
ADF Internal Floating Points
ADI Internal Integers
AI Analog Inputs
AO Analog Outputs
BI Binary Inputs
BO Binary Outputs
COS Change Of State
HPFB High Performance Field Network
JCI Johnson Controls Inc. developers of the METASYS N2 protocol
N2 METASYS N2
N2 master A N2 master is either a PC with JCI software or a dedicated JCI controller
NAK Not acknowledged
NPA N2 Point Address (Each N2 Point Type has a address range from 0 to 255)
NPT N2 Point Type
PAR Parameter Number
2.1.2 Network Connection
Connect signal wires to terminal 68 (N+) and terminal 69 (N-) on main control board of the drive. If shielded cabling is used, connect one end of the shield to
terminal 61. This terminal is connected to ground via an internal RC link. It is highly recommended to use twisted-pair cables to reduce the differential mode
interference between the conductors
Torque Specifications: 4.5 in.lb. (0.5 Nm)
Control wire: 18 - 24 AWG, shielded, twisted pair
AF-600 FP Metasys
5
2

2.1.3 Hardware Set-up
RS485 Network Connection:
One or more frequency converters can be connected to a control (or master) using the RS485 standardized interface. Terminal 68 is connected to the P signal (TX
+, RX+), while terminal 69 is connected to the N signal (TX-,RX-). If more than one frequency converter is connected to a master, use parallel connections.
Illustration 2.1: Network termination switch
In order to avoid potential equalizing currents in the screen, earth the cable screen via terminal 61, which is connected to the frame via an RC-link.
Network termination: The RS485 network must be terminated by a resistor network at both ends. For this purpose, set switch S801 on the control card to "ON".
For more information, see the paragraph: Switches S201, S202 and S801.
NB!
Communication protocol must be set to Drive MC par. O-30.
AF-600 FP Metasys
6
2

2.1.4 Error Codes
Error codes
Error Code 00 is issued after power up or after a time out where all overridden points were released, as long as no Identify yourself command
has been issued by the master.
Error Code 01 is issued if the command is not supported or not known by the drive.
Error Code 02 is issued if the received message has a checksum error.
Error Code 03 is issued if the N2 message receive buffer exceeds 256 characters.
Error Code 05 is issued if the received N2 message is too long.
Error Code 10 is issued the data is out of expected range
Error Code 11 is issued when:
1. A point attributes or attribute bit is unused.
2. A point attributes or attribute bit is for JCI use only.
3. An internal data point attribute for current value can not be changed while running
Error Code 12 is issued when:
1. The N2 master tries to change attribute 2 bit 6 "Current State" on a BO and the drive is tripped.
2. The N2 master tries to change attribute 2 bit 6 "Current State" on a BO and the drive is trip locked except for BO 5 "reset"
2.1.5 Drive Parameters
The following parameters may need to be manually set for each drive in the Metasys N2 network. Refer to the Installation, Operation and Maintenance Manual
for the frequency converter for programming.
Parameter list
DRIVEPARAMETER DESCRIPTION DEFAULT DESIRED SETTING
O-01 Control Side Digital & Ctrl. Word
O-02 Control Source Drive Port Drive Port
O-03 Control Word Timeout 60 s 1-18000 s
O-30 Protocol Drive Metasys N2
O-31 Address 11-255
O-32 Drive Port Baud Rate 9600 Fixed to 9600
O-33 Drive Port Parity Even, 1stop Fixed to No Parity, 1stop
O-37 Maximum Inter-char Delay 25 s for Metasys N2
AF-600 FP Metasys
7
2

2.1.6 General Commands (Acknowledged)
DRIVE Response Command Subcommand NPA Object
no. Attribute Message Type Error Code Comments
ACK 0 4 - Poll Message
No Acknowledge -
The slave is to respond with any data points,
analog or binary I/O that have been flagged
for COS
ACK 0 5 - Poll message
With Acknowledge -
The slave is to respond with any data points,
analog or binary I/O that have been flagged
for COS
ACK 0 9 - Status update Message -
Slave device must respond with device man-
ufacturing model number (Par. AN-21), days in
service (Par. AN-00) and device status
ACK F - - Identify Device Type -Slave device responds with an identification
number of 10H to indicate non JCI device
ACK 0 0 - Synch Time - The internal clock is syncronized by this com-
mand
ACK, no action 8 0 - Upload -Optional, no support in the frequency
converter
ACK, no action 8 1 - Upload - Optional, no support in the frequency
converter
ACK, no action 8 3 - Upload Record -Optional, no support in the frequency
converter
ACK, no action 8 4 - Upload Complete - Optional, no support in the frequency
converter
ACK, no action 9 0 - Download -Optional, no support in the frequency
converter
ACK, no action 9 1 - Download - Optional, no support in the frequency
converter
ACK, no action 9 3 - Download -Record optional, no support in the frequency
converter
ACK, no action 9 4 - Download Complete - Optional, no support in the frequency
converter
NAK 0 1 - Read Memory 01 Slave device memory read based on memory
addresses
NAK 0 8 - Warm Start 01 JCI use only
Table 2.1: No Region, Attribute Number and -type in this table.
AF-600 FP Metasys
8
2

2.1.7 Analog Input Commands (Acknowledged)
DRIVE Re-
sponse Command Subcom- mand Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 1 0-23 1 Byte Read Analog Input
Read Object Configuration at-
tribute associated with each
individual point
ACK 1 - 1 0-23 2Byte Read Analog Input
1) Read Object Status attribute
associated with each
individual point
ACK 1 - 1 0-23 3 Float Read Analog Input
2) Read Analog Input Value at-
tribute associated with each
individual point
ACK 1 - 1 0-23 8Float Read Analog Input
Read Low Alarm attribute as-
sociated with each
individual point
ACK 1 - 1 0-23 9 Float Read Analog Input
Read Low Warning attribute
associated with each
individual point
ACK 1 - 1 0-23 10 Float Read Analog Input
Read High Warning attribute
associated with each
individual point
ACK 1 - 1 0-23 11 Float Read Analog Input
Read High Alarm attribute as-
sociated with each
individual point
ACK 1 - 1 0-23 12 Float Read Analog Input
Read Differential attribute as-
sociated with each
individual point
ACK 2 - 1 0-23 1 Byte Write Analog Input
Write to Object Configuration
attribute associated with each
individual point
ACK 2 - 1 0-23 8Float Write Analog Input
Write to Low Alarm Limit attrib-
ute associated with each
individual point
ACK 2 - 1 0-23 9 Float Write Analog Input
Write to Low Warning Limit at-
tribute associated with each
individual point
ACK 2 - 1 0-23 10 Float Write Analog Input
Write to High Warning Limitat-
tribute associated with each
individual point
ACK 2 - 1 0-23 11 Float Write Analog Input
Write to High Alarm Limit at-
tribute associated with each
individual point
ACK 2 - 1 0-23 12 Float Write Analog Input
Write to Differential attribute
associated with each
individual point
ACK, no action 7 2 1 0-23 - Float Override Analog in-
puts
Analog inputs are "outputs"
from the frequency converter
and should not be written over
by the network controller
ACK, no action 7 3 1 0-23 - - Override Analog Re-
lease
Analog inputs are "outputs"
from the frequency converter
and should not be written over
by the network controller
ACK, no action 7 7 1 0-23 - - Write Analog Input
Attributes
Optional command for slave
devices. Only used for N2
commissioning purposes
Table 2.2: No Error code in this table.
AF-600 FP Metasys
9
2

2.1.8 Analog Input Commands (Not Acknowledged)
DRIVE
Response
Com-
mand
Region NPA Object no. Attribu-
te No.
Attribute Message Type Error
Code
Comments
NAK 1 1 0-23 4 Float Read Analog Input 111 ) Read Linear Ranging Parameter 1
attribute associated with each
individual point. (JCI use only)
NAK 1 1 0-23 5Float Read Analog Input 111) Read Linear Ranging Parameter 2
attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 2 Byte Write Analog Input 111) Object Status writeable
NAK 2 - 0-23 3Float Write Analog Input 111) Analog Input Value not writeable
NAK 2 - 0-23 4 Float Write Analog Input 111) Write to Linear Ranging Parameter
1 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 5Float Write Analog Input 111) Write to Linear Ranging Parameter
2 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 6 Float Write Analog Input 111) Write to Linear Ranging Parameter
3 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 7 Float Write Analog Input 111) Write to Linear Ranging Parameter
4 attribute associated with each
individual point. (JCI use only)
NAK 2 - 0-23 13 Integer Write Analog Input 111) Write to Filter Weight attribute as-
sociated with each individual point.
(JCI use only)
NAK 2 - 0-23 14 Float Write Analog Input 111) Write to AI Offset attribute associ-
ated with each
individual point. (JCI use only)
1) Error code 11 is used because attributes are considered as fields/records in the point map database.
Table 2.3: No Subcommand coloumn in this table.
AF-600 FP Metasys
10
2

2.1.9 Analog Output Commands (Acknowledged)
DRIVE
Response
Command Sub
command
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 3 0-2 1 Byte Read Analog Output Read Object Configuration attrib-
ute associated with each
individual point
ACK 1 - 3 0-2 2Byte Read Analog Output Read Object Status attribute asso-
ciated with each individual point
ACK 0 9 - - - - Status update Mes-
sage
Slave device must respond with
device manufacturing model
number (Par. AN-21), days in ser-
vice (Par. AN-00) and device status
ACK 1 - 3 0-2 3Float Read Analog Output Read Current Value attribute asso-
ciated with each individual point
ACK 2 - 3 0-2 1 Byte Write Analog Output Write to Object Configuration at-
tribute associated with each
individual point
ACK 7 2 3 0-2 -Float Override Analog Out-
put
Write to analog output current
value (frequency setpoint)
ACK 7 2 3 0-2 - Float Override Analog Out-
put
Write to analog output current
value (frequency setpoint)
ACK 7 3 3 0-2 - - Override Release Set the current value, the value
that it was before the 1. Override
Command was issued
ACK, no action 7 7 3 0-2 - - Write Analog Output Optional command for slave devi-
ces. Only used for N2 Attributes
commissioning purposes. Not to
be implemented at this time
ACK, no action 7 8 3 0-2 - - Read Analog Output
Attributes
Optional command for no action
slave devices. Only used for N2
commissioning purposes. Not to
be implemented at this time
Table 2.4: No Error Code coloumn in this table.
AF-600 FP Metasys
11
2

2.1.10 Analog Output Commands (Not Acknowledged)
DRIVE
Response
Command Region NPA Object no. Attribute No. Attribute Message Type Error
Code
Comments
0-2 1 3 0-2 4 Float Read Analog Output 111Read Low Linear Ranging Parameter
attribute associated with each
individual point. (JCI use only)
NAK 1 3 0-2 5Float Read Analog Output 111Read High Linear Ranging Para-
meter attribute associated with
each individual point. (JCI use only)
NAK 2 3 0-2 2 Byte Write Analog Out-
put
111Object Status not writeable
NAK 2 3 0-2 3Float Write Analog Out-
put
111Write to Current Value structure at-
tributes associated with each
individual point. (N2 does not sup-
port this, override function must be
used)
NAK 2 3 0-2 4 Float Write Analog Out-
put
111Write Debouncing Value in msec at-
tribute associated with each
individual point.(JCI use only)
NAK 2 3 0-2 5Float Write Analog Out-
put
111Write Accumulator value attribute
associated with each individual
point. (JCI use only)
1) Error code 11 is used because attributes are considered as fields/records in the point map database.
Table 2.5: No Subcommand coloumn in this table.
AF-600 FP Metasys
12
2

2.1.11 Binary Input (BI) Commands (Acknowledged)
DRIVE
Response
Command Subcom-
mand
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 2 0-135 1 Byte Read Binary In-
put
Read Object Configuration at-
tribute associated with each
individual point
ACK 1 - 2 0-135 2Byte Read Binary In-
put
Read Object Status attribute
associated with each individual
point
ACK 2 - 2 0-135 1 Byte Write Binary In-
put
Write to Object Configuration at-
tribute associated with each
individual point
ACK, no action 7 2 2 0-135 -Byte(0/1) Override Binary
Input
Binary inputs are "outputs" from
the frequency converter and
should not be written over by the
network controller. (Status word,
Warnings, and Alarms)
ACK, no action 7 3 2 0-135 - - OverrideRelease Binary inputs are "outputs" from
the drive and should not be writ-
ten over by the network control-
ler. (Status word, Warnings and
Alarms)
ACK, no action 7 7 2 0-135 - - Write Binary In-
put
Optional command for slave de-
vices. Only Attributes used for N2
commissioning purposes. Not to
be implemented at this time
ACK, no action 7 8 2 0-135 - - Read Binary In-
put
Optional command for Attrib-
utes slave devices. Only used for
N2 commissioning purposes. Not
to be implemented at this time
2.1.12 Binary Input (BI) Commands (Not Acknowledged)
DRIVE
Response
Command Region NPA Object no. Attribute No. Attribute Message Type Error Code Comments
NAK 2 2 0-135 2 Byte Write Binary In-
put
111Object Status not writeable
NAK 2 2 0-135 3Integer Write Binary In-
put
111Write Debouncing Value in msec at-
tribute associated with each
individual point.(JCI use only)
NAK 2 2 0-135 4 Inte-
ger32
Write Binary In-
put
111Write Accumulator value attribute
associated with each individual
point (JCI use only)
Table 2.6: No Subcommand coloumn in this table.
AF-600 FP Metasys
13
2

2.1.13 Binary Output Commands (Acknowledged)
DRIVE
Response
Com-
mand
Subcom-
mand
Region NPA Object
no.
Attribute No. Attribute Message Type Comments
ACK 1 - 4 0-10 1 Byte Read Binary Output Read structure attributes associ-
ated with each individual point
ACK 1 - 4 0-10 2Byte Read Binary Output Read structure attributes associ-
ated with each individual point
ACK 2 - 4 0-10 1 Byte Write Binary Output Write to Object Configuration at-
tribute associated with each
individual point
ACK 7 2 4 0-10 -Byte(0/1) Override Binary Out-
put
Write to binary output current
state (Drive control word)
ACK 7 2 4 0-10 - Byte(0/1) Override Binary Out-
put
Write to binary output current
state (Drive control word)
ACK 7 3 4 0-10 - - Override Release Set the current value, the value
that it was before the 1. Override
Command was issued
ACK, no action 1 - 4 0-10 3 Integer Read Binary Output Read Minimum On-time attribute
associated with each
individual point. Return value = 0
ACK, no action 1 - 4 0-10 4Integer Read Binary Output Read Minimum Off-time attribute
associated with each
individual point. Return value = 0
ACK, no action 1 - 4 0-10 5 Integer Read Binary Output Read Maximum Cycles/ Hour at-
tribute associated with each
individual point. Return value = 0
ACK, no action 2 - 4 0-10 3Integer Write Binary Output Write Minimum On-time attribute
associated with each individual
point
ACK, no action 2 - 4 0-10 4 Integer Write Binary Output Write Minimum Off-time attribute
associated with each individual
point
ACK, no action 2 - 4 0-10 5Integer Write Binary Output Write Maximum Cycles/ Hour at-
tribute associated with each
individual point
ACK, no action 7 7 4 0-10 - - Write Binary Output Optional command for slave de-
vices. Only Attributes used for N2
commissioning purposes
ACK, no action 7 8 4 0-10 - - Read Binary Output Optional command for slave de-
vices. Only Attributes used for N2
commissioning purposes
Table 2.7: No Error Code coloumn in this table.
2.1.14 Binary Output (BO) Commands (Not Acknowledged)
DRIVE
Response
Command Region NPA Object no. Attribute No. Attribute Message Type Error Code Comments
NAK 1 4 0-10 6 Integer Read Binary Out-
put
111) Read Interstage on delay attribute
associated with each individual
point. (JCI use only)
NAK 1 4 0-10 7Integer Read Binary Out-
put
111) Read Interstage off delay attribute
associated with each individual
point. (JCI use only)
NAK 2 4 0-10 2 Byte Write Binary Out-
put
111) Object Status not writeable
NAK 2 4 0-10 6Integer Write Binary Out-
put
111) Write Interstage on delay attribute
associated with each individual
point. (JCI use only)
NAK 2 4 0-10 7 Integer Write Binary Out-
put
111) Write Interstage off delay attribute
associated with each individual
point. (JCI use only)
1) Error code 11 is used because attributes are considered as fields/records in the point map database.
Table 2.8: No Subcommand coloumn in this table.
AF-600 FP Metasys
14
2

2.1.15 Internal Integers (ADI) Commands (Acknowledged)
DRIVE
Response
Command Subcom-
mand
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 6 0-254 1 Integer Read Internal Pa-
rameter of object
type integer (16 bit)
Read Object Status associ-
ated with each individual
point
ACK 1 - 6 0-254 2Integer Read Internal Pa-
rameter of object
type integer (16bit)
Read Current Value attribute
associated with each
individual point
ACK 2 - 6 0-254 - Integer Write Internal Pa-
rameter of object
type integer (16bit)
Write to Current Value attrib-
ute associated with each
individual point
ACK 7 2 6 0-254 -Integer Override Internal
Parameter of ob-
ject type Integer
(16 bit)
Write to internal parameter
current value (set-up para-
meters for Drive)
ACK 7 3 6 0-254 - - Override Release Set the current value, the val-
ue that it was before the 1.
Override Command was
issued
Table 2.9: No Error Code coloumn in this table.
2.1.16 Internal Floating Point Commands (Acknowledged)
DRIVE
Response
Command Subcom-
mand
Region NPA Object no. Attribute No. Attribute Message Type Comments
ACK 1 - 5 0-101 1 Byte Read Internal Pa-
rameter of object
type float
Read Object Status associ-
ated with each individual
point
ACK 1 - 5 0-101 2Float Read Internal Pa-
rameter of object
type float
Read Current Value attrib-
ute associated with each
individual point
ACK 2 - 5 0-101 - Float Write Internal Pa-
rameter of object
type float
Write to Current Value
attribute associated with
each individual point
ACK 2 - 5 0-101 -Float Write Internal Pa-
rameter of object
type float
Write to Current Value
attribute associated with
each individual point
ACK 7 2 5 0-101 - Float Override Internal
Parameter of object
type float
Write to internal parameter
current value (set-up
parameters for Drive)
ACK 7 3 5 0-101 - - Override Release Set the current value, the
value that it was before the
1. Override Command was
issued
Table 2.10: No Error Code coloumn in this table.
AF-600 FP Metasys
15
2

2.2.1 Start-up of the Frequency Converter
Use the frequency converter keypad mounted either on the drive or remote. Use the Extended Menu key to access the O-## group parameters (Options / Comms).
The settings shown below are typical. Some settings may be changed to meet the application requirements. The settings below will serve as a good starting
reference. Refer to the operating instruction manual for instructions on changing parameters and programming the drive.
Examples of typical settings. Program the following:
Parameter: Setting:
par. O-30 Protocol [3] Metasys N2
par. O-31 Address 1 (Default)
par. O-32 Drive Port Baud Rate [2] 9600 Baud (fixed at 9600 for N2 protocol)
par. O-50 Coasting Select [3] Logic OR
par. O-52 DC Brake Select [3] Logic OR
par. O-53 Start Select [3] Logic OR
par. O-54 Reversing Select [0] Digital input
par. O-55 Set-up Select [3] Logic OR
par. O-56 Preset Reference Select [3] Logic OR
par. O-94 Bus Feedback 1 0
par. O-95 Bus Feedback 2 0
NB!
Send an F command to begin communications between the master and the drive!
Example 1:
F command Setting:
Device address XX
Char1 command F
Checksum YY
Message code:
>XXFYY <CR>
Issue a run command through the master, to the device:
Example 2:
Network start, BO override command: Setting:
Device address XX
Char1 command 7
Char1 subcommand 2
Char2 region 04
Char2 object number (NPA) 04 (Start)
Char2 override value 01 (Active)
Checksum YY
Message code:
>XX72040401YY <CR>
Issue a frequency reference through the master, to the device:
AF-600 FP Metasys
16
2

Example 3:
Over-ride analog output, speed (50%) change command: Setting:
Device address XX
Char1 command 7
Char1 subcommand 2
Char2 region 03
Char2 object number (NPA) 00
Char8 override value * 4E 00 00 00 override value = 50% speed (IEEE floating point, format)
Checksum YY
Message code:
>XX7203004E000000<CR>
To calculate override value for speed: refer to Scaling of Network Reference
and Network Feedback. Issue an override release command through the
master to the device:
Example 4:
Bus stop, BO over-ride release command: Setting:
Device address XX
Char1 command 7
Char1 subcommand 2
Char2 region 04
Char2 object number (NPA) 04 (Start)
Char8 override value * 00 (Not active)
Checksum Y
Message code:
>XX72040400YY <CR>
If the preceding commands were issued, the drive should have accelerated
to 50% after the speed reference was issued. After the override release, the
drive should have stopped.
2.2.2 Scaling of Bus Reference and Feedback
Reference/feedback Scaling Float IEEX hex
20% 20 * 16384/100 3276.8 454C CCCD
50% 50 * 16384/100 8192 4600 0000
100% 100 * 16384/100 16384 4680 0000
200% 200 * 16384/100 32767 46FF FE00
-100% -100 * 16384/100 -16384 C680 0000
-200% -200 * 16384/100 -32768 C700 0000
Table 2.11: Reference/feedback values
The reference/feedback value is the percentage of the range of parameter F-52 and F-53. Values within the ranges 100% to 200% and -200% to -100% applies
only to the reference. The Float representation of the value 200% must be limited to maximum 32767 and minimum -32768.
AF-600 FP Metasys
17
2

2.2.3 Status Update Request
A Status Update Request will cause the drive to report its current operating status. The status codes, descriptions and associated alarms are shown in the chart
below.
The Device Status Code consists of two parts. The Least Significant Byte, (LSB) of the hex number is the Alarm Number. The Most Significant Byte (MSB) indicates
if the alarm is a normal trip (01) that can be reset automatically or manually, or if the alarm is a trip lock (02) requiring cycling power to the drive.
Status codes with associated alarms and descriptions
Device Status Code1 Alarm No. Description
0x0000 - Device OK
0x0102 2Live zero error
0x0204 4 Phase fault (Trip lock)
0x0107 7Over voltage
0x0108 8 Under voltage
0x0109 9Inverter overloaded
0x010A 10 Motor overloaded
0x010B 11 Motor thermistor
0x010C 12 Current limit
0x020D 13 Over current (Trip lock)
0x020E 14 Earth fault (Trip lock)
0x020F 15 Switch mode fault (Trip lock)
0x0210 16 Short circuit (Trip lock)
0x0111 17 Standard bus time out
0x0112 18 HPFB time out
0x0116 22 Auto optimization not OK
0x021D 29 Heat sink temperature to high (Trip lock)
0x011E 30 Motor phase U missing
0x011F 31 Motor phase V missing
0x0120 32 Motor phase W missing
0x0122 34 Profibus communication error
0x0225 37 Inverter fault (Trip lock)
0x013C 60 Safety interlock
0x0263 99 Unknown fault (Trip lock)
Read / Write Notes
A write command to an ADF (Internal Floating Point) or BD (Internal Byte) point type will be stored in the drive's EEPROM.
NB!
If write command is issued to an overridden point, the new value will not be stored in the drive's EEPROM.
AF-600 FP Metasys
18
2

2.2.4 Override/Override Release Commands and Time Out, O-04 (Setting [20], N2 Override release)
The way the overridden points are released is very important to the way the drive will behave during the override release time out or for release commands issued
by the N2 master. This is due to the fact that the active setup can be changed to a different setup. If one would release the active setup before the values that
have been overridden in that setup, the backup values would then be restored to the wrong setup, leaving the overridden values in the old setup unchanged.
The release after override time out:
During an override release time-out, all points which are overridden, will be released in the order, which they are specified in Appendix POINTMAP:
1. Release Analog Outputs from point address (NPA) 0 to 255.
2. Release Binary Outputs from point address (NPA) 0 to 255.
3. Release Internal Floating Points from point address (NPA) 0 to 255.
4. Release Internal Integer Points from point address (NPA) 0 to 255.
5. Release Internal Byte points from point address (NPA) 0 to 255.
2.2.5 Change of State (COS)/POLLING
A change of state occurs when a new command has been issued for the drive. This command can be issued through the bus or through a drive related status
change or command. The master can issue a series of poll commands to the network devices to get an update on any status changes from the time of the last
polling. When polling a frequency converter for the first time after a network has been powered up after an F command has been issued, a 0/4 poll command
must be issued.
2.2.6 Handling of Poll Message Commands
The Identity Command will cause the drive to report all AI, AO, BI and BO points, which are available when the next Poll (0/4) is received. The drive also supports
COS for AI and BI point types. The drive is limited to responding with up to 200 ASCII characters, so multiple messages may need to be sent before all available
points have been reported.
Upon receiving the Poll (0/4), the frequency converter will begin exporting the requested information. The frequency converter will continue to export new
information upon receiving the 0/5 Poll until it has sent all requested information. Then it will respond to a new 0/5 Poll with an ACK response to indicate all
information has been transmitted and complete the Poll sequence receiving a 0/4 Poll before sending the ACK response will cause the frequency converter to re-
transmit its latest response.
AF-600 FP Metasys
19
2
