GE IM4 Operating instructions

Icemaker Accessory Kit
www.GEAppliances.com
Kit IM-4
This kit fits most models calling for
UK-KIT-1, UK-KIT-2, UK-KIT-4, and
all models calling for Kit IM-1,
IM-2 or IM-3. If you are replacing
an icemaker with Kit IM-1or IM-2,
see page 5.
Owner’s Manual and
Installation Instructions
IM-4
162D4614P008 49-60109 01-01 JR
Safety Information . . . . . . . . . . 2
Operating Instructions . . . . . .3
Befor You Call For Service . . . . .4
Normal Sounds
You May Hear . . . . . . . . . . . . . . . .3
Preparing for Vacation . . . . . . . .3
When You Should
Set the Icemaker
Power Switch to OFF . . . . . . . . . .3
Installation Instructions
Cold Water Line . . . . . . . . .58–61
Fill Tube Extension
Templates . . . . . . . . . . . . . . .62, 63
Icemaker . . . . . . . . . . . . .10–13
Icemaker . . . . . . . . . . . . .14–17
Icemaker . . . . . . . . . . . . .18–21
Icemaker . . . . . . . . . . . . .22–25
Icemaker . . . . . . . . . . . . .26–29
Icemaker . . . . . . . . . . . . .30–33
Icemaker . . . . . . . . . . . . .34–37
Icemaker . . . . . . . . . . . .38–41
Icemaker . . . . . . . . . . . . .42–45
Icemaker . . . . . . . . . . . . .46–49
Icemaker . . . . . . . . . . . . .50–53
Icemaker . . . . . . . . . . . . .54–57
Parts List . . . . . . . . . . . . . . . . . .6, 7
Removing Existing Ice Cube
Tray Holder . . . . . . . . . . . . . . . . .8
Repositioning or Removing
the Freezer Shelf . . . . . . . . . . . . .9
Consumer Support
Consumer Support . . Back Cover
Warranty . . . . . . . . . . . . . . . . . . 64
R
Q
P
N
M
L
K
J
H
G
F
C
Which instructions should
you follow?
Look for a label on the back of the
refrigerator that will tell you which
instructions to use:
or RQPN
MLKJHGFC

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
READ AND SAVE THESE INSTRUCTIONS
SAFETY PRECAUTIONS
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
FOR YOUR SAFETY:
Do not place fingers or hands in the automatic
icemaking mechanism while the refrigerator is
plugged in. This will help protect you from
possible injury.
It will also prevent interference with moving parts
of the ejector mechanism and the heating
element that releases the cubes, located on the
bottom of the icemaker.
2

■The icemaker water valve will buzz
when the icemaker fills with water. If
the power switch is in the ON position,
it will buzz even if it has not yet been
hooked up to water. Keeping the power
switch in the ON position before it is
hooked up to water can damage the
icemaker. To prevent this, move the power
switch to the OFF position.
This will stop the buzzing.
■The sound of cubes dropping into the bin
and water running in the pipes as the
icemaker refills.
About the automatic icemaker. www.GEAppliances.com
A newly-installed refrigerator may take 12 to 24 hours to begin making ice.
Icemaker
Feeler Arm
Power
Switch
Automatic Icemaker
The icemaker will produce seven cubes
per cycle—approximately 100–130 cubes
in a 24-hour period, depending on
freezer compartment temperature, room
temperature, number of door openings
and other use conditions.
If the refrigerator is operated before the
water connection is made to the icemaker,
set the power switch to OFF .
When the refrigerator has been connected
to the water supply, set the power switch to
ON . The green light will come on.
The icemaker will fill with water when
it cools to freezing. A newly-installed
refrigerator may take 12 to 24 hours
to begin making ice cubes.
Throw away the first few batches of ice to
allow the water line to clear.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler
arm, the icemaker will stop producing ice.
It is normal for several cubes to be joined
together.
If ice is not used frequently, old ice cubes
will become cloudy, taste stale
and shrink.
If ice cubes get stuck in the icemaker, the
green power light will blink. To correct
this, set the power switch to OFF and
remove the cubes. Set the power switch to
ON to restart the icemaker.
NOTE: In homes with lower-than-average water
pressure, you may hear the icemaker cycle multiple
times when making one batch of ice.
Green Power Light
3
Preparing for Vacation
Set the icemaker power switch to OFF
and shut off the water supply to the
refrigerator.
If the temperature can drop below freezing,
have a qualified servicer drain the water
supply system (on some models) to prevent
serious property damage due to flooding.
When you should set the icemaker power switch to OFF
■When the ice storage bin is removed for
more than a minute or two.
■When the water supply will be shut off for
several hours.
■When the refrigerator will not be used for
several days.
Normal sounds you may hear

Problem Possible Causes What To Do
Automatic icemaker Icemaker power switch in •Move the switch to the ON position.
does not work the OFF position.
Water supply turned off or •See Installing the Water Line .
not connected.
Freezer compartment •Wait 24 hours for the refrigerator to completely
too warm cool down.
Piled up cubes in the storage •Level cubes by hand.
bin cause the icemaker to
shut off.
Cubes too small Water shutoff valve connecting •Call the plumber to clear the valve.
refrigerator to water line may
be clogged.
Slow ice cube freezing Door left open. •Check to see if package is holding door open.
Temperature control not •See About the Temperature Control .
set cold enough.
Ice cubes have Ice storage bin needs cleaning. •Empty and wash bin. Discard old cubes.
odor/taste
Food transmitting odor/taste •Wrap foods well.
to ice cubes.
Interior of refrigerator •See Care and cleaning .
needs cleaning.
Before you call for service…
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
4

5
BEFORE YOU BEGIN
Installation IM-4 Icemaker Kit
Instructions
Read these instructions completely and carefully.
•IMPORTANT –Save these
instructions for local inspector’s use.
•IMPORTANT –Observe all
governing codes and ordinances.
•Note to Installer –Be sure to leave these
instructions with the Consumer.
•Note to Consumer –Keep these instructions
for future reference.
•Skill level – Installation of this appliance requires
basic mechanical and electrical skills.
•Completion time – 20–60 minutes
•Proper installation is the responsibility of the
installer.
•Product failure due to improper installation is not
covered under the Warranty.
It’s important that you use the water valve and fill tube
extension that come with this kit, even though your
refrigerator may already have them installed.
The old valve will not allow enough water through to
fill the icemaker properly and cause damage.
The fill tube extension needs to be a different length
than the original tube for proper water flow. Cut the
tube to the length indicated for your model of
refrigerator.
ARE YOU REPLACING AN
ICEMAKER WITH THIS KIT?
Questions? Visit our Website at: www.geappliances.com or Call GE Answer Center at 800.626.2000
There is a label on the back of the refrigerator
that will tell you whether to use Instructions:
or
Pages 10–57 contain twelve different Installation
Instructions.
The actual installation of the icemaker will depend on
which model refrigerator you have.
RQPNMLKJHGFC
WHICH INSTRUCTIONS SHOULD
YOU FOLLOW?
• If the unit is damaged in shipment, return the unit
to the store in which it was bought for repair or
replacement.
• If the unit is damaged by the customer, repair or
replacement is the responsibility of the customer.
• If the unit is damaged by the installer (if other than
the customer), repair or replacement must be made
by arrangement between customer and installer.
DAMAGE – SHIPMENT/INSTALLATION

6
Installation Instructions
CONTENTS OF KIT IM-4
6
3
Owners Manual &
Installation Instructions
2
Ice Bucket
11
Water Line Clamp
(strain relief)
8
Water Line Clamp
12
Hex-Head Screw for Copper
Water Line Clamp
7
Water Valve and
Tube Assembly
4
Hose Clamp
(black)
Hose Clamp
(not black)
Hex-Head
Screw
13
Adhesive-Backed
Water Line Fasteners
5
15 Water Tube Inlet
14 Phillips Head
Screws (2)
Warranty Label
9
ICE MAKER
WARRANTY VERIFICATION
Date Installed
Dealer
Fill Tube Extension
(3/4″O.D.)
10
21
18
Water Fill Tube
(5/8″O.D.)
16
Hex-Head Screw (2)
17
Icemaker Bracket
25
Screws to Install
Bracket to Refrig.
Wall (3)
26
Icemaker Power Cord
Adapter (6 pin)
22
Icemaker Fill Cup
(center-mounted)
19
Icemaker Fill Cup
(side-mounted)
Icemaker Power Cord
Adapter (4 pin)
Plug Buttons (2)
27
Icemaker Insert
20
Water Valve
Wire Extension
23
Wire Ties (2)
24
Icemaker
1
Installation
Instructions

7
Installation Instructions
Parts List Use with Installation Instructions:
C FGHJ K LMNPQ R
1 Icemaker XXXXXXXXXXXX
2 Owner’s Manual and XXXXXXXXXXXX
Installation Instructions
3 Hose Clamp (black) XXXXXXXXXX
4 Valve and Tube Assembly* XXXXXXXXXXXX
5 Adhesive-Backed Water Line Fasteners XXXXXXXXXXXX
6 Hose Clamp (not black) XXXXXXXXXXXX
7 Hex-Head Screw for Copper Water XX
Line Clamp
8 Water Line Clamp (strain relief) XXX XXXXXX X
9 Warranty Label XXXXXXXXXXXX
10 Fill Tube Extension (3/4″O.D.) XXXXX XX XX
11 Ice Bucket XXXXXXXXXXX
12 Water Line Clamp (strain relief) X XXXXXXXX
13 Hex-Head Screw X XXXX
14 Phillips Head Screw (2) X X XXXXXX
15 Water Tube Inlet XXXXXXXXXX
16 Water Fill Tube (5/8″O.D.) XXXXXXXXXX
17 Hex-Head Screw (2) X
18 Icemaker Fill Cup (side-mounted) XXXXX XXXXXX
19 Icemaker Fill Cup (center-mounted) X
20 Icemaker Insert X
21 Icemaker Power Cord Adapter (4 pin) XXXXX
22 Icemaker Power Cord Adapter (6 pin) XXXXXXX
23 Water Valve wire extension X
24 Wire Ties (2) XX
25 Icemaker Bracket X
26 Screws to Install Bracket to X
Refrigerator Wall (3)
27 Plug Buttons (2) XXXXXX
* Always change the water valve when replacing an icemaker that makes round cubes. This new
icemaker uses a different voltage which may cause the old valve to fail.
For dispenser models, order GE Part Number WR57X96.

8
Installation Instructions
REMOVE EXISTING ICE TRAY HOLDER
Follow the instructions below for the ice tray holder that looks like yours.
Type 1
•Unhook the ice tray holder side and bottom from the
retaining hooks. Lower the holder until the side is
clear of the freezer shelf and remove it from the
freezer. You will not need this part.
Retaining hooks
Type 2
•As you lift the tab on the left side in the holder with
the blade of a screwdriver, pull the holder forward
and out. You will not need this part.
Do not
lift here
Lift this
tab out
Type 3
•When following Instructions G, it is not necessary
to remove the ice tray shelf or, on some models,
the wire shelf next to it.
•Tilt the ice tray shelf and remove it. You will not
need this part.
Type 4
•Remove the 2 screws and save them for installation
of the icemaker.
•Lift the ice tray holder off the plastic hook. You will
not need this part.
Screws
Plastic hook
Type 5
•Remove the screw with a 1/4″nutdriver.
•Pull the ice tray shelf away from the wall. Remove
the shelf. You will not need this part.
•Replace the screw.
Screw

9
REPOSITION OR REMOVE FREEZER SHELVES
On some models, you may need to remove or reposition the freezer shelf so the icemaker and
bucket sit properly. Follow the instructions below for the ice tray holder that looks like yours.
Type 1
•To reposition the two-piece shelf supports, slide the
shelf up off the base mount.
Base
mount
Shelf
support
Type 2
•On some bottom-mount no-frost refrigerators, you
need to remove a full width flat freezer shelf before
installing the icemaker.
Installation Instructions

10
PREPARE FOR INSTALLATION
•Remove the screw (A) that holds the electrical
plug cover in place. You will not need this screw
and cover.
•Remove the light shield insert (B) and discard it.
•Loosen the two mounting screws (C)
approximately 1/2″(13 mm). DO NOT REMOVE
THESE SCREWS.
INSTALL FILL TUBE
Cut the fill tube extension (10) to the length
(refer to the template on page 63) with a
sharp knife or single-edge razor blade and slide
it onto the fill tube against the stop.
CC
1
2
Installation Instructions
ICEMAKER INSTALLATION INSTRUCTIONS C
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator— or RQPNMLKJHGFC
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
•CAUTION –Unplug the
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator from
its electrical outlet.
Flat blade and Phillips
screwdrivers Pliers
TOOLS YOU WILL NEED
Sharp knife
Cover
removed
B
C
A
C
10
SET POWER SWITCH TO OFF
Set the icemaker power switch to OFF. Leave the power
switch in the OFF position until the refrigerator is
connected to the water supply to prevent premature
operation.
3
Power
Switch
POWER CORD ADAPTER
There are two power cord adapters included with the
kit; be sure to use the one specified in the Parts List on
page 7. Plug the female end of the power cord adapter
(21) onto the male terminals on the icemaker power
cord. When connecting the adapter to the power cord,
make sure the seal is in place between the connectors.
Secure the power cord adapter to the icemaker by
putting it into the hook at the back of the icemaker
and attaching it to the icemaker with a wire tie (24).
4
Hook
Hole for
wire tie
Hook
Wire tie
Seal

11
INSTALL THE ICEMAKER FILL CUP
Install the icemaker fill cup (side-mounted)(18) into
the icemaker as shown.
5
18
MOUNT THE ICEMAKER
•Lift the icemaker so the fill tube extension
(10) fits in the fill cup opening (E). Hang the
icemaker on the two mounting screws (C).
Make sure:
•The power cord is still firmly in the socket.
•The fill tube extension (10) is still in the fill cup
opening. (Check the rear of the refrigerator to
make sure the fill tube has not been pushed out
of the back of the refrigerator).
•The icemaker mounting screws are located in the
uppermost position of the mounting slots.
THEN SECURELY TIGHTEN THE ICEMAKER
MOUNTING SCREWS.
7
10
E
C
PLUG IN THE ICEMAKER
Place the icemaker in the freezer compartment on its
side as shown. Insert the icemaker power cord plug
(D) into the socket on the side wall, making sure the
prongs and holes are matched. Press the plug firmly
into the socket.
6
D
INSTALL THE ICE BUCKET
Put the ice bucket (11) directly under the icemaker
(to the left and all the way to the rear of the shelf
under the icemaker).
Make sure the icemaker power switch is set to OFF .
8
11
ATTACH WARRANTY LABEL
A label (9) is provided with this kit to record the date
of installation for warranty purposes. Apply it to the
back of the refrigerator.
9
KEEP THIS MANUAL
The warranty for the icemaker is printed in this
manual. Keep this manual with your Refrigerator
Owner’s Manual.
The icemaker installation inside the freezer is now
complete. Continue to the Water Valve Assembly
section.
10
Installation Instructions

12
REMOVE THE COVER
At the bottom rear of the refrigerator, remove the
screw(s) holding the compressor compartment
cover (if covered) and save for reinstallation later.
Bend the cover back for access to the compartment.
1
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
•CAUTION –Unplug the
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator from
its electrical outlet.
Flat blade and Phillips
screwdrivers Pliers
TOOLS YOU WILL NEED
Sharp knife
5/16″Nutdriver
ATTACH THE WATER VALVE
•Locate the female connector plug (A) which is
attached to the cabinet with a wire tie. Remove
the wire tie and discard it.
2
Wire tie
A
4
A
13
•Remove and discard the tape from the female
connector (A) and plug onto the male terminals
on the water valve (4). Either wire can go on
either terminal.
•Fasten the water valve to the cabinet edge hole
using the hex-head screw (13) from the kit.
DO NOT DRILL ANY ADDITIONAL HOLES.
•Check the plastic water line nut on the bottom of
the water valve to be sure it is hand tight.
DO NOT USE TOOLS.
Installation Instructions
WATER VALVE ASSEMBLY INSTALLATION INSTRUCTIONS C
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator— or RQPNMLKJHGFC

13
Installation Instructions
INSTALL WATER LINE CLAMP
•Push the metal water line clamp (strain relief) (12)
onto the lower flange of the cabinet back, directly
in line with the water valve.
•The metal clamp is for the house water line. (See
the Water Line Installation Instructions). It is not
to be used for the tubing from the water valve up
to the icemaker.
3
12
ROUTE THE PLASTIC WATER LINE
On models that have condensor tubing on the back
of the cabinet, insert the plastic water line between
the tubing and the back of the cabinet.
4
Condenser
tubing Plastic water line
CONNECT THE WATER LINE
•Remove the small plastic cap (B) from the bottom
of the water tube inlet located in the upper-right
rear corner of the refrigerator.
•Squeeze the ends of the hose clamp (6) from the
kit with pliers and slide the clamp over the water
tube inlet.
•While still squeezing the clamp, insert the
plastic water line into the inlet as far as it will
go (approximately 1″[25 mm]).
•Then slide the clamp downward to capture the
plastic water line in place.
•Make sure the fill tube is aimed down.
5
6
Water tube
inlet
B
ATTACH THE PLASTIC WATER LINE
Fasten the plastic water line to the back of the cabinet
with adhesive-backed fasteners (5), spacing the
fasteners as shown to take up the slack in the line.
6
Adhesive-backed fasteners for plastic water line
5
5
WATER VALVE INSTALLED
Refer to the Water Line Installation Instructions for
connection to the home water supply. After water
line installation is completed, set the icemaker
power switch to ON .
The icemaking cycle will not begin until the icemaker
and freezer compartment reach operating temperature,
then icemaking will begin automatically.
7

LOOSEN MOUNTING SCREWS
Loosen the two mounting screws (A) but do not
screw them all the way out. The screws should
extend approximately 1/2″(13 mm) out from the
freezer wall.
INSTALL FILL TUBE
•Remove and discard the white plug from the
upper left corner of the freezer wall.
•Cut the fill tube extension (10) to the length
(refer to the template on page 63) with a
sharp knife or a single-edge razor blade and slide
it onto the fill tube against the stop.
FF
2
3
Installation Instructions
ICEMAKER INSTALLATION INSTRUCTIONS F
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator— or RQPNMLKJHGFC
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
•CAUTION –Unplug the
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator
from its electrical outlet.
Flat blade and Phillips
screwdrivers Pliers
TOOLS YOU WILL NEED
Sharp knife
14
Fig. 1
REMOVE PLUG COVER
Remove the electric plug cover.
To remove the type shown in Fig. 1,
insert a standard screwdriver blade
in slot at bottom of cover, apply
pressure upwards, and pry cover
away from freezer wall. Discard this
cover.
To remove the type shown in Fig.
2, press top of cover down to free
its upper tab from slot in freezer
wall. Then pull cover straight out
to free the lower tabs from their
slots. Save this cover for
reinstallation later.
1
A
Remove
plug F
10
SET POWER SWITCH TO OFF
Set the icemaker power switch to OFF. Leave the
power switch in the OFF position until the refrigerator
is connected to the water supply to prevent
premature operation.
4
Power
Switch
POWER CORD ADAPTER
There are two power cord adapters included with the
kit; be sure to use the one specified in the Parts List on
page 7. Plug the female end of the power cord adapter
(21) onto the male terminals on the icemaker power
cord. When connecting the adapter to the power
cord, make sure the seal is in place between the
connectors. Secure the power cord adapter to the
icemaker by putting it into the hook at the back of the
icemaker and attaching it to the icemaker with a wire
tie (24).
5
Hook
Hole for
wire tie
Hook
Wire tie
Seal
Fig. 2

15
PLUG IN THE ICEMAKER
Hold the icemaker in the freezer compartment as
shown. Insert the icemaker power cord plug (B)
into the socket on the rear wall, making sure the
prongs and holes are matched. Press the plug
firmly into the socket.
7
B
Installation Instructions
MOUNT THE ICEMAKER
•Lift the icemaker so the fill tube extension (10) fits
in the fill cup opening (C). Hang the icemaker on
the two mounting screws (A).
Make sure:
•The power cord is still firmly in the socket.
•The fill tube extension (10) is still in the fill cup
opening. (Check the rear of the refrigerator to
make sure the fill tube has not been pushed out of
the back of the refrigerator.)
•The icemaker mounting screws are located in the
uppermost position of the mounting slots.
THEN SECURELY
TIGHTEN THE
ICEMAKER
MOUNTING SCREWS .
9
INSTALL THE ICEMAKER FILL CUP
Install the icemaker fill cup (side-mounted) (18)
into the icemaker as shown.
6
18
INSTALL THE ICE BUCKET
Put the ice bucket (11)
directly under the
icemaker (to the left
and all the way to the
rear of the shelf under
the icemaker).
The straight 2- position
shelf should be in the
lower position. The step
shelf’s lower step should
be under the icemaker.
The cantilever shelf’s top hooks should be in the 6th
slot up from the bottom of the track.
Make sure the icemaker power switch is set to OFF .
10
11
ATTACH WARRANTY LABEL
A label (9) is provided with this kit to record the date
of installation for warranty purposes. Apply it to the
back of the refrigerator.
11
KEEP THIS MANUAL
The warranty for the icemaker is printed in this
manual. Keep this manual with your Refrigerator
Owner’s Manual.
The icemaker installation inside the freezer is now
complete. Continue to the Water Valve Assembly
section.
12
10
A
C
REINSTALL THE ELECTRIC
PLUG COVER
If the plug cover removed in Step 1 matched Figure 1,
continue to Step 9.
If the plug cover removed in Step 1 matched Figure 2,
it must be reinstalled.
•Remove the break-out tab on the right side of
the cover. Hold the cover and twist off the tab
with pliers.
•Place the cover over the electric plug with the
power cord running through the opening.
•Insert the tabs in the top or bottom and snap the
other end in place.
IMPORTANT: This cover will help keep the electric
plug from coming out of the socket when mounting
the icemaker. Be sure to install it now.
8

•Fasten the water valve to the cabinet edge hole
using the hex-head screw that you removed at
the beginning of Step 2.
DO NOT DRILL ANY ADDITIONAL HOLES.
•Check the plastic water line nut on the bottom of
the water valve to be sure it is hand tight.
DO NOT USE TOOLS.
16
Installation Instructions
REMOVE THE COVER
At the bottom rear of the refrigerator, remove the
screw(s) holding the compressor compartment
cover (if covered) and save for reinstallation later.
Bend the cover back for access to the compartment.
1
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
•CAUTION –Unplug the
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator
from its electrical outlet.
WATER VALVE ASSEMBLY INSTALLATION INSTRUCTIONS F
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator— or RQPNMLKJHGFC
Flat blade and Phillips
screwdrivers Pliers
TOOLS YOU WILL NEED
Sharp knife
1/4″Nutdriver
ATTACH THE WATER VALVE
•Locate the female connector plug (C) which is
attached to the cabinet by a metal or plastic clip.
Remove the clip by removing the screw. Save the
screw for mounting the water valve later. Discard
the clip.
2
•Plug the female connector (C) onto the male
terminals on the water valve (4). Either wire
can go on either terminal.
Metal or
plastic clip
C
C
4

Installation Instructions
INSTALL WATER LINE CLAMP
•Attach the metal water line clamp (strain relief) (8)
to the refrigerator. Drive one of the screws,
removed in Step 1, into the cabinet edge through
the clamp and hole in compressor cover.
•The metal clamp is for the house water line (see
Water Line Installation Instructions). It is not to
be used for the tubing from the water valve up to
the icemaker.
3
4CONNECT THE WATER LINE
•Remove the small plastic cap (B) from the bottom
of the water tube inlet located in the upper-right
rear corner of the refrigerator.
•Squeeze the ends of the hose clamp (6) from the
kit with pliers and slide the clamp over the water
tube inlet.
•While still squeezing the clamp, insert the
plastic water line into the inlet as far as it will
go (approximately 1″[25 mm]).
•Then slide the clamp downward to capture the
plastic water line in place.
•Make sure the fill tube is aimed down.
ATTACH THE PLASTIC WATER LINE
Fasten the plastic water line to the back of the
cabinet with adhesive-backed fasteners (5),
spacing the fasteners as shown to take up the
slack in the line.
5
Adhesive-backed fasteners
for plastic water line
5
WATER VALVE INSTALLED
Refer to the Water Line Installation Instructions for
connection to the home water supply. After water
line installation is completed, set the icemaker
power switch to ON .
The icemaking cycle will not begin until the icemaker
and freezer compartment reach operating temperature,
then icemaking will begin automatically.
6
8
Screw
17
6
Water tube
inlet
B

LOOSEN MOUNTING SCREWS
Loosen the two mounting screws (B) but do not
screw them all the way out. If your model does not
have the screws already in the freezer wall, look for
two plug buttons. Remove the plug buttons and
insert the two Phillips head screws (14). The screws
should extend approximately 1/2″(13 mm) out
from the freezer wall.
INSTALL FILL TUBE
•Remove and discard the white plug from the
upper left corner of the freezer wall.
•Cut the fill tube extension (10) to the length
(refer to the template on page 63) with a sharp
knife or a single-edge razor blade and slide it onto
the fill tube against the stop.
GG
3
4
Installation Instructions
ICEMAKER INSTALLATION INSTRUCTIONS G
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator— or RQPNMLKJHGFC
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
•CAUTION –Unplug the
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator
from its electrical outlet.
Flat blade and Phillips
screwdrivers Pliers
TOOLS YOU WILL NEED
Sharp knife
18
1
Remove
plug G
10
SET POWER SWITCH TO OFF
Set the icemaker power switch to OFF. Leave the
power switch in the OFF position until the refrigerator
is connected to the water supply to prevent
premature operation.
5
Power
Switch
REMOVE PLUG COVER
Remove the electric plug cover from
the left side wall of the freezer by
pulling the cover (A) straight out
while pressing the sides of the cover
to free its tabs from the slots. Discard
the cover.
2
A
INSTALL WATER TUBE INLET
If the refrigerator already has a water tube inlet
on the back of the refrigerator, go to Step 2.
•Cut the fill tube (16) to the length (refer
to the template on page
62),with a sharp knife or a
single-edge razor blade.
•Slide the fill tube (16) onto
the water tube inlet (15).
•Find the small label in the
upper right hand corner on the back of the
refrigerator. Peel off the label.
•On the tube side of the
water tube inlet (15) there
is an adhesive backing.
Remove the adhesive
backing and slide the tube
into the hole near the top
at the back of the refrigerator. Firmly press on
the inlet to secure it.
GG
B
Hole for
wire tie
15
16

19
PLUG IN THE ICEMAKER
Hold the icemaker in the freezer compartment as
shown. Insert the icemaker power cord plug (D)
into the socket, making sure the prongs and holes
are matched. Press the plug firmly into the socket.
8
Installation Instructions
MOUNT ICEMAKER
•Lift the icemaker so the fill tube extension (10) fits
in the fill cup opening (C). Hang the icemaker on
the two mounting screws (A).
Make sure:
•The power cord is still firmly in the socket.
•The fill tube extension (10) is still in the fill cup
opening. (Check the rear of the refrigerator to
make sure the fill tube has not been pushed out of
the back of the refrigerator.)
•The icemaker mounting screws are located in the
uppermost position of the mounting slots.
THEN TIGHTEN THE ICEMAKER MOUNTING
SCREWS SECURELY.
9
INSTALL THE ICEMAKER FILL CUP
Install the icemaker fill cup (side-mounted) (18) into
the icemaker as shown.
7
18
INSTALL THE ICE BUCKET
Put the ice bucket (11)
directly under the
icemaker (to the left and
all the way to the rear of
the shelf under the
icemaker).
Make sure the icemaker
power switch is set to OFF .
10
11
ATTACH WARRANTY LABEL
A label (9) is provided with this kit to record the
date of installation for warranty purposes. Apply it
to the back of the refrigerator.
11
KEEP THIS MANUAL
The warranty for the icemaker is printed in this
manual. Keep this manual with your Refrigerator
Owner’s Manual.
The icemaker installation inside the freezer is now
complete. Continue to the Water Valve Assembly
section.
12
10
C
A
D
POWER CORD ADAPTER
There are two power cord adapters included with the
kit; be sure to use the one specified in the Parts List on
page 7. Plug the female end of the power cord adapter
(21) onto the male terminals on the icemaker power
cord. When connecting the adapter to the power cord,
make sure the seal is in place between the connectors.
Secure the power cord adapter to the icemaker by
putting it into the hook at the back of the icemaker
and attaching it to the icemaker with a wire tie (24).
6
Hook
Hook
Wire tie
Seal

20
Installation Instructions
REMOVE THE COVER
At the bottom rear of the refrigerator, remove the
screw(s) holding the compressor compartment
cover (if covered) and save for reinstallation later.
Bend the cover back for access to the compartment.
1
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
•CAUTION –Unplug the
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator from
its electrical outlet.
WATER VALVE ASSEMBLY INSTALLATION INSTRUCTIONS G
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator— or RQPNMLKJHGFC
Flat blade and Phillips
screwdrivers Pliers
TOOLS YOU WILL NEED
Sharp knife
1/4″and 5/16″ Nutdrivers
ATTACH THE WATER VALVE
•Locate the female connector plug (B).
2
•Plug the female connector (B) onto the male
terminals on the water valve (4). Either wire
can go on either terminal.
•Fasten the water valve to the cabinet edge hole
using the hex-head screw (13) from the kit .
DO NOT DRILL ANY ADDITIONAL HOLES.
•Check the plastic water line nut on the bottom of
the water valve to be sure it is hand tight. DO NOT
USE TOOLS.
B
B
4
13
