GE MONOGRAM ZDIS15CSS User guide

Specification Revised 2/00
Monogram.
™
ZDIS15CSS - GE Monogram™High-Production, Large Capacity Automatic Icemaker
Dimensions and Specifications (in inches)
Dimensions:
H 33-1/2"
W 14-13/16”
D 23-5/16”
Note: The finished cut-out is determined by the type
of installation. Before installing, consult installation
instructions packed with product for current dimen-
sional data.
Warranty Information: Full one-year warranty,
in-home service, parts and labor.*
Full five-year warranty, parts and labor on the
compressor, evaporator and all connecting tubing.*
*See written warranty for complete details.
14-13/16"
24"
min.
4-1/2"
5"
15"
34" Min.
Adjustable
to 34-1/2"
Water supply should enter
cutout from right rear wall.
34" Min.
to
34-1/2" Max.
Locate Outlet
on Back
Wall
Floor Drain
23-5/16"
R
Listed by
Underwriters
Laboratories
Note: The addition of a 3/4” thick front panel will result in a front to back
depth of 24-1/16”.
For answers to your Monogram,
®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.

Specification Revised 2/00
Monogram.
™
ZDIS15CSS - GE Monogram™High-Production, Large Capacity Automatic Icemaker
Dimensions and Specifications (in inches)
The Monogram™automatic icemaker can be used free-standing or as a built-in, under
the countertop.
The Monogram™automatic icemaker requires a 115 Volt, 60 Hz., AC only power
supply, with an individual, properly grounded branch circuit, protected by a 15 amp fuse
or circuit breaker.
The Monogram™automatic icemaker is equipped with a gravity drain to prevent water
from flowing back into the ice storage bin. Although a floor drain is acceptable, the ideal
installation has a standpipe with a 2” to 1-1/2” pvc drain reducer installed directly below
the outlet of the drain tube.
To achieve a custom appearance, the icemaker door accepts 3/4” custom panels (using
ZIP75BB Black Kit) to coordinate or contrast with cabinetry.
Note: A drain pump is necessary when a floor drain is not available. Order ZPK1 Drain
Pump Kit or contact your local plumber for a recommended pump available in your area.
14-23/32"
29-1/2"
Left Trim
Right Trim
Handle
Custom
Panel
11-1/2"
9"
Electrical Supply Should
Enter From Back Wall
In Shaded Area.
3"
28-1/2"
4-5/8"
High
7-1/2"
Locate Standpipe in exact
Center of The Cutout
15"
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,
®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.

Specification Revised 2/00
Monogram.
™
ZDIS15CSS - GE Monogram™High-Production, Large Capacity Automatic Icemaker
Features and Benefits
•50-lb. Daily Crystal Clear Ice Production
•Automatic Shut-Off
•On, Off and Clean Cycles
•25-lb. Capacity Easy Access Ice Storage Bin
•Electronic Control with Pushpads
•Interior Light and Clean Indicator Light
•Full-Length Reversible Door with Door Stop
•Cast Aluminum Ice Scoop
•Model ZDI15CWW - White
•Model ZDI15CBB - Black
•Model ZDIS15CSS - Stainless Steel
