GE DLSR483GG Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
370119
Specification Revised 5/09
DLSR483GG
GE® Long Vent Super 7.0 Cu. Ft. Capacity Gas Dryer
Dimensions and Installation Information (in inches)
Exhaust Options:
2-way via rear and bottom. Dryer is shipped exhausted to the rear.
Alternate exhausting knockouts are supplied.
Gas: An individual properly-grounded branch circuit, with a three-
prong grounding-type receptacle, protected by a 15 or 20 amp
circuit breaker or a time-delay fuse is required.
Gas Dryer Electric Rating: 120V, 60Hz, 6A
Gas (BTU/HR): 22,000. Factory-equipped for natural gas. Tested for
LP gas. LP gas supply requires a conversion kit. Check installation
instructions for correct kit and have a qualified gas technician install a
conversion kit. See dryer ducting information for proper installation.
Note: Dryer wall outlet must be located within 36" of service cord
entry and accessible when dryer is mounted in position.
Installation Information: For complete information, see installation
instructions packed with your dryer.
36
25-1/2
42
51
Side View
27
Rear View
36 42
27
23-1/2
2-1/2
25-1/2*
Side View Rear View
8-1/2
28-1/4
23-1/2
11-1/2
*24-1/2" from the edge of the side panel to the front.
25-1/2" from front to edge of endcaps.
Washer/Dryers SC QSart

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
370119
Specification Revised 5/09
DLSR483GG
GE® Long Vent Super 7.0 Cu. Ft. Capacity Gas Dryer
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust duct. If
rigid metal duct cannot be used, then UL-listed flexible metal (semi-rigid) ducting can be used (Kit
WX08X10077). In special installations, it may be necessary to connect the dryer to the house vent
using a flexible metal (foil-type) duct. A UL-listed flexible metal (foil-type) duct may be used ONLY
in installations where rigid metal or flexible metal (semi-rigid) ducting cannot be used AND where
a 4” diameter can be maintained throughout the entire length of the transition duct. Please see
installation instruction packed with your dryer for complete instructions when using flexible metal
(foil type) ducting.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or
bottom of dryer, add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is shown
in the table.
2. A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated as
a 90° elbow.
A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed house
floor (crawl space), or into an attic, since the accumulated lint could create a fire hazard or mois-
ture could cause damage. Never terminate the exhaust into a common duct or plenum with a
kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting,
etc. The wall cap must also be located at least 12" above the ground or any other obstruction with
the opening pointed down.
For more information on venting kits and accessories, please call 1-800-GE CARES.
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side
3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52".
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in. of open
area equally distributed. If this closet contains both a washer and a dryer, doors must contain
a minimum of 120 sq. in. of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes, with the National
Electric Code and National Fuel Gas Code, ANSI Z223 for gas dryers.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides
3" rear
Dimensions and Installation Information (in inches)
Best performance
Domestic
dryer models
Maximum length of 4"
dia. rigid metal duct
Number
of
90°
turns
Exhaust hood type
A
4"
opening
B
2-1/2"
opening
DLSR483EG/GG
0
1
2
3
4
5
150 ft.
135 ft.
125 ft.
115 ft.
105 ft.
95 ft.
125 ft.
115 ft.
105 ft.
95 ft.
85 ft.
75 ft.
A
4
B
2-1/2
A

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
370119
Specification Revised 5/09
DLSR483GG
GE® Long Vent Super 7.0 Cu. Ft. Capacity Gas Dryer
DLSR483G
Features and Benefits
• 7.0 Cu. Ft. Super Capacity - Handles large-size items and
family-size loads
• DuraDrum™- Provides long-lasting dependability and durability
• Four Heat Selections - Provide the right temperature for the right
drying results
• Eight Dry Cycles - A variety of fast, flexible options for drying clothes
• Auto Dry - Uses thermostats to monitor air temperature and
reduce fabric wear
• Variable End-Of-Cycle Signal - Adjustable volume offers
added flexibility
• Long Vent - Delivers exceptional drying performance with duct
runs of up to 150 ft.* for greater installation flexibility
(*of equivalent ducting)
• Interior Dryer Light - Lets you see everything inside for easy loading
and unloading
• Model DLSR483GGWW – White on white
