†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 4/07 321599
KW Rating
240V 11.6
208V 8.7
Breaker Size
40 Amps†
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
25-3/8
47-5/8
46-1/4
Dimension from wall to front of
closed door handle is 28-3/4".
29-7/8
JBP61DM
GE®30" Free-Standing QuickClean™Electric Range
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
25-3/8
47-5/8
46-1/4
Dimension from wall to front of
closed door handle is 28-3/4".
29-7/8

Features and Benefits
• Self-Clean Oven - Conveniently cleans the oven cavity without the need for scrubbing
• Super-Large Oven Capacity - Provides an impressively large oven interior for cooking
more dishes and large meals at one time
• QuickSet III Oven Controls - Feature an easy to use design that lets you set precise
cooking temperatures
• Ribbon Heating Elements - Provide powerful heat beneath a smooth glass surface
to ensure even heat and fast warm-up times
• Ceramic Glass Cooktop - A smooth cooktop surface makes cleaning quick and easy
• Dual Element Bake - Alternates the upper broiling element and the lower baking
element for even heating and optimal baking results
• Six Rack Positions - Provides flexibility and allows consumers to make the most
of available oven capacity
• Audible Preheat Signal - Features an audible signal that activates when the oven
has reached the desired cooking temperature
• Preheat Oven Light - Illuminates to conveniently inform when the oven is preheating
• Porcelain Upswept Cooktop - Features raised edges to help contain spills and make
clean-up easy
• Model JBP61DMWW – White on white
JBP61DM
BROILOVEN
LIGHT
CLOCK
TIMECONTROLS
OVENCONTROLS
ONOFF
KITCHEN
LIGHT
ONOFF
BAKESTART
ON
CLEAR
OFF
Specification Created 4/07 321599
JBP61DM
GE®30" Free-Standing QuickClean™Electric Range
