Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
As an ENERGY STAR®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Created 6/09 350202
Panel
Thickness
Kit ABC
GPF325 18-7/8" 23-9/16" 3-11/16" 1/4"
GPF375 18-15/16" 23-5/8"* 4-1/4" to
3-3/4"**
3/4"
Listed by
Underwriters
Laboratories
This wall area
must be free of
pipes or wires
Countertop
4
6
Hot
water
line on
left
44
2Plumbing and electrical
service must enter
inside shaded area
24" From wall
24" MIN.
90°
19" MIN. from wall
24"
MIN.
6
34" to 34-3/4"
Underside
of countertop
to floor
55
90°
Electrical
wiring on
right
Electrical
wiring is
3" from
cabinet
24
25-3/4
MAX.
21-1/2
3-1/4 4 (Adjustable)
34 MIN.
adj. to 35
24-3/4
23-3/8
B
Access insert
Door insert A
C
Models/Kits A B C Thickness
GE Models
GPF325 Kit 18-7/8” 23-9/16” 3-11/16” 1/4”
GPF375 Kit 18-15/16” 23-5/8”* 3-3/4”** 3/4”
*Bottom of panel must be notched 1-1/2"x1/2" to clear
across panel
**Adjustment required to match adjcent cabinets fronts due to
leveling leg adjustment, 4" nominal.
4-1/4" to
Electrical Rating
Voltage AC.......................................................... 120
Hertz..................................................................... 60
Total connected load amperage............. 6.2
Calrod® heater watts max........................ 500
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Note: Dishwasher must not be installed
more than 10 feet from sink for proper
drainage. All plumbing and electrical work
must be in accordance with local codes.
GSD2300/2301/2350R
GE®Built-In Dishwasher
* Bottom of panel must be notched 1-1/2" x 1/2" to clear across panel
** Adjustment required to match adjacent cabinet fronts due
to leveling leg adjustment, 4" nominal

Features and Benefits
• 4-level PowerScrub™wash system - Precision water jets and hot temperatures
power away tough food stains
• ENERGY STAR®Qualified - Meets or exceeds federal guidelines for energy efficiency
for year-round energy and money savings
• Piranha™hard food disposer - This disposal grinds food into tiny particles that are
easily washed away
• HotStart™option - Ensures that water temperatures remain consistent from the
beginning of a cycle to the end
• Electronic controls with 5 cycles/2 options - Modern controls make it easy to
program the dishwasher
• Two-stage filterationwithExtraFine filter - extra filteration keeps water clean
• Pots and Pans cycle - Tough food stains are scrubbed and scoured clean with ease
• Model GSD2300RWW - White on white
• Model GSD2300RBB - Black on black
• Model GSD2301RWW - White on white, has power cord attached
• Model GSD2301RBB - Black on black, has power cord attached
• Model GSD2350RCS - CleanSteel™
Specification Created 6/09 350202
GSD2300/2301/2350R
GE®Built-In Dishwasher
™
• Model GSD2340RSA - Silver Metallic
