GE TFX27R User manual

Refrigerator
Conten&
Apptiance Registration
2
Water Supply to Icemaker
4
Base Gfle
4 Light Bulb Replacement
14
Care and Cleaning
13,14
Model and Serial Numbers
2
Condenser
13
Problem Solver
15-18
Consumer Services
19 Stiety Inswctions
EnerW Saver 5
Shelves
1:
EnerW-Saving Tips
2
Storage Drawers
10, 11
Food Saver System
10 Dmwer & Cover Removal
11
Food Storage Suggestions 9
Temperature Controls
5
Storage Times
9
Vacation & Moving Tips
14
Ice Dispenser
6% Warranty
Back Cover
Icemaker
6% Water Filter Accessow
14
Instition
3,4
Adapter Plug
4
Adjustable RoUers 4
Clearances
4
Electrical Requirements 3,4
Extension Cord
4
Grounding
3
GE Answer Center@
Location
4
800.626.2000
GE Appliances

Help us help you...
Read this book carefully.
It is intended to help you operate
and maintain your new refrigerator
properly.
Keep it handy for answers to your
questions.
If you don’t understand something
or need more help, write (include
your phone number):
Consumer Affairs
GE Appliances
Appliance Park
Louisville, KY 40225
Write down the model and
serial numbers.
You’ll see them on a label at the
bottom, just inside the fresh food
compartment door.
These numbers are also on the
Consumer Product Ownership
Registration Card that came with
your refrigerator.
Before sending in the registration
card, please write these numbers
here:
Model Number
Serial Number
Use these numbers in any
correspondence or service calls
concerning your refrigerator.
If you received a damaged
refrigerator, immediately contact
the dealer (or builder) that sold you
the refrigerator.
Save time and money.
Before you request service, check
the Problem Solver. It lists causes
of minor operating problems that
you can correct yourself.
Energy-sating tips
● Location of your refrigerator is
important. Avoid locating it next to
your range, a heating vent or
where the sun will shine directly
on it.
● Don’t open the doors more often
than necessary.
● Close the doors as soon as
possible, particularly in hot,
humid weather.
● Be sure the doors are closed
tightly. Before leaving the house or
retiring for the night, check to be
sure the doors haven’t been left
open accidentally.
● Store only those foods requiring
refrigeration in your refrigerator.
● Wipe moisture from bottles and
cartons before putting them. in the
refrigerator.
● Keep foods covered to reduce
moisture buildup inside the
refrigerator.
Q If you turn the controls to the
coldest position for quick chilling
or freezing, be sure to turn them
back to regular settings.
● Don’t overcrowd your refrigerator.
Overcrowding can require extra
electrical energy to keep everything
cool.
Eyou need setice
To obtain service, see the
Consumer Services page in the
back of this book.
We’re proud of our service and
want you to be pleased. If for some
reason you are not happy with the
service you receive, here are three
steps to follow for further help.
FIRST, contact the people who
serviced your appliance. Explain
why you are not pleased. In most
cases, this will solve the problem.
NEXT, if you are still not pleased,
write all the details—including
your phone number—to:
Manager, Consumer Relations
GE Appliances
Appliance Park
Louisville, Kentucky 40225
Finally, if your problem is still not
resolved, write:
Major Appliance Consumer
Action Panel
20 North
Wacker Drive
Chicago, Illinois 60606
.—
—
2

-RTANT SA~W ~STRUCTIONS
Read all instructions before wing this appliance.
WA~IN& men using tiis
appliance, always exercise basic
safety precautions, including the
following:
s Use this appliance only for its
intended purpose as described in
this Use and Care Book.
● Thfi refrigerator must be
properly installed in accordance
tith the InsW1ation Instructions
before it is used. See grounding
instructions below and on page 4.
* Never unplug your refrigerator
by pulling on the power cord.
Always grip plug firmly and pull
straight out from the outlet.
● Repair or replace immediately
all electric service cords that
have become frayed or otherwise
damaged. Do not use a cord that
shows cracks or abrasion damage
along its length or at either the
plug or connector end.
—
● When moving your refrigerator
away from the wall, be careful
rtnt to roll over or damage the
power cord.
s ~er your refrigerator is in
operation, do not touch tie cold
surfac=, Wrticdarly when hands
are damp or wet.
Skin may adhere
to these extremely cold surfaces.
● Do not place fingers or hands
on the automatic icemaking
mechanism while the refrigerator
is plugged in.
This wdl prevent
contact with the moving parts of the
ejector mechanism, or with the
heating element that releases the
cubes.
● Don’t refreeze frozen foods
which have thawed completely.
The United States Department of
Agriculture in Home and Garden
Bulletin
No. 69 says:
“..
,You may safely refreeze frozen
foods that have thawed if they still
contain ice
crystis or if they are
still cold—below W“F.
“.. .Thawed ground meats, poultry
or fish that have
any off-odor or
off-color should not be refrozen
and should not be eaten. Thawed
ice cream should be discarded. If
the odor or color of any food is
poor or questionable, get rid of it.
The food may be dangerous to eat.
“Even partial thawing and refreezing
reduce the eating quality of foods,
particularly fruits, vegetables and
prepared foods. The eating quality
of red meat is affected less than that
of many other foods. Use refrozen
foods as soon as possible to save
as much of their eating quality as
you
can:’
● U your old refrigerator is still
around the house but not in use,
be sure to remove the doors. This
will reduce the possibility of
danger to children.
● Unplug your refrigerator:
A. Before making any repairs.
Note: We strongly recommend
that any servicing be performed
by a qualified individual.
B. Before cleaning.
C. Before replacing a burned-out
light bulb, the refrigerator should
be unplugged in order to avoid
contact with a live wire filament.
(A burned-out
tight bulb may
break when being replaced.)
Note: Turning control to OFF
position does not remove power
to the light circuit.
● Do not store or use combustible
materhds, gasobe or other
flammable vapors or
Mquids in
the
vacinity of this or any other
apptiance.
SAVE THESE
INSTRUCTIONS
~~ation Requiremen&l~ORTANT. ..Please read camfuUy.
How to connect
PREFERRED
,
electricity
METHOD
@Q ~\
For personal safety,
%
this appliance must be
properly grounded.
mm
G’--
-
‘
\
.,
INSURE PROPER
GROUND EXISTS
The power cord of this appliance is
Fig.1
])
BEFORE USE
equipped with a three-prong
(grounded)
plug which mates with Have wall outlet and circuit
a standard three-prong (grounding) checked by a qualified electrician
wall outlet (Fig. 1) to minimize the to make sure the outlet is properly
possibility of electric shock hazard
from this appliance. grounded.
Where a standard two-prong wall
outlet is encountered, it is your
personal responsibility and
obligation to have it replaced with
a properly grounded three-prong
wall outlet.
DO NOT,< UNDER Am
CIRCUMSTANCES, CUT
OR
REMO~ THE THIRD
(GROUND) PRONG FROM
THE POWER CORD.
(continued next page)
3

hS~atiOn Reqtiremenk (c.ntinued)–IMPORTANT...P1ease Read Carefully.
Use of Adapter Plug
Because of potential safety hazards
under certain conditions, we strongly
recommend against use of an adapter
plug. However, if you still elect to
use an adapter, where local codes
permit, a TEMPORARY
CONNEC~ON maybe made to a
properly grounded two-prong wdl
outlet by use of a ~ listed adapter
(Fig. 2) available at most local
hardware stores.
w-)
INSURE PROPER GROUND
Fig.2
AND FIRM ~NNEHION
BEFORE USE
The larger slot in the adapter must be
aligned-with the larger sl~t in the
wdl outlet to provide proper polarity
in the connection of the power cord.
CAUTION: Attaching an adapter
ground terminal to
wdl outlet cover
screw does not ground an appliance
unless cover screw is metal, and
not
insulated, and wdl outlet is
grounded through house wiring.
You should have circuit checked by
a qualified electrician to make” sure
the outlet is properly grounded.
When disconnecting the power
cord from the adapter, always
hold the adapter with one hand.
If this is not done, the adapter
ground terminal is very likely to
break with repeated use.
Should the adapter ground
terminal
bmk, DO NOT USE the
appliance until a proper ground
has again been established.
Use of Extension Cords
Because of potential safety hazards
under certain conditions, we
strongly recommend against the
use of an extension cord. However,
if you still elect to use an extension
cord, it is absolutely necessary that
it be a UL listed 3-wire grounding
type appliance extension cord
having a grounding type plug and
4
outlet and that the electrical rating
of the cord be 15 amperes
(minimum) and 120 volts.
The refrigerator should always
be plugged into
i~ own
individual electrical outlet—
(115 volt, 60 Hertz, or 100 volt, 50
Hertz, single phase AC). This is
recommended for best performance
and to prevent overloading house
wiring circuits, which could cause a
fire hazard from overheating wires.
Refrigerator Location
Do not install refrigerator where
temperature will go below
60°F.
because it will not run often enough
to maintain proper temperatures.
Do install it on a floor strong
enough to support it fully loaded.
Also see Energy-Saving Tips
regarding location.
Clearances
Allow the following clearances for
ease of installation, proper air
circulation, and plumbing and
electrical connections:
Sides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . %“
Top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . O“
(~built in, allow 7/8” at the top for
hinge covers.)
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1“
Allow the following door clearance:
Refrigerator Side ......................l
Z”
Freezer Side
..............................1%”
Water Supply to Icemaker
You will need to connect your
icemaker to a cold water line. A
water supply kit containing copper
tubing, shut-off valve, fittings and
instructions is available at extra cost
from your dealer. There should be
sufficient tubing for the icemaker
from the cold water supply to allow
moving the refrigerator out from the
wdl several feet (approximately 8
feet of 1/4” copper tubing in three
10-inch diameter coils).
Rollers
Adjustable rollers behind the base
grille enable you to move your
refrigerator away from the
wdl for
cleaning. These rollers should be set
so the refrigerator rests ftiy on the
floor. To
as;ure that the doors will
close automatically from a halfway -
open position, there is a built-in tilt
from the front to the back of the
cabinet. Side-by-side refrigerators
dso have specially designed door
hinges that lift both doors
sfightly
when opened, allowing the force of
gravity to help close them securely.
To adjust rollers, remove the base
grille by grasping it at the bottom
and pulling it out.
—
~rn the roller adjusting screws
clockwise to raise the refrigerator,
counterclockwise to lower it. Use
an adjustable wrench (3/8” hex
head bolt) or pliers.
When adjusting front rollers for
proper door closure, we recommend
the bottom front edge of the cabinet
be approximately 5/8” from the floor.
To replace base grille, align prongs -
on back of grille with clamps in
cabinet and-push forward
until
grille snaps into place.

Operating Your Refrigerator
—
Set the
Temperature Controls
I
1
FREEZER C INITIAL SETTING
E COLDEST I
INITIAL SETTING 5 FRESH FOOD
COLDEST 9
1
Your refrigerator has two controls
that let you regulate the temperature
in the fresh food and freezer
compartments.
INITMLLY, set the FRESH
FOOD controls at 5 and the
FREEZER control at C.
For colder or warmer temperatures,
—
adjust the desired compartment
control one letter or number at
a time.
~PORTANT
When initially setting the controls,
or when adjusting them, allow 24
hours for the temperatures to
stibilize, or even out.
Note:
~rning the fresh food
control to “OFF” stops cooling in
BOTH compartmen~fresh
food AND freezer—but does not
shut off power to the refrigerator.
How to Test Temperatures
Use the milk test for the fresh
food compartment.
Place a
container of milk on the top shelf in
the fresh food compartment. Check
it a day later. If the milk is too
warm or too cold, adjust the
temperature controls.
Use the ice cream test for the
freezer compartment.
Place a
container of ice cream in the center
of the freezer compartment. Check
it after a day. If it’s too hard or too
soft, adjust the temperature controls.
Always aBow M hours for the
refrigerator to reach the
temperature you set.
If you turn your
household thermostat
below
60°F. at night
. .
you may want to turn the lettered
control one step colder, as from “C”
to
“D:’ Cooler temperatures in the
house may cause the compress to
operate less frequently, thus
allowing the freezer compartment
to warm somewhat. To protect your
frozen food supply, leave your
lettered setting at this colder setting
for the entire winter or for whatever
period of time you are turning down
your thermostat. This is especially
important when the thermostat is
turned down for an extended period.
This change should have no effect
on your fresh food compartment.
However, if freezing occurs, turn
the numbered control one step
warmer, as from “5” to “4”.
When you stop turning the
Automatic
Energy Saver System
You won’t find an “energy saver”
switch on this refrigerator.
Warm liquid from the refrigerator’s
condenser is automatically
circulated around the front edge of
the freezer compartment to help
keep moisture from forming on the
outside of the refrigerator during
humid weather.
Many refrigerators use special
electric heaters. This refrigerator
needs none. That’s why there is no
“energy saver” switch.. there’s no
need for it.
No Defrosting
It is not necessary to defrost the
freezer or fresh food compartments.
Your refrigerator is designed and
equipped to defrost itself
automatically.
thermostat down, turn temperature
controls back to their regular setting.

Ice & Water Dispenser
—
Automatic Icemaker and
Ice & Water Dispenser
Your refrigerator has an automatic
icemaker and a dispenser that
dispenses water, ice cubes and
crushed ice through the freezer
compartment door. Here’s how
they work.
Water flows from the household
supply through a
(1) dual solenoid valve to the
(2) water reservoir and to the
(3) automatic icemaker as needed.
Water is frozen in the
(4) cube mold and ejected into the
(5) storage bin where a motor-
powered auger moves cubes forward
into the dispensing unit. Cubed or
crushed ice, as selected, dispense
through chute in door when cradle
is pressed.
When the switch is moved to
CRUSHED, baffle in housing
channels cubes through the crusher
and crashed ice falls through chute
into glass.
Water from reservoir flows
through the
(6) tubing in the door and is
dispensed when the cradle is
pressed.
(7) A light switch turns the night
light in the dispenser on or off.
Important Fact about Your
Ice & Water Dispenser
● Your icemaker will prodttce eight
cubes per cycleapproximately 120
cubes in a 24-hour period—
depending on freezer compartment
~mpemture, room temperature,
number of door openings and other
use conditions.
● Intermittent dispensing of ice
is normal. If
ice flow interruption
is more than brief, ice clump(s)
may be the cause and should be
removed by following instructions
in this section.
s Avoid ovefilhng glasses with ice
and using narrow or extra-tall
glasses. This can jam the chute or
cause the door in the chute to freeze
shut. Periodicdly open the freezer
compartment door and look down
into the chute. If ice is blocking the
chute, poke it through with a
wooden spoon.
* To help keep bits of ice from
being sprayed beyond the glass,
place glass close to ice chute—but
not so close that it blocks
outcoming ice.
● Ice should not be dispensed into
thin glasses, fine china or delicate
crystal-they can crack or chip
from the combined pressure of your
hand pressing them against
the
cradle and ice dropping into the
container.
● Ice should be dispensed before
fi~ing glass with soda or other
beverage mixes. This will prevent
splashing which is annoying md
which, if the splash reaches the ice
selector switch, could cause it to
stick or bind.
o Beverages and foods should not
be quick-chilled in the ice storage
bin. Cans, bottles or food packages
in the storage bin may cause tie
icemaker to malfunction.
● Ice other thm that produced by
your icemaker should not be
added to the ice storage bin—it
may not crush or dispense
wefl.
Before Using Your
Icemaker and Dispenser
If you use your refrigerator before
the water connection is made, raise
the ice access door and make sure
the icemaker feeler arm is in the
OFF (up) position as shown below.
Ice access
door
Icemaker
When water supply has been
connected to icemaker, move
feeler arm to ON (down) position.
in
Depress water dispenser cradle for
about two minutes to remove
trapped air from the water line and
to fill water reservoir automatically.
Ice cube mold automatically fills
with water after cooling to freezing
temperatures. First cubes normally
freeze after several hours.
NOTE: With a newly-instiled
refrigerator, allow about 24 hours for
the freezer compartment to cool down -
to the proper ice-making temperature.
6

Once Your Icemaker and
Dispenser Are in Operation
Throw away the first few batches
of ice cubes (16 or 24 cubes). This
will flush away any impurities in
the water line. Do the same thing
after vacations or extended periods
when ice isn’t used.
Discard the first six glassfuls of
water in the kitchen sink. This will
eliminate the slight “plastic” taste
temporarily imparted to the water
by the water reservoir.
Keep ice level to keep icemaker
productive. Cubes ejected into an
empty storage bin will pile up
close to the icemaker and push the
feeler arm up to the OFF position
prematurely when the bin is only
partially
fulI. Open the ice access
door, reach in, level the cubes by
hand and
icemaking will resume.
Keeping cubes distributed evenly
will allow the icemaker to produce
enough ice to fill the bin to its
maximum capacity.
Under certain rare circumstances,
ice cubes may be discolored,
usually appearing with a
~n-
bluish hue. The cause of this
unusual discoloration is
apparently
due to a combination
of factors such m certain
characteristics of local waters,
household plumbing and
the
accurrndation of copper s~ts in
an inactive water supply line
which feeds the icemaker.
Continued consumption of such
discolored ice
cubes may be
injurious to heahh. If such
discoloration is observed, discard
the ice cubes md contact your
GE Factov Service Center or an
authorized Customer Care@
Semicer.
To Dispense Ice and Water
● For ice, set selector switch to
CUBED or CRUSHED. For water,
simply position glass beneath the
word “WATER.”
● Grip glass or other container
gently near the rim and press rim
firmly against ice or water
dispenser cradle.
Caution: Never put fingers or
other objects into the ice
crusher discharge opening.
When Dispensing Ice...
Some crushed ice may be
dispensed even though you
selected CUBED. This happens
occasionally when a few cubes
accidentally get channeled to the
crusher.
Sometimes a mound of snow will
form on the door in the ice chute.
This condition is normal, and
usually occurs when you have
dispensed crushed ice repeatedly.
The snow will eventually
evaporate.
When Dispensing Water...
The water system provides
approximately six successive
6-ounce glassfuls—after which
several hours must be allowed for
replenished water reservoir supply
to cool. You probably will not
drain all the water from the
reservoir on a single occasion.
The first glass of water dispensed
may be warmer than the
following ones. This is normal.
Dispensed water is cool, not iced.
For colder water, simply add
crushed ice or cubes before
dispensing water.
7

Ice & Water Dispenser (continued)
To Stop Dispensing
Release pressure from cradle and
withdraw slowly to catch last bits
of ice or drops of water.
Some slight dripping may occur
following dispensing of crushed
ice or water. If excessive, the spill
should be wiped dry immediately.
Do not pour water in spill shelf
because it is not self-draining—
pour it in the kitchen sink. The
shelf and its grille should be
cleaned regularly according to
the Care and Cleaning section.
If Ice Clumps Form in
Storage Bin...
The icemaker ejects cubes in
groups of eight, and it is normal for
several cubes to be joined together.
However,
infrequent usage of ice
can cause ice clumps to form in
the storage bin, resulting in
temporary malfunction of the
dispenser mechanism.
If this happens:
● Remove storage bin from freezer
compartment.
● Break up ice clumps with
fingertip pressure and discard
remaining clumps.
● Replace bin before remaining
cubes melt and fuse together.
To Remove Ice Cube
Storage Bin...
A
I
Lift the left corner to free the bin
from the
shelf, and pull the bin
straight out while supporting it at
front and back.
To Replace Ice Cube
Storage Bin
Slide the bin back until the tab on
the bin locks into the slot in the
shelf.
If bin does not go all the way back,
remove it and rotate the drive
mechanism 1/4 turn. Then push bin
back again until the tab on the bin
locks into the slot in the shelf.
If Ice Is Not Used
Frequently...
“Old” ice cubes will become
cloudy and taste stale. Empty ice
storage bin periodically and wash
it in lukewarm water. Be sure to
allow storage bin to cool before
replacing
it+therwise ice cubes
will stick to the metal auger.
Move Icemaker Feeler
Arm to OFF (up) Position
When...
● Home water supply is to be
turned off for several hours.
● Ice storage bin is to be removed
for a period of time.
● Going away on vacation, at
which time you should also turn
off the valve in the water supply
line to your refrigerator.
If This Is Your First
Icemaker...
You’ll hear occasional sounds that
may be unfamiliar. These are
normal
icemaking sounds and are
not cause for concern.
8

Food Storage Suggestions
- Suggested storage times
for meat and poultry*
DAYS MONTHS
IN
IN
Eating quality drops
REFRIGERATOR FREEZER
after time shown AT AT
35” to 40°F. O°F.
Fresh Meats
Roasts (Beef & Lamb) 3 to 5 6 to 12
Roasts (Pork & Veal) 3 to 5
4 tO a
Steaks (Beef) 3 to 5 6 to 12
Chops (Lamb) . . . . . . . . . . . . . . . . . . . . . . . . . . 3 to 5 6 to 9
Chops (Pork) 3 to 5 3 to 4
Ground & Stew Meats . . . . . . . . . . . . . . 1 to 2 3 to 4
Variety Meats 1 to 2 3 to 4
Sausage (Pork) 1 to 2 1 to 2
Processed Meats
Bacon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 1
Frankfuflers 7 1/2
Ham (Whole) 7 1 to 2
Ham (Half) 3 to 5 1 to 2
Ham (Slices) 3 1 to 2
Luncheon Meats 3 to 5 Freezing
Sausage (Smoked) . . . . . . . . . . . . . . . . . . . 7 not recom-
Sausage (Dry & Semi-Dry) 14to 21 mended.
Cooked Meats
Cooked Meats and
Meat Dishes 3 to 4 2 to 3
Gravy & Meat Broth 1 to 2 2 to 3
Fresh Poultry
—
Chicken & Turkey (Whole) 1 to 2 12
Chicken (Pieces) 1 to 2 9
Turkey (Pieces) 1 to 2 6
Duck & Goose (Whole) 1 to 2
6
Giblets 1 to 2 3
Cooked Poultry
Pieces (Covered with Broth) 1 to 2
6
Pieces (Not Covered) 3 to 4
1
Cooked Poultry Dishes . . . . . . . . . . . . . 3 to 4 4 to 6
Fried Chicken 3 to 4
(Other than for meats& pOUltry) FRE;ZER
Most fruits and vegetables ........................8-12 months
Lean fish ....................................................6.8 months
Fatty fish, rolls and breads,
soups, stew, casseroles ..........................2-3 months
Cakes, pies, sandwiches,
leftovers (cooked),
ice cream (original carton) ....,................1 month max.
New techniques are constantly being developed.
Consult the College or County Extension Service
or your local Utility Company for the latest
information on freezing and storing foods.
*U.S. Depatiment of Agriculture
Meats, fish and poultry purchased
from the store vary in quality and
age; consequently, safe storage
time in your refrigerator will vary.
To store unfrozen meats, fish and
—
poultry:
● Always remove store wrappings.
● Rewrap in foil, film or wax paper
and refrigerate immediately.
To store cheese, wrap well with
wax paper or aluminum foil, or put
in a plastic bag.
● Carefully wrap to expel air and
help prevent mold.
● Store pre-packaged cheese in its
own wrapping if you wish.
To store vegetables, use the
vegetable drawers—they’ve
been
designed to preserve the natural
moisture and freshness of produce.
● Covering vegetables with a moist
towel helps maintain crispness.
● As a further aid to freshness, pre-
packaged vegetables can be stored
in their original wrapping.
Note: Special fresh fo{~d
compartment drawers make it
unnecessary
to wrap certain ,foods
which they ‘ve been desig~zed to
preserve. These drawers are
described in the Food-Saver
S>stem section.
To store ice cream—Fine-quality
ice cream, with high cream
content, will normally require
slightly lower temperatures than
more “airy” already-packaged
brands with low cream content.
● It will be necessary to
experiment to determine the
freezer compartment location and
temperature control setting to keep
your ice cream at the right serving
temperature.
● The rear of the freezer
compartment is slightly colder
than the front.
Tips on freezing foods
There are three essential
requirements for efficient home
freezing.
1. Initial quality. Freeze only top-
quality foods. Freezing retains
quality and flavor; it cannot
improve quality.
2.
Speed. The quicker fruits and
vegetables are frozen after picking,
the better the frozen product will
be. You’ll save time, too, with less
culling and sorting to do.
3. Proper packaging. Use food
wraps designed especially for
freezing; they’re readily available
at most food stores.
To freeze meat, fish and poultry,
wrap well in freezer-weight foil (or
other heavy-duty wrapping
material) forming it carefully to
the shape of the contents, This
expels air. Fold and crimp ends of
the package to provide a good,
lasting seal.
Don’t refreeze meat that has
completely thawed; meat, whether
raw or cooked, can be frozen
successfully only once.
Limit freezing of fresh (unfrozen)
meats or seafoods to 29 pounds at
a time.
For convenience...
● Store like things together. This
saves both time and electricity
because you can find foods faster.
● Place the oldest items up front so
they can be used up promptly.
● Use shelves on the door for most
often used sauces and condiments.
To save money in energy
and food costs
● Cover moist foods with tight lids,
plastic film or foil.
● Leaf vegetables and fruits placed
in drawers will
last longer when
stored in closed plastic containers
or wrapped in plastic film.
● Do not overload your fresh food
or freezer compartment with a lot
of warm food at once.
● Open the door the fewest times
possible to save electrical energy.
● When going out of town
for several days, leave as few
perishables as possible in the
refrigerator. Move the
icemaker
feeler arm to the OFF (up) position
and shut off water to the refrigerator.
9

General Electric Food-Saver System
Moist ‘n Fresh
drawer—
close
t;ghtly —
Convertible
Meat Keeper —
Moist ‘n Fresh Drawer
The top drawer is designed to
keep unwrapped foods fresh by
retaining the natural moisture
content of foods such as:
● Artichokes ● Cherries ● Plums
● Asparagus ● Corn ● Radishes
● Beets, topped ● Currants ● Rhubarb
● Blueberries ● Greens, leafy ● Spinach
● Carrots ● Lettuce ● Tomatoes,
● Celery ● Parsley ripe
● Peas, green
As in any refrigerated storage area,
it is recommended that odorous
foods be stored wrapped—foods
such
as:
● Broccoli ● Cabbage ● Parsnips
● Brussels ● Cauliflower ● Turnips
Sprouts ● Green Onions
Storage time will depend upon the
type of food and its condition
when placed in the drawer.
Excess water which may accumulate
in the bottom of the Moist ‘n Fresh
drawer should be poured out and the
drawer wiped dry.
The Moist ‘n Fresh drawer is
partially sealed by gaskets attached
to the cover at the front and back
edges.
Alway.~ replace it in this
cover and push the drawer all the
way in.
Convertible Meat Keeper
The Convertible Meat Pan drawer
has its own cold air duct to allow a
stream of cold air from the freezer
compartment to
flow around the
drawer.
The variable temperature control
regulates the air flow from the
freezer compartment.
Drawer Removal
Drawers will stop before coming
all the way out of refrigerator to
help prevent spilling onto
floor.
Drawers can easily be removed by
tilting up slightly and pulling past
“stop” location.
To remove drawers when the
fresh food compartment door
cannot be opened fully:
1. Remove food from the shelf
above the Moist ‘n Fresh drawer
and take out the shelf. Take food
off the glass cover and out of
drawer.
2. Remove the flexlble gasket at
the rear of the Moist ‘n Fresh
drawer. Lift each end straight up
until the slots on the gasket are
free of the drawer support tabs.
Set control lever to MEAT—the
coldest setting—to store fresh
meats. If lever is left in meat
position for a long period of time,
some frost may form
on the inside
of the drawer.
3. Pull the drawer part-way out.
Reach in, push the rear of the glass
up and, at the same time, push it
back until it clears the front corner
retainers.
4. Tilt and remove the cover.
Set control lever to VEG to
convert the drawer to normal
refrigerator temperature and
provide extra vegetable storage
space. Cold air duct is turned off.
Variable settings between these
extremes can be selected.
—
10

Quick ServeTM System
(on models so equipped)
5. Pull the drawer forward, lift the
front to clear stops, and remove the
drawer. If the refrigerator door
doesn’t open completely, pull the
drawer out until it hits the door.
Then lift the drawer up until it is
higher than the drawer supports,
—
tilt it and take it out.
6. If tape holds Convertible Meat
Pan cover to drawer supports,
remove the tape. Pull drawer
partway out. Reach in, push the
rear of the glass up and, at the
same time, back, until it clears
front-corner retainers.
—L
II I
7. Tilt and remove the cover.
8. Tilt and remove the drawer.
After cleaning, replace in reverse
order
9. Reinstall the gasket at the rear of
the vegetable drawer. Fit the end of
the plastic drawer support into the
slot on the gasket, with the rubber
gasket flap facing you. Make sure
the gasket snaps into place.
Sealed Snack Pack
The Sealed Snack Pack—and shelf
to which it is attached—can be
relocated within the Fresh Food
compartment. The sealed drawer
retains high humidity
for
convenient storage of meats and
cheese, bacon, hors d’oeuvres,
spreads and snacks.
Cooking-serving-storage dishes
with durable lids fit into a space
saving under-the-shelf rack. Dishes
can be removed from and returned
to the rack as needed, and the rack
(and shelf to which it is attached)
can be relocated anywhere in the
fresh food compartment.
Dishes and lids are:
● safe for use in microwave ovens.
● safe for use in refrigerators and
freezers.
● dishwasher safe.
Quick
Serve”’’” dishes only are safe
for use in conventional ovens at
temperatures up to
400°F.
CAUTION:
Dishes and lids are not designed
for range top cooking or broiler
use. Such use can be hazardous.
Lids cannot withstand the heat
generated in conventional ovens.
● Use both hands when removing
a dish, especially when it is full.
Otherwise, it may slip out of your
grasp, fall and spill.
11

SheMPositions
How to Rearrange Your
Shelves
Shelves in the fresh food and
freezer compartments are
adjustable, enabling you to make
efficient shelf arrangements to fit
your family’s food storage needs.
Tempered Glass Shelves in
Fresh Food Compartment
To remove shelves: Tilt the shelf
up at front, then lift it up and out of
the tracks on the rear wall of the
refrigerator.
, ~1~
❑ Engage -~
top lug ‘ -
E,owerto ,,,
lock into place
4
1
P
4“
To relocate shelves: Select desired
shelf height. With shelf front raised
slightly, engage the top lugs in the
tracks at the rear of the cabinet.
Then lower the front of the shelf
until it locks into position.
Removable Wine Rack
(on models so equipped)
The wine rack is designed to hold
a bottle on its side and will fit on
any shelf.
To relocate the wine rack:
Pull wine rack straight out. Then
position its lip over either edge of
the shelf you want to suspend it
from and push it all the way in.
Porta-Bins on Fresh Food
Compartment Door
Adjustable Porta-Bins can easily
be carried from the refrigerator to
your work area.
Snuggers hold smaller items
securely in the bin to help prevent
tipping, spilling and sliding.
To remove: Lift Porta-Bin straight
up until mounting hooks
disengage.
To replace or relocate: Select
desired shelf height, engage
Porta-
Bin’s hook in slots on the tracks of
the door, and push in.
Porta-Bin
will lock in place.
Multi-Position Shelves in
Freezer Compartment
Shelf supports at various levels in
the freezer compartment let you
reposition the shelves from time to
time to better accommodate your
variable inventory of frozen foods.
To reposition shelves:
1.
While pressing
tabs on shelf
supports on right
wall, lift shelf out
of grooves in
supports.
2. Pull shelf
sideways until
shelf rods come
out of holes on
left wall.
,
—
3. Select desired
shelf height and
insert shelf rods
into holes on left
wall. If shelf
supports at
desired level on right wall have
tabs, lower shelf into grooves on
support while pressing tabs. Be
sure shelf wire is fully inserted into
grooves.
If shelf supports at desired level
on right wall do not have tabs,
merely lower shelf into place on
supports.
Deep Door Shelves in
Freezer Compartment
Detachable shelf extenders deepen
and enclose three fixed door
shelves, providing more storage
room and greater storage
flexibility.
To remove, lift the shelf extender
straight up until the mounting
hooks come out of the slots in the
door.
To replace, lineup the hooks with –
the slots in the door then push in
and down.
12

Care and Cleating
Cleaning-Ouhide
The water and ice dispenser
spill shelf should be wiped dry
immediately to prevent spotting.
Water left on the shelf may leave
deposits that you can remove by
soaking in undiluted vinegar.
You can also use a paste of non-
precipitating water softener (such
as
Calgon brand) and water, or one
teaspoon of citric acid powder per
pint of hot tap water. Soak until the
deposit disappears or becomes
loose enough to rinse away.
Usually 30 minutes soaking time is
adequate. Avoid using wax on the
spill shelf and trim.
The door handles and trim can
be cleaned with a cloth dampened
with a solution of mild liquid
dishwashing detergent and water.
Dry with a soft cloth. Don’t use
wax on the door handles and trim.
Keep the finish clean. Wipe with
a clean cloth lightly dampened
with kitchen appliance wax or mild
liquid dishwashing detergent. Dry
and polish with a clean, soft cloth.
Do not wipe the refrigerator with a
soiled dishwashing cloth or wet
towel. These may leave a residue
that can damage the paint. Do not
use scouring pads, powdered
cleaners, bleach or cleaners
containing bleach because these
products can scratch and weaken
the paint finish.
Protect the paint finish. The finish
on the outside of the refrigerator is a
high quality, baked-on paint finish.
With proper care, it will stay new-
looking and rust-free for years.
Apply a coat of kitchen appliance
wax when the refrigerator is new
and then at
least twice a year.
Appliance Polish Wax & Cleaner
(Cat. No. WR92X0216) is
available from GE Appliance Parts
Marts.
Cleaning-Inside
inside the fresh food and freezer
compartments should be cleaned
at least once a year. Unplug the
refrigerator before cleaning. If this
is not practical, wring excess
moisture out of sponge or cloth
when cleaning around switches,
lights or controls.
Use warm water and baking soda
solution—about a tablespoon of
baking soda to a quart of water.
This both cleans and neutralizes
odors. Rinse thoroughly with water
and wipe dry.
Other parts of the refrigerator—
including door gaskets, meat and
vegetable drawers, ice storage bin
and all plastic parts-can
be
cleaned the same way. Do not use
cleansing powders or other
abrasive cleaners.
To help prevent odors, leave an
open box of baking soda in the rear
of the refrigerator, on the top shelf.
Change the box every three
months. An open box of baking
soda in the freezer will absorb
stale
freezer odors.
Do not wash any plastic parts
from your refrigerator in your
automatic dishwasher.
Drain opening in freezer
compartment. During yearly
cleaning, remove bottom freezer
basket and flush a solution of
baking
soda+ne teaspoon and
two cups of hot (not boiling)
water—through the drain line with
the help of a meat baster. This will
help eliminate odor and reduce the
likelihood of a clogged drain line.
If drain becomes
\
clogged, use a
meat baster and
baking-soda-and-
water solution to
force the clog
through the
drain line.
Behind Refrigerator
Care should be taken in moving
your refrigerator away from the
wall. All types of floor coverings
can be damaged, particularly
cushioned coverings and those
with embossed surfaces. Pull the
refrigerator straight out and return
it to position by pushing it straight
in. Moving your refrigerator in a
side direction may result in
damage to your floor covering
or refrigerator.
Condenser
For most efficient operation,
remove the base grille (see the
Installation Requirements section)
and either sweep away or vacuum
up dust that is readily accessible.
For best results, use a brush
specially designed for this purpose.
It is available at most appliance
parts stores. This easy cleaning
operation should be done at least
once a year.
(continued next page)
13

Care and Cleafing (continued)
Light bdb
replacement
In Fresh Food Compartment
1. Unplug refrigerator.
2. To align the control knob
properly, note position of
numbered control for proper
reassembly and pull off knob.
3. Pull bottom of light panel down
about
l/4’’—just enough to
disengage lip at rear from grooves
in retainers on rear wall.
4. Lift panel to disengage top from
pins on side walls; remove panel.
After replacing with same size
bulb, reinstall panel (hang top on
pins; pull bottom down, push it
back and release it to let lip engage
grooves in retainers). Replace
temperature control knob in OFF
position, turn it to previous setting,
and plug refrigerator back in.
In Freezer Compartment
1. Unplug refrigerator.
H
After replacing with same size
bulb, reinstall shield and shelf and
plug refrigerator back in.
When you goon
vacation
For extended vacations or
absences, shut off power to
refrigerator, turn the numbered
control to OFF, clean interior with
baking soda solution of one
tablespoon of soda to one quart of
water. Wipe dry. To prevent odors,
leave open box of soda in
refrigerator. Leave doors open.
For shorter vacations, remove
perishable foods and leave controls
at regular settings. However, if
room temperature is expected to
drop below
60°F., follow same
instructions as for extended
vacations.
Move icemaker feeler arm to OFF
(up) position and be sure to shut
off water supply to the refrigerator.
When you move
Disconnect power cord from wall
outlet, remove all food and clean
and dry the interior.
Secure all loose items such as
grille, shelves and storage pans by
taping them securely in place to
prevent damage.
Be sure refrigerator stays in
upright position during actual
moving and in van. Refrigerator
must be secured in van to prevent
movement. Protect outside of
refrigerator with blanket.
Water filter
accessory
The perfect companion to
your automatic icemaker—
a water filter
Your ice cubes can only
be as fresh-tasting as the
water that produces
them. That’s why it’s a
good idea to purify your
water with a water filter.
Its activated charcoal
removes musty, stale
odors and unpleasant
medicinal, metallic
tastes. A porous fiber
cartridge catches dirt,
rust particles, sand and
silt while special crystals
reduce deposits of
hard scale.
The water filter is an option at
extra cost and is available from
your GE dealer. Specify
WR97X0214. It has complete
installation instructions and installs
in minutes on 1/4” O.D. copper
water line.
2. Remove shelf just below light
shield. (Shelf will be easier to
remove if it is emptied first.)
3. Pull plastic light shield toward
you. (It will bend to free tabs from
grooves.)
14

Questi(
Use Th
PROBLEM
REFRIGERATOR
DOES NOT OPERATE
MOTOR OPERATES
FOR LONG PERIODS
MOTOR STARTS &
STOPS FREQWNTLY
VIBRATION OR
RATTL~G
HOT AIR FROM
BOTTOM
OF
REFRIGERATOR
DOOR NOT CLOSING
PROPERLY
Ins?
is Problem Solver
POSSIBLE CAUSE AND REMEDY
* May be in defrost cycle when motor does not operate for about 30 minutes.
● Temperature control in OFF position.
● If interior light is not on, refrigerator may not be plugged in at wall outlet.
● If plug is secure and the refrigerator still fails to operate, plug a lamp or a small
appliance into the same outlet to determine if there is a tripped circuit breaker or
burned out fuse.
* Modern refrigerators with more storage space and a larger freezer compartment
require more operating time.
● Norrnrd when refrigerator is first delivered to your home—usually requires 24 hours
to completely cool down.
● Large amounts of food placed in refrigerator to be cooled or frozen.
* Hot weather-frequent door openings.
s Door left open.
● Temperature controls are set too cold. Refer to instructions for use of
TEMPERA~RE CONTROLS.
● Grille and condenser need cleaning. Refer to Care and Cleaning section.
● Check ENERGY-SAV~G TIPS.
● Temperature control starts and stops motor to maintain even temperatures.
. If refrigerator vibrates, more than likely it is not resting solidly on the floor and front
roller screws or front leveling legs need adjusting or floor is weak or uneven. Refer to
ROLLERS section.
● If dishes vibrate on shelves, try moving them, Slight vibration is normal.
● Normal air flow cooling motor. In the refrigeration process, it is normal that
heat be expelled in the area under the refrigerator. Some floor coverings will discolor
at these normal and safe operating temperatures. Your floor covering supplier should
be consulted if you object to this discoloration.
● Door gasket on hinge side sticking or folding over. To correct, put a small amount of
petroleum jelly on face of gasket.
(continued next page)
15
—
—

The Woblem Solver (continued)
PROBLEM
OPERATWG SOUNDS
FRESH FOOD
OR FREEZER
COMPARTMENT
TEMPERATURE
TOO WARM
FOODS DRY OUT
FROST
OR ICE
CRYST&S ON
FROZEN FOOD
SLOW ICE C~E
FREEZ~G
ICE CUBES HAVE
ODO~ASTE
—
POSSIBLE CAUSE AND REMEDY
* The high speed compressor motor required to maintain near zero temperatures in the
large freezer compartment may produce higher
sound levels than your old refrigerator.
* Normrd fan air flow+ne fan blows cold air through the retigerator and freezer
compartments, another fan
cools the compressor motor.
● These NORMAL sounds will also be heard from time to time:
* Defrost timer switch clicks at defrost.
● Defrost water dripping.
● Temperature control clicks ON or OFF.
. Refrigerant boiling or gurgling.
* Cracking or popping of cooling coils caused by expansion and contraction dting
defrost and refrigeration following defrost.
● With automatic icemaker, the sound of cubes dropping into the bin and water
running in pipes as
icemaker refills.
“ Temperature control not set cold enough. Refer to TEMPEU~RE CONTROLS
section.
● Warm weather—frequent door openings.
● Door left open too long.
● Package may be holdi~g door open.
● Foods not covered, wrapped or sealed properly.
* Door may have been left ajar or package holding door open.
* Door openings too frequent and too long .
* Frost within package is norrnd.
● Door may have been left ajar.
● Turn down temperature of freezer compartment.
* Old cubes need to be discarded.
* Ice storage bin needs to be emptied or washed.
● Unsealed packages in refrigerator an~or free2er compartments may be transmitting
odor/taste to ice cubes.
* hterior of refrigerator needs cleaning—refer
t~ the Care and Cleaning section.
● Poor-tasting incoming water. Install a water f~lter—
see Water filter accessory section.
—
16

PROBLEM
AUTOMATIC
ICEMA~R
DOES NOT WORK
CUBE DISPENSER
DOES NOT WORK
WATER HAS POOR
TASTWODOR
WATER IN ~RST
GLASS IS WARM
WATER DISPENSER
DOES NOT WORK
DIVIDER BETWEEN
COMPARTMENTS
~ELS WARM
MOISTURE FORMS
ON OUTSIDE OF
REFRIGERATOR
MOISTURE
COLLECTS
~S~E
WA~R ON FLOOR
POSSIBLE CAUSE AND REMEDY
● Icem&er feeler arm in OFF (up) position.
● Water supply turned off or not connected.
* Freemr compartment too warm.
● Cubes too smrdl-water shutoff valve connecting refrigerator to home waterline may
be clogged.
* Piled up cubes in storage bin may cause
icemaker to shut off prematurely. Witi
icemaker feeler arm in 0~ (up) position, level cubes in bin by hand.
● No ice cubes. Remove storage bin. If cubes are fro2en to wire arm, remove cubes.
● No ice cubes. Icemaker turned off or water supply turned off.
● Irregular ice clumps in storage container. Break up as many as you can with fingertip
pressure and discard the remaining clumps.
*
H water dispenser has not been used for an extended period, dispense water in regular
manner until all water in reservoir is replenished with fresh water.
● Poor-tasting incoming water. Install a water filter-see Water filter accessory section.
● Allow about 24 hours for water to cool to proper temperature after refrigerator is
first installed.
● If water dispenser has not been used for extended period, water in f~st glass will not
be as cool as in succeeding glasses.
● H water reservoir has been drained, allow several hours for replenished supply to chill.
● Water supply line turned off or not connected.
● Supply line may be clogged with sediment.
● Normal warmth is created by automatic energy saver system circulating warm liquid
around front edge of freezer compartment to help prevent condensation on outside of
refrigerator in hot, humid weather.
● Not unusual during period of high humidity.
● Door openings too frequent and too long.
● In humid weather, air carries moisture into refrigerator when doors are opened.
● The drain at the bottom of the freezer may be clogged. Remove any ice on the free2er
bottom and clean the drain. Refer to the Care and Cleaning section.
● If you use a glass over 6 inches tall, you may be j
amming the cubes in the
fumel chute. They can fuse inside the chute and drop out later, leaving water or
ice on the floor.
(continued next page)
17

The Problem Solver (continued)
PROBLEM POSSIBLE CAUSE AND REMEDY
I
REFRIGERATOR
● Foods with strong odors should be tightly covered.
HAS ODOR
● Check for spoiled food.
I
● Interior needs cleaning. Refer to the Care and Cleaning section.
I ● Defrost watersystemneeds cleaning.
● Keep open box of baking soda in refrigerator; replace every three months.
INTERIOR LIGHT
● No power at outlet.
DOES NOT LIGHT
● Light bulb needs replacing. See the Care and CIeaning section.
If you need more help...call, toll free:
GE Answer
Center@
800.626.2000
consumer information service
18

Wdll Be There
With tie purchase of your new GE appliance, receive tie
assurancethatifyoueverneedinformationorassistance
from GE, we’ll be there.
Al you have to do is cdl—toll-free!
GEAnswer Center@
lmHome Repak
Service
M-GE-CARES
AGE Consumer Service professional
—
wfll provide mpert repair semice,
scheduled at a time that’s convenient
for you. Many GE Consumer Service
company-opem~d locations offer you
service today or tomorrow, or at your
convenience (7:00 a.m. to 7:00 p.m.
weekda~ 9:00 a.m. to 2:00 p.m. Satur-
days). Our factory-trained technicians
know your appliance inside and out—
so most repairs can be handed in just
one visit.
Service Contracts
8M-626-~4
You can have the secure feeling that
GE Consumer Service
wdl stall be
there af~r your warranty mpires. Pur-
chase a GE contract whale your war-
ranty is
stfil in effect and you’ll receive
a subs~tid discount. With a mdtiple-
year contract, you’re assured of future
service at today’s prices.
WhateveL your question about any GE
major appliance, GE Answer Cente#
information service is avaflable to
help. Your cdl—and your
question—
wdl be answered prompdy and
courteously And you can
cdl any
time. GE Answer Cente@ service is
open 24 hours a day 7 days a week.
Pam andAccewories
8M-626-2M2
L
—
t.
.
bdividu~ qtiled to service their
own appliances can have needed
parts or accessories sent
direcdy to
their home, free of shipping charge!
The GE par~ system provides access
to over 47,000 parts.. and dl GE
Genuine Rena Parfi are filly
warranted.
WSA, MasterCard and
Discover cards are accepted.
User maintenance instructions
contained in this boo~et cover
proce-
d~
ktended to be performed by
any user. Other servicing
genedy
shodd be referred to qtied ser-
vice pe~nnel. Caution must be
exercised, since improper servicing
may cause unsafe operation.
For Customers Wfih
~.T,. ,,-
,1
I
Special Needs...
Upon request, GE will provide Bradle
controls for a variety of GE appliances,
and a brochure to assist in planning a
barrier-free kitchen for persons with
limited
mobtiity To obmin these items,
free of charge, cdl 800.626,2000.
Consumers with impaired hearing
or speech who have access to a TDD
or a conventional teletypewriter may
Cdl 800-TDD-GEAc (800-833-4322)
to request information or service.

YOUR GE REFRIGERATOR
WARRANTY
Save proof of original purchase date such as your sales slip or cancelled check to establish warranty petiod.
LI
WHAT IS COVERED
FULL ONE-YEAR WARRANTY
For one year from date of original
purchase, we will provide, free of
charge, parts and service labor in
your home to repair or replace any
part of the refrigerator that fails
because of a manufacturing
defect.
FULL FIVE-YEAR WARRANTY
For five years from date of original
purchase, we will provide, free of
charge, parts and service labor in
your home to repair or replace any
part of the sealed refrigerating
system (the compressor,
condenser, evaporator and all
connecting tubing) that fails
because of a manufacturing
defect.
LIMITED LIFETIME WARRANTY
For the life of the refrigerator, we
will replace, free of charge,
any
tinted see-through pan or drawer
made from Lexafl polycarbonate
resin
and furnished with the
refrigerator if the pan or drawer
breaks during normal household
use. Drawer covers are not included.
To avoid any trip charges, you must
take the pan or drawer to a General
Electric Appliance
Pads Mart and
pick up a replacement.
This warranty is extended to
the original purchaser and any
succeeding owner for products
purchased for ordinary home use
in the 48 mainland states, Hawaii
and Washington, D.C. In Alaska the
warranty is the same except that it
is LIMITED because you must pay
to ship the product to the service
shop or for the service technician’s
travel costs to your home.
All warranty service will be
provided by our Factory Service
Centers or by our authorized
Customer Care” servicers during
normal working hours.
Look in the White or Yellow Pages
of your telephone directory for
GENERAL ELECTRIC COMPANY,
GENERAL ELECTRIC FACTORY
SERVICE, GENERAL
ELECTRIC-
HOTPOINT FACTORY SERVICE
or GENERAL ELECTRIC
CUSTOMER CARE” SERVICE.
WHAT IS NOT COVERED
● Service trips to your home to ● Replacement of house fuses
or
teach you how to use the product. resetting of circuit breakers.
Read your Use and Care material.
● Failure of the product if it is used
If you then have any questions for other than its intended purpose
about operating the product please
or used commercially.
contact your dealer or our
Consumer Affairs office at the ● Damage to product caused
by accident, fire, floods or acts
address below, or call, toll free:
of God.
GE Answer CenteF
800.626.2000 ● Loss of food due to spoilage.
consumer information service WARRANTOR IS NOT
RESPONSIBLE FOR
● Improper installation. CONSEQUENTIAL DAMAGES.
If you have an installation problem,
contact your dealer or installer.
You are responsible for providing
adequate electrical, plumbing and
other connecting facilities.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which va~ from state to state
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company
If further help is needed concerning this warranty, write:
Manager<onsumer Affairs, GE Appliances, Louisville, KY 40225
This book is prjnted on recycled paper
—
Pad No. 162 D1527PO08 TFX27R
Pub. No. 49-6666 TFX27V
TFXW27R
5-91 CG
