GE Spacemaker 7-4235 User manual

FCC Information
EN
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
In accordance with FCC requirements, changes or
modifications not expressly approved by Thomson
Inc. could void the user’s authority to operate this
product.
This device generates and uses radio frequency (RF)
energy, and if not installed and used properly, this
equipment may cause interference to radio and
television reception.
If this equipment does cause interference to radio
or television reception (which you can determine
by turning the equipment off and on), try to
correct the interference by one or more of the
following measures:
• Reorient the receiving antenna (that is, the
antenna for the radio or television that is
"receiving" the interference).
• Move the unit away from the equipment that is
receiving interference.
• Plug the unit into a different wall outlet so that
the unit and the equipment receiving interference
are on different branch circuits.
If these measures do not eliminate the
interference, please consult your dealer or an
experienced radio/television technician for
additional suggestions.
Also, the Federal Communications Commission has
prepared a helpful booklet, "How To Identify and
Resolve Radio TV Interference Problems." This
booklet is available from the U.S. Government
Printing Office, Washington, DC 20402. Please
specify stock number 004-000-00345-4 when
ordering copies.
For Your Safety
The AC power plug is polarized
(one blade is wider than the
other) and only fits into AC
power outlets one way. If the
plug will not go into the outlet
completely, turn the plug over
and try to insert it the other way. If it still will not
fit, contact a qualified electrician to change the
outlet, or use a different one.
Do not attempt to bypass this safety feature.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
Technical Specification
Product: Spacemaker
Brand: GE
Model: 7-4235
Electrical Consumption
Power Supply: 120V~60Hz
Power Consumption: 45 Watts
IMPORTER
Comercializadora Thomson de México, S.A. de C.V.
Miguel de Cervantes Saavedra 57
Col. Ampliación Granada
C.P. 11529 Mexico D.F.
Telefono: (55)25 81 53 20
RFC: CTM-980723-KS5
WARNING: TO PREVENT FIRE OR ELECTRICAL
SHOCK HAZARD, DO NOT EXPOSETHIS PRODUCT
TO RAIN OR MOISTURE.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER-
SERVICEABLE PARTS IN-
SIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
Untitled-2 3/5/03, 9:38 AM1

FCC Information
EN
Service Information
This product should be serviced only by those
specially trained in appropriate servicing
techniques. For instructions on how to obtain
service, refer to the warranty at the end of the
User’s Manuel.
For Your Records
In the event that service should be required, you
may need both the model number and the serial
number. In the space below, record the date and
place of purchase, and the serial number:
Model No.:
Date of Purchase:
Place of Purchase:
Table of Content
FCC Information
First Things First ................. 1
Tools Required ................................... 1
Parts Packed with Your Unit ............ 1
Before Mounting ............................... 1
Mounting Procedure ......................... 2
General Controls ................ 4
Front View .......................................... 4
Side Views .......................................... 4
Display ................................. 5
Settings ............................... 5
Setting the Clock ............................... 5
Setting the Countdown Timer ......... 5
Setting Display Brightness ................ 5
Operating the Radio .......... 6
Built-In AFC ........................................ 6
Turning On the Radio ....................... 6
Turning Off the Radio ....................... 6
Selecting Band ................................... 6
Tuning ................................................. 6
Setting Memory Stations .................. 6
Using the Weather Band .................. 6
TV Band .............................................. 6
Using the Countertop
Light .................................... 7
Replacing the Bulb ............................ 7
Care and Maintenance ....... 7
Cleaning the Exterior ........................ 7
Precaution .......................................... 7
U.S. Warranty ...................... 8
Canadian Warranty .......... 10
Untitled-2 3/5/03, 9:38 AM2

First Things First
1
Under Cabinet Mounting
Instructions
Tools Required
•Drill and
1
/
4
" Drill Bit
•Ruler or Tape Measure
•Nail or Awl
•Scissors
•Screwdriver - Phillips
•Countersink (Optional)
•Masking Tape
•Safety Glasses
Parts Packed with your Unit
3 — Washers
Spacers
3 —
1
/
4
"
3 —
1
/
2
"
3 — 1"
2 — Cord hooks
USE:
3 — 2
3
/
4
" Phillips head screws
or
3 — 1
5
/
8
" Phillips head screws
Before Mounting
Empty contents of the selected cabinet under which
the unit will be mounted and thoroughly clean the
underside of the cabinet to remove any grease
residue which might be present.
We recommend the unit be mounted at the front
edge of the cabinet.
Important: For secure mounting, the screws must
go into the radio to a depth of at least
3
/
8
". If
the overall length from the bottom of the cabinet
shelf to the bottom of the overhang is more than 1
3
/
4
", then a wood shim will be necessary. A shim can
be made from a sheet of plywood, using the
Template to locate the central lines for drilling the
1
/
4
" mounting holes. The shim can be located
between the cabinet shelf bottom and spacers.
Make sure the wood is at least as thick as the
excess over 1
3
/
4
" If a shim is necessary, longer
screws are required. Longer screws (Type #10-32)
are available at most local hardware stores.
Cut out the Template on the line indicated. The
Template size and screw hole positions are identical
to the top of the clock radio.
EN
If no overhang, front edge of templet
should be even with front edge of cabinet.
Si no hay una parte sobresaliente la parte
delantera de la plantilla debe ser igual con
el borde delantero del cabinete.
FRONT FRENTE
Cutout on solid black line.
Cortesobre la línea sólida negra.
Cutout on solid black line.
Cortesobre la línea sólida negra.
Foldguidelines for cabinet with overhang. Líneasde guía para ser dobladas en la parte sobresaliente de los gabinetes.
Cutout on solid black line. Cortesobre la línea sólida negra.
Cutout on solid black line. Cortesobre la línea sólida negra.
Model2-4290
349A2708-0001(Rev 0 E/S)
95-10
Printedin Singapore
1 — Mounting
template
Untitled-2 3/5/03, 9:38 AM3

First Things First
2
Mounting Procedure
1. If your cabinet does not have an
overhang:
(a) Position Template in desired location on
underside of cabinet, flush with front
edge.
(b) Then tape Template in place, and go to
Step 2 (Read “Caution”).
MEASURE THICKNESS OF
CABINET OVERHANG
FRONT EDGE
OF CABINET
MOUNTING
TEMPLATE
FOLD TEMPLATE ON
DOTTED LINE
If your cabinet has an overhang:
(a) Measure the thickness of the overhang.
(b) Fold front of Template downward along
the printed guideline that is closest to the
thickness of your cabinet.
(c) Tape fold-down portion to backside of
overhang, Tape Template to cabinet
underside.
NOTE:NOTE:
NOTE:NOTE:
NOTE: If your cabinet has glue blocks or
other obstructions, cut out corresponding
areas on the Template to clear them. Do
not cut out or cut through the screw holes
indicated on the Template.
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION: It is recommended that
safety glasses be worn while drilling screw
holes to prevent the possibility of eye
injury.
2. Drill
1
/
4
-inch diameter holes through the
underside of the cabinet bottom shelf using
the 3 points marked on the Template.
Helpful Hints:
On wooden cabinets you may want to mark
and start the drill holes with a nail or an awl.
Be sure to hold the drill very firmly against the
cabinet to reduce “walking” of the drill bit
from the markings.
Use masking tape above the hole locations on
inside of wooden cabinet shelf to help reduce
splintering.
If installing the unit under a wood cabinet, you
may wish to countersink the drilled hole from
the INSIDE of the cabinet if a countersink
attachment for your drill is available. This will
eliminate the use of washers and allow the
screw heads to be flush with the floor of your
cabinet. If you cannot countersink the holes,
use the supplied washers.
EN
Untitled-2 3/5/03, 9:38 AM4

First Things First
3
3. Remove Template and clean drill shavings from
inside and underside of cabinet.
4. If your cabinet does not have an
overhang, go to Step 5.
If your cabinet has an overhang, select the
spacer or combination of spacers that is equal
to or longer than the cabinet overhang.
EQUAL TO OR
LONGER THAN
CABINET
OVERHANG
3
/
8
" MINIMUM
3
/
4
" MAXIMUM
CABINET
OVERHANG
CABINET
BOTTOM
WASHER
SPACERS
SELECTED SCREWS WHICH MEET MINIMUM,
BUT DO NOT EXCEED MAXIMUM LENGHT.
5. Insert screws FROM INSIDE THE CABINET. The
washers must be used on metal cabinets, and
on wood cabinets if you did not countersink
the drilled holes. Position washers, flat side
down, and place screws into the holes.
If your cabinet does not have an
overhang, go to Step 7.
6. Hold screw heads down while you push the
selected spacers onto the screws under the
cabinet. Be sure to push up spacers until they
are firmly against the cabinet bottom and/or
fully nested (if more than one is used).
7. Align radio under the screws. Hold the screw
holes in the top of the clock radio against the
mounting screws and partially tighten the
screws.
Do not fully tighten until all 3 screws have
been started. (The top front edge of the clock
radio should clear the overhang.)
8. Extend cord towards electrical outlet and
secure by using the Cord Hooks to hold cord
out of the way. For most attractive appearance,
place Cord Hooks at back edge of cabinet (on
or next to wall) directly over outlet to be used.
To attach Cord Hooks, peel off adhesive back
and attach to a clean, dry surface on underside
of cabinet or back wall. Plug Cord into 120-volt
AC electrical outlet.
We recommend that the line cord be fully
extended for best FM reception.
COMPACTDISC PLAYER
OF RADI
STERE
A
A
F 8592 96 100 104 108MH
530650800100013001700kHz
HighPerformanceSub-wooferAM/FMStereoCompactDIsc Player
Spacemaker
CLOCK/TIMERDISPLAY
OF
MINUTSE
HOU
TIMERON/SET
STO
REPEA
TRAC
SEARC
SHUFFL
PLAY/PAUS
C
EN
-DIGITAL2 BAND RADIO RECEIVER
TUNING/
CLOCKSET
FUNCTION
OFF INSTANT
WEATHER
SET
CLOCK
ON/
BAND
12345
TIMER
ON/OFF
MEMORYSTATIONS
Untitled-2 3/5/03, 9:38 AM5

TIMER ON/OFF - Enters timer setting mode;
turns timer on and off.
TUNING/CLOCK SET - When the unit is
on, these arrows are used to tune up and down
radio frequencies. In Clock and Timer setting mode
- Use the arrow buttons to select clock time and
timer duration.
General Controls
4
Front View
EN
- DIGITAL 2 BAND RADIO RECEIVER
TUNING /
CLOCK SET
FUNCTION
OFF INSTANT
WEATHER
SET
CLOCK
ON /
BAND
12345
TIMER
ON / OFF
MEMORY STATIONS
ON/BAND - Turns the unit on. Selects radio band.
FUNCTION OFF - Turns the unit off.
SET CLOCK - Enters clock setting mode.
INSTANT WEATHER - Selects weather
broadcast stations given by U.S. Government
Weather Stations.
MEMORY STATIONS (1 to 5) - Directly accesses
preset stations for FM, AM and TV bands.
Side Views
LIGHT (OFF/LO/HIGH) - Slide the switch to OFF to
switch off countertop light, slide to LO for dimmer
light, and slide to HIGH for brighter light.
VOLUME - /+ - Rotate to adjust volume level.
BRIGHTNESS - Adjusts display brightness.
Untitled-2 3/5/03, 9:38 AM6

5
EN
Setting the Clock
1. Press SET CLOCK to enter clock setting
mode.
The clock icon lights on the display.
2. While the clock icon is still displayed, use the
TUNING/CLOCK SET arrows to select
current clock time.
Press and hold TUNING/CLOCK SET arrows
to fast forward and fast reverse clock
time.
The clock is in 12 hour format. AM and PM
indicator will light to show AM or PM time
respectively.
3. Press SET CLOCK to save clock settings.
Setting the Countdown
Timer
1. Press TIMER ON/OFF to enter timer setting
mode.
The Timer icon flashes on the display.
2. While the icon is still flashing, use the TUNING/
CLOCK SET arrows to select the timer
duration.
Settings
Display
3. Press TIMER ON/OFF again to start
countdown.
A beep will sound indicating countdown has
started.
4. The alarm will sound once countdown has
reached 0:00.
Press TIMER ON/OFF or FUNCTION OFF to
turn the timer off.
Tip: You can turn off timer at any time by
pressing TIMER ON/OFFTIMER ON/OFF
TIMER ON/OFFTIMER ON/OFF
TIMER ON/OFF.
Setting Display Brightness
Press the BRIGHTNESS button on the side of the
unit to select among the three brightness levels.
Observe the changes on the display.
FM/AM radio band
Instant weather channel
In clock setting mode Weather channel number
TV channel number (2-13)
Timer is activated Preset Station Number
Displays current clock time,
timer time and
radio frequency
Radio frequency unit
AM/PM Clock
time indicator
TV Band
Untitled-2 3/5/03, 9:38 AM7

Operating the Radio
6
EN
Built-In AFC
The Built-In Automatic Frequency Control (AFC)
works only on FM. It helps to reduce drift on FM
reception and to keep the radio locked in on the
FM station to which it is tuned.
When tuning in FM stations, you may notice that
often the station you desire can be heard on two
or three nearby points on the dial. Always tune
carefully to the loudest and clearest point.
Antennas
AM Antenna - A built-in ferrite rod antenna
eliminates the need for an outside antenna for AM
reception. Rotating the unit slightly may improve
reception of distant AM stations.
FM Antenna - The power cord acts as your FM
antenna. The power cord picks up moderate to
strong stations and eliminates the need for an
external antenna in most strong signal areas. Be
sure the power cord is stretched out to its full
length. Do not coil or bunch the cord together.
Changing position of the power cord may improve
reception.
Turning on the Radio
Press ON/BAND to turn the unit on.
Turning Off the Radio
Press FUNCTION OFF to turn the unit off.
Selecting Band
Press ON/BAND to select between FM, AM and TV
radio bands.
Tuning
Press TUNING/CLOCK SET to tune up radio
frequency.
Press TUNING/CLOCK SET to tune down radio
frequency.
Automatic Station Search
Press and hold TUNING/CLOCK SET arrows for
more than 1 seconds and release. Automatic
station search starts and will stop when the next
station is found.
Setting Memory Stations
FM, AM and TV bands each has 5 memory locations
available.
1. Tune to the desired station using the TUNING/
CLOCK SET arrow buttons.
2. Press and hold the MEMORY STATION number
where you want to store the station.
icon flashes on the display and the
memory station you have selected lights on the
display. Hold the button down until the icon
stops flashing.
Memory Recall
Press the MEMORY STATION 1,2,3,4 or 5 buttons
to directly accesses preset station memory.
Using the Weather Band
Weather information is given continuously from
U.S. Government Weather Stations on frequencies
from 162.4MHz to 162.55MHz.
The Weather transmission, broadcast 24 hours a
day, are taped messages that are repeated every 4
to 6 minutes and revised and updated as needed to
match the changing weather conditions. For
additional information, check your location office
of the National Weather Service (Department of
Commerce).
IMPORTANT: The listening range of NOAA
weather stations varies from 10 miles up to
a maximum of 40 miles from the station’s
transmitter. In some areas of the United
States, weather transmissions cannot be
monitored. The effective range of this
radio will have side variations due to the
height of the local transmitting antenna,
atmospheric conditions, and the terrain
between the transmitter and your radio’s
location.
1. Press the INSTANT WEATHER button to
access Weather Bands with strong signals to the
unit.
2. Use the TUNING/CLOCK SET arrow buttons to
select among the 7 weather channels.
TV Band
CH 2-13 are available for TV Band.
Untitled-2 3/5/03, 9:38 AM8

7
CAUTION:CAUTION:
CAUTION:CAUTION:
CAUTION: Use only a 40-watt
appliance-type bulb or equivalent for
replacement. To prevent hazard, do not
operate light without the cover.
DI
SC PLAYER
OFF RADIO
H
z
kH
z
fer
OFF
MINUTE SET
HOUR
TIMER ON/SET
STOP
REPEAT
TRACK
SEARCH
SHUFFLE
PLAY/PAUSE
CD
The countertop light switch is
located on the left side of the
unit, and has three settings: HIGH,
LO, and OFF.
Using the Countertop Light
Replacing the Bulb
1. Unplug the unit cord from the AC power
outlet.
2. Unlatch the cover to open it.
3. Unscrew and remove the bulb.
4. Install the replacement bulb.
5. Swing the cover up and snap it in place.
6. Plug the cord into the AC outlet, and reset the
clock.
• For dimmer light, move the light switch to the
LO position.
• For more illumination, switch to HIGH.
• To turn the light off, place Light switch to OFF.
- DIGITAL2 BAND RADIO RECEIVER
TUNING /
CLOCK SET
345
TIMER
ON / OFF
E
MORYSTATIONS
Cleaning the Exterior
Prior to cleaning the exterior, be sure to unplug
the power cord from the AC power outlet. Wipe
the exterior with a soft, clean, and slightly water-
dampened cloth.
Precautions
•Never open the cabinet under any
circumstances. Any repairs or internal
adjustments should be made only by a trained
technician.
•Warning: Never operate this product with the
cabinet removed.
• The apparatus shall not be exposed to dripping
and splashing.
Care and Maintenance
The descriptions and characteristics in this owner’s manual are for the purpose of general reference only and not as a
guarantee. In order to provide you with the highest quality product, we may make changes or modifications without prior
notice. The English version serves as the final reference on all product and operational details should any discrepancies arise in
other languages.
EN
Untitled-2 3/5/03, 9:38 AM9

U.S. Warranty
EN
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year from date of purchase.
The warranty period for rental units begins with the first rental or 45 days from date of shipment to
the rental firm, whichever comes first.
What we will do:
• Provide you with a new, or at our option, a refurbished unit. The exchange unit is under warranty
for the remainder of the original product’s warranty period.
• Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the product
is within the warranty period must be presented to obtain warranty service. For rental firms, proof of
first rental is also required.
How to make a warranty claim:
• Properly pack your unit. Include any cables, etc., which were originally provided with the product.
We recommend using the original carton and packing materials.
• Include evidence of purchase date such as the bill of sale. Also print your name and address and a
description of the defect. Send via standard UPS or its equivalent to:
Thomson Inc.
Product Exchange Center
11721 B Alameda Avenue
Socorro, Texas 79927
• Insure your shipment for of loss or damage. Thomson accepts no liability in case of damage or loss
en route to Thomson.
• Pay any charges billed to you by the Exchange Center for service not covered by the warranty.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty does not cover:
• Customer instruction. (Your Owner’s Manual provides information regarding operating Instructions
and user controls. For additional information, ask your dealer.)
• Installation and set-up service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
8
Untitled-2 3/5/03, 9:38 AM10

U.S. Warranty
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT.
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO
VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON INC., ITS AGENTS OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF
ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER
OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF
INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or consequential damages, or
limitations on how long an implied warranty lasts, so the above limitations or exclusions may not
apply to you.
• This warranty gives you specific legal rights, and you also may have other rights that vary from
state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
EN
9
Untitled-2 3/5/03, 9:38 AM11

Canadian Warranty
Thomson multimedia Ltd. warrants to the purchaser or gift recipient that if any manufacturing defect
becomes apparent in this product within 1 year from the original date of purchase, it will be
replaced free of charge, including return transportation.
This warranty does not include damage to the product resulting from accidents, misuse or leaking
batteries.
Should your product not perform properly during the warranty period, either:
1. Return it to the selling dealer with proof of purchase for replacement,
OR
2. Remove the batteries (where applicable), and pack product complete with accessories in the
original carton (or equivalent). Mail prepaid (with proof of purchase) and insured to:
Thomson multimedia Ltd.
6200 Edwards Blvd.,
Mississauga, Ontario,
L5T 2V7
Canada
The provisions of this written warranty are in addition to and not a modification of or subtraction
from the statutory warranties and other rights and remedies contained in any applicable legislation,
and to the extent that any such provisions purport to disclaim, exclude or limit any such statutory
warranties and other rights and remedies, such provisions shall be deemed to be amended to the
extent necessary to comply therewith.
If you are unable to find a qualified servicer for out of warranty service, you may write to:
Thomson Inc.
P.O. Box 0944
Indianapolis, Indiana, U.S.A., 46206-0944
Attach your sales receipt to this booklet for future reference. This information is required if service is
needed during the warranty period.
PURCHASE DATE
NAME OF STORE
EN
10
Untitled-2 3/5/03, 9:38 AM12
