1. Introduction
The Model C-RS clamp-on ultrasonic flow transducer for liquids is used exclusively with the GE line of ultrasonic
flowmeters. These transducers measure the flow rate of sonically-conductive liquids through pipes having diameters
from 2 in. (5 cm) to over 300 in. (7.6 m). Such measurements are typically independent of the pipe material.
2. Transducer Construction
C-RS transducers may be used at process temperatures from -40 to 302oF (-40 to 150oC). Each C-RS transducer
assembly consists of the following components (see Figure 1):
•A stainless steel adapter with 3/4” NPT male thread for attaching a junction box
•A transducer that consists of a piezoelectric element mounted on a wedge and wired to the BNC connector
•A BNC style connector for use in connecting the transducer to the flowmeter.
Note: The process temperature range specified above is for ATEX certified designs. Consult the factory for higher
temperatures.
Figure 1: General C-RS Transducer Assembly
BNC Connector
Transducer Body
Adapter

2C-RS Ultrasonic Flow Transducer Installation Guide
3. Couplants
An ultrasonic couplant is supplied for your C-RS installation. The purpose of the couplant is to provide reliable
transmission of ultrasound between two adjacent solid surfaces. Generally speaking, couplants perform this task by
excluding air from between the adjacent surfaces. Accordingly, the C-RS transducers should be pressed tightly against
the pipe, using hand pressure on the set screw to squeeze the couplant to as thin a film as practical for the given pipe
surface.
The most commonly used couplants in ultrasonic testing are ordinarily satisfactory for any short-term clamp-on
flowmeter application. These couplants include, in general order of preference: gels, grease, propylene glycol, oil,
glycerine, and water. Long-term couplants include grease, epoxy adhesive, and solid rubber-like sheet couplant.
The factory provides couplants for both permanent and temporary use as well as for high- and low-temperature
applications. For long-term installations, make sure the couplant does not dry or run out.
Standard couplants supplied by GE are listed in Table 1.
4. Preparing for Installation
Before the clamping fixture and transducers can be properly installed, you must do the following:
•Choose an installation location
•Prepare the pipe
•Obtain the transducer spacing
•Determine the number of traverses
CAUTION! A flowmeter’s accuracy and performance depends on the location, spacing, and alignment of
the transducers. The transducer spacing is unique to your installation.
Table 1: Couplants
PART NO. TYPE TEMP. RANGE USE
CPL-1 Standard -40 to 149oF (-40 to +65oC) Semi-Permanent
CPL-2 High/Low Temperature -256 to 500oF (-160 to +260oC) Semi-Permanent
CPL-3 For Portable -4 to 140oF (-20 to +60oC) Temporary
CPL-4 Special As Required *Difficult Applications
CPL-7 Epoxy 14 to 122oF (-10 to +50oC) Permanent
CPL-8 Solid Sheet -40 to 446oF (-40 to +230oC) Permanent
*Installations involving hotter or colder temperatures than listed above, may require special
couplants. Consult the factory for such applications.

C-RS Ultrasonic Flow Transducer Installation Guide 3
4.1 Choosing an Installation Location
To select a suitable transducer location, complete the following steps:
1. Locate the transducer measurement point at least 3 ft (1 m) from any butt welds or flanges. Ideally the location
would be in the center of a 20 ft (6 m) section of straight pipe. Make sure there is sufficient clearance on both sides
of the pipe for easy transducer installation:
•6 in. (15 cm) if you are not using a junction box, or
•9 in. (22.5 cm) if you are using a junction box.
Note: To guarantee the specified accuracy of the flowmeter, a straight section of pipe and a fully-developed flow
profile are highly recommended. If such conditions are not possible, the transducer location should be such
that the acoustic signal travels through the full distribution of the under-developed flow profile for best
repeatability.
2. Place the transducers as close as possible to the horizontal plane of the pipe (see Figure 2). Locate the transducers
on opposite sides of the pipe 180oapart, ideally at the 3 and 9 o’clock positions.
IMPORTANT: Do not place transducers on the top or bottom of the pipe.
Note: For the best flow profile identification in limited straight section of pipe, place the transducers at 1 and 7
o’clock.
Figure 2: Transducer Placement
Transducer
Pipe
Signal Path
End View

4C-RS Ultrasonic Flow Transducer Installation Guide
4.2 Preparing the Pipe
To prepare the pipe for transducer installation, complete the following steps:
1. Remove any rust and paint from an area 2 in. (5 cm) wide by 4 in. (10 cm) long on one side of the pipe.
2. Polish the cleaned area, taking care to preserve the original curvature of the pipe.
3. With an ultrasonic thickness gage, measure the pipe thickness at a minimum of six spots on the cleared area. Take
at least three measurements at each spot to ensure accuracy. The thickness readings should not vary by more than
5% at each spot. If you encounter more than a 5% variation at each spot, try a different section of the pipe. Verify
that the wall thickness at both transducer locations has less than the 5% variation.
4. Measure the outside diameter (OD) of the pipe using a tape measure or the supplied pipe wrap.
4.3 Obtaining the Transducer Spacing
Before installing the clamping fixture, you must obtain the calculated transducer spacing from the flowmeter. You will
need to know the transducer spacing to complete this procedure.
To obtain the transducer spacing, you must enter the measured pipe OD and the pipe wall thickness into the Pipe
Parameters menu of the flowmeter User Program The flowmeter will then calculate the correct transducer spacing for
the installation. Refer to your flowmeter User’s Manual for more details.
4.4 Determining the Number of Traverses
The next step in the installation is to determine the number of traverses that you will use. The transducers can be
mounted using one of two methods (see Figure 3 on the next page):
Note: The “number of traverses” refers to the number of times the ultrasonic signal transmitted from one transducer
passes through the fluid from one side of the pipe to the other before it reaches the second transducer.
•Double-traverse method (“V” method) - transducers are mounted on the same side of the pipe. The ultrasonic
signal is sent from one transducer to the other by bouncing it off the opposite pipe wall.
•Single-traverse method (“Z” method) - transducers are mounted diagonally across from each other. The ultrasonic
signal is transmitted directly from one transducer to the other by traveling across the pipe.
If the pipe diameter is 4 to 20 in. (10 to 50 cm), you should always try the double-traverse method first, because it
easier to install and provides greater accuracy. The single-traverse method is preferred in the following situations:
•pipe diameters greater than 20 in. (50 cm)
•pipes with poor inside surface conditions
•applications with a highly attenuating fluid
Note: For all installations, it may be useful to try both methods to determine which one yields more accurate results.
Proceed to the appropriate section to properly install your clamping fixture and transducers.

C-RS Ultrasonic Flow Transducer Installation Guide 5
4.4 Determining the Number of Traverses (cont.)
Figure 3: Double- and Single-Traverse Installations
Double Traverse (“V” Method)
Single Traverse (“Z” Method)
Ultrasonic Signal Path
Transducer
Transducer
Transducers
TOP VIEW
TOP VIEW

6C-RS Ultrasonic Flow Transducer Installation Guide
5. Installing the Universal Clamping Fixture and Transducers - UCF
The Universal Clamping Fixture (UCF) acts as a spacing device and a transducer holder. The UCF is available in two
lengths and includes several components. Before you begin the installation, you should verify that your fixture is the
correct length and familiarize yourself with the fixture components.
IMPORTANT: To maintain ATEX certification the transducer face must be protected against impact. Protection is
provided by properly installing the transducer into the clamping fixture. Care must be taken during
installation to ensure that protection is provided.
5.1 Verify Fixture Length
The UCF is available in 12 in. (30 cm) and 24-in. (60 cm) lengths. Each size fixture can be used for either the single- or
double-traverse method. However, the pipe size ranges listed in Table 2 below must be followed for each method.
Note: The mounting chain or strap provided by GE with your UCF is the one best suited for your application.
5.2 Identifying the UCF Components
The UCF includes the following components (see Figure 4 on page 7):
•Two adjustable short blocks for use in the double-traverse method
•Two slide tracks that connect the two blocks
•A ruler attached to one of the slide tracks to help set the transducer spacing
•A long block for use in the single-traverse method
The UCF is chained or strapped to the pipe. Two blocks, which are positioned using the transducer spacing calculated
by the flowmeter, are used to hold the transducers in the proper location on the pipe.
Table 2: UCF Pipe Size Ranges
Clamping Fixture
Length
Single-Traverse
Pipe Diameter
Double-Traverse
Pipe Diameter
12-in.
(30 cm)
2 to 24 in.
(5 to 60 cm)
2 to 12 in.
(5 to 30 cm)
24-in.
(60 cm)
2 to 48 in.
(5 to 120 cm)
2 to 24 in.
(5 to 60 cm)

C-RS Ultrasonic Flow Transducer Installation Guide 7
5.2 Identifying the UCF Components (cont.)
Figure 4: Components of the UCF
End View Side View
Locking Nut
Short Block
1 Screw Hook
Long Block
2 Screw Hooks
Thumbscrew
Chain
Example with Short Blocks
Slide Track
(fixed and adjustable)
Pressure Bolt

8C-RS Ultrasonic Flow Transducer Installation Guide
5.3 The Double-Traverse Method -UCF
Note: The instructions in this section can also be used for a multiple-traverse method. However, you must use an
EVEN number of traverses. Consult the factory for details.
There are three advantages to using the double-traverse method:
•Accuracy is improved because the signal is in contact with the fluid longer than with a single-traverse method
•This configuration can reduce some effect of an underdeveloped flow profile.
•If there is enough pipe length available, the double-traverse fixture is easier to install.
Note: You will only need the short block assembly for a double-traverse installation. The long block is not used.
To install a double-traverse UCF, complete the following steps:
1. Obtain the transducer spacing dimension, as described in your flowmeter User’s Manual.
2. Be sure the location you have chosen for the installation has a straight pipe and undisturbed flow for at least 10
pipe diameters upstream and 5 pipe diameters downstream from the flow measurement point.
3. Prepare the pipe where you intend to place the clamping fixture by making sure it is clean and free of loose
material. Sanding, though usually not required, may be necessary to remove any high spots on the pipe. When
sanding, be careful to preserve the original curvature of the pipe.

C-RS Ultrasonic Flow Transducer Installation Guide 9
5.3 The Double-Traverse Method -UCF (cont.)
4. Using the attached ruler, move the blocks so they are a distance Sfrom each other. As shown below, use either the
pressure bolts or the ends of the blocks as reference points.
5. Position the clamping fixture along the horizontal plane of the pipe - not on the top or bottom. Make sure the
chains are both on the opposite side of the pipe from the slide track with the ruler.
S = Spacing
S = Spacing
S = Spacing
Centerline
Centerline
Side View

10 C-RS Ultrasonic Flow Transducer Installation Guide
5.3 The Double-Traverse Method -UCF (cont.)
6. Wrap the chain around the pipe and fasten the chain on the “J” screw hook on the opposite side of the block. Do
this for both blocks.
7. Using the screw hook on the blocks, tighten the chains until the fixture is secured snugly to the side of the pipe.
Note: Make sure the chains are perpendicular to the clamping fixture and are not twisted. If the chains are slanted,
the fixture may move and this could change the final transducer spacing.
Figure 5 shows a completed double-traverse installation without transducers.
Figure 5: Double-Traverse Clamping Fixture w/o Transducers
Top View
Side View
Top View

C-RS Ultrasonic Flow Transducer Installation Guide 11
5.4 The Single-Traverse Method - UCF
Note: The instructions in this section can also be used for a multiple-traverse method. However, you must use an
ODD number of traverses. Consult the factory for details.
Note: You will need both the short block assembly and the long block for a single-traverse installation. You will also
need a marker or scribe to mark the transducer locations on the pipe
To install a single-traverse UCF, complete the following steps:
1. Obtain the transducer spacing dimension, as described in your flowmeter User’s Manual.
2. Be sure the location you have chosen for the installation has a straight pipe and undisturbed flow for at least 10
pipe diameters upstream and 5 pipe diameters downstream from the flow measurement point.
3. Prepare the pipe where you intend to place the clamping fixture by making sure it is clean and free of loose
material. Sanding, though usually not required, may be necessary to remove any high spots on the pipe. When
sanding, be careful to preserve the original curvature of the pipe.
4. Find the top of the pipe and use a level to draw a line parallel to the center line of the pipe.
Line Top of Pipe
Side View

12 C-RS Ultrasonic Flow Transducer Installation Guide
5.4 The Single-Traverse Method -UCF (cont.)
5. Make two marks on the line at the top of the pipe. The distance between these two marks must equal the calculated
transducer spacing S.
6. From one of the marks, measure around the circumference of the pipe a distance equal to 1/4 of the pipe
circumference. Make a crossmark at this point.
Spacing
Mark Mark
Side View
Spacing
Crossmark
Side View
