GE Profile PDWT380RSS Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
PDWT300/380R
GE Profile™Fully Integrated Built-In Dishwasher with SmartDispense™Technology
Specification Created 6/09 250231
Listed by
Underwriters
Laboratories
This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34" to 34-3/4"
Underside
of countertop
to floor
55
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
24
24-3/4*
21-1/4
3-1/2
4" (Adjustable)
33-13/16" MIN.
adj. to 35"
27-1/2
22-1/2
* Allow and additional 2.525" for the handle on
CDWT980 Series models.
Electrical Rating
Voltage AC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 9.9
Calrod®heater watts max........................ 875
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
†† Add 1/2" for deepest part of contour door.
Allow an additional 2” for the handle on
PDWT500/PDWT400/PDWT200 Series
models.

PDWT300/380R
GE Profile™Fully Integrated Built-In Dishwasher with SmartDispense™Technology
Specification Created 6/09 250231
PDWT380RSS
Features and Benefits
• PureCleanwashsystemwith5-stagefiltration-Multiplefiltrationlevelsensure
clean dishes
• ENERGYSTAR®Qualified - Meets or exceeds federal guidelines for energy efficiency for
year-round energy and money savings
• SmartDispense™technology - Holds up to 47 oz of detergent and dispenses it at just
the right time
• DeepClean™cycle with Steam Prewash - Steam helps to loosen tough soils, like eggs,
oatmeal and rice
• Eclipseblacknylondeep-tieredrack-Durableracksaredesignedtoresistrustand
secure dishes
• Electroniccontrolswith4cycles/5options-Moderncontrolsmakeiteasytoprogram
the dishwasher
• QuietPower™51 sound package - 51 dBA - An enhanced sound-deadening system
muffles noises and keeps the kitchen quiet
• Anti-bacterialselection-Cycleraisestemperatureupto151°Ftosanitizedishes,baby
bottles and sippy cups
• ModelPDWT380RSS-Stainlesssteel(shown)
• ModelPDWT300RWW-Whiteonwhite
• ModelPDWT300RBB-Blackonblack
