Ge Gsd1821 User manual

Use and Care Guide

Dishwasher

GE Appliances

To obtain a Spanish language

version of this book, call

GE Answer Center®

800.626.2000

consumer information service.

Para obtener la versi´

on en

espa~

nol de este manual,

llame a

GE Answer Center,®

servicio de informaci´

para el consumidor,

tel´

efono 800.626.2000.

Safety Instructions.........................3

Operating Instructions, Tips

China, Crystal, Sterling ...............................10

Cycle Features ............................................4, 5

Cycle Selection Chart ....................................5

Detergent Guide .............................................7

Dispenser Cups...............................................7

Drying Options............................................4, 5

Features........................................................4, 5

Loading.........................................................8, 9

Operating Instructions..............................4, 5

Rinse Agent......................................................6

Water Temperature .......................................6

Care and Cleaning

Air Gap............................................................11

Winter Storage.............................................11

Problem Solver.......................13–15

More questions ?…call

GE Answer Center® 800.626.2000

Preparation

Front Panel Change.....................................12

Consumer Services...................19

Appliance Registration..................................2

Important Phone Numbers........................19

Model and Serial Numbers ..........................2

Repair Service...............................................18

Warranty ........................................Back Cover

Model: GSD1821

• HOT WATER—Your dishwasher

needs hot water for best results. Water

entering the dishwasher should be at

least 120°F. but your dishwasher

performs BETTER with HIGHER

water temperatures not to exceed 150°F.

• WATER HARDNESS—The hardness

of the water plays an important part in

how well your dishwasher cleans. In

areas where water is very hard (12 grains

or more), it may be necessary to install

a water softener. If you do not know the

hardness of your water supply, contact

your local water department.

• DETERGENTS—Only use detergents

labeled for use in automatic dishwashers.

Never use laundry detergents or

liquid soaps…that will cause oversudsing

and leaks. The amount of detergent you

use depends on the water hardness and the

amount of soil on your dishes. In most

cases, detergent amounts should be

increased for hard water and heavy soil.

• RINSE AGENT—should always be used:

— to reduce water spotting.

— to improve drying.

Always check and refill the rinse agent

when necessary.

• FOR BEST RESULTS—The cycles

and the options you choose have an

effect on the results you get. The

following are examples. (Please, see the

Operating Instructions, Tips for more

information.)

• TEMP BOOST OPTION—

—

use with heavily soiled loads.

— extends cycle to heat water for best

washing and drying.

• POTSCRUBBER CYCLE—

— use with dried or baked-on heavily

soiled loads.

• HEATED DRY OPTION—

—

assures faster drying.

— be sure to use a rinse agent.

Before using your dishwasher,

read this guide carefully.

It is intended to help you operate and

maintain your new dishwasher properly.

Keep it handy for answers to your questions.

If you don’t understand something or need more help, call:

GE Answer Center®

800.626.2000

24 hours a day, 7 days a week.

If you received a

damaged dishwasher…

Immediately contact the dealer (or

builder) that sold you the dishwasher.

Save time and money.

Before you request service…

Check the Problem Solver in the back of this guide. It lists

causes of minor operating problems that you can correct

yourself.

Write down the model

and serial numbers.

You’ll find them on a label fastened to the

tub wall just inside the dishwasher door.

These numbers are also on the Consumer Product

Ownership Registration Card that came with your

dishwasher. Before sending in this card, please write

these numbers here:

Model Number

Serial Number

Use these numbers in any correspondence or service calls

concerning your dishwasher.

We’ll be there…

No matter what major appliance you buy from us, you

always get more than a quality product. You receive the

added assurance that, should you ever need our help, we’ll

be there.

We ask that you please be sure to read all the Important

Safety Instructions before operating your new appliance

to insure your safety.

Potscrubber1125

Cycles Options

WATER

SAVER

POT-

SCRUBBERNORMAL

WASH RINSE

&HOLD HEATED

DRY



ENERGY

SAVER

WASHHEAT

BOOST



(NOHEATBOOST)

RINSING

OFF

START

WASHING

DELAYED

START

QuietPower

DRYING

































ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ

































ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ





ÀÀ

A note to consumer—

We’d like to thank you and congratulate you for making the wise decision in purchasing your dishwasher.

This User Guide is designed to be kept near your dishwasher at all times for quick and easy reference. Features

may vary on some dishwasher models. Please read the following tips to insure your dishwasher is operating at its

best performance.

We care about you and your appliance and we want your dishwasher to do its job for you.

IMPORTANT SAFETY INSTRUCTIONS

Read all instructions before using this appliance.

WARNING—When using this

appliance, always exercise basic

safety precautions, including the

following:

• Use this appliance only for its intended

purpose, as you will find described in this

Use and Care Guide.

• This dishwasher must be properly

installed and located in accordance

with the Installation Instructions

before it is used. If you did not

receive an Installation Instructions sheet with your

dishwasher, you can obtain one by calling, toll

free, the GE Answer Center,®800.626.2000.

—This appliance must be connected to a grounded

metal, permanent wiring system; or an

equipment-grounding conductor must be run

with the circuit conductors and connected to

the equipment-grounding terminal or lead of

the appliance.

—Connect to a properly rated, protected and sized

power-supply circuit to avoid electrical overload.

• Do not store or use combustible

materials, gasoline or other

flammable vapors and liquids

in the vicinity of this or any other appliance.

• Use only powder or liquid detergents or wetting

agents recommended for use in a dishwasher.

• Do not wash plastic items unless marked

‘‘dishwasher safe’’ or the equivalent. For plastic

items not so marked, check the manufacturer’s

recommendations.

• Load light plastic items so they will not

become dislodged and drop to the bottom of

the dishwasher—they might come into contact

with the heating element and be damaged.

To minimize the possibility of injury.

• When loading items to be washed:

A. Locate sharp items so that they are not likely

to damage the door seal, and

B. Load sharp knives with the handles up to

reduce the risk of cut-type injuries.

•Do not tamper with controls.

•Do not touch the heating element during or

immediately after use.

•Do not operate your dishwasher unless all enclosure

panels are properly in place.

•Do not abuse, sit on, or stand on the door or dish

rack of the dishwasher.

•Close supervision is necessary if this appliance

is used by or near children. Do not allow children

to play inside, on or with this appliance or any

discarded appliance. Dispose of discarded

appliances and shipping or packing material

properly. Before discarding a dishwasher, remove

the door of the washing compartment.

•Keep all washing detergents and wetting agents

out of the reach of children, preferably in a locked

cabinet. Observe all warnings on container labels

to avoid personal injury.

• To minimize the possibility of

electric shock, disconnect this

appliance from the power supply

before attempting any maintenance. NOTE:

Turning the control dial to the OFF position

does not disconnect the appliance from the

power supply. We recommend having a qualified

technician service your appliance.

• Do not attempt to repair or replace any part

of your dishwasher unless it is specifically

recommended in this guide. All other servicing

should be referred to a qualified technician.

WARNING—HYDROGEN GAS

is produced by the chemical action

within your water heater. It can

accumulate in the water heater and/or

water pipes if hot water has not been used for a

period of two weeks or longer. HYDROGEN GAS

IS EXPLOSIVE. To prevent the possibility of

damage or injury, if you have not used hot water

for two weeks or more, or moved into a residence

in which the hot water system may not have been

used for some time, turn on all hot water faucets

and allow them to run for several minutes before

using any electrical appliance which is connected

to the hot water system. This will allow any

hydrogen gas to escape. Also, since the gas is

flammable, do not smoke or use an open flame

or appliance during this process.

SAVE THESE

INSTRUCTIONS

GAS

Potscrubber1125

Cycles Options

WATER

SAVER

POT-

SCRUBBERNORMAL

WASH RINSE

&HOLD HEATED

DRYENERGY

SAVER

WASHHEAT

BOOST



(NOHEATBOOST)

RINSING

OFF

START

WASHING

DELAYED

START

QuietPower

DRYING

Important Safety Instructions

HOW TO OPERATE YOUR DISHWASHER

Your dishwasher is designed to give maximum

performance on loads with normal and heavy soils.

You may find that many of your dishes have lighter

soils than normal; if this is the case you can save

water and energy by selecting a cycle other than

NORMAL WASH.

NOTE: The lights over the Cycle and Energy Option

pads come ON to indicate the cycle/option that has

been selected. Press pad firmly until the light comes

on. These Cycle and Energy Option Indicator lights

remain on while the door is latched.

The CYCLE ON light will come on when the

dishwasher is in a Start Delay, Wash or Dry cycle.

The light will go out when all cycles are complete.

If dishwasher drains into a food waste disposal,

operate the disposal until it is empty before starting

dishwasher.

Step 1. Load your dishwasher. (See Loading section.)

Step 2.

Make sure the Cycle Indicator Dial is at

the OFF position and the CYCLE ON light is off,

indicating all cycles are complete. Add detergent to

the detergent dispenser. (See Detergent Guide.) Use

a rinse aid agent to help prevent spotting. (See

How to Use a Rinse Agent section.)

Step 3.

Latch the door.

Step 4.

Select desired wash cycle.

• POTSCRUBBER—For items such as pots, pans

and casseroles with dried-on or baked-on soils.

Everyday dishes may be included. This cycle will

get heavily soiled dishes cleaner than the normal

cycle. It will not remove burned-on foods.

• NORMAL WASH—For most loads of everyday

dishes, glasses and cookware with medium soils.

Designed to yield high performance on normal soils.

• WATER SAVER—For dishes with light soils. This

cycle uses less water than the other cycles.

• LIGHT WASH—For loads that have dishes with

light soils.

Step 5. Select the desired Energy Options.

• TEMP BOOST—Use this option for best

performance with heavily-soiled dishes. When

selected, the wash cycle is extended while the

dishwasher heats the water for the best washing

and drying. (See Cycle Selection Chart.)

• HEATED DRY—Turns the drying heater on for

fast drying. When selected, the cycle time will be

extended for 36 minutes.

• ENERGY SAVER—Shuts off the heating unit,

thus saving energy. Dishes air-dry naturally. It takes

longer but saves energy. You can open the door after

the motor stops to speed drying. Excellent for

overnight drying.

Step 6.

Turn the Cycle Indicator Dial to START

or to the desired START DELAY time.

• Turning the dial to START will begin the cycle

immediately. To obtain the benefits of a complete

cycle, be careful that you do not turn the dial any

farther than is necessary to start the dishwasher.

There is a time delay between start-up and water

fill so you will not hear any wash action right away.

• The START DELAY will allow you to delay the

start time of your dishwasher automatically for up

to 6 hours. Turn the Cycle Indicator Dial to the

desired time. The CYCLE ON light will come on.

Dial Cycles

The SHORT WASH cycle allows you to quickly

wash loads of everyday dishes with medium soils

that have not dried on, such as loads consisting mostly

of glasses. Start Delay cannot be used with this cycle.

a. Select the NORMAL WASH cycle and any

Energy Option if desired.

b. Be sure the door is unlatched.

c. Slowly turn the Cycle Indicator Dial to

SHORT WASH.

d. Latch the door to start the cycle.

Features and appearance may vary slightly.

NORMAL

WASH WATER

SAVER TEMP

BOOST HEATED

DRY ENERGY

SAVER

LIGHT

WASH

POT-

SCRUBBER

ENERGY OPTIONSCYCLES

Operating Instructions

Dial Cycles (continued)

The RINSE & HOLD cycle is for rinsing

partial loads which will be washed later.

Do not use detergent.

a. Make sure ENERGY SAVER is selected.

b. Be sure the door is unlatched.

c. Slowly turn the Cycle Indicator Dial to

RINSE & HOLD.

d. Latch the door to start the cycle.

The PLATE WARMER cycle is for warming clean

dishes and serving plates for the serving of hot foods.

The cycle will take approximately 36 minutes if selected.

a. Load clean plates and dishes to be warmed.

b. Select HEATED DRY.

c. Be sure the door is unlatched.

d. Slowly turn the Cycle Indicator Dial to

PLATE WARMER.

e. Latch the door to start the cycle.

Wash Cycles

POTSCRUBBER

NORMAL WASH

LIGHT WASH

WATER SAVER

SHORT WASH

RINSE & HOLD

Water Use

Gallons

(approx.)

11.1

9.4

8.2

6.5

7.7

3.0

Wash Cycle

Time

Minutes

(approx.)

76*

64*

56*

12*

Rinse Rinse

Rinse

Rinse Main

Wash Rinse Rinse

Cycle Sequence

Rinse

Main

Wash

Rinse Rinse Rinse Rinse

Rinse

*Unextended times. These cycle times will be increased approximately 12 minutes if TEMP BOOST option is selected.

Drying Options:

HEATED DRY. Available on all wash cycles except RINSE & HOLD. Add 36 minutes to wash cycle time.

ENERGY SAVER. Drying heater is turned off. Dishes dry naturally.

Rinse

Rinse Main

Wash Rinse Rinse

Rinse Main

Wash

Main

Wash

Rinse Rinse Rinse Rinse

Rinse Rinse

Cycle Selection Chart

Rinse

Quiet Power Plus

CYCLE

SHORT WASH

RINSE & HOLD

START

START DELAY

(HRS)

PLATE

WARMER

(PRESS

HEATED DRY)

OFF

The rinse agent makes water flow off dishes

quicker than usual. This lessens water spotting

and makes drying faster, too.

For best dishwashing performance, use of a rinse

agent such as JET-DRY brand is recommended.

Rinse agents come in either liquid or solid form.

Your dishwasher uses the liquid form.

How to fill the rinse agent dispenser.

Unscrew the cap.

Add liquid rinse agent

until it just reaches the

bottom of lip inside the

dispenser opening.

Replace cap. The

dispenser automatically

releases rinse agent into

final rinse water.

You may check to see if you need to add rinse agent by

removing the fill cap and looking into the container.

You may also check the rinse agent, on some models,

by pressing the clear center of the fill cap 2 or 3 times.

If rinse agent is drawn into the center of the fill cap,

you have enough. If the center area remains clear add

rinse agent.

Your dishwasher’s rinse agent container holds

approximately 41⁄2ounces. This should last about

3 months. Fill as needed.

If you accidentally spill: Wipe up the rinse

agent with a damp cloth. Don’t leave the spill in the

dishwasher. It can keep your detergent from working.

If you can’t find any rinse agent, write:

BENCKISER CONSUMER PRODUCTS, INC.

(‘‘JET-DRY’’)

Corporate Centre 1

55 Federal Road

P.O. Box 1991

Danbury, CT 06813-1991

To get dishes clean and dry, you need hot water. For good washing and drying,

the entering water must be at least 120

F. To prevent dish damage, inlet water should not exceed 150

Good Dishwashing Starts with HOT Water

How to Use a Rinse Agent

How to Test Water Temperature

Check your water temperature with a candy or meat

thermometer. Turn on the hot water faucet nearest

the dishwasher. Put the thermometer in a glass and

let the water run continuously into the glass until the

temperature stops rising. If the water temperature is

below 120°F., adjust your water heater.

Helpful hints: If outside temperatures are unusually

low, or if your water travels a long distance from water

heater to dishwasher, you may need to set your water

heater’s thermostat up. If you have not used hot water

for some time, the water in the pipes will be cold. Turn

on the hot water faucet at the sink and allow it to run

until the water is hot. Then start the dishwasher. If

you’ve recently done laundry or run hot water for

showers, give your water heater time to recover before

operating the dishwasher.

To improve washability if the water is less than

120°F. and you cannot adjust your water heater: Select

a longer cycle or the TEMP BOOST option and fill

both detergent cups at least half-full with detergent.

SOFT WATER (0-3 grains hardness) MEDIUM WATER (3-7 grains) HARD WATER (7-12 grains*)

CYCLES Main Cup Open Cup Main Cup Open Cup Main Cup‡ Open Cup‡

POTSCRUBBER Half Full Half Full Completely Half Full Completely Completely

NORMAL WASH Full Full Full

LIGHT WASH Half Full None Half Full None Completely None

WATER SAVER Full

SHORT WASH

RINSE & HOLD Use no detergent Use no detergent Use no detergent

*12 grains and up is extremely hard water. A water softener is recommended. Without it, lime ‡Filled Main Cup holds 3 tablespoons;

can build up in the water valve. The water valve may stick while open and cause flooding. filled Open Cup holds 2 tablespoons.

You’ll find two detergent dispensers on the inside

door of your dishwasher. Two, because

some cycles use two washes.

See ‘‘Detergent Usage Guide’’below.

(Be sure the CYCLE INDICATOR

DIAL is at OFF position before

adding detergent. Otherwise,

the detergent

cup will not

close and latch properly.)

Close the main cup.

NOTE: To open detergent cup after it has

been closed, unlatch the door and rotate the

Cycle Indicator Dial a full turn to the OFF

position. When the closed cup contains

soap it is best that the door be in a partially

open position before rotating the Cycle

Indicator Dial. This will help reduce the amount of

detergent and rinse aid agent spillage into the tub.

Detergent Usage Guide (powder or liquid)

++ +

Open

Cup

Main

Cup

Grasp handle,

rotate and

close tightly

Use only powder or liquid detergent specifically

made

for use in dishwashers. Other types will cause

oversudsing.

How much detergent should you use?That depends.

Is your water ‘‘hard’’ or ‘‘soft’’? With hard water, you

need extra detergent to get dishes clean. With soft water,

you need less detergent.

Your water department can tell you how hard your

water is. So can your county extension agent or your

area’s water softener company. Just call and ask them

how many ‘‘grains’’ of hardness there are in your water.

Too much detergent with soft water not only wastes

money, it can be harmful. It can cause a permanent

cloudiness of glassware, called ‘‘etching.’’ An outside

layer of glass is etched away! Of course, this takes some

time. But why take a chance when it’s easy to find out the

hardness of your water.

Keep your detergent fresh and dry. Under the sink

isn’t a good place to store detergent because there is

too much moisture. Don’t put

powder detergent into

the dispenser until you’re ready to wash dishes, either.

(It won’t be fresh OR dry.)

If your powder detergent gets old or lumpy, throw it

away. Old detergent often won’t dissolve. If you use a

liquid dishwasher detergent, these precautions are not

necessary because liquid detergents don’t ‘‘lump’’ as

they age or come in contact with moisture.

How to Choose and Use the Right Detergent

How to Prepare the Dishes for Washing

If this is your first dishwasher, or if you’re

replacing a much older model, you may wonder

how much preparation your dishes need. Actually

very little. Scrape off bones, seeds, skins, toothpicks

and other hard solids. Remove excessive quantities

of oil or grease.

NOTE: You may also want to consider removing

foods such as mustard, mayonnaise, vinegar, lemon

juice and other foods that can cause discoloration of

stainless steel if allowed to remain on dishes for a long

period of time.

The POTSCRUBBER cycle can wash heavily soiled

dishes and remove dried-on and baked-on soils from

pots, pans and casseroles. Items with burned-on

soils need extra preparation.

Detergent Dispensers

Hot Water Rinse Agents Detergents Dish Preparation

The upper rack is best for glasses, cups and saucers.

Cups and glasses fit best along the sides. This is also

the place for dishwasher-safe plastics. Make sure small

plastic items are lodged in tightly so they can’t fall onto

the heating unit. Arrange stemware so that it cannot

move easily. Don’t let the glasses touch each other.

The cup shelves (number may vary) may be placed

in the up or down position to add flexibility. Load the

bottom row first, then fold down the shelf and load the

top row.

The upper rack is handy for all kinds of odd shapes.

Sauce pans, mixing bowls and other items should

be placed face down. When loading dishwasher safe

plastics make sure each plastic item is secured over

two fingers. This will insure good washing results.

Keep center area clear in the lower rack.

The wash tower rises through the center of the lower

rack during the wash and rinse portions of the cycle.

Don’t block it or load tall things next to it. Also, be

careful not to let a portion of an item such as a pot or

dish handle extend through the bottom rack. This could

block the wash arm and cause poor washing results.

HOW TO LOAD YOUR DISHWASHER

NOTE: Do not load large platters or trays in front right corner of lower

rack. They may prevent detergent from circulating in the wash cycle.

Loading Your Dishwasher

The lower rack is best used for plates, saucers, and

cookware. Large items such as broiler pans and racks

should go in the lower rack along the edge. Load

platters, pots and bowls along the sides, in corners,

or in the back. For best washing results, all items

should be positioned with the soiled side facing the

center of rack.

Put flatware in the removable basket with fork and knife

handles up to protect your hands. Place spoons in the

basket with handles down. Mix knives, forks and

spoons so they don’t nest together. Distribute evenly.

Be sure handles do not touch upper rack. For best

washing results be sure not to load large plates and

cookware between silverware basket and the center

of the rack.

The fold-down fingers in the lower rack provide

flexibility for loading extra large and hard-to-fit items.

The fingers may be left in the up position or folded

down to customize the rack.

To increase the flexibility of the lower rack, the flexible

silverware basket may be split. Grasp the silverware

basket at opposite corners and slide apart. The silverware

basket sections should be placed in the lower rack by

hanging them on the top hoop.

Don’t place the silverware basket in the front right corner

because the detergent could pour into it and damage

silverware.

Don’t let any

item extend

through bottom.

WHAT YOU CAN USUALLY WASH SAFELY

IN YOUR DISHWASHER

Usually

Material Safe Exceptions (not safe) Special Instructions

Aluminum YES Some colored anodized Some darkening or spotting possible. Remove by

aluminum can fade. scouring with soap-filled steel wool pads.

China/ YES Antique, metal-trimmed, If in doubt, check with the manufacturer. Or test wash

Stoneware hand-painted or over-the-glaze one piece daily for at least a month. Compare with the

patterns fade. Gold leaf rest of the set.

will discolor.

Crystal YES Antique, metal-trimmed or Load securely to prevent movement. Check your

hand-painted patterns fade. manufacturer’s instructions for your crystal.

Gold leaf will discolor.

Non-dishwasher

NO Do not wash in dishwasher. Damage to dishwasher

items—such and discoloration or staining of dishwasher may result.

as electronic

air cleaner

filters, furnace

filters, paint

brushes, etc.

Glass YES

Iron NO Iron will rust.

Pewter NO Pewter tarnishes.

Plastics YES If it doesn’t say DISHWASHER SAFE, test one piece in

the top rack before dishwashing an entire set.

Stainless steel YES Rinse if not washing immediately. Salty or acidic foods

can stain if left on.

Sterling silver YES Don’t put in same silverware Rinse if not washing immediately. Salty or acidic foods can

and silver plate basket with stainless steel. stain if left on. Dry detergent can cause difficult-to-remove

Contact between metals can black spots. Place in back section of silverware basket to

damage silver. avoid exposure to detergent from the detergent cup.

Don’t wash copper utensils in

the same load. Silver may get a

brown film.

Adhesive used to attach some

hollow-handle knives can loosen.

Non-stick YES After washing, wipe the non-stick coating area with

coatings vegetable oil to keep it from losing its non-stick quality.

Tin NO Tin can rust.

Wood NO Wood can warp, crack or lose

its finish with any type of washing.

Add dishes any time during the RINSE & HOLD

cycle. With other wash cycles, you can add dishes

at any time BEFORE the main detergent wash portion

of the cycle.

However, opening the door during any cycle

lessens cleaning power. So try to load everything

at the beginning.

Here’s how to add a forgotten dish:

1. Push the door latch to the left. Washing will stop.

2. Wait a few seconds until the water calms. Then

open the door. WARNING: Hot vapor may rise

from opened door.

3. Add dishes you’ve forgotten.

4. Close the door and push the latch to the far right.

When the door is locked, washing will continue.

Forget a dish? Here’s when you can add it.

CARE AND CLEANING

USER MAINTENANCE INSTRUCTIONS

Clean the control panel with a lightly dampened

cloth. Dry thoroughly. Do not use abrasives or

sharp objects on the panel. They can damage it.

Clean the outside with a good appliance polish

wax. The outside cabinet finish is durable, but it

can scratch. So use no scouring pads, or harsh or

gritty cleaners.

Appliance Polish Wax & Cleaner (Cat. No.

WR97X0216) is available from GE Service and

Parts Centers.

The inside usually takes care of itself. If it should

ever need cleaning, use a mild cleansing powder.

Scouring pads and harsh cleaners can mar the finish.

What is Dishwasher Safe Care and Cleaning

Not Using Your Dishwasher in Winter? Protect Against Freezing.

If your dishwasher is left in an

unheated place during the winter,

ask a service technician to:

• Cut off electrical power to the

dishwasher. Remove fuses or trip

circuit breaker.

• Turn off the water supply.

• Disconnect the water inlet line

from the water valve.

• Drain water from the inlet line

and water valve. (Use a pan to

catch the water.)

• Reconnect the water inlet line to

the water valve.

• Remove the plastic pump cover

in the tub bottom and use a

sponge to soak up water in

the rubber boot.

Built-in Dishwashers Often Use an Air Gap. Keep It Clean.

An air gap is a plumbing device.

It protects your dishwasher against

water backing up into it if a drain

clogs. The air gap is not a part of

the dishwasher. And you may not

even have one. Not all plumbing

codes require air gaps.

Check the air gap any time your

dishwasher isn’t draining well.

If you have an air gap, check it at

least once a month. IT IS NOT

PART OF YOUR DISHWASHER.

IT IS NOT COVERED IN YOUR

WARRANTY.

The air gap is easy to clean.

With most types, first turn off the

dishwasher, then lift off the chrome

cover. Then unscrew the plastic cap

and check for any buildup of grit.

A toothpick makes cleaning easy.

Two Types of Air Gaps

Pump Cover Screws

HOW TO CHANGE COLOR PANELS

If you are redecorating, you can change your dishwasher’s front panels

to match or blend with your new colors by flipping them over. You may

also paint a panel with a color of your own choice.

How to Change the Door Panel:

1. Take out trim screws on either side of the

dishwasher door. Remove the side trim.

2. Slide the door panel out.

(Careful—edges may be sharp.)

3. Turn the door panel around and put the color you

want in front.

4. Replace the door panel, side trim and screws.

NOTE: Do not operate

dishwasher while changing

panels or when lower access

panel is removed.

How to Change the Lower Panel:

1. Remove the bottom panel attachment screws.

2. Remove the top mounting screws.

3. Take out the top trim screws and remove the

top trim.

4. Slide the color panel(s) up and out and put the

color you want in front.

5. Replace the top trim and screws.

6. Replace the entire access assembly by reversing

the steps.

Bottom Panel Attachment Screws

Top

Trim

Top

Mounting

Screw

Adding 1/4″Wood Inserts

Color insert panels for both the door and the lower panel can be replaced by

1/4″thick wood inserts to match your kitchen cabinets. Get them from your

nearest cabinet or lumber dealer.

Dimensions for 1/4″wood inserts:

Door Panel: 191⁄8″H x 239⁄16″W.

Lower Panel: 311⁄16″H x 239⁄16″W.

QUESTIONS?

USE THIS PROBLEM SOLVER

Color Panels The Problem Solver

PROBLEM POSSIBLE CAUSE

DISHWASHER A fuse in your home may be blown, or the circuit breaker tripped. Replace fuse or

WON’T RUN reset circuit breaker. Remove any other appliances from the circuit.

UNUSUAL NOISE Utensils may not be secure on rack pins, or something small may have dropped from the

rack. Water is causing utensils to rattle. Make sure everything is secured in dishwasher.

DISHES DON’T DRY

Make sure inlet water temperature is correct. (See How to Test Water Temperature section.)

Unload the bottom rack first. Water from dishes in the top rack may be spilling into

the bottom rack.

Make sure the Cycle On light is off, indicating the dry cycle (if selected) is complete.

Check for improper loading. Dishes shouldn’t nest together. Avoid overloading.

Check the rinse agent dispenser to see that it’s not empty.

UNCLEAN DISHES Check inlet water temperature. It should be at least 120°F. (To test, see How to Test

AND FLATWARE Water Temperature section.) Try to use the Temp Boost option.

Water pressure may be temporarily low. Turn on a faucet. Is water coming out slower

than usual? If so, wait until pressure is normal before using your dishwasher.

Plugged air gap. (See Care and Cleaning section.)

Improper rack loading. (See Loading section.)

Choose another cycle to give you longer washing time.

DETERGENT LEFT Water may not be reaching the detergent cups. Move dishes that may be blocking

IN DISPENSER CUPS detergent cup.

The dispenser cover may not be opening or may be blocked by improperly loaded

items. If you used a powder detergent, open the cup and remove any caked-on

detergent. If the cup still doesn’t open automatically, call for service.

Detergent may be old. If the powder detergent is hard or caked in the box, throw it away.

The detergent may not be working well. Try another brand.

DETERGENT CUP Cycle Indicator Dial must be in OFF position and Cycle On light must be off for

LID WON’T LATCH cup lid to close and latch properly. If you unlatch the door and open it to dry your

AFTER ADDING dishes, the Cycle Indicator Dial does not advance by itself.

DETERGENT

YELLOW OR Tea or coffee can stain cups. Remove the stain by hand, using a solution of 1/2 cup

BROWN FILM bleach and 3 cups warm water.

An overall yellow or brown film on dishes or glassware can be caused by iron

deposits in water. A special filter in the water supply line is the only way to correct

this problem. Your water softener company can tell you about the filter.

Yellow film on sterling silver results when you wash copper utensils in the same load.

Silver polish will usually remove this stain.

CYCLE AND OPTION This is normal. Unlatch the door to turn off the Cycle and Energy Option Indicator lights.

INDICATOR LIGHTS NOTE: The Cycle On light will stay on until all cycles are complete. Wait until this

STAY ON WHEN light goes off to unlatch the door or a cycle will be interrupted.

CYCLE IS

COMPLETED

(continued next page)

PROBLEM POSSIBLE CAUSE

Spotting can be caused by all these things:

• Extremely hard water. (See How to Choose and Use Detergent section.)

• Low inlet water temperature. (See How to Test Water Temperature section.)

• Overloading the dishwasher.

• Improper loading. (See Loading section.)

• Old or damp powder detergent.

• Phosphate level in detergent too low. (See How to Choose and Use

Detergent section.)

• Rinse agent dispenser empty. (See How to Use a Rinse Agent section.)

• Too little detergent. (See How to Choose and Use Detergent section.)

Local water conditions and personal preferences vary. Try several brands of

detergents to find one that gives the best results for you. A liquid dishwasher

detergent may help reduce filming.

To remove stubborn spots and film from glassware:

1. Remove all metal utensils from the dishwasher.

2. Do not add detergent.

3. Select POTSCRUBBER cycle.

4. Start the dishwasher and allow to run for 18 to 22 minutes. The dishwasher will

now be in the main wash.

5. Then open the door and pour 2 cups (500 ml) of white vinegar into the bottom of

the dishwasher.

6. Close the door and allow to complete the cycle.

If vinegar rinse doesn’t work: Repeat as above, except use 1/4 cup (60 ml) of citric

acid crystals instead of vinegar. (Most drugstores carry citric acid crystals. If yours

doesn’t, call GE Factory Service.)

Using a vinegar or citric acid crystal rinse more than twice a month? Consider a home

water softener.

CLOUDINESS ON If vinegar or citric acid crystal rinse doesn’t work, the cloudiness is “etching.”

GLASSWARE The film cannot be removed.

It can be prevented: Use less detergent if you have soft water. Wash glassware in

the shortest cycle that will get them clean.

Water temperature entering dishwasher exceeds 150°F.

CHIPPING OF CHINA Rough handling can cause chipping. Load with care. Make sure glassware and china

are secure and can’t jar loose. (See Loading section.) Make sure tall glasses and

stemware will clear the top of the tub when you push the rack into the dishwasher.

Always use the top rack for delicate items.

THE PROBLEM SOLVER

(continued)

SPOTS AND

FILMING ON

GLASSES AND

FLATWARE

PROBLEM POSSIBLE CAUSE

BLACK OR GRAY Aluminum utensils often leave marks when they rub against dishes. Remove marks

MARKS ON DISHES with a mild abrasive cleanser.

SMALL AMOUNT OF Water around the outlet on the tub bottom at the back of the tub is normal. It is clean

WATER STANDING water. It’s there to keep the water seal lubricated.

IN THE BOTTOM

OF THE TUB

WATER WON’T PUMP If the entire bottom of the tub has water, you may have a drain problem. Clean the air

OUT OF THE TUB gap, if you have one. (See Care and Cleaning section.)

Check the kitchen sink. Is it draining well? You may need a plumber.

If dishwasher drains into disposer, run disposer to clear. Be sure disposer is not

clogged.

SUDS IN THE TUB Sudsing detergents are not meant for dishwashers. USE ONLY AUTOMATIC

DISHWASHER DETERGENTS TO AVOID SUDSING.

To remove suds from the tub: Open the dishwasher. Let suds evaporate. Add

1 gallon of cold water to the tub. Close and latch the dishwasher. Pump out water

by slowly turning the control dial until a drain period is reached.

Repeat if necessary.

DISHWASHER Suds can cause unit to overflow. That’s why it’s so important to use a detergent that’s

LEAKS designed for automatic dishwashers.

Spilling the rinse agent can cause foam during washing. This can lead to overflowing.

Wipe up accidental spill of rinse agent with a damp cloth.

MOTOR HUMS Dishwasher has not been used on a regular basis.

If you do not use your dishwasher often, set it to fill and pump out once every week.

This will help keep the seal moist, and the garbage disposer clear.

STAINING OF Some detergents contain colorant (pigment or dyes) that will discolor the tub

TUB INTERIOR interior with extended use. Check the detergent cup for signs of any discoloration.

If cup is discolored, change to detergent without any colorant.

SOUNDS YOU You’ll hear occasional clicking sounds. These are normal.

WILL HEAR • Soft food disposal shredding action.

• Drain valve opening to pump water out.

• Timer control as cycle progresses.

• Detergent cup opening.

During the drying period:

The motor stops.

VAPOR AT Water vapor comes through the vent by the door latch during drying and when

THE VENT water is being pumped out.

If you need more help…call, toll free:

GE Answer Center®

800.626.2000

consumer information service

The Problem Solver

NOTES

IF YOU NEED SERVICE...

To obtain service, see the Consumer Services page.

We’re proud of our service and want you to be

pleased. If for some reason you are not happy with the

service you receive, here are three steps to follow for

further help.

FIRST, contact the people who serviced your

appliance. Explain why you are not pleased. In most

cases, this will solve the problem.

NEXT, if you are still not pleased, write all the

details—including your phone number—to:

Manager, Consumer Relations

GE Appliances

Appliance Park

Louisville, KY 40225

FINALLY, if your problem is still not resolved, write:

Major Appliance Consumer Action Program

20 North Wacker Drive

Chicago, IL 60606

We’ll Be There

With the purchase of your new GE appliance, receive the assurance that if you ever need

information or assistance from GE, we’ll be there. All you have to do is call—toll-free!

Parts and Accessories

800-626-2002

Individuals qualified to service their own appliances

can have parts or accessories sent directly to their home.

The GE parts system provides access to over 47,000

parts…and all GE Genuine Renewal Parts are fully

warranted. VISA, MasterCard and Discover cards

are accepted.

User maintenance instructions contained in this booklet

cover procedures intended to be performed by any user.

Other servicing generally should be referred to qualified

service personnel. Caution must be exercised, since

improper servicing may cause unsafe operation.

Consumer Services

Upon request, GE will provide

Braille controls for a variety of GE

appliances, and a brochure to

assist in planning a barrier-free

kitchen for persons with limited

mobility. To obtain these items,

free of charge, call 800.626.2000.

Consumers with impaired hearing or speech who have

access to a TDD or a conventional teletypewriter may

call 800-TDD-GEAC (800-833-4322) to request

information or service.

In-Home Repair Service

800-GE-CARES (800-432-2737)

A GE consumer service professional will provide expert repair service,

scheduled at a time that’s convenient for you. Many GE Consumer Service

company-operated locations offer you service today or tomorrow, or at your

convenience (7:00 a.m. to 7:00 p.m. weekdays, 9:00 a.m. to 2:00 p.m. Saturdays).

Our factory-trained technicians know your appliance inside and out—so most

repairs can be handled in just one visit.

Service Contracts

800-626-2224

You can have the secure feeling that GE Consumer Service will still be there

after your warranty expires. Purchase a GE contract while your warranty is still

in effect and you’ll receive a substantial discount. With a multiple-year contract,

you’re assured of future service at today’s prices.

For Customers With Special Needs…

800.626.2000

SINGLE CONTROL

FAUCET

TBXTOLITE

ON WALL

6’ 10"

8" 6"

1’ 0"

R SHALLOW DEPTH SINKS (6") WITH REAR DRAIN.

SINK SHOULD ALSO BE UNDERCOATED

2’ 10"

3’ 1/8"

SCALE 1’=1"

SECTION A-A

FLUORESCENT

FIXTURE

THIS LIGHT CAN

BE INSTALLED

IN BOTTOM OF

WALL CABINETS

2’ 6"

GE Answer Center®

800.626.2000

Whatever your question about any GE major appliance, GE Answer Center®

information service is available to help. Your call—and your question—will be

answered promptly and courteously. And you can call any time. GE Answer

Center®service is open 24 hours a day, 7 days a week.

WHAT IS COVERED

FULL ONE-YEAR WARRANTY

For one year from date of original

purchase, we will provide, free of

charge, parts and service labor in

your home to repair or replace

any

part of the dishwasher

that fails

because of a manufacturing defect.

LIMITED SECOND-YEAR PARTS

WARRANTY

For the second year from date of

original purchase, we will provide,

free of charge, replacement parts for

any part of the dishwasher

that fails

because of a manufacturing defect.

You pay for the service trip to your

home and service labor charges.

LIMITED FIVE-YEAR

RACK WARRANTY

For five years from date of original

purchase, we will provide, free of

charge, replacement parts for any

•

rack

that rusts because of a

manufacturing defect

You pay for the service trip to your

home and service labor charges.

FULL TWENTY-YEAR TUB/DOOR

LINER WARRANTY

For twenty years from date of original

purchase, we will provide, free of

charge, parts and service labor in

your home to repair or replace

the

PermaTuf

tub or door liner

if it

fails to contain water because of a

manufacturing defect.

*******************************

This warranty is extended to

the original purchaser and any

succeeding owner for products

purchased for ordinary home use in

the 48 mainland states, Hawaii and

Washington, D.C. In Alaska the

warranty is the same except that it is

LIMITED because you must pay to

ship the product to the service shop

or for the service technician’s travel

costs to your home.

All warranty service will be

provided by our Factory Service

Centers or by our authorized

Customer Care®servicers during

normal working hours.

Should your appliance need

service, during warranty period or

beyond, call 800-GE-CARES

(800-432-2737).

WHAT IS NOT COVERED • Service trips to your home to teach

you how to use the product.

Read your Use and Care material.

If you then have any questions

about operating the product, please

contact your dealer or our

Consumer Affairs office at the

address below, or call, toll free:

GE Answer Center®

800.626.2000

consumer information service

• Improper installation.

If you have an installation problem,

contact your dealer or installer. You

are responsible for providing

adequate electrical, plumbing, and

other connecting facilities.

• Replacement of house fuses or

resetting of circuit breakers.

• Cleaning or servicing of air gap

device in drain line.

• Failure of the product if it is used for

other than its intended purpose or

used commercially.

• Damage to product caused by

accident, fire, floods or acts of God.

WARRANTOR IS

NOT

RESPONSIBLE

FOR CONSEQUENTIAL DAMAGES.

Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion

may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General.

Warrantor: General Electric Company

If further help is needed concerning this warranty, write:

Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225

GSD1821

Part No. 165D4700P072

Pub No. 49-5728

This book is printed on recycled paper.

8-95 CG

YOUR GE DISHWASHER WITH

PERMATUF®INTERIOR

WARRANTY

Staple sales slip or cancelled check

here. Proof of original purchase date

is needed to obtain service

under warranty.

Printed in Louisville, KY

Table of contents

Popular Dishwasher manuals by other brands

Haier

Haier DW12-TFE5 Operation manual

Bosch

Bosch SN61HX04AE INFORMATION FOR USE

Thermador

Thermador TOPAZ DWHD640JFP Use and care guide

Smeg

Smeg DWI612C instruction manual

Frigidaire

Frigidaire Gallery FGBD2431K Specifications

Frigidaire

Frigidaire FDB710LC Factory parts catalog

Electrolux

Electrolux ESL 4115 operating instructions

Whirlpool

Whirlpool Series 960 Use and care guide

Veetsan

Veetsan VDU30 Installation, operation and maintenance

Maytag

Maytag W10438304A User instructions

Candy

Candy CDI 2212 User information

Amica

Amica EGSPU 500 910 E quick start guide

Parmco

Parmco PD6-PSE-2 Installation and operating instructions

Blomberg

Blomberg DW 14110 NBL00 use and care manual

Electrolux

Electrolux ESL 67930 user manual

LG LDT779# series owner's manual

Cosmo

Cosmo COS-DIS6502 installation guide

DCS

DCS DishDrawer DD24DUT7 installation instructions

GE GSD1821 User manual

Popular Dishwasher manuals by other brands
