GE Spacemaker JVM1430WD Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340196
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM1430BD/WD
GE Spacemaker® 1.4 Cu. Ft. Capacity Over-the-Range Microwave Oven
Ventilation Options: The Spacemaker
microwave ovens are designed for
adaptation to the following three types
of ventilation:
• Outside exhaust (vertical – as shown)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless
– see Filter Kit drawing)
Installation Information: This
information is not intended to be
used for installing unit described.
Before installing, consult installation
instructions packed with product/kit for
current dimensional data.
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required Exhaust outlet
connects to
3-1/4" X 10" duct
16-13/32
(rear)
105°
Door open
15-1/4
24-1/2
16
29-7/8
Minimum distance from
door hinge side to adjacent
wall should equal 1/2-inch.
(without
obstruction)
13"
MAX.
12"
MIN.
Dimensions (in inches)
Over-the-Range Microwave Oven
Dimensions and Installation Information (in inches) Optional Accessories (Available at additional cost)
JX41/JX46BL-Black Filler Panel Kit
JX40WH/JX46WH-White Filler Panel Kit
When replacing a 36"
range hood, this kit fills
in the additional width to
provide a custom built-in
appearance. For installation
between cabinets only; not
for end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.
Filter KitsJX81A–
Recirculating Charcoal
Filter Kit To be used
when the Spacemaker
microwave oven
cannot be vented to
the outside.

340196
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM1430BD/WD
GE Spacemaker® 1.4 Cu. Ft. Capacity Over-the-Range Microwave Oven
Features and Benefits
• 1.4 Cu. Ft. Capacity/950 Watts*
• Electronic Scrolling Digital Display with Clock and AM/PM Pad
• Convenience Cooking Control Pads for Beverage, Popcorn
and Reheat
• Auto Defrost/Time Defrost
• Express Cook with Instant On Controls
• 10 Power Levels
• Glass Turntable
• Cooktop Lighting with Night Light Setting
• Help Pad
• Full One Year Product; Limited Ten Year Magnetron Warranty
• Model JVM1430WD - White on white
• Model JVM1430BD - Black on black
*IEC-705 Test Procedure
