GE GLD6700N User instructions

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Created 9/06 350247
Panel
Thickness
Kit A B C
GPF525 25-1/4" 23-1/2" N/A 1/4"
GPF575 25-1/2" 23-5/8" 1/4" 3/4"
Listed by
Underwriters
Laboratories
• The rough cabinet opening must be at least 24" deep,
24" wide and approximately 34-1/2" high from floor to
underside of the countertop.
4"
6"
5" 5"
4"
Figure A
Floor MUST be Even
With Room Floor
Cabinets
Square
and
Plumb
This Wall Area
must be Free
of Pipes or
wires
24"
Min.
24"
Min.
34-1/2"1/4"
Underside of
Countertop
to Floor
Plumbing and Electric Service
Must Enter Inside This Area
24
25
MAX.
20-1/2
4
4 (Adjustable)
33-3/4" MIN.
adj. to 35"
27-1/2
22
B
See Detail E for 3/4" Panel Detail E for 3/4 panel only
Door insert ABack ViewFront View
F
F
1-7/8 1-7/8
20
Section E-F
C
3/8
3/4
B
See Detail E for 3/4" Panel Detail E for 3/4 panel only
Door insert ABack ViewFront View
F
F
1-7/8 1-7/8
20
Section E-F
C
3/8
3/4
Electrical Rating
Voltage AC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 10
Calrod® heater watts max........................ 875
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Note: The rough cabinet opening must be at
least 24" deep, 24" wide and approximately
34-1/2" high from floor to underside of
the countertop. Dishwasher must not be
installed more than 10 feet from sink for
proper drainage. All plumbing and
electrical work must be in accordance
with local codes. The power cord and
connections must comply with the National
Electrical Code Section 422 and/or local
codes and ordinances. The cord must be no
longer than 6 ft. from the junction box to
the receptacle.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
GLD6700/60N
GE®Tall Tub Built-In Dishwasher
GLD6760NSS
Features and Benefits
• Giant Tub with Maximum Capacity Nylon Racking - Holds tall and oversized items;
washes 16 place settings at once
• Two Utility Shelves in Tiered Upper Rack with StemSafe™, Silver - Provide extra room
for small items and an extra layer of security for washing delicate stemware
• Maximum Capacity 3-Piece Silverware Basket with 3 Cell Covers and ExtraBasket™-
Provides the ultimate flexibility, keeping silverware and small items separate;
allows the baskets to be placed in either the upper or lower rack
• Four-Position Adjustable Upper Rack - Moves up, down and diagonally
for maximum loading flexibility
• 6-Level BrilliantClean™Towerless Wash System with CleanSensor™- Scrubs dishes clean
with three full-sized wash arms, six levels of wash action and a sensor that continually
monitors and adjusts the wash cycle for a superior clean
• Light-Touch Electronic Controls with 4 Status Lights - Provide a smooth surface
and requires only a gentle touch to operate
• Countdown Display with 1-9 Hour Delay Start - Signals remaining cycle time and
makes it easier than ever to wash dishes at any hour, taking advantage of reduced
energy rates or washing dishes even when the family is asleep
• SpeedCycle™- Cuts the length of the normal cycle in half, washing and drying lightly
soiled dishes effectively in 45 minutes or less
• QuietPower™3 Sound Package - Dramatically reduces the sound of washing the dishes
• 100% Triple Water Filtration - Water stays clean, so just-washed dishes do, too
• Model GLD6700NWW - White on white
• Model GLD6700NCC - Bique on bisque
• Model GLD6700NBB - Black on black
• Model GLD6760NSS - Stainless steel
Specification Created 9/06 350247
GLD6700/60N
GE®Tall Tub Built-In Dishwasher
