GE GSD1125 User manual

Useand&re Guide
Dishwasher
❑
!
Safe~ instructions .........................3
❑
Operating Instructions, Tips
ApplianceRegistration..................................2
China,Crystal,Sterling...............................10
CycleFeatures.................................................4
Detergent Guide ......,......................................5
DispenserCups...............................................7
Drying Options ...............................,................4
Energy-Saving Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Features ........................................................4, 5
Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ........................8, 9
Operatinginstructions.................,............4,5
Rinse
Agent......................................................6
WaterTemperature........................................6
❑
~~;: Care and Cleaning
Air Gap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
❑
●
Problem Solver ......,................13-15
More questions
?..,call
GE Answer Center” 800.626.2000
❑
Preparation
Front Panel Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
H
Q
Consumer Services .............,.....l 9
Model and Serial Numbers .................,......,.2
RepairService.................................................2
Warranty........................................BackCover
I
~ Model GSDl125
Winter Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GE Appliances

~LP US ~LP YOU...
Before using your
dishwasher, read this
guide carefully.
It is intended to help you
operate and maintain your new
dishwasher properly.
Keep it handy for answers to
your questions.
If you don’t understand something
or need more help, write (include
your phone number):
If you received
a damaged dishwasher...
Immediately contact the dealer
(or builder) that sold you the
dishwasher.
Save time and money.
Before you request
service . . .
Check the Problem Solver in the
back of this guide. It lists causes
of minor operating problems that
you can correct yourself.
Consumer Affairs
GE Appliances
Appliance Park
Louisville, KY 40225
To obtain a Spanish language
Para obtener la versi6n en
version of this book, call Espafiol de este manual,
GE Answer
Center@
name a
800.626.2000 GE Answer Center,”
consumer information service.
servicio de information
para el consumidor,
telifono 800.626.2000.
Write down the model
and serial numbers.
You’ll find them on a label
fastened to the tub wall just
inside the dishwasher door.
These numbers are also on the
Consumer Product Ownership
Registration Card that came
with your dishwasher. Before
sending in this card, please write
these numbers here:
Model Number
Serial Number
Use these numbers in any
correspondence or service calls
concerning your dishwasher.
m YOU NEED SERVICE...
To obtain service, see the Consumer Services page in
the back of this guide.
We’re proud of our service and want you to be
pleased. If for some reason you are
not happy with the
service you receive, here are three steps to follow for
further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased. In most
cases, this will solve the problem.
2
NEXT, if you are still not pleased, write all the
details—including your phone number—to:
Manager, Consumer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
FINALLY, if your problem is still not resolved, write:
Major Appliance Consumer Action Panel
20 North
Wacker Drive
Chicago, IL 60606

A
WARNING—When using this
appliance, always exercise basic
safety precautions, including the
following:
● Use this appliance only for iti intended purpose,
as you will find described in this
Use and Care
Guide.
a
● This dishwasher must be properly
\Q i:’ ~
installed and located in accordance
+ + ,.
with the Installation Instructions
.. *.
before it is used. If you did not
receive an Installation Instructions sheet with your
dishwasher, you can obtain one by calling, toll
free, the GE Answer Center? 800.626.2000.
—This appliance must be connected to a grounded
metal, permanent wiring system; or an
equipment-grounding conductor must be run
with the circuit conductors and connected to
the equipment-grounding terminal or lead of
the appliance.
—Connect to a properly rated, protected and sized
power-supply circuit to avoid electrical overload.
s
● Do not store or use combustible
materials, gasoline or other
. . .
flammable vapors and liquids
●
●
●

in the vicinity of this or an~ other appkance.
Use only powder or liquid detergents or wetting
agents recommended for use in a dishwasher.
Do not wash plastic items unless marked
“dishwasher safe” or the equivalent. For plastic
items not so marked, check the manufacturer’s
recommendations.
Load light plastic items so they will not become
dislodged and drop to the bottom of the
dishwasher—they might come into contact with
the Calrod@ heating element and be damaged.
To minimize the possibility of injury.
● When loading items to be washed:
A. Locate sharp items so that they are not likely
to damage the door seal, and
B. Load sharp knives with the handles up to
reduce the risk of cut-type injuries.
● Do not tamper with controls.
c Do not touch the Calrod@heating element during or
immediately after use.
● Do not operate your dishwasher unless all enclosure
panels are properly in place,
● Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.
● Close supervision is necessary if this appliance
is used by or near children. Do not allow children
to play inside, on or with this appliance or any
discarded appliance. Dispose of discarded
appliances and shipping or packing material
properly. Before discarding a dishwasher, remove
the door of the washing compartment.
. Keep all washing detergents and wetting agents
out of the reach of children, preferably in a locked
cabinet. Observe all warnings on container labels
to avoid personal injury,
#a
● To minimize the possibility of
/.
electric shock, disconnect this
/“
appliance from the power supply
before attempting any maintenance. NOTE:
Turning the control dial to the OFF position
does not disconnect the appliance from the
power supply. We recommend having a qualified
technician service your aW1iance.
A
WARNING—HYDROGEN GAS is
produced by the chemical action
within your water heater. It can
accumulate in the water heater andor
water pipes if hot water has not been used for a
period of two weeks or longer. HYDROGEN GAS
IS EXPLOSIVE. To prevent the possibility of
damage or injury, if you have not used hot water
for two weeks or more, or moved into a residence
in which the hot water system may not have been
used for some time, turn on all hot water faucets
and allow them to run for several minutes before
using any electrical appliance which is connected
to the hot water system. This will allow any
hydrogen gas to escape. Also, since the gas is
flammable, do not smoke or use an open flame
or appliance during this process.
SAVE THESE
INSTRUCTIONS
n

HOW TO OPERATE YOUR DISHWASHER
STEP 1. Load your dishwasher with dishes, silverware,
pots, pans. bowls, etc., according to the Loading section.
STEP 2. Add detergent to the detergent dispenser.
Make sure the Cycle Indicator Dial is at OFF position
before adding detergent. (See Detergent Guide.)
Use rinse
aid agent to help prevent spotting.
Occasionally check to insure that rinse agent container
is
a[ least half full. (See How to Use a
Rinse Agent section. )
STEP 3. Select drying option.
HEATED DRY. Turns the drying
heater on
for fast drying.
ENERGY SAVER (No Heat Boost).
Turns the
drying heater off to save
❑
H:~\ED Ef:;::
,.,.-,80,$.,
En
energy. Dishes will dry naturally over a longer period
such as overnight,
If you need your dishes sooner, open the dishwasher
door after the cycle is complete to reduce the natural
drying time.
NOTE: The ENERGY SAVER option will also cancel
the WASH HEAT BOOST. To obtain WASH HEAT
BOOST without HEATED DRY, select only the WASH
HEAT BOOST option. (See Energy-Saving Tips.)
STEP 4. WASH HEAT BOOST Option.
See How to Test Water Temperature
section.
The entering water must be between 120°F.
and 140°F. Use the wash heat boost option
n
W);~~;AT
u
when water is less than 140°F.
When selected, the wash cycle will be extended for 21
minutes while the dishwasher heats the water for good
washing and drying.
STEP 5. Select the wash cycle and start the dishwasher.
(See Cycle Selection Hints.)
[f your dishwasher drains into a food waste disposer,
operate the disposer until it is empty before starting the
dishwasher.
● When NOT using DELAY START (for all cycles):
a. Be sure door is unlatched.
b. Push selected cycle button.
c. Push selected option button.
d. Slowly turn Cycle Indicator ,J**
Dial to START.
Cm)
.START
.
WASHING
OFF ●
e,
.
,
and water fill so you will not hear any wash action
right away.
● When using DELAY START (for all cycles):
NOTE: START can be delayed automatically for up to
6 hours.
a. Be sure door is unlatched.
b. Push selected cycle button.
c. Push selected option button.
d. Slowly turn Cycle Indicator ,’ ,,
Dial to desired delay time.
OFF ●
e. Latch door to start timer.
DRYING ●
The DELAY START light
Q
.sTAm
WASHING
@
—-
●
will come on and stay on
RINSING
until dishwasher starts. Dishwasher will start
automatically at end of selected delay time.
Cycle Selection Hints
It is important to
follow the Loading instructions.
● POTSCRUBBER—For items such as pots, pans and
casseroles with dried-on or baked-on soils. Everyday
dishes may be included.
● NORMAL WASH—For loads of everyday dishes,
glasses and cookware with medium soils. Designed
to yield high performance on normal soils.
● WATER SAVER—For most loads of everyday
dishes with light soils or soils that have not dried
on. Also for everyday dishes that have had extra
preparation before loading.
● RINSE & HOLD—For rinsing partial loads which
will be washed later. Do not use detergent. Delay
Start is not recommended for this cycle.
4

What Happens in Each Cycle
● You’11 hear occasional clicking sounds:
c During the drying period:
—Soft food disposer shredding action. —The motor stops.
—Drain valve opening to pump water out.
— Water vapor comes through the vent by the door
—Timer control as cvcle ~ro~resses.
latch during drying and when water is being
.,”
—Detergent cup opening.
pumped out.
Wash Cycle
Water Use Time
Gallons
Minutes
Wash Cycles
(appl”ox.) (approx. ) Cycle Sequence
POTSCRUBBER
11.4
65*
mmmmmmm
NORNIAL WASH
11.4 50*
mmmmmmm
WATER SAVER
8.2
5~:k
mmmmm
RINSE & HOLD
3.1
9
mm
*Unextended times. These cycle times will be increased approximately 2 I minutes if WASH HEAT BOOST Option
is selected.
Drying Options:
HEATED DRYING. Available on all wash cycles except RINSE& HOLD. Add 32 minutes to wash cycle time.
ENERGY SAVER (No Heat Boost) Drying heater is turned off. Dishes dry naturally.
Energy-Saving Tips
● Operate dishwasher only when it’s full. Let the
dishes accumulate in dishwasher. When you put in
only a partial load, use the RINSE & HOLD
cycle to
rinse off heavy soils. Be sure to latch the door when
waiting for a full load. This helps keep soils moist,
easier to remove.
● If you don’t need your dishes right away, use your
ENERGY SAVER no-heat boost drying feature
that turns the drying heater off automatically. Dishes
dry naturally over a longer period such as overnight.
● Always select the cycle that uses the least amount
of water that will remove the soil from the load.
(See the Operating section.)
● Turn your water heater down to deliver 120°F.
water to your dishwasher and use the WASH HEAT
BOOST Option. Make sure the entering water
temperature is no less than
120°F. (See How to Test
Water Temperature section).
Good Dishwashing Starts with HOT Water
To get dishes clean and dry, you need hot water. To help you get water of the
proper temperature, your dishwasher has a WATER HEAT BOOST feature.
When selected (see Operating section), this water heating feature allows you
to turn down your household water heater and save energy if you’re willing to
let the dishwasher run a little longer while it heats water. For good washing
and drying, the entering water must be between 120°F. and 140°F. To prevent
dish damage, inlet water shodd not exceed
150°F.
5

How to Test Water Temperature
Higher water temperature is needed to dissolve grease
and activate powder detergents. If the water temperature
is less than
140°F., use the WATER HEAT BOOST
option. See WATER HEAT BOOST section.
Check your water temperature with a candy or meat
thermometer. Turn on the hot water faucet nearest
the dishwasher. Put the thermometer in a glass and
let the water run continuously into the glass until the
temperature stops rising. If the water temperature is
below
120°F., adjust your water heater.
Helpful hints: If outside temperatures are unusually
low, or if your water travels a long distance from water
heater to dishwasher, you may need to set your water
heater’s thermostat up. If you have not used hot water
for some time, the water in the pipes will be cold. Turn
on the
hot water faucet at the sink and allow it to run
until the water is hot. Then start the dishwasher. If
you’ve recently done laundry or run hot water for
showers, give your water heater time to recover before
operating the dishwasher.
To improve washability if the water is less than 120°F.
and you cannot adjust your water heater: Select a longer
cycle and fill both detergent cups at least half-full with
detergent.
How to Use a Rinse Agent
The rinse agent makes water flow off dishes quicker
than usual. This lessens water spotting and makes
drying faster, too.
For best dishwashing performance, use of a rinse agent
such as JET-DRY brand is recommended.
Rinse agents come in either liquid or solid form. Your
dishwasher uses the liquid form.
How to fill the rinse agent dispenser.
“,
l-w I 11!,!,19
Unscrew the cap. Add liquid rinse agent
r
until it just reaches the bottom of the lip
d
II ~
inside the dispenser opening. Replace the 1;
cap. The dispenser automatically releases
\
the rinse agent into the final rinse water.
FULL
Your dishwasher’s rinse agent container holds 4 X
ounces. This should last about 3 months. Fill as
needed. Do not overfill,
If you accidentally spill: Wipe up the rinse agent with
a damp cloth. Don’t leave the spill in the dishwasher. It
can keep your detergent from working.
If you can’t find any rinse agent, write:
BENCKISER CONSUMER PRODUCTS, INC.
(“JET-DRY”)
Corporate Centre I
55 Federal Road
P.O. Box 1991
Danbury, CT 06813-1991
How to Choose and Use the Right Detergent
First, use only powder or liquid
detergent specifically made for
use in dishwashers. Other types
will cause
oversudsing.
Second, check the phosphate
content. Phosphate helps prevent
hard-water materials from forming
spots or film on your dishes. If your
water is hard (7 grains or more),
your detergent has to work harder.
Detergents with a higher phosphate
level will probably work better. If
the phosphate content is low (8.7%
or less), you’ll have to use extra
detergent with hard water.
Your water department can tell
you how hard your water is. So
can your county extension agent or
your area’s water softener company.
Just call and ask them how many
“grains”
of hardness there are in
your water.
How much detergent should you
use?
That depends. 1s your water
“hard” or “soft’”? With hard water,
you need extra detergent to get
dishes clean. With soft water, you
need less detergent.
Too much detergent with soft water
not only wastes money, it can be
harmful. It can cause a permanent
cloudiness of glassware, called
“etching.” An outside layer of glass
is etched away! Of course, this takes
some time. But why take a chance
when it’s easy to find out the
hardness of your water.
6

Keep your detergent fresh and
dry. Under the sink isn’t a good
place to store detergent because there
is too much moisture. Don’t put
powder detergent into the dispenser
until you’re ready to wash dishes,
either. (It won’t be fresh OR dry.)
If your powder detergent gets old
or lumpy, throw it away. Old
detergent often won’t dissolve. If
you use a liquid dishwasher
detergent, these precautions are not
necessary because liquid detergents
don’t “lump” as they age or come
in contact with moisture.
You’ll find two detergent
dispensers on the inside door
of your dishwasher.
There are
two because some cycles use
two washes.
See “Detergent Usage
Guide” below. ~P~~ ~“P
~f
/
(Be sure the
CYCLE
INDICATOR
4
i!
DIAL is at
o~
‘o,
OFF position
before
/
~\
MAIN CUP
adding detergent.
Otherwise, the detergent cup will not
close and latch properly.)
Close the main cup.
NOTE: To open the detergent cup
after it has been closed, unlatch the
door and rotate the Cycle Indicator
Dial a
full turn to the OFF
position. When the
/
in a partially
GRASP HANDLE,
open position
ROTATE AND
before rotating the cLosE ‘lGHTLY
C~cle Indicator Dial. This will help
reduce the amount of detergent and
rinse aid agent spillage into the tub.
Detergent Usage Guide (powder or liquid)
SOFT WATER MEDIUM WATER HARD WATER
(0-3 grains hardness) (3-7 grains) (7-12 grains*)
CYCLES Main Cup Open Cup
Main Cup
Open Cup Main
Cup$ Open Cup*
POTSCRUBBER
Half Full Half Full Completely +
Half Full Completely Completely
NORMAL WASH
+
Full
Full
+ Full
WATER SAVER Half Full None Half Full None Completely None
Full
RINSE & HOLD Use no detergent Use no detergent Use no detergent
* 12 grains and up is extremely hard water. A water softener is recommended. Without it, lime $Filled Main Cup holds 3 tablespoons;
can build up in the water valve. The water valve may stick while open and cause tlooding.
Filled Open Cup bolds 2 tablespoons.
How to Prepare the Dishes for Washing
If this is your first dishwasher, or if you’re replacing
a much older model, you may wonder how much
preparation your dishes need. Actually very little.
Pre-rinsing of normal food soils is not necessary. With
common sense and a little practice you’ll soon know
what foods to remove. Here are some guidelines:
1. Scrape off bones, seeds, skins, toothpicks and other
hard solids. It is also best to remove hard-shelled
vegetables, meat trimmings, leafy vegetables and
crusts. Remove excessive quantities of oil or grease.
2. Remove large quantities of any food. Your
dishwasher has a built-in soft food disposer that
pulverizes soft food bits and flushes them away.
It can handle small amounts of soft foods, but
large amounts will be difficult to handle.
3. Try to remove food scraps and place dishes in
dishwasher before soil has a chance to dry and
become hard. Dishes with dried-on soil are more
difficult to wash and may not come clean in the
NORMAL WASH cycle. Remember to use your
RINSE & HOLD cycle for small “holding” loads.
NOTE: The foods mentioned are examples only.
Other foods not mentioned may
also need to be
removed from your dishes. You may also want to
consider removing foods such as mustard, mayonnaise,
vinegar, lemon juice and other foods that can cause
discoloration of stainless steel if allowed to remain
on dishes for a long period of time.
When using the POTS & PANS cycle, less preparation
is required before loading. The POTS & PANS cycle
can wash heavily soiled dishes
and remove dried-on
and baked-on soils from pots, pans and casseroles.
Items with burned-on soils may not come clean, and
the dishwasher cannot remove burn marks or restore
fading caused by over heating during cooking.
7

HOW TO LOAD YOUR DISHWASHER
Make sure dishes are properly loaded to insure that
water
can reach the soiled surfaces. The wash arm in
the bottom sprays water up. The tower that rises in the
center sends water out over the dishes to wash the
items in the upper rack. A spray arm in the top washes
down also. Make sure to place tall items to the outside
so the upper wash arm is not blocked.
WATCH OUT FOR THIS.
The washer tower rises through the center of the bottom
rack during the wash and rinse portions
of the cycle.
Don’t block it or
load tall things next to it. Also, be
careful not to let a portion of an item such as a pot or
dish handle extend through the bottom rack. This could
block the wash arm and cause poor washing results.
HOW TO LOAD T
Below is the special upper rack that comes with
this model.
8
HE TOP RACK
The top rack is best for glasses, cups and saucers. Cups
and utensils can be washed when using the folding
shelves. Load the bottom row first, then fold down the
shelf and load the top row. Cups and glasses fit best
along the sides. This is the place
for dishwasher-safe
plastics, too. Make sure small plastic items are lodged
in tightly so they can’t fall onto the Cal rod” heating
element. Arrange stemware so that it cannot move
easily. Don’t let the glasses touch each other.
Sauce pans, mixing bowls and other small items may
be placed—face down—in the top rack. The top rack is
handy for all kinds of odd shapes. Be sure the force of
water and detergent can reach
soiled surfaces.

HOW TO LOAD THE BOTTOM WCK
Fit plates and saucers between the pins. Load platters,
pots and bowls along the sides, in corners or in the back.
As shown here this plate is being placed with the soiled
side facing the center of the rack so water and detergent
from wash arm can reach soiled surfaces.
Heavily soiled pots, pans and casseroles MUST be
loaded in the bottom rack, facing down. Prop broiler
pans and racks along the edge.
,-
Don’t let any item
-b
extend through
Put flatware in the removable basket with handles up to
protect your hands. Mix knives, forks and spoons so they
don’t n;st together. Distribute evenly. Small plastic
item”s,
such as measuring spoons and lids from small containers,
are not recommended for automatic
dishwashing. If
placed in the dishwasher, they should go in the bottom of
silverware basket with silverware on top.
Precaution!
Take out anything that may fall or extend through the
bottom of the basket.
9

W~T YOU CAN USUALLY WASH SAFELY
IN YOUR DISHWASHER.
Usually
SafeMaterial
Exceptions (not safe) Special Instructions
Aluminum
YES
YES
Some coloredanodized
aluminum can fade.
Antique, metal-trimmed,
hand-painted or over-the-glaze
patterns fade. Gold leaf
will discolor.
Antique, metal-trimmed or
hand-painted patterns
fade,
Gold leaf will discolor.
Some darkening or spotting possible. Remove by
scouring with soap-filled steel wool pads.
If in doubt, check with the manufacturer. Or test wash
one piece daily
fur at least a month. Compare with the
rest of the set.
Load securely to prevent movement, Check your
manufacturer’s instructions for your crystal.
Chinti
Stoneware
YES
Crystal
Non-dishwasher
items—such
as electronic
air cleaner
filters, furnace
filters, paint
brushes, etc.
Glass
NO
Do not wash in dishwasher, Damage to dishwasher
and discoloration or staining of dishwasher may result
YES Milk glass may yellow.
Iron NO
Iron will rust.
Pewter
NO
YES
Pewter tarnishes.
[fit doesn’t say DISHWASHER SAFE, test one piece in
the top rack before dishwashing an entire set.
Plastics
Stainless steel
YES
Rinse if not washing immediately. Salty or acid foods
can stain if left on.
Sterling Silver
and Silver plate
YES Don’t put in same silverware
basket with stainless steel.
Contact between metals can
damage silver.
Don’t wash copper utensils in
the same
load. Silver may get a
brown film.
Adhesive used to attach some
hollow-handle knives can loosen.
Rinse if not washing immediately. Salty or acid foods can
stain if left on. Dry detergent can cause difficult-to-remove
black spots. Place in back section of silverware basket to avoid
exposure to detergent from the detergent cup.
Non-stick
coatinzs
YES After washing, wipe the non-stick coating area with
vegetable oil
to keep it from losing its non-stick quality,
Tin
NO
Tin can rust.
Wood NO
Wood can warp, crack or lose
its finish with any type of washing.
Forget a dish? Here’s when you can add it.
Add dishes any time during the RINSE & HOLD
cycle. With other wash cycles, you
can add dishes
at any time BEFORE the main detergent wash portion
of the cycle.
However, opening the door during any cycle lessens
cleaning power, So try to load everything at the
beginning.
Here’s how to add a forgotten dish:
1. Push the door latch to the left. Washing will stop.
2. Wait a few seconds until the water calms. Then
open the door. WARNING: Hot vapor may rise
from opened door.
3. Add dishes you’ve forgotten.
4. Close the door and push the latch to the far right.
When the door is locked, washing will continue.
10

USER MAINTENANCE INSTRUCTIONS
Clean the control panel with a lightly dampened Appliance Polish Wax & Cleaner (Cat. No.
cloth. Dry thoroughly. Do not use abrasives or
WR97X0216) is available from GE Appliance
sharp objects on the panel. They can damage it.
Parts Marts.
Clean the outside with a good appliance polish The inside usually takes care of itself. If it should
wax. The outside cabinet finish is durable, but it ever need cleaning, use a mild cleansing powder.
can scratch. So use no scouring pads, or harsh or Scouring pads and harsh cleaners can mar the finish.
gritty cleaners.
Not Using Your Dishwasher in Winter? Protect Against Freezing.
If your dishwasher is left in an
unheated place during the winter,
ask a service technician to:
● Cut off electrical power to the
dishwasher. Remove fuses or trip
circuit breaker.
● Turn off the water supply.
● Disconnect the water inlet line
from the water valve.
● Drain water from the inlet line
and water valve. (Use a pan to
catch the water.)
PUMP COVER SCREWS
● Reconnect the water inlet line to
the water valve.
● Drain the collection chamber at
rear of unit below filter by
disconnecting hose to pump.
Reconnect after draining.
● Remove the plastic pump cover
in the tub bottom and use a
sponge to soak up water in
the rubber boot.
Built-in Dishwashers Often Use an Air Gap. Keep It Clean.
An air gap is a plumbing device.
It protects your dishwasher against
water backing up into it if a drain
clogs. The air gap is not a part of
the dishwasher. And you may not
even have one. Not all plumbing
codes require air gaps.
Check the air gap any time your
dishwasher isn’t draining well.
,i
TWO TYPES OF AIR GA~~
@j: ~~
1
;.lf. l!
r7_,. ~
(~, y: ~
,+:, ); ;
~ ..—-—- -- “. >..-=:-
- —.T..—. :—--:———..—..-:--- .
a. —
—+. . .
— ,-. . ~—:. :.:..— -.
s%
———. .
——. —.. -
—— . . .
.,———–. –
-=.—.—
.– –..=. - -
... -,
If you have an air gap, check it at
least once a month. IT IS NOT
PART OF YOUR DISHWASHER.
IT IS NOT COVERED IN YOUR
WARRANTY.
The air gap is easy to clean.
With most types, first turn off the
dishwasher, then lift off the chrome
cover. Then unscrew the plastic cap
and check for any buildup of grit.
A toothpick makes cleaning easy.
11

If you are
redecorating, you
can change your
dishwasher’s front
panels to match or
blend with your
new colors.
The panels are
held in place by
the door trim and
the trim on the panel
HOW TO CHANGE COLOR PANELS
below the door. Each side of each
panel is a different color. Or you can paint a panel with
the color of your own choice.
How to change door panel insert:
1. Take out trim screws on either side of the dishwasher
door. Remove the side trim.
2. Slide out the insert panel.
3. Put the color you want in front. (Careful—edges may
be sharp.)
4. Replace the insert panel, side trim and screws.
How to change lower panel insert:
1. Remove panel attachment screws.
2. Remove the entire panel.
3. Take out screws and remove the top trim.
4. Slide out the insert panel.
5. Put the color you want in front.
6. Replace the insert panel, top trim and screws.
7. Replace the entire panel and attachment screws.
Color insert panels for both the door and the lower
panel can be replaced by 1/4” thick wood inserts to
match your kitchen cabinets. Get them from your
nearest cabinet or lumber dealer.
Dimensions for 1/4” wood inserts:
Door Panel: 19X” H X 23Yc” W.
Lower Panel: 3’X~” H X 23 X,” W.
NOTE: Do not operate dishwasher while changing
panels or when lower access panel is removed.
12

PROBLEM
DISHWASHER
WON’T RUN
UNUSUAL NOISE
DISHES DON’T DRY
UNCLEAN DISHES
AND FLATWARE
DETERGENT LE~
IN DISPENSER CUPS
DETERGENT CUP
LID WON’T LATCH
A~ER ADDING
DETERGENT
YELLOW OR
BROWN FILM
POSSIBLE CAUSE
A fuse in your home maybe blown, or the circuit breaker tripped. Replace fuse or
reset circuit breaker. Remove any other appliances from the circuit.
Utensils may not be secure on rack pins, or something small may have dropped from
the rack. Water is causing utensils to rattle. Make sure everything is securely placed
in dishwasher.
Make sure inlet water temperature is correct. (See How to Test Water Temperature
section.)
Unload the bottom rack first. Water from dishes in the top rack maybe spilling into
the bottom rack.
Check for improper loading. Dishes shouldn’t nest together. Avoid overloading.
Check the rinse agent dispenser to see that it’s not empty.
Check inlet water temperature. It should be at least
120°F. (To test, see How to Test
Water Temperature section.)
Water pressure may be temporarily low. Turn on a faucet. Is water coming out slower
than usual? If so, wait until pressure is normal before using your dishwasher.
Plugged air gap. (See Care and Cleaning section.)
Improper rack loading. (See Loading section.) ‘“’
Water may not be reaching the detergent cups. Move dishes that maybe blocking
detergent cup.
The dispenser cover may not be opening or may be blocked by improperly loaded
items. If you used a powder detergent, open the cup and remove any caked-on
detergent. If the cup still doesn’t open automatically, call for service.
Detergent may be old. If the powder detergent is hard or caked in the box, throw it
away. The detergent may not be working well. Try another brand.
Cycle Indicator Dial must be OFF for cup lid to close and latch properly. If
you
unlatch the door and open it to dry your dishes, the Cycle Indicator Dial does
not advance by itself.
Tea or coffee can stain cups. Remove the stain by hand, using a solution of 1/2 cup
bleach and 3 cups warm water.
An overall yellow or brown film on dishes or glassware can be caused by iron
deposits in water. A special filter in the water supply line is the only way to correct
this problem. Your water softener company can tell you about the filter.
Yellow film on sterling silver results when you wash copper utensils in the same load.
Silver polish will usually remove this stain.
(cc]nlinued ntxt IIcIge)
13

THE PROBLEM SOLVER
(continued)
PROBLEM
SPOTS AND
FILMING ON
GLASSES AND
FLATWARE
CLOUDINESS ON
GLASSWARE
CHIPPING OF CHINA
POSSIBLE CAUSE
Spotting can be caused by all these things:
c Extremely hard water. ( See How to Choose and Use Detergent section.)
● Low inlet water temperature. (See How to Test Water Temperature section.)
. Overloading the dishwasher.
● Improper loading. (See Loading section.)
● Old or damp powder detergent,
● Phosphate level in detergent too low. (See How to Choose and Use Detergent
section.)
● Rinse agent dispenser empty. (See How to Use a Rinse Agent section.)
● Too little detergent. (See How to Choose and Use Detergent section. )
Local water conditions and personal preferences vary. Try several brands of
detergents to find one that gives the best results for you. A liquid dishwasher
detergent may help reduce filming.
To remove stubborn spok and film from glassware:
1. Remove all metal utensils from the dishwasher.
2. Do not add detergent.
3. Select POTSCRUBBER cycle.
4. Start the dishwasher and allow to run for 18 to 22 minutes. The dishwasher will
now be in the main wash.
5. Then open the door and pour 2 cups (500 ml) of white vinegar into the bottom of
the dishwasher.
6. Close the door and allow to complete the cycle.
If vinegar rinse doesn’t work: Repeat as above, except use 1/4 cup (60 ml) of citric
acid crystals instead of vinegar. (Most drugstores carry citric acid crystals. If yours
doesn’t, call GE Factory Service.)
Using a vinegar or citric acid crystal rinse more than twice a month? Consider a home
water softener.
If vinegar or citric acid crystal rinse doesn’t work, the cloudiness is “etching.”
The film cannot be removed.
It can be prevented: Use less detergent if you have soft water. Wash glassware in
the shortest cycle that will get them clean.
Water temperature entering dishwasher exceeds 150°F.
Rough handling can cause chipping. Load with care. Make sure glassware and china
are secure and can’t jar loose. (See Loading section.) Make sure tall glasses and
stemware will
clear the top of the tub when you push the rack into the dishwasher.
Always use the top rack for delicate items.
14

PROBLEM
BLACK OR GRAY
MARKS ON DIS~
WATER WON’T PUMP
OUT OF THE
~B
SUDS m THE TUB
DISHWAS~R
LEAKs
MOTOR -S
POSSIBLE CAUSE
Aluminum utensils often leave marks when they rub against dishes. Remove marks
with a mild
abrasivs cleanser.
Water around the outlet on the tub bottom at the back of the tub is normal. It is clean
water.
It’s there to keep the water sed lubricated.
If the entire bottom of the tub has water, you may have a drain problem. Clean the air
gap,
if you have one, (See Care and Cleaning section.)
Check
the kitchen sink, Is it draining well? You may need a plumber.
If dishwasher drains into disposer, run disposer to clear. Be sure disposer is not
clogged.
Sudsing detergents are not meant for dishwashers. USE ONLY AUTO~~C
DISHWASHER DETERGENTS TO AVO~ SUDSING.
~ remove suds fmm the tub: Open the dishwasher. Let suds evapora@. Add 1 gallon
of cold
water to the tub. Close and latch the dishwasher. Pump out water by slowly
turning the control did until a drain period is reached.
Repeat if necessary.
Suds can cause unit to oveflow. That’s why it’s so important to use a detergent that’s
designed for automatic dishwashers.
Spilling the rinse agent can cause foam during washing. This can lead to oveMowing.
Wipe up accidenti spill af rinse agent with a damp cloth.
Dishwasher has not &n used on a regular basis.
If you’do not use your dishwasher often, set it to ml and pump out once every week.
This
wMI help keep be sed moist, and the garbage disposer clear.
Some
deterg~nts contain colorant Qigment of dyes) that wfll &scoior the tub
interior with
extenW use. Chink the detrgent cup for signs of any discoloration.
If cup is discolored, change to detergent without any colorat.
If you need more help... call, toll free:
GE Answer
Center@
800.626.2000
consumer information service
15

NOTES
16

NOTES
17

NOTES
18

We’ll Be There
With the purchase ofyour new GE appliance, receive the assurance hat ifyou ever need
information or assistance from GE, we’ll be there. All you have to do is call—toll-free!
/mHome Repair Service
80MEXARES(80M32-2737)
AGE consumer service professional will provide expert repair service, sched-
uled at a time that’s convenient fi)r you. Many GE [lonsurner Service company-
operat.ed locations off-er you service today or tomorrow, or at your convenience
(7:00 a.m. to 7:00 p.m. weekdays, 9:00 a.m. to 2:()() p.m. Saturdays). Our factoq-
trained technicians know your appliance inside and out-so most repairs can be
handled in,just one visit.
GEAnswer Cente~
80~6262000
Whatever your question about any GE major appliance, GE Answer Genter@
information service is available to help. Your call—and your question—
witl be
answered promptly and courteously. And you can call any time. GE Answer
CenLer@ service is open 24 hours a day, 7 days a week.
S,CTIONA.A
-,.-. -a s,”.. ,.., -”.... m..
..--,.., -”.”......7,. s... ,.,
kr Customers With Special Needs...
80~6262000
Upon request, (;F. will provide
(;onsumers with impaired hearing or speech who have
13raille controls for a variety of” GE access to a TDD or aconventional teletypewriter may
aP~li~nces, arid a brochure t. call 800-TDD-GEAC (800-853-4322) to request informa-
asslsl In planning a barrier-free tion or service.
kitchen
f’or persons with limited
mobility. To obtain these items,
fi-ee of’charge, call 800.626.2000.
Service Contracts
80M2&2224
You can have the secure feeling I hat (1E (;onsumer Service will still be there
after your warranly expires.
~’ur’chase a (;E contract while your warranty is still
in eff’ect and you’ll receive a substantial discount. With a multiple-year contract,
you’re assured of’ future service at today’s prices.
Parts andAccessories
80M2&2002
Inditidu& qualified to service their own appliances User maintenance instructions contained in this
booktet
can have needed parts or accessories sent directly (()
cover procedures intended to be performed by any user.
their home. The CIE1 parLs sys[em pl-(~vides access 10 ovel-
Other seticing generdy shotid be referred to qu~fied
47,000 parts... and all (;E (lerruiue Renewal l’arts are
sedce personnel. Caution must be exercised, since
fully warranted. VISA, Master(;ard and Discovel- cards
improper serticing may cause unsafe operation.
are accepted.

YOUR GE DISHWASHER
WARRANTY
Save proof of original purchase date such as your sales slip or cancelled check to establish warranty period.
II
WHAT IS COVERED
FULL ONE-YEAR WARRANTY
For one year from date of original
purchase, we will provide, free of
charge, parts and service labor in
your home to repair or replace any
part ot
the dishwasher that fails
because of a manufacturing defect.
LIMITED SECOND-YEAR PARTS
WARRANTY
For the second year from date of
original purchase, we will provide,
free of charge, replacement parts for
any pafi of the dishwasher that fails
because of a manufacturing defect.
You pay for the service trip to your
home and
sewice labor charges.
LIMITED FIVE-YEAR
RACWELECTRONIC PARTS
WARRANTY
For five years from date of original
purchase, we will provide, free of
charge, replacement parts for any
c rack that rusts because of a
manufacturing defect
or any
● e/ectronjc contro/ module that fails
because of a manufacturing defect.
You pay for the service trip to your
home and service labor charges.
FULL TWENTY-YEAR TUB/DOOR
LINER WARRANTY
For twenty years from date of original
purchase, we will provide, free of
charge, patis and”sewice labor in
your home to repair or replace
the
PermaTufCO tub or door ijner if it
fails to contain water because of a
manufacturing defect.
This warranty is extended to
the original purchaser and any
succeeding owner for products
purchased for
ordinay home use in
the 48 mainland states, Hawaii and
Washington, D.C. In Alaska the
warranty is the same except that it is
LIMITED because you must pay to
ship the product to the
sewice shop
or for the
sewice technician’s travel
costs to your home.
All warranty service will be
provided by our Facto~ Sewice
Centers or by our authorized
Customer Care
(
”
)
sewicers during
normal working hours.
Should your appliance need
service, during warranty period or
beyond, call 800-GE-CARES
(800-432-2737).
WHAT IS NOT COVERED
● Service trips to your home to teach
you how to use the product.
Read your Use and Care material.
If you then have any questions
about operating the product, please
contact your dealer or our
Consumer Affairs office at the
address below, or call, toll free:
GE Answer Center@
800.626.2000
consumer information service
● Improper installation.
If you have an installation problem,
contact your dealer or installer. You
are responsible for providing
adequate electrical, plumbing, and
other connecting facilities.
● Replacement of house fuses or
resetting of circuit breakers.
“ Cleaning or servicing of air gap
device in drain line.
● Failure of the product if it is used for
other than its intended purpose or
used commercially.
● Damage to product caused by
accident, fire, floods or acts of God.
WARRANTOR IS
NOT RESPONSIBLE
FOR CONSEQUENTIAL DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above Iimitat;on or exclusion
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which
vay from state to state
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company
If further help is needed concerning this warranty, write:
Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225
Thjs book is printed on recycled pape~
Part No. 165D3080P265
mg-5575
GSDI125
11-92 CG
